viceroy WRECOIND60 User manual

WRECOIND60
PLUG & PLAY User Manual
WRECOIND60
PLUG & PLAY User Manual

02
Contents
| Before you start 03
| Safety 03
| Electrical installation 05
| Technical data 08
| Troubleshooting 09
| Guarantee 10
| What's required for installation 12
| What's in the box 12
| Installation 13
| Connectivity
To connect your appliance with another appliance with
RF technology please refer to Viceroy Hood Manual.
| Use 16
| Functions & Settings 18
| Care & Maintenance 23
| Service & Spares 24

If the surface of the hob is
cracked, switch o the appliance
to avoid the possibility of electric
shock.
The hob will not be installed
directly above a dishwasher,
fridge, freezer, washing machine
or clothes dryer, as the humidity
may damage the hob electronics.
The hob shall be installed such
that better heat radiation can be
ensured to enhance its reliability.
The wall and induced heating
zone above the table surface shall
withstand heat.
To avoid any damage, the worktop
and adhesive must be resistant
to heat.
DANGER OF FIRE: Do not store
items on the cooking surfaces.
Unattended cooking on a hob
with fat or oil can be dangerous
and may result in a re.
Before obtaining access to
terminals, all supply circuits must
be disconnected.
The hob and its accessible parts
become hot during use.
continued overleaf
03
Safety
These instructions are for your safety. Please
read them thoroughly prior to installation
and retain them for future reference.
WARNING: All installation
work must be carried out by
a suitably qualied person,
strictly following local
building regulations and these
instructions.
• To avoid the risks that are always present
when you use an electrical appliance
it is important that this hob is installed
correctly and that you read the safety
instructions carefully to avoid misuse and
hazards. After unpacking the hob please
check that it is not damaged. If in doubt,
do not use the appliance but contact
Customer Services.
• Check the package and make sure you
have all of the parts listed and decide
upon the appropriate location for your
product. If this product contains glass
please take care with tting or handling to
prevent personal injury or damage to the
product. The specication plate shown on
this appliance displays all the necessary
identication information for ordering
replacement parts. If you sell the appliance,
give it away, or leave it behind when you
move house, please ensure that you pass
on this manual so that the new owner can
become familiar with the appliance and its
safety warnings.
| Before you start | Safety
People with a heart
pacemaker should consult
with their doctor before
using any induction hob.

04
Safety
| Safety (continued) • CAUTION: The cooking process has to be
supervised. A short term cooking process
has to be supervised continuously.
• After use, switch o the hob element by its
control and do not rely on the pan detector.
• Care should be taken to avoid touching
heating elements.
• Metallic objects such as knives, forks,
spoons and lids should not be placed on
the hob surface since they can get hot.
• Do not use a steam cleaner for care and
maintenance.
• The appliance is not intended to be
operated by means of an external timer or
separate remote control system.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order
to avoid a safety hazard.
• Please dispose of the packing material
carefully. There is a re risk if cleaning is not
carried out in accordance with
the instructions.
• Do not use the hob if it shows signs of
damage or imperfection. Contact customer
services for assistance.
• The manufacturer declines all liability for
personal or material damage as a result
of misuse or incorrect installation of this
appliance.
• The appliance incorporates an earth
connection for functional purposes only.
• The appliance is for domestic use only as
a hob.
Use only hob guards designed
by the manufacturer of the
cooking appliance or indicated
by the manufacturer of the
appliance in the instructions for
use as suitable or hob guards
incorporated in the appliance.
The use of inappropriate guards
can cause accidents.
NEVER try to extinguish a re
with water, but switch o the
appliance and then cover ame
eg. with a lid or a re blanket.
This hob can be used by children
aged from 8 years and above and
persons with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children shall
not play with the hood. Cleaning
and user maintenance shall not
be made by children without
supervision. Keep the hob and its
supply cord out of the reach of
children less than 8years old.

05
Safety
| Electrical installation
• If the power cable is damaged or to be
replaced, the operation must be carried
out the by after-sale agent with dedicated
tools to avoid any accidents.
• If the appliance is being connected directly
to the mains an omnipolar circuit-breaker
must be installed with a minimum opening
of 3mm between contacts.
• The installer must ensure that the correct
electrical connection has been made and
that it is compliant with safety regulations.
• The cable must not be bent or compressed.
• The cable must be checked regularly and
replaced by authorised technicians only.
01 Factory Fitted Power Plug Connection
This hob can be plugged directly into a
mains power outlet using the 3 pin (UK)
plug supplied.
Power plug option (default, limited to max.
input power of 2800W)
As shown in illustration, please plug the
power cord into the outlet.
IMPORTANT
This hob can be plugged directly into a mains power outlet using the 3 pin (UK) plug supplied.
Plugged Version (Factory Supplied - Maximum Input 2800W)
Electrical Installation
Note: The electrical cable required for conversion to permanent wiring is not
supplied.
If you use the hardwired version, the appliance must be connected directly to the
mains using an omnipolar circuit breaker with a minimum opening of 3 mm between
the contacts.
The installer must ensure that the correct electrical connection has been made and
that it complies with the wiring diagram.
The cable must not be bent or compressed.
Regularly check the the mains connection and power cord for damage. If the supply
cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a safety hazard.
IMPORTANT
This hob can be plugged directly into a mains power outlet using the 3 pin (UK)
plug supplied.
Plugged Version (Factory Supplied - Maximum Input 2800W)
Electrical Installation
Permanently Wired Version (Professional Fit Only - Maximum Input 7200 W)
CAUTION: THE FOLLOWING SECTION IS FOR
PROFESSIONAL QUALIFIED ELECTRICAL INSTALLERS
ONLY!
21
The Hob
Outlet Power cord
with plug

06
Safety
| Electrical installation
When connected to a mains outlet using the factory tted plug, the software will limit the
hob maximum power to 2800W. Once congured as a permanent installation, the maximum
power output is 6400W.
THE FOLLOWING SECTION IS FOR PROFESSIONAL QUALIFIED
ELECTRICAL INSTALLERS ONLY.
02 Conversion to permanent wiring
WARNING: Do not convert the hob to high power whilst still
connected with the factory tted cable and plug.
WARNING: Ensure the cable conversion has been completed before
proceeding to the software conguration.
FAILURE TO DO THIS WILL DAMAGE THE HOB AND INVALIDATE
YOUR WARRANTY!
Replacing the cable
1. Remove the screw and terminal cover.
L1L2 N2 N1
N
L
Grey
Black
Green/Yellow
Blue
Brown
N (Blue/Grey)
L (Brown/Black)
(Green/Yellow)
2. Remove the factory tted cable and replace
it with the correct grade for the permanent
installation as per the connection diagram
below. Power cable can be purchased
separately at viceroy.co.uk

07
Safety
Software Conguration
1. Turn on the hob using the ON/OFF key. The
hob will show '-' on each cooking zone.
2. Touch the front left zone key and the Timer
key together for three seconds. The hob
will beep and show '5' in the timer display.
3. Touch the Timer key once and the display
will change to '5E'.
4. Touch the front left zone key and the
Timer key again and the two front zones
will indicate '2' and '8' (this is the factory
setting of 2800W).
5. Touch the front left zone key to switch the
display to '6' and '4'. This indicates high
power at 6400W.
6. Touch the Timer key again to nish
conguration.
Note: If required, the hob can be converted back to a plugged version by following the
cable conversion and software steps above again.
B
B
B
B
B
B

08
Safety
| Technical data
Model identication WRECOIND60
Cooking zones 4 Zones
Supply voltage 220-240V
Installed electric power 6400W (Preset 2800W)
Product size L x W x H (mm) 590 x 520 x 60
Built-in dimensions A x B (mm) 565 x 495
Weight and dimensions are approximate. Because we continually strive to improve our products
we may change specications and designs without prior notice.

09
Safety
| Troubleshooting
IMPORTANT: The connectivity operation above must be completed
within two minutes of turning on the power to the cooker hood. If this
is not successful, switch o both the hood and the hob, wait for one
minute and attempt the connectivity again.
Error code Possible cause Solution
No pan or pan not suitable. Replace the pan.
ER03 Pan placed over the controls or water on
the glass/over the controls.
Clean the control panel or move the
pan.
F1 E
The connection between the display
board and the left mainboard is fail
(the cooking zone which indicator
showing ''E')
1. Connection cable not correctly
plugged or defective;
2. Replace the mainboard.
F3 E
Coil temperature sensor failure.
(the cooking zone which indicator
showing 'E')
Replace the coil sensor.
F4 E
Mainboard temperature sensor failure.
(the cooking zone which indicator
showing 'E')
Replace the mainboard.
E1 E Temperature sensor of the ceramic glass
plate is high.
Please restart after the induction
hob cools down.
E2 E Temperature sensor of the IGBT
is high.
Please restart after the induction
hob cools down.
E3 E Abnormal supply voltage
(too high)
Please inspect whether power
supply is normal; Power on after the
power supply is normal.
E4 E Abnormal supply voltage (too low)
Please inspect whether power
supply is normal; Power on after the
power supply is normal.
E5 E Temperature sensor failure (the cooking
zone which indicator showing 'E')
Check connection cable is correctly
plugged in or assembly defective.
The above is a table of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and damages to the
induction hob and please contact the service department.
U
–
If an abnormality occurs , the induction hob will enter the protective state automatically and
display corresponding protective codes:

10
Guarantee
| Declaration of Conformity
(EU & UK) Declaration of Conformity
Name and address of the manufacturer or his
authorised representative:
AAUK Ltd
Unit 3 Normandy Landings
Pope Street, Castleford
West Yorkshire
WF6 2AG
This declaration of conformity is issued under
the sole responsibility of the manufacturer.
Object of the declaration:
• Product: ECO Plug & Play Induction Hob
• Model: WRECOIND60
EU: The object of the declaration described
above is in conformity with the relevant
Union harmonisation legislation:
• 2014/53/EU as amended Radio Equipment
Directive
UK: The object of the declaration described
above is in conformity with the relevant
legislation:
• Radio Equipment Regulations 2017 as
amended
References to the relevant harmonised
standards used or references to the other
technical specications in relation to which
conformity is declared:
• EN 60335-2-6: 2015 + A1 + A11
• EN 60335-1: 2012 + A11 + A13+ A1 + A14
+ A2
• EN 62233: 2008
• BS EN 60335-2-6: 2015 + A11: 2020
• BS EN 60335-1: 2012 + A2: 2019
• BS EN 62233: 2008
• EN 60350-2:2013+A11
• BS EN 55014-1:2017+A11:2020
• BS EN 55014-2:2015
• BS EN IEC 61000-3-2:2019+A1:2021
• BS EN 50663:2017
• EN 301 489-3 V2.1.1
• EN 55014-1:2017+A11:2020
• EN 55014-2:2015
• EN IEC 61000-3-2:2019+A1:2021
• EN 50663:2017
• BS EN IEC 55014-1:2021
• BS EN IEC 55014-2:2021
• BS EN 61000-3-3:2013+A1:2019
• EN 301 489-1 V2.2.3
• EN 300 220-2 V3.1.1
• EN IEC 55014-1:2021
• EN IEC 55014-2:2021
• EN 61000-3-3:2013+A1:2019

11
This appliance is labelled in compliance with
European directive 2011/65/EU for Waste
Electrical and Electronic Equipment (WEEE).
By ensuring that this appliance is disposed of
correctly, you will help prevent any possible
damage to the environment and to human
health, which might otherwise be caused if it
were disposed of in the wrong way.
The symbol on the product indicates that
it may not be treated as normal household
waste. It should be taken to a collection point
for the recycling of electrical and electronic
goods.
This appliance requires specialist waste
disposal. For further information regarding
the treatment, recover and recycling of this
product please contact your local council,
your household waste disposal service, or the
shop where you purchased it.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city oce,
your household waste disposal service or the
shop where you purchased the product.
| Recycling & disposal
DISPOSAL: Do not dispose
this product as unsorted
municipal waste. Collection
of such waste separately
for special treatment is
necessary.
Guarantee

12
Installation
[02] x 1[01] x 1
| What's in the box
| What's required for installation
X2

13
Installation
01
| Cut out work surface
Cut out the work surface according to
the sizes shown in the drawing.
For the purpose of installation and use,
a minimum of 50mm space shall be
preserved around the hole.
Be sure the thickness of the work
surface is at least 18mm.
Please select heat-resistant work surface
material to avoid larger deformation
caused by the heat radiation from the
hotplate as shown above.
Make sure the Induction cooker hob
is well ventilated and the air inlet and
outlet are not blocked.
Note: Where a cooker hood is
NOT installed the safety distance
between the hotplate and the
cupboard above the hotplate should
be at least 500mm.
If a cooker hood is installed please
refer to the cooker hood user
manual for required safety distance.
L (mm) 590
W (mm) 520
H (mm) 60
D (mm) 56
A (mm) 565
B (mm) 495
X (mm) 50 min
13amp: 32amp:
A (mm) 500 500
B (mm) 10 min 10 min
C (mm) 20 min 20 min
DAir intake Air intake
EAir exit 5mm Air exit 5mm
••••
≥50mm
≥500mm ≥400mm

14
Installation
02
Before locating the xing brackets the
hob should be placed on a stable, smooth
surface (use the packaging). Do not apply
force onto the controls protruding from
the hob.
Make sure that . . .
• The work surface is square and level, and
no structural members interfere with space
requirements.
• The work surface is made of a heat-
resistant material.
• If the hob is installed above an oven, the
oven has a built-in cooling fan.
• If the appliance is installed above a drawer
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
• There is adequate ow of fresh air from
outside the cabinetry to the base of the
hob.
• The power supply cable is not accessible
through cupboard doors or drawers.
• The installation will comply with all
clearance requirements and applicable
standards and regulations.
| Before you install the hob
• A suitable isolating switch providing full
disconnection from the mains power
supply is incorporated in the permanent
wiring, mounted and positioned to comply
with the local wiring rules and regulations.
• The isolating switch must be of an
approved type and provide a 3 mm air
gap contact separation in all poles (or in
all active [phase] conductors if the local
wiring rules allow for this variation of the
requirements).
• The isolating switch will be easily
accessible to the customer with the hob
installed.
• You consult local building authorities and
by-laws if in doubt regarding installation.
• You use heat-resistant and easy-to-clean
nishes (such as ceramic tiles) for the wall
surface surrounding the hob.

15
Installation
WARNING: Do not use adhesive to x the hob into the worktop.
Once the seal is tted, position the hob into the cut-out in the worktop. Apply
gentle downwards pressure onto the hob to push it into the worktop ensuring a
good seal around the outer edge as shown.
03
Cut out worktop to supplied
dimensions shown in
DIAGRAM 01 with suitable
equipment. Seal the cut edge
of the worktop using silicone
or PTFE prior to tting the hob.
| Seal the work surface & hob
04 Stretch out and stick the supplied seal along the underside edge of the hob,
ensuring the ends overlap.
[02]
[02] x 1
IMPORTANT: Ensure that the product is fully cured as per
the manufacturers instructions before you commence
installation of the hob. The hob MUST NOT be sealed into
the worktop.
05
SEAL

16
Use
| Induction Cooking
Induction cooking is a safe, advanced, ecient, and economical cooking technology. It works by
electromagnetic vibrations generating heat directly in the pan, rather than indirectly through
heating the glass surface. The glass becomes hot only because the pan eventually warms it up.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your nger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a
cloth) covering them. Even a thin lm of water may make the controls dicult to operate.
Before using your Induction Hob
• Read this guide, taking special note of the Safety section.
• Remove any protective lm that may still be on your Induction hob.
iron pan
magnetic circuit
ceramic glass plate
induction oil
induced currents

17
Use
Only use cookware with a base suitable for induction
cooking. Look for the induction symbol on the packaging
or on the bottom of the pan.
• You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan.
If it is attracted, the pan is suitable for induction.
If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not ash in the display and the water is heating, the pan is suitable.
Cookware made from the following materials is not suitable: pure stainless steel, aluminium
or copper without a magnetic base, glass, wood, porcelain, ceramic and earthenware.
U
–
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at against the glass, and is the same size
as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected.
Using a pot a slightly wider energy will be used at its maximum eciency. If you use smaller pot
eciency could be less than expected. Pot less than 140 mm could be undetected by the hob.
Always centre your pan on the cooking zone.
Always lift pans o the Induction hob – do not slide, or they may scratch the glass.
| Choosing the right cookware

18
Use
| Functions & Settings
01 User interface
1. Zone Select Key
2. On/O Key
3. Child Lock/Connectivity Key
4. Power/Timer Slider Regulating Key
5. Boost Control/Keep Warm Key
6. Timer/Pause Key
Heating Zone Max. Power (220-240V~50/60Hz)
1500/2000W (Booster)
1200/1500W (Booster)
1500/2000W (Booster)
1200/1500W (Booster)
Limit Rating Power 2800W
342 5 6
1
Switch on the appliance at the plug socket or double pole isolation switch. The appliance is
ready for use.
| Before you start
WARNING: Read the instructions
before using the appliance.
People with a heart
pacemaker should consult
with their doctor before
using any induction hob.

19
Use
Child Lock Function
• You can lock the controls to prevent
unintended use (for example children
accidentally turning the cooking
zones on).
• When the controls are locked, all the
controls except the OFF control are
disabled.
To lock the controls
• Touch the Key Lock Control for
3 seconds. The Timer indicator will
show 'Lo'.
To unlock the controls
1. Make sure the Induction hob is
turned on.
2. Touch and hold the Key Lock Control
for a while.
3. You can now start using your
Induction hob.
Boost Control/Keep Warm Functions
Activate Boost Control
• Select the heating zone you wish to
use by touching the relevant Zone
Select Key.
• Touching the Boost Control/Keep
Warm Key, the zone indicator will
show 'P' and the power reaches Max.
Cancel Boost Control
• Touching the relevant Zone Select
Key that you wish to cancel.
• Touching the Slider Regulating Key
to choose the new power level.
• The function can work in any cooking
zone.
• The cooking zone returns to level 9
after 5 minutes.
Activate Keep Warm Function
• Touch the Zone Select Key button of
the zone that you wish to keep warm,
an indicator next to the key will ash.
• Touch the Boost Control/Keep Warm
Key and hold for 3 seconds, the
cooking zone indicator will display
Cancel Keep Warm Function
• Select the cooking zone you wish to
operate, and then touch the Boost
Control/Keep Warm Key and hold for
3 seconds. The cooking zone will be
OFF.
02 General Use
Pause Function
The hob has a handy restart function to
pause and restart the cooking process
if you’re interrupted.
• When the hob is on and working,
press the Pause Key and hold for 3
seconds, all burner will stop working,
and all LED indicator will show the
symbol '='.
• Press the Pause Key and hold for
3 seconds again, all functions will
restart at the previous setting.
When the hob is in the lock
mode, all the controls are
disabled except OFF, you
can always turn the hob o
with the OFF control in an
emergency, but you shall
unlock the hob rst in the
next operation.

20
Use
02 General Use
Timer/Pause Functions
You can use the timer in two dierent
ways:
• You can use it as a Minute Minder.
In this case, the timer will not turn
any cooking zone o when the set
time has expired.
• You can set it to turn one cooking
zone o after the set time has
expired.
• You can set the timer for up to
99 minutes.
Using the Timer as a Minute Minder
if you are not selecting any cooking
zone:
1. Make sure at least one cooking zone
is turned on.
Note: you can use the Minute
Minder even if you’re not selecting
any cooking zone.
2. Touch the Timer Key .
The minder indicator will start
ashing and '10' will show in the
timer display.
3. Set the time by touching the or
control of the timer
Hint: Touch the or control
of the timer once to decrease or
increase by 1 minute.
Touch and hold the or control
of the timer to decrease or increase
by 10 minutes.
Touching the until the timer
indicator display shows '00' to cancel
the timer.
4. When the time is set, it will begin to
count down immediately. The display
will show the remaining time .
5. Buzzer will beep for 30 seconds and the
timer indicator will turn o when the set
time has expired.
Setting the timer to turn one or more
cooking zones o if the timer is set on one
zone:
1. Select the relevant cooking zone which is
working by touching the Zone Select Key.
2. Press the Timer Key .
The minder indicator will start ashing '10'
and you can set the timer at this point.
3. Using the or control you can set the
timer from1 to 99 minutes.
Hint: Touch the or control of the
timer once to decrease or increase by
1 minute.
Touch and hold the or control of the
timer to decrease or increase by 10 minutes.
Touching the until the timer indicator
display shows '00' to cancel the timer.
4. When the time is set, it will begin to count
down immediately. The display will show
the remaining time and the timer indicator
ashes for 5 seconds.
NOTE: The red dot next to power
level indicator will illuminate
indicating that zone is selected.
5. When cooking timer expires, the
corresponding cooking zone will be
switched o automatically.
6. Other cooking zones will keep operating if
they were turned on previously.
7. When using 'the timer as an alarm' and 'the
timer to switch o the zones' together,
the display will show the remaining time of
alarm as rst priority. Press cooking zone
to show the remaining time of switch-o
timer.
