VERO DESIGN GALA Manual

Instal. GAL
A
®
1/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
GALA®
Closed fireplace
for
natural gas
propane

Instal. GAL
A
®
2/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Introduction …………………………………………………………………………………. 2
Caution ……………………………….……………………………………………….….. 4
Certificates ………………………………………….………………………………………… 5
Components …………………………….…………………………………………………….. 6
Gastechnical instructions ……………………………….…………………………………….. 7 - 8
Technical data GALA®……………….…………………………………….………………… 9 - 12
Summary of delivered material ………………………………………………….….………… 13
Air flow ………………….………………………………………………….…………….…… 14
Preparations …………..………………………………………..………………………………. 15 - 17
Connection ……..………………………………………..…………………….…………… 18
Checking the gas line ……………..…………………………..………………..……………. 19
Remove and replace the glass frame …..……………………………………….…………… 19
Lighting ……………..…………………………………………………………….…………….. 20
Installation : general ……..…………………………………………………………..…….….. 21
Insulation ……..………………………………………………………………..………….. 22 + 28
Installation in a wall ……………………………………………………………………….. 23 - 29
Installation in a wall : detailed ………..……………………………………..……...………. 30 - 31
Electrical information .……………………………………………………..……………… 32
Problems + solutions ………….……………………………………………………..……….. 33 - 36
Warning ………………………………………………………………………………..….. 37
Warranty ………..…………………………………………………………………….…… 38
Warranty card …………………………………………………………………… in the back of manaul
Summary

Instal. GAL
A
®
3/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Congratulations with your new GALA®gas fireplace. We selected the best materials to produce our
fireplaces. This way you can enjoy your appliance for many years. Before using the GALA, please read
this manual.
CERTIFICATE OF CONFORMITY
VERO DESIGN nv Koralenhoeve 3, Industriepark Noord – 2160 Wommelgem - Belgium
herewith declares that GALA®is produced in accordance with European Security Regulations
90 / 396 EEG.
The appliance can only be installed by a licensed fitter.
Security systems on our fireplaces :
1. Thermo-electrical pilot flame (piëzo)
2. TTB
3. Cold air repercusion safety
4. Infra-red remote control (appliance can not be lighted uncontrolled)
Reinhild Roland
General Manager
Introduction

Instal. GAL
A
®
4/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Installation must be performed by a licensed plumber or gas fitter. Installation must comply
with manufacturer’s installation instructions and national and regional instructions.
If you have any doubts, consult your local energy provider.
Before installation, determine if the information on the CE label matches the type of gas and
gaspressure for your region. Conversion from natural gas to propane (or vice versa) is not
recommended in a more advanced phase.
GALA can be connected to a new or existing chimney vent, using the diameter as
recommended, with natural draft.
GALA can also be connected concentric.
Fresh air supply for combustion from outside or basement. The appliance can be installed in a
normally ventilated house. An extra ventilation system is not necessary.
Vero Design nv is not responsible for manipulated appliances !
Only use the stones which are delivered with the appliance. Place the stones over the burner and
bottom of the fireplace. Make sure there are no stones placed on or against the pilot flame.
Keep flammable materials away from the fireplace (1 m).
Maintenance must be in accordance with regional guidelines, laws and regulations. Although have a
qualified service technician check the appliance once a year. Have your chimney swept once a year
by a qualified chimney-sweeper.
Children or unauthorised persons can only be in the vicinity of the appliance under supervision.
CAUTION !

Instal. GAL
A
®
5/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Certificate

Instal. GAL
A
®
6/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Components
Appliance GALA
Gasbed Certificate number E1530
Product identificaton PIN 0063BM1630
Gas block BM 740/3 modulerating
Transfo IR (IRT)230Vac-24Vac
Sensor IR receiver (IRR)
Modubox MF-301C modubox
Category I 2E+,I 2H,I 2L,I 2ELL,I 3+,I 3p
Gas line pressure G20/20 – G25/25
The fireplace is equipped with the following safeties :
Atmospheric safety : on the pilot flame
TTB : in connection piece to chimney
Cold air repercusion safety : in connection piece to chimney
Thermal safety device and gasflexible
GALA is already pre-assembled and tested in our warehouse.
No assembly is requested at the site.
CE label : on the bottom of the technical box
Vero Design NV-Koralenhoeve 3/Industriepark Noord-B 2160 Wommelgem
GALA SERIAL NR. 120529 TYPE: GA
YEAR 2012 DATE: 17/10/2005 CATEG.: B11 – I2H
Gas line pressure G20/20mbar
Nom. efficiency kW Hi : 26
The appliance has to be installed according the applied regulations can only be used in a sufficient ventilated space.
Read the instructions manual before installing and using the appliance.
Pin : 05-0434-GEE Land : LV Type : B11BS
Manufacturer : Vero Design NV – Wommelgem, Belgium tel [phone]
Components
0461/030461/03

Instal. GAL
A
®
7/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
DE – Deutschland
Nationale Einbauvorschriften: DVGW-TRGI 86 / 96, technische Regel, Arbeitsblatt G600 bzw TRF
Feu VO der jeweiligen Länderfassung
AT – Österreich
Nationale Einbauvorschriften: ÖVGW – Richtlinien G1 Gas, G2 Flüssiggas
BE – Belgien
Nationale inbouwvoorschriften: NBN D51 – 003 Gas , AREI/RGIE electrititeit
CH – Schweiz
Nationale Einbauvorschriften: SVGW-Gasleitsätze G1 Erdgas, EKAS-Richtlinie 1942 Flüssiggas Teil 2,
Richtlinien der örtlichen Instanzen z.B. Feuerpolizei
Gasanschluss an das öffentlichen Gasnetz darf ausschliesslich mit festen
Gasrohren oder mit einem SVGW-zugelassenen Gassicherheitsschlauch
ausgeführt werden
LU – Luxemburg
Nationale Einbauvorschriften: A-nr. 104 Instalaltions de combustion alimentees en gaz
Gastechnical
instructions

Instal. GAL
A
®
8/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Gas Natural gas Propane
Country
AT:Österreich
BE: Belgien
CH: Schweiz
DE: Deutschland
LUX: Luxemburg
NO: Norway
AT:Österreich
BE: Belgien
CH: Schweiz
DE: Deutschland
LUX: Luxemburg
NO: Norway
appliance category
AT/CH: I2H Natural gas H
BE: I2E+ Nat.gas G20 / G25
DE: I2ELL Nat.gas E/LL
LU: I2E Natural gas E
NO: I2H Natural gas G20
I3P Propane G31
I3P Propane G31
I3P Propane G31
I3P Propane G31
I3B/P Propane G31
efficiency 65.76 % 64.00%
NOx classification 5 5
E / H : 20.0 mbar
LL : 20.0 mbar
AT: 50.0 mbar
CH: 50.0 mbar
DE: 50.0 mbar
LU: 50.0 mbar
NO: 30.0 mbar
Gas pressure
BE: G20 20 mbar
G25 25 mba
BE : 37.0 mbar
Appliance safeties
1. atmospheric safety :
on the pilot flame
2. TTB : in the connection to
the chimney
3. Cold air repercusion
safety : in the connection
to the chimney
4. thermal safety device and
gasflexible
1. atmosperic safety :
on the pilot flame
2. TTB : in the connection to
the chimney
3. Cold air repercusion
safety: in the connection
to the chimney
4. thermal safety device and
gasflexible
Gastechnical
instructions

Instal. GAL
A
®
9/ 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
code A (mm) D (mm) O (mm) Gas Ø (mm) Kg consumtion m³/h
natural gas Gas °C kW
GALA 1F 800 130 150 15 mm ~120 0.85 155°C 5.0 – 11.0
GALA 2F 900 130 150 15 mm ~130 1.00 180°C 5.0 – 13.0
GALA 3F 1000 130 150 18 mm ~140 1.15 210°C 6.5 – 15.6
GALA 4F 1250 130 150 18 mm ~160 1.40 223°C 6.5 – 17.0
GALA 5F 1500 150 200 22 mm ~170 1.70 292°C 7.0 – 17.8
GALA 6F 1750 180 200 22 mm ~190 2.00 360°C 8.4 – 19.0
GALA 7F 2000 180 200 22 mm ~210 2.30 420°C 8.5 – 20.0
Technical data

Instal. GAL
A
®
10 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Artikelnr. A (mm) D (mm) O (mm) Gas Ø (mm) Kg verbuik
m³/h
aardgas Gas °C kW
GALA 1D 800 130 150 15 mm ~120 0.85 155°C 5.0 – 11.0
GALA 2D 900 130 150 15 mm ~130 1.00 180°C 5.0 – 13.0
GALA 3D 1000 130 150 18 mm ~140 1.15 210°C 6.5 – 15.6
GALA 4D 1250 130 150 18 mm ~160 1.40 223°C 6.5 – 17.0
GALA 5D 1500 150 200 22 mm ~170 1.70 292°C 7.0 – 17.8
GALA 6D 1750 180 200 22 mm ~190 2.00 360°C 8.4 – 19.0
GALA 7D 2000 180 200 22 mm ~210 2.30 420°C 8.5 – 20.0
Technical data
see-thru / tunnel

Instal. GAL
A
®
11 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Technical data
square
code A (mm) D (mm) O (mm) Gas Ø (mm) Kg Gas m³/h °C kW
GALA 70 F 700 130 150 15 ~110 0.73 220°C 5.0 – 11.0
GALA 80 F 800 130 150 15 ~125 0.80 230°C 5.0 – 13.0
GALA 90 F 900 130 150 18 ~140 0.85 238°C 6.5 – 15.6

Instal. GAL
A
®
12 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Technical data
square tunnel
code A (mm) D (mm) O (mm) Gas Ø (mm) Kg Gas m³/h °C kW
GALA 70 D 700 130 150 15 ~110 0.73 220°C 5.0 – 11.0
GALA 80 D 800 130 150 15 ~125 0.80 230°C 5.0 – 13.0
GALA 90 D 900 130 150 18 ~140 0.85 238°C 6.5 – 15.6

Instal. GAL
A
®
13 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Before you unpack the fireplace, check packaging for damages. In case of damage, contact us at
+32/33.85.06.91. If possible send a picture of the damage to : [e-mail]
Delivered goods :
•GALA fireplace, entirely pre-assembled
•Convection system with 2 warm and 2 cold air connections
•100 cm RTD gasflexible – already assembled on the fireplace
•100 cm EU plug – already assembled on the fireplace
•Repercussion safety
•4 adjustable feet - already assembled on the fireplace
•1 box with decoration material - only use the delivered material :
is part of total approvement of fireplace
•1 infra-red remote control, incl. batteries – all electronic parts are already installed
•Installation instructions and warranty card
Be sure that all parts were delivered. If not, please contact us at : +32/33.85.06.91
Remove packaging. You will find the stones, the remote control, installation and operating instructions,
warranty papers in the cardboard box.
Installation of GALA only in a dry building. Moist areas can cause damage to the electronic parts.
GALA fireplaces are tested individually, properly and lighted in our workshop.
Delivered material

Instal. GAL
A
®
14 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Air flow
Combustion air
Fresh air, combustion air, primary air, has to be brought into the unit. This is possible from a different
place under the unit or via a tube from an outside wall.
1 or 2 col air vent
CONNECT !
Air from the room will go
into the convection
chamber and warms up
Convection air system
When the convection air system is not wanted, close the openings on the unit with insulation material.
This is how the convection air system has to be connected :
1 or 2 warm air vent
CONNECT !
Warm air will get into the room
again via the vent
!
Supply the unit
with combustion air from underneath, do not connect.
The air will find ist way into the burner by several openings.

Instal. GAL
A
®
15 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
!
GALA has to be connected to an existing or new flue.
GALA®IS NOT CONNECTED CONCENTRIC :
The appliance draws combustion air from outside. Before installation, be sure that your flue is suitable for
the ordered appliance. The flue ends outside.
Have your flue swept by a certified chimney-sweeper !
Preparations
Flue - situation 1
Flue - situation 2

Instal. GAL
A
®
16 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Preparing
airflow
Before installation: with or without airflow
GALA®is equiped with 2 (1 x right + 1 x left) cold air entrances and 2 (1 x right + 1 x left) warm air outlets.
If you connect the airflow system, there will be a better, natural circulation of the warm air in the room
where the fireplace will be installed. There is no fan used.
The perforation has
already been done.
Turn the perforated piece until it loosens. Now you can
take away the perforated piece.
Put the delivered connection pieces in the holes.
Then bow on the inside.
The connection pieces
are installed.

Instal. GAL
A
®
17 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
GALA®Install the fireplace on a flat surface. Installation conform local fire safety instructions!
By using the adjustable feet, you can level the fireplace.
Preparations
Flue - vertical termination :
Install the fireplace underneath, centered the flue and in the center of the fresh air supply. Socket on the
right, max. 100 cm from the fireplace. Gas line, in recommended Ø on the right of the appliance.
Connect gas hose to gasline. (1, pag. 15).

Instal. GAL
A
®
18 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Flue – Horizontal termination :
Install the appliance so that only one 45° elbow is used. Socket on the right side (see pag. 14) of the
appliance, gas line on the right side of the fireplace and shut off with terminal safety device (1) (see
example underneath).
Connect and test !!!
Put the plug in the socket, put gas hose (2) in therminal safety device (1)
and turn until you see a green arrow.
Connect the appliance to the chimney vent using the recommended
diameter.
Purge the gasline and check for gas leaks.
1
2
GALA®- Cover the burner and bottom of combustion chamber only with the
delivered stones. Make sure that the pilot flame remains free.
Gas connection

Instal. GAL
A
®
19 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
Purge the air from the gaslines.
Check for gas leaks by using a qualified gas tester.
GALA® - Only light the appliance when all lines are closed !
GALA®- Cover the burner and the bottom of the combustion chamber with the
delivered stones. They are part of the entire CE approval
of the appliance.
Put max. 2 layers of pebbles and keep the rest seperately.
Make sure that the pilot flame remains free !
Checking the
gaslines
Removing and
replacing glass frame

Instal. GAL
A
®
20 / 40
VERO DESIGN NV © all rights reserved [phone]
Installation instructions Operating instructions
G
A
L
A
When first operated, the appliance may release an odor. This is
caused by the curing of the paint. This is a normal result. Ventilate
the room properly !
GALA®The fireplace is controlled with a FULL-OPTION infra red
remote control. The remote has a reach of ~4.00m.
FULL-OPTION means :
The appliance is lid from the OFF position of the pilot flame.
Aim the remote control towards the infra red receiver. You will find
the infra red receiver in the middle of the lower side of the frontal
frame.
Always keep the pilot flame free from stones. Do not put any
decoration material against or on the pilot flame !
LIGHTING
1. Press buttons 3 and 4 at the same time during 3 sec.
2. Meanwhile the LED-indication on the remote control lights 3 sec.
3. The pilot flame ignites. You hear a „click“ followed by „tic, tic, tic“.
The order to light has been recognized and the securities are
activated.
4. The pilot flame ignites and starts to burn. The flame lights the gas
in the burner starting from the middle to the sides. Wait for the
gaspressure in the burner to build up, so it burns over the whole
lenght. This could take up to 20 seconds, depending on the size
of the burner.
5. Higher flames : keep pressing button 1until the desired height of
flames is reached. The maximum available height depends on
local gaspressure and the amount of gas that’s feeding the
appliance (Ø gasline).
6. Lower flames : keep pressing button 2.
7. Button 5 activates automatic modulation
SWITCH OFF
1. Press button 4. The pilot flame and the burner extinguish slowly
until all remaining gas is burned. Once they are extinguished,
there is no more use of gas.
RESET + INTERRUPTION
Press buttons 3 and 4 more than 3 sec. at the same time. The
system changes from interruption to standy. The LED lids during 3
sec.
Lighting the
fireplace
ONLY LIGHT THE
FIREPLACE WHEN
GLASS IS INSTALLED
Direction
B - 6
B - 5
B - 4
LED 1
B - 1
B - 2
B - 3
