Vextra VX3849 User manual

OPERATING INSTRUCTIONS
Personal Compact Disc Player
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
VX3849

Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
This compact disc player is classified as a CLASS
1 LASER product.
Invisible laser radiation when open and
interlocks defeated. Avoid exposure to
beam.
To maintain good performance
Do not use the unit in places which are extremely
hot, cold, dusty or humid, In particular, do not use
or keep the unit in following places.
in a high humidity area such as a bathroom
near a heater
in an area exposed to direct sunlight (e. g., inside
a parked car, where it can become extremely hot)
near sources of strong magnetism, such as televi-
sions, speakers, or magnets
where there is a lot of movementor vibration,
such as on a car dashboard or an unstable shelf
CAUTION
PRECAUTIONS
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
If you hear no sound when playing a disc, DO
NOT turn the volume up high because the music
could suddenly begin at high volume. To avoid
hurting your ears or damaging the speakers, turn
the volume control to the lowest level before
starting playback and slowly turn it up to the
desired level
Listen at moderate volumes to avoid hearing
damage
Do not wear the headphones while driving or
cycling. lt may create a traffic hazard
You should use extreme caution or temporarily
discontinue use in potentially hazardous situations,
such as walking, jogging, etc
Listening to headphone stereo at full power for
extended periods of time can result in hearing
damage
Do not touch pickup lens
lf the unit is suddenly moved from a cold place
to a warm one, it may cause in condensation on
the pickup lens and malfunction or playback
difficulties, should this occur, leave the unit for
a few hours, then try playback again.
Note on listening with the headphones
CAUTION
Note on condensation
For safety
Do not attempt to disassemble this unit. Laser rays
f om the optical pickup are dangerous to the eyes
Make sure that pins or other foreign objects do
not get inside the player
Take care not to drop the unit or subject it to
strong shocks
To keep dust f om the pickup lens, keep the disc
compartment lid closed after use. Never touch
the lens
r
r
OPERATING
INSTRUCTIONS Personal Compact Disc Player
1
VX3849

USING ON DRY CELL
BATTERIES A
Open the battery compartment and insert two LR6
(size AA) alkaline batteries with the and marks
correctly aligned.
The battery indicator in the display according
to the remaining power of the batteries. Replace
the batteries when lights. If the unit remains in
use after lights. the operation will stop.
Note on dry cell batteries
Do not mix the different types of batteries, or an
old battery with a new one
To prevent the risk of electrolyte leakage or
explosions. never recharge the batteries, apply
heat to them, or take them apart
When not using the batteries, remove them to
prevent needless battery wear
If liquid leaks from the batteries, wipe thoroughly
to remove
Battery replacement
If the cover of the battery compartment
comes off you should insert it by bands
please picture
B
BEFORE PLAYBACK
HOLD switch
Turning on and off
Turning the power on
Turning off the power
Standby mode
Release the HOLD switch to OFF position before
playback.
When not using the unit, set the HOLD switch to
the ON position, Accidentally pressed button will
not function. If buttons are pressed when the HOLD
switch is set to the ON position. "HOLD" light on
the display.
Press PLAY/PAUSE. Power is turned on and
playback starts.
If no new operations are done within 30 seconds
from the end of last operation, the power is turned
off automatically. (Auto power off function) you can
turn off the power before it is automatically turned
off by pressing STOP
When an operation finishes, the unit goes into
Standby mode until the auto power off function
automatically
turns off the power.
To enter standby mode, press PLAY/PAUSE to
start playback, then press STOP
C
C
C
AA (LR6)X2
A
B
C
2

PLAYBACK G
Playback starts from the first track.
3. Press PLAY/PAUSE
2. Place a disc.
1. Release HOLD to OFF position.
Connect the supplied headphone to the PHONE jack.
BASIC OPERATION
To stop: Press STOP
To pause: Press PLAY/PAUSE
To resume, press it again.
To search for the
beginning of a track: Press or
To locate a
desired
passage: Keep
or Pressed.
Release thebutton until the
start of desired passage.
G
11
33
2
2
1
OFF ONOFF ON
HOLDHOLD
3
Adjusting the sound
Volume
Turn the VOLUME control to adjust the volume.
X-BASS
Switch on the X-BASS for extra bass emphasized.
D
D
the pivot gently.
Pick up the disc, holding its edge, while pressing
To remove the disc
F
3. Close the disc compartment.
2. Place a disc in the center with the label side
facing up.
1. Push the OPEN switch to open the disc
compartment
Inserting a disc E
3
BASS

CONNECTION TO AN
EXTERNAL UNIT H
Use a commercially available connection cord
which has a 3.5mm stereo plug at one and two
phono plugs at the other end.
Connect the stereo plug to the LINE OUT jack
of the unit and connect the phono plugs to the
analog input (AUX) terminals of the external unit.
Turn off the power of both units before connection.
DO NOT connect to the PHONES inputs of an
amplifier(with a built-in phonoequalizer - amplifier)
Adjust the volume and BASS on this unit.
NOTE
H
LINE OUT
LINE IN
CD IN
AUX
R LR L
PROGRAM:
W
1. Press PROGRAM key,Then "PROG 00" start flashing
2. Press skip/searched or key to search the track
no.
3. hen desired track is display, press PROGRAM
key to register, Then track no. display to "00" again.
4. Repeat 2-3 (up to 20 tracks) after register 20 tracks.
display shows the first registered track.
5. Press play key, then PROG stops flashing and starts
playing.
6. To clear programing, press the STOP button.
MODE KEY:
REPEAT ONE: " 1 "light on display
and will repeat the track you selected
REPEAT ALL: " ALL" light on display
and will repeat entire tracks
Er: If no diSC, then " Er " is display
INTRO "INTRO" light on display
Plays every tracks at the first 10
seconds introduce music
4

MAINTENANCE
To clean the lens
Note
To clean the discs
If the lens become dirty, the player will skip or not
play, If this occurs, clean the lens in the following.
manner, To remove dust or dust particles, first use
a camera lens blower/brush 1 to blow a few times
to loosen particles, then gently brush the lens 2
clean finish by blowing the lens again.
Take care not to get too much solution on the swab.
which could flow into the unit and cause damage.
Pressing too strongly with the swab could scratch
or break the lens.
Before playing, wipe the disc from the center out
with a cleaning cloth, After playing, store the disc
in its case.
I
J
I1
2
J
SPECIFICATIONS
Tracking system 1-beam laser
Laser pickup Semiconductor laser
D/A conversion 8-times oversampling digital
fillter +1- bit DAC
Frequency response
20-20,000 Hz
Outputs PHONES:stereo jack (3.5mm)
[ ,32 ohms at 1
kHz]
Input DC 4.5V for external power
from AC adaptor
Power DC 3V f m Alkaline batteries
(2 x AA or LR6): Not included.
Supplied accessory
Stereo headphones (1)
The specifications and external appearance of
this unit are subjected to change without notice.
20mW+20mW
ro
Dimensions 142 x 29(H) mm
( 5 /16x 1 /8 inches)
Weight 280 grams (9.8 oz.) without
batteries
91
5

.
FOR ADDITIONAL SET UP OR OPERATING ASSISTANCE,
PLEASE CONTACT CUSTOMER SERVICE AT [phone]
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST
90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT
TO PLACE OR PURCHASE.
FOR PARTS AND ACCESSORIES, CONTACT FOX
INTERNATIONAL AT 1-800-321-6993

SUBJECT TO MODIFICATION WITHOUT NOTICE!
