Vetek ACS-3S/NEW SU Series User manual

user manual
3S/NEW
SU-3
3S/NEW
SU-6
3S/NEW
SU-15
3S/NEW
SU-30
Max. Capa. 3000g 6000g15 kg30 kg
Min. Capa. 20e
Test Divi. 1g2g5g10g
Display
Divi.1
0.5g1g2g5g
Display
Divi.2
0.2g0.5g1g2g
Max. Tare 100% Max. Capa.
Accuracy III
Pan size 3S/NEW SU 190x230mm
Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Email [email protected]
Web www.vetek.com 1
SUPERSS
ELECTRONIC SINGLE/DUAL DISPLAY
Thank you for using our ACS-3S/NEW SU serial single/double side displays product of electronic
waterproof weighing/counting scale. New SU are plastic scales and 3S a stainless steel scale. The
scale is manufactured with advances computer-controlled hi-techniques. It has the characteristics
of satisfactory in performance accurate in weighing, convenient for carrying, cheap in price. It is
sturdy and durable and widely used in not only retail stores and weighing of ration packing of
commodities but also in high humidity surroundings because of it’s well waterproof function.
I. MAIN TECHNICAL INDEX
1. BASIC DATA
2. WORKING TEMPERATURE: 5~+35OC
3. STORAGE TEMPERATURE: 25~+50OC
4. POWER: 6V4.5Ah rechargeable battery
5. NET WEIGHT: 3.6kg/pc
6. DIMENSION: 4pcs/ctn, 580x350x300
Manual_SUP-SS_V1

user manual
www.vetek.com [email protected] 2
II. KEYBOARD AND CHARACTER PROMPT
1. KEYBOARD
ON/
ZERO Turns the scale on and zero
TARE Tare key
OFF Power O
SET
0~9 Set/Fig. Key. Set parameterand input Fig.
2. CHARACTER PROMPT
dc x.xx: Mean the voltage of battery is x.xx V.
------: Show this as the weight over 100%FS+9e, with the ding sounding, this means over load,
reduce the weight.
-AdC-: As the A/D change overowing, display shows this with the ding sounding
bATLo: The voltage is lower. You can use a short while and charge immediately.
c _End: Recharge is end.
Err-0: Overload zero of loadcell. Please re-adjust or change loadcell.
II. OPERATION GUIDE
1.Preparation
Adjust the base foot, watch the level, make the pan in horizontal.
2. Turn on or turn o
2.1 Turn on
Press the [ON/ZERO] key, the ding sound, it displays version No. and the battery voltage level and
9,8,7···1,0, the “ZERO” lamp lighting. Now the scale is in a working state.
2.2 Turn o Long- press [OFF] key.
2.3 Auto-o
After 10 minutes in zeroing, auto-o.
2.4 Low voltage auto-o
When the voltage lower than 5.6V, then power-o.

user manual
www.vetek.com [email protected] 3
3. Zero
When without taring the weight display is ≤4% Max. capa., press the [ON/ZERO] key, the display
shows “ 0 ”, the zero lamp lighting.
4. Weighing
Put weight to pan.
5. Tare weighing
Press the [TARE] key, it’s being think the “skin” tare, the weight display is “ 0 ”, the “ZERO” lamp
o, the “TARE” lamp lighting. Pick up the weight and the “skin”, the weight display is negative, the
“ZERO” lamp lighting, press the [TARE] key, the “TARE” lamp o.
6. Save power function
Zero after 40 seconds, auto save power, shows “ 0 ”. Put a weight start weighing
7. Battery indicate.
Battery lamp: “High” means voltage higher than 6.3V, “Mid” means voltage between 6V and 6.3V,
“Low” means voltage lower than 6V.
8. Charge
Power supplied by a internal rechargeable lead acid battery (6V/4Ah). When it shows “-bAtLo-”.
Please turn o and charge immediately. The time of full charging is 12 hours.
9. Set parameter
Press [SET/0~9] key 3 seconds to set. Now show menu. Press [SET/0~9] continuous it displays :
rAngE(set limit)
UnItS(choose unit)
A-oFF(choose auto power o)
FILt(set display mode)
ZEro(set auto zero)
bUZZEr(set buzzle )
d(choose division)
on-rA(choose range of power on)
d-dP(choose single or dual display)
9.1 Set of upper and low limit
9.1.1 When it shows rAngE, press [TARE] and then [SET/0~9] to choose on or oFF, on is start the
function,oFF is exit,press [TARE] to confrim.
9.1.2 When choose on and press [TARE],now weighing with limit,“ under” lighting, max gure is
blinking,press [SET/0~9] once to add 1,press [TARE] to conrm,when nishing auto exit and set
“over”.After setting into weighing.
9.1.3 When low limit > high limit, it displays o,then exit.

user manual
www.vetek.com [email protected] 4
9.1.4 Alarming indicate
“m” is the weight
when m≥high limit, “over” lamp is lighting.
When low limit <m<high limit, “accept” lamp is lighting.
When m≤low limit, “under” lamp is lighting.
Caution: When the display is not stabilization, no lamp lights.
9.2 Change unit
9.2.1 When it displays “units”, press [TARE], then press [SET/0~9] to choose, then press [TARE] to
conrm and exit.
Unit: H9(kg), 9(g), Lb, Lb.oz, pcs(counting). (We may not choose imperial units when calibrating).
9.2.2 counting: When it displays “pcs”, press [TARE]. Now “pcs” lamp lighting.
Longtime press [ON/ZERO], it displays count and return to 0. then put the sample and press
[TARE]. Press [SET/0~9] to add 1 and press [TARE] to choose. After nishing it display pcs and pcs
lamp lighting.
Exit counting: choose a unit.
Caution: Pick quantities of Max less 30000
9.3 A-oFF(choose auto power o)
When menu displays A-oFF,press [TARE] to enter,press [SET/0~9] to choose n or y, n is not auto
power o,y is after 10 minutes in zeroing, auto-o.
9.4 Change display mode
When it displays “FILtX” (FILt1 means one step to display, FILt2 means 3-4 steps to display, FILt3
means 6-8 steps to display, FILt4 means display is fast). Press [SET/0~9] to change, press [TARE] to
conrm and exit.
9.5 Set range of auto-zero:
When it displays zero, press [TARE], now show zero x.x(x.x is the range:0.5d,1d,1.5d,2d,2.5d,3d,3.5
d,4d,4.5d,5d. d is the division value when n=3000).
Press [SET/0~9] to choose and [TARE] to conrm.
9.6 bUZZEr(set buzzle sound on or o)
When menu displays bUZZEr,press [TARE] to enter,press [SET/0~9] to choose on or o, press
[TARE] to conrm.
9.7 Change division gure
When menu displays d,press [TARE] to enter,press [SET/0~9] to choose division.
9.8 On-rA(choose range of power on)
When menu displays On-rA,press [TARE] to enter,press [SET/0~9] to choose 100, 100 is 100%
capacity. Press [TARE] to conrm.

user manual
www.vetek.com [email protected] 5
1. Not overloading. Not throw heavy things on the scale violently. The damage for overloading is
not within the range of guaranteed maintenance.
2. Don’t use sharp thing to operation the keyboard. If the rubber is damaged it will inuence the
performance of waterproof.
3. Keep the scale clean in order to weighing well.
4. There is a lead seal on the bottom of the scale. Users are not allowed to remove the seal. If the
seal is damaged the scale is not guaranteed for maintenance.
5. a. You must charge the battery at least per 3 months when you don’t use the
scale for a long time.
b. Please correctly connect line between adapter and battery, black to black,
red to red.
c. If after charging the used time becomes short than often, please change a
new battery.
IV. NOTE
9.9 d-dP(choose single or dual display)
When menu displays d-dP,press [TARE] to enter,press [SET/0~9] to choose n or y, n is single
display,y is dual display, Press [TARE] to conrm.
10. Tune LED lighting
On powering on, long time press [zero/on], it shows LC-,press [SET/0~9] to choose LU-1 or LU-
2,LU-1 is saving mode(commend),Press [TARE] to conrm.
CALIBRATION OF SS SCALE VERSION 3S5.3OR5.4
A. Multi-point adjust:
1. Push the adjust key to switch on, the switch is on the bottom of the scale, locked with a seal.
.Press “ on/zero “ key, after a while start to adjust.
2. Press “set/0~9” and “ on/zero “ key the same time, choose weighing units-kg, lb or counting
function, press tare to conrm. Then the display shows “c”. “c” is the Max. capacity, press “set/0~9”
to choose c-600,c-1500,c-3000,c-6000,c-15H9(15kg),c-30H9(30kg) and press “tare” to conrm.
3. Now it displays 1/3 Max capacity, then display 0. (If is not 0, press “on/zero”)
4. Put the displayed weights on the centre of the plat, after it shows stable, press the “tare”,
it shows 2/3 Max capacity. Then put the displayed weight it displays Max capacity, put the
displayed weight. Press “tare”.
5. Now it shows c-0, “c” is ashing. Now change gravity. Press “ on/zero “ to add 1
internal number, Press “set/0~9” to reduce 1 internal number. 60000 internal number means the
max. capacity. Press “tare” to exit adjustment.
6. Push the adjust key to switch o.
B. One-point user ADJUST:
Push the adjust key to switch on. Press “tare” 3 seconds, display “CAL””0”. Press “tare” to conrm
zero. Put the Max capacity weight, after 5 seconds press “tare”, it shows CAEnd and exit
adjustment. Push the adjust key to switch o. NOTE: After changed loadcell or PCB, if you need
adjust but it shows “Err-0”, it means zero is not in the limited range. Then after power on please
press “tare” immediately, it will go into adjusting.
