Dear Customer,
First of all, congratulations for choosing a nature and technology
friendly VESTEL product. Aspiring to offer products above and
beyond your expectations, VESTEL presents your device, which
has been manufactured meticulously and quality-controlled
rigorously at VESTEL's modern plants, to your use.
This operating manual will guide you through the use of your
appliance.
You will see that your appliance is equipped with the most advanced
technological solutions and quite easy to use.
Provided that you take care of your appliance and carry out the
necessary maintenance, it will serve you for years. We hope you
enjoy using your appliance.
This product has been manufactured at environment-friendly
VESTEL BEYAZ EŞYA A.Ş. facilities without causing any harm to
the nature.
Important Information on Safety
This operating manual includes important information about the
initial use, safety, intended use, cleaning and maintenance of your
air conditioner.
Always keep this operating manual with your air conditioner. When
you transfer your air conditioner make sure to transfer its manual
too.
Readtheoperatingmanualcarefullybeforeusingyourairconditioner
to prevent burns, electric shocks, fire or injury risk, and follow the
instructions on operating your air conditioner, troubleshooting and
cleaning.
The air conditioner must be mounted by Vestel Authorised Service.
The air conditioner must be grounded.

3
ATTENTION: Denotes injury or property damage
risk.
WARNING: Denotes death or severe injury risk.
WARNING: Contains flammable gas.

4
Table of Contents
Safety Warnings .......................................................................................6
Safety Information on Installation of the Air Conditioner ��������������������6
Safety Information on Use of the Air Conditioner �������������������������������� 7
Safety Information to be Considered when Performing Cleaning and
Maintenance Procedures �������������������������������������������������������������������������11
Safety Information to Take into Consideration During Handling and
Transportation��������������������������������������������������������������������������������������������12
Installation .............................................................................................. 12
Choosing the Mounting Position �����������������������������������������������������������13
Indoor Unit�������������������������������������������������������������������������������������������������13
Outdoor Unit���������������������������������������������������������������������������������������������13
Cooling Circuit����������������������������������������������������������������������������������������� 14
Heating Circuit����������������������������������������������������������������������������������������� 14
Power Connections of Indoor and Outdoor Units �������������������������������15
Batteries.................................................................................................. 16
Liability Limitation ................................................................................. 16
Technical Values...................................................................................... 17
Important Information About R32 Gas.................................................. 18
Technical Specifications ......................................................................... 19
FLORA DOĞA INVERTER 092 A++ WIFI��������������������������������������� 19
FLORA DOĞA INVERTER 122 A++ WIFI����������������������������������������20
FLORA DOĞA INVERTER 152 A++ WIFI�����������������������������������������21
FLORA DOĞA INVERTER 182 A++ WIFI���������������������������������������� 22
FLORA DOĞA INVERTER 242 A++ WIFI���������������������������������������� 23
General View ..........................................................................................24
Remote Control......................................................................................25
Installing and Replacing Remote Control Batteries�����������������������������26
Setting the Remote Control Clock��������������������������������������������������������26
Points to Take into Consideration While Using the Remote Control 27
Operating Your Air Conditioner without Remote Control����������������� 27
Use ..........................................................................................................28
Getting Started and Fast Use�����������������������������������������������������������������28
Operating Temperature Intervals�����������������������������������������������������������28
Functions of Your Air Conditioner.........................................................29
WiFi Function�������������������������������������������������������������������������������������������30
Mode Function������������������������������������������������������������������������������������������31

5
Cooling Function ��������������������������������������������������������������������������������������31
Heating Function ������������������������������������������������������������������������������������� 32
Energy Saving Mode Function������������������������������������������������������������ 32
Vertical Airflow Direction Function ������������������������������������������������������ 33
Automatic Mode�������������������������������������������������������������������������������������� 33
Fan Function��������������������������������������������������������������������������������������������� 33
Dehumidification Function���������������������������������������������������������������������34
Super Turbo Function������������������������������������������������������������������������������34
Sleep Mode Function������������������������������������������������������������������������������35
I Feel Function������������������������������������������������������������������������������������������ 35
Auto Power Off Function �����������������������������������������������������������������������36
Auto Start/Stop Function�����������������������������������������������������������������������36
Remote Led / Signal Sound Cancellation Function ����������������������������36
Reset Function������������������������������������������������������������������������������������������ 37
Favourite Function����������������������������������������������������������������������������������� 37
Easy Bill Function�������������������������������������������������������������������������������������38
Indoor Unit Display Light Function�������������������������������������������������������38
Ionizer Function����������������������������������������������������������������������������������������38
Suggestions for Operation..................................................................... 41
Troubleshooting......................................................................................42
Error and Protection Messages..............................................................44
Product Information Tag FLORA DOĞA INVERTER 092 A++ WIFI.45
Product Information Tag FLORA DOĞA INVERTER 122 A++ WIFI..46
Product Information Tag FLORA DOĞA INVERTER 152 A++ WIFI..47
Product Information Tag FLORA DOĞA INVERTER 182 A++ WIFI .48
Product Information Tag FLORA DOĞA INVERTER 242 A++ WIFI .49
Disposal of the Appliance in an Environment Friendly Manner ...........50
Package Information ..............................................................................50
Recommendations on Energy Saving .................................................... 51
Customer's Elective Rights....................................................................52

6
Safety Warnings
Safety Information on
Installation of the Air
Conditioner
WARNING: Your air
conditioner contains
R32 refrigerant gas. R32
refrigerant gas is slightly
flammable.
WARNING: The air
conditioner must be grounded.
Insufficient grounding may
cause electric shocks. Do
not connect the grounding
wire to gas pipes, water
pipes, lightning conductors
or telephone grounding wire.
After mounting, the appliance
should be powered up in order
to determine grounding leak
check. If you neglect, it may
cause electric shocks and
damages to the product.
WARNING: The appliance
shouldbemountedinaccordance
with “Mounting Instructions”
by Vestel Authorized Service
. Customers should not install
the air conditioner themselves.
Otherwise, damages and
injuries will occur.
WARNING: Wiring should be
done by an expert electrician
accordingtonationalregulations
on electrical wiring.
WARNING: In the event that
yourairconditionerisconnected
permanently to a fixed harness
system and has a leakage
current that may exceed 10 mA,
a leakage preventer relay with
an operating current not more
than 30 mA should be installed
on the fixed cable.
WARNING: Your air
conditioner should be wired
up to the mains at appropriate
current with a lagged V-switch.
WARNING: Do not mount the
air conditioner near inflammable
gases or liquids. This might
cause fire.
WARNING: In order to
avoid extraordinary noise and
vibration, request from the
authorised service personnel
a proper fixation of the air
conditioner.
WARNING: Request from the
authorised service personnel the
mounting of the air conditioner
to somewhere that would not
disturb your neighbors.

7
WARNING: After the
mounting, electrical switch/fuse
should be easily accessible.
• The air conditioner should
be connected and operated
only according to the
information on the product
label. Before using the air
conditioner, check that the
voltage rating of your mains
is compatible with the value
specified on the product
label.
WARNING: Connect and
operate your air conditioner
necessarily to a grounded
energy line via a fuse.
WARNING: Manufacturer
companyshallnotberesponsible
for the damages resulting from
operating without grounding.
• Installation and repairs
should always be done by
the Authorised Service.
• The manufacturing
company shall not be held
responsible for any damage
duetooperationsconducted
by unauthorised persons.
• Your indoor unit should be
mounted at no less than
1.8 meters high from the
ground.
WARNING: The air
conditioner is designed to be
used in indoor spaces such as
home, office, etc. It should not
be installed on motor vehicles
such as cars, trucks, buses,
cranes, ships, etc.
Safety Information on Use
of the Air Conditioner
WARNING: Do not put your
fingers or any other object in the
air inlet or outlet on the indoor
and outdoor units.
WARNING: Do not put any
obstacle in front of the outdoor
unit and do not cover.
WARNING: Do not insert
anything between the fins of air
flow router; indoor unit fan may
be damaged and cause injuries.
WARNING: As the fan rotates
with high speed, it may cause
injuries.
WARNING: In order to
prevent the air conditioner
getting damaged during power
cuts or thunder and lightning
storms, power off the appliance
by switching the fuse/power
switch off. Neglecting to do so
may cause fire or electric shocks.

8
WARNING: Contains
fluorinated greenhouse gases
specified within the scope of the
Kyoto Protocol.
ATTENTION: Do not expose
your body directly to the air flow
for a long time. Do not expose
humans, pets or plants directly
to the hot or cool airflow of the
air conditioner in any way. Set
the direction of the airflow in
such a way that it does not blow
directly onto humans.
Do not expose yourself to the
cool air for a long time. This
may lead to physical and health
problems.
ATTENTION:Closethedoors
and windows, otherwise cooling
and heating performance will
decline.
• Donotusetheairconditioner
for a long time in spaces
that is not ventilated at all.
Ventilate the environment
occasionally while operating
the air conditioner with
devices such as stove etc. at
the same time.
• If the humidity is very high
or the doors or windows are
open, do not leave the air
conditioner running for a
long time.
• Do not leave the air
conditioner under open air
conditions (sun, rain etc.)
except the outdoor unit.
• The air conditioner is
designed for household
applications and indoors. Do
not use the air conditioner
for purposes (e.g. for the
protection of sensitive
equipment, foods, pets,
plants etc.) other than
heating and cooling the
space you are in.
WARNING: Operation of the
air conditioner for purposes
other than its intended
purpose may cause damage
or dangerous conditions and
renders the warranty void.
Damages occurred due to these
conditions are compensated by
theuser.Useyour air conditioner
only according to the intended
use defined.
• In order to prevent
overloading of the electrical
circuit, do not operate any
other high-power appliance
on the same circuit. Do
not connect with extension
cables or multi plugs. If you
neglect, it may cause electric

9
shocks or damages in the air
conditioner.
• For children at the age of 8
or older, and those who have
restricted physical, sensory,
mental capacity or those
who have lack of knowledge
and experience; it is needed
to supervise them and
make them understand
the instructions and risks
concerning the safe usage of
the air conditioner.
• Children should not be
allowed to play with the air
conditioner. Cleaning and
usermaintenanceoperations
should not be made by
children unless supervised
by an adult.
• Keep children away
particularly from the indoor
unit of the appliance.
• Cleaning and user
maintenance operations
should not be made by
children unless supervised
by an adults.
• Packaging materials may
lead to a choking. Keep them
away from the children.
• Before use, check the
functions of your air
conditioner accurately.
• The air conditioner should
be used only if there is no
damage on its body and on
the power cable.
• Check the power cable for
damages regularly. Do not
strain the power cable of the
air conditioner. Do not put
any objects on the power
cable.
• If the power cable is
damaged, it should be
replaced by the authorised
service recommended by
the producer only in order to
avoid any danger.
Never use your air conditioner
under the following conditions:
• If the air conditioner or the
power cable is damaged,
• If the air conditioner is not
running properly,
• If the electrical parts of the
air conditioner are visibly
damaged,
• If the air conditioner is wet,
has dropped into water or
any other liquid, exposed
to water flooding incident,
its electrical components
have come into contact with
water,

10
• If strange noises, smoke or
smells emanate from the air
conditioner.
If any of the cases mentioned
above is detected, shut down
yourairconditionerimmediately,
disconnect the power supply
connection and contact with the
authorised service.
• A damaged air conditioner
or damaged parts of the
air conditioner may cause
severe injuries and fire.
• In case of any malfunction,
do not attempt to repair
or disassemble the air
conditioner yourself.
• If it is re-mounted wrongly,
it may cause electric shocks
during use. There is no part
within your air conditioner
which can be repaired by the
user.
• Use of accessories not
recommended by the
manufacturer may cause
injuries and damages to the
air conditioner.
• Do not damage the air
conditioner's cooling system
in which refrigerating gas
circulates with sharp objects.
If the top surface coatings
of the heat exchanger gas
ducts and pipe extensions
are punctured, the sprayed
refrigerant gas can cause
skin irritation and eye injuries.
• Do not cover or put any
object in front of the air
inlets and outlets of the air
conditioner or the outdoor
unit while running.
• Do not spray flammable and
refrigerant gases onto the air
conditioner.
• When there is a refrigerant
gas leakage in the air
conditioner, open the
windows to ventilate the
area and call the Authorised
Service.
• When there is a flammable
gas leakage in the
environment in which the air
conditioner is, close the gas
and the air conditioner. Do
not restart the air conditioner
before ventilating the
environment completely.
• Do not put heating devices
near the air conditioner and
the power cable. Excess
heat that might be radiated
from these devices may melt
the plastic parts of the air

11
• Do not leave the indoor unit
under the rain or at a location
where it can get wet.
• If the air conditioner will be
displaced and re-mounted
at a new location, contact
the authorised service.
Safety Information to
be Considered when
Performing Cleaning and
Maintenance Procedures
• To prevent the risk of electric
shock, switch off the air
conditioner, shut down its
fuse or switch gear before
cleaning.
• Do not use liquid or abrasive
detergents to clean the air
conditioner. Do not splash
with water or other liquids;
otherwise plastic parts may
get damaged and even
electric shocks may occur.
• In order to prevent short
circuits and fires, keep the
indoor unit dry. Clean and
maintain your air conditioner
asdescribedinthe"Cleaning
and Maintenance" section.
• Do not use or approximate
chemicals to your air
conditioner. Do not use
conditioner.
• Do not touch or run the air
conditioner with wet and
moist hands.
• If the air conditioner will
not be used for a long time,
disconnect the power supply
from the fuse.
• When the power is restored
after a blackout, your air
conditioner will restart
running again at the last
mode it is set.
• If you are going to leave your
homeduringapoweroutage,
switch off the automat of
your air conditioner.
• Do not throw or insert any
object inside the holes.
Makesurethattheairconditioner
is switched off and the power is
cut from the fuse/power switch
under the following conditions:
– Before installation,
– Before cleaning and
maintenance,
– Before repairs,
• Do not drink the water
drained off from the air
conditioner. Otherwise,
severe health problems may
occur.

12
substances such as gasoline
or thinner.
• Insert the air filter after it gets
dry completely. Operating
the appliance without filters
may cause breakdowns.
Safety Information to
Take into Consideration
During Handling and
Transportation
• During handling and
transportation of your air
conditioner, watch out the
ARROWsignwhilehandling
the indoor unit.
• Carry the outdoor unit
vertically and keep it
vertically at the place it is
stored.
• Do not step on and do not
put heavy objects on the
indoor and outdoor unit
boxes.
• For the re-mounting of
the air conditioner at a
new location, contact the
authorised service.
Installation
WARNING: The air
conditioner must be installed
according to national plumbing
directive.
WARNING: The air
conditioner should be installed
by Vessel Authorized Service in
accordance with the “Installation
Instructions”.
WARNING: The appliance
should not be mounted on the
stairs, exits or hallways of the
building.
The stable pressure by which the
air conditioner is experienced is
100 KPa.
The fuse that should be used in
the electrical connection of the
air conditioner is type C 16 A for
9,000 and 12,000 btu and type
C 20 A for 18,000 and 24,000
btu.
Care should be given to the
wire diameter cross-section in
the electrical wiring of the place
where the air condition will be
installed.

13
Only the outdoor unit of your
air conditioner is proper for use
outside the building.
Choosing the Mounting
Position
Indoor Unit
• There should not be any
vapour or heat source near
the air conditioner.
• There should not be any
obstacle preventing air
circulation at the mounting
position.
• Air circulation should be
sufficient.
• Discharge should be easily
executable.
• It should not be close to the
door entrance.
• There should be enough
distance between the air
conditioner and the wall,
ceiling, decorations and
other obstacles.
• The mounting position
should be about 30
centimetres below the
ceiling.
Outdoor Unit
• If there is an awning
protecting the outdoor unit
from sunlight or rain, make
sure that it does not prevent
condenser from distributing
the heat.
• There should be enough
distance between the air
conditioner and the wall,
ceiling, decorations and
other obstacles.

14
Cooling Circuit
Heating Circuit
OUTDOOR
UNIT
COMPRESSOR
EXPANSION
VALVE
INDOOR UNIT
OUTDOOR
UNIT
COMPRESSOR
INDOOR UNIT
EXPANSION
VALVE

15
Power Connections of Indoor and Outdoor Units
1
2
3
4
5
L
N
S
İç ÜnteDış Ünte
Faz
Nötr
Snyal
Topraklama
Enerj Besleme
Faz
Nötr
Topraklama
The distances stated in the chart below should be applied in the installation of
indoor and outdoor units.
Minimum 1800 millimetres
Minimum 125
millimetres
Minimum 600
millimetres
Minimum 300 millimetres
Minimum 600 millimetres
Minimum 150 millimetres
Minimum 300 millimetres

16
Batteries
• Do not expose the batteries
directly to sunlight, fire,
excessive heat and etc.
• Do not use used batteries
together with new batteries.
Replace the used batteries
with the batteries whose
shapes and types are the
same as defined in the
battery installation section.
Do not use rechargeable
batteries.
• Do not use the remote
control if the batteries
have leaked. Do not touch
the liquid leaking from the
batteries. In case of contact,
wash out with water.
• The symbol on the
remote control display
show that the batteries are
drained off. When you see
this symbol, change the
batteries.
Liability Limitation
All of the technical information,
instructions in this manual
includes the latest information
on your air conditioner, its
operating and maintaining.
The manufacturing firm shall
not bear any responsibility for
any possible damages and
injuries due to non-compliance
with the instructions in this
operating manual, misuse of
the appliance, unauthorised
reparations, making
unauthorised modifications
on the appliance and use of
spare parts unapproved by the
manufacturing firm.
Make sure that the supply
voltage at the installation
site matches properly with
the operation voltage range
specified in the technical
specifications of your air
conditioner and that necessary
measures are taken. The user
is responsible for assuring the
compliance of the electrical
wiring at the site where the air
conditioner will be installed.

17
This appliance conforms to the Directive on Supervision
ofthe Waste Electricand Electronic Appliances (AEEE).
This product complies with the European CE Directives
no. 2014/53/EU (Electromagnetic Compliance
Directive).
Technical Values
• Nominal values are determined according to T1 climate
conditions of TS EN 14511 standards. In case that indoor and
outdoor temperatures are different from the temperature values
on which the standard is based; cooling and heating capacities
would change.
• Seasonal efficiency values are determined according to EN
14825 Standard.
• The values declared in the printed documents supplied with the
product, on the markings on the product and on www.vestel.
com.tr are the values obtained in the laboratory in accordance
with the relevant standards. These values may vary depending
on the usage and ambient conditions of the product.
• Technical specifications and this manual are subject to change
without prior notification.
Wi-Fi
Operating frequency range: 2412Mhz~2472Mhz�
Highest output power: 19.60dBm
Simplified Declaration of Conformity
VESTEL Beyaz Eşya Sanayi ve Ticaret A.Ş. hereby declares
that the wireless equipment type FLORA DOĞA INVERTER
092/122/182/242 A++ WIFI complies with the Directive 2014/53/
EU.

18
Important Information About R32 Gas
This product contains fluorinated greenhouse gases� Refrigerant
must not be released to the atmosphere�
Refrigerant: R32
GWP (Global Warming Potential: 675
Periodic checks may be required for gas leakage. Contact your
dealer or authorised service for more information.
Note: CO2 equivalent (tCO2eq): Greenhouse gas emissions of the total
refrigerant charge in the product is used to specify the maintenance intervals. Refer
to the relevant regulations for detailed information.
Greenhouse gas
emission value =Refrigerant GWP value x Total refrigerant amount
1000
WARNING: Refrigerant used in product is flammable. Normally
refrigerant leakage will not occur. Fire may arise or harmful gases
may be released if the refrigerant comes into contact with the
flame on heaters, cookers, etc. in the environment in case of a gas
leakage.
Observe the following measures in case of a refrigerant leakage:
- Switch of all heaters, cookers and etc.
- Ventilate the room.
- Inform the dealer or authorised service from whom you have
purchased the product.
- NEVER operate the product until the authorised service confirms
that the problem related with the gas release is remedied.

19
Technical Specifications
FLORA DOĞA INVERTER 092 A++ WIFI
Nominal Capacity Cooling Btu/h 8.530
Heating Btu/h 10.000
Nominal Capacity Cooling (kW) 2,50
Heating (kW) 2,93
Capacity Interval Cooling Btu/h 3.800 - 11.000
Heating Btu/h 3.700 - 12.200
Input Power
(Nominal) Cooling W 780
Heating W 870
Operating Current
(Nominal) Cooling A 3,6
Heating A 4,0
Design Load Cooling (kW) 2,5
Heating (kW) 2,0
Seasonal Energy
Efficiency (SEER) Cooling 6,6
(SCOP) Heating 4,0
Seasonal Energy
Class Cooling/Heating A++/A+
Refrigerant R32
Power source 220-240V / 50 Hz
Outdoor Unit
Measures WxHxD mm 815x532x300
Indoor Unit
Measures WxHxD mm 822x281x190
Interconnection
Pipes Liquid line inch 1/4"
Gas Line inch 3/8"
Noise level Indoor Unit dbA 52
Outdoor unit dbA 62
Outdoor Operating
Temperature
Heating (Minimum) -15
Cooling (Maximum) +46

20
FLORA DOĞA INVERTER 122 A++ WIFI
Nominal Capacity Cooling Btu/h 11.600
Heating Btu/h 13.000
Nominal Capacity Cooling (kW) 3,40
Heating (kW) 3,81
Capacity Interval Cooling Btu/h 4.400 - 14.100
Heating Btu/h 4.100 - 16.000
Input Power
(Nominal) Cooling W 1450
Heating W 1120
Operating Current
(Nominal) Cooling A 6,6
Heating A 5,1
Design Load Cooling (kW) 3,4
Heating (kW) 2,3
Seasonal Energy
Efficiency (SEER) Cooling 6,6
(SCOP) Heating 4,0
Seasonal Energy
Class Cooling/Heating A++/A+
Refrigerant R32
Power source 220-240V / 50 Hz
Outdoor Unit
Measures WxHxD mm 815x532x300
Indoor Unit
Measures WxHxD mm 822x281x190
Interconnection
Pipes Liquid line inch 1/4"
Gas Line inch 3/8"
Noise level Indoor Unit dbA 52
Outdoor unit dbA 63
Outdoor Operating
Temperature
Heating (Minimum) -15
Cooling (Maximum) +46
This manual suits for next models
4
Table of contents
Other VESTEL Air Conditioner manuals
Popular Air Conditioner manuals by other brands

LG
LG A2UN186FA0 Service manual

Ocean Breeze
Ocean Breeze OBZ-10ESN owner's manual

Mitsubishi Electric
Mitsubishi Electric Mr. SLIM SLZ-M15FA2.TH Technical & service manual

Frigidaire
Frigidaire 220218A007 use and care manual

Hitachi
Hitachi RAD-25NH4 Service manual

Daikin
Daikin Super Multi NX 3MKS50E3V1B Service manual
