Vicon VC355-DSP User manual









Vicon part number 8009-8131-00-00 Rev 403 Section 1
XX131-00-00
VC355-DSP, VC365-DSP,
VC355C-DSP AND VC365C-DSP
DIGITAL COLOR CAMERAS
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not be
used for this purpose.
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com





To prevent fire or shock hazard, do not expose the unit
to rain or moisture.
The symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.


Warning -- This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Caution -- Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority to operate the
equipment.






WARNING







1. Installation of the camera must be performed by qualified service personnel in
accordance with all local and national electrical and mechanical codes.
2. Do not attempt to disassemble the camera.
In order to prevent electric shock, do not remove screws or cover. There are no user-
serviceable parts inside.
Refer all servicing to qualified service personnel.
3. Handle the camera with care.
The camera could be damaged by improper handling or storage.
4. Do not expose the camera to rain or moisture or try to operate it in wet areas.
Take immediate action if the camera becomes wet. Turn the power off and refer servicing
to qualified service personnel. Moisture can damage the camera and also create a danger
of electric shock.
5. Do not use strong or abrasive detergents when cleaning the camera body.
Use a dry cloth to clean the camera when dirty. In a case when the dirt is hard to remove,
use a mild detergent and wipe gently.
6. Never point the camera toward the sun.
Whether the camera is used outdoors or not, never point it toward the sun. Use caution
when operating the camera in the vicinity of spot lights or other bright lights and light-
reflecting objects.
7. Do not operate the camera beyond its temperature, humidity or power source ratings.
Do not use the camera in an extreme environment where high temperature or high
humidity exists. Use the camera under conditions where temperatures are between
14°~122° F (-10 to +50°C), and humidity is below 85%. For the correct power supply, refer
to the specification sheet.
8. If using 24 VAC power adapter, only use a AC 24V UL Listed Class 2 power transformer.

Caution:
To prevent fire or shock hazard, the UL listed wire VW-1, style 1007 should be used for
24 VAC input terminals.
PRECAUTIONS



1. Iris lens connector plug for DC or VIDEO drive – 1pc
2. Dust protective cap - 1pc
3. Manual – 1pc
PACKING LIST





Video output connector (BNC)
1.0 V p-p/75Ωcomposite video signal is provided at this connector.


Power input connector (screw terminal






This terminal accepts 24 VAC power source.
Recommended Power Supply: Minimum 300 mA or 7.2 W.
Caution:
1. Only use AC 24V UL listed Class 2 power transformer.
2. To prevent fire or shock hazard, UL listed wire VW-1, style 1007, should
be used for the cable for AC 24V input terminal.
CONNECTORS AND CONTROLS



Autoiris lens connector for DC or VIDEO drive lens
Use of a DC drive lens:
It supplies the control signals to the DC drive autoiris lens.
When using a DC drive lens, set DC and VIDEO drive select switch (switch !) to DC
drive and MODE SELECT SWITCH 4 (ALC/ELC) to ALC MODE.

Use of a VIDEO drive lens:
It supplies the control signals to the VIDEO drive autoiris lens.
VIDEO Drive Lens Cable Pin Connections
PIN Signal
1
2
3
4
POWER SUPPLY (9 VDC, 40 mA)
OPEN
VIDEO OUTPUT (0.7 V p-p without sync)
GROUND
When using a VIDEO drive lens, set DC and VIDEO drive select switch (switch !) to
VIDEO drive and MODE SELECT SWITCH 4 (ALC/ELC) to ALCMODE




VIDEO and DC drive select switch
This switch allows the selection of DC drive lens or VIDEO drive lens.








Power Indicator LED
This LED turns ON only when power is supplied properly and the DC-DC converter (or
the regulator) inside the camera works properly.




!
!!
!

V-Phase Adjustment pushbutton
This camera is designed to keep the initial data value of V-phase in EEPROM.
NOTE : This camera offers V-phase adjustment over a range of ±180°. If two or more
cameras are connected to a switcher and the picture on the monitor rolls while
switching from camera A to B, adjusting the vertical phase (V-phase) of the cameras
will probably eliminate the rolling. If this adjustment is necessary, it should only be
performed by a qualified technician. Before making any adjustment, confirm that
cameras A and B are connected to the power supply with the same polarity.
To make an adjustment, follow the steps below.
1. While observing the video output signals from both cameras on an oscilloscope,
press camera A's V-phase control pushbutton (on back of camera) until vertical sync
from both cameras are in phase.
2. If camera A's adjustment range is insufficient, adjust camera B's V-phase control
pushbutton in the opposite direction to camera A until they are in phase.
3. If these adjustments do not bring vertical sync from both cameras in phase, recheck
the polarity of the power supply connections.
Camera A's VIDEO OUT

Camera B's VIDEO OUT

Should be in phase




"
""
"

AWB HOLD pushbutton
Use of the AWB HOLD pushbutton:
1. When a subject is lighted by many kinds of light.
2. When you use a special lamp, such as a sodium lamp or mercury vapor lamp.
How to use:
1. Select AWB of mode select switch "Pole 5 (AWB/ATW) (AWB is OFF).
2. Display a full screen of white paper or white subject on the monitor.
3. Adjust the screen color to be white pushing AWB HOLD pushbutton.
#
##
#ALC level adjustment potentiometer for DC drive lens
This potentiometer is used only if the camera is fitted with a DC drive autoiris lens. It is
used to control the amount of light striking the CCD image sensor.
LEVEL

Monitor Screen LEVEL Control Direction
To increase the brightness Clockwise
To decrease the brightness Counterclockwise
"
""
"


MODE select switch
1. INT/LL switch
This camera can operate independently, using its internal crystal-controlled sync generator, or it may
be synchronized using line-locking.
To select one or the other of these sync modes, set the DIP switch on the rear panel to either INT or
LL. Pole 1 is set to ON for LL and OFF for INT.
If line-locking is selected, all the cameras in the system must be adjusted to begin the video field
scan at the same time. This is described in #and ".
LENS-IRIS level

2. FLON switch (FLICKERLESS ON / OFF)
This function is only used in JAPAN.
When the DIP switch on the rear panel is set to ON, the shutter speed is fixed at a rate of 1/100
(120) (sec).

3. BLC (backlight compensation) ON/OFF switch
If the subject you wish to view is too dim because of a bright background, set the BLC switch to ON
to compensate for the bright background.
With BLC ON, the background brightness may saturate in some cases. This function may not
operate properly if the object is too small compared to the area of the background. This function can
be used with either the linear shutter (EE or ELC mode) or an autoiris lens (AI lens or ALC mode).

WITH BLC OFF WITH BLC ON
4. ALC/ELC select switch
This switch is used to select EE (electronic exposure) or ELC (electronic light control)
mode or AI (autoiris lens) or ALC (automatic light control) mode. Pole 4 is set to ON for
ELC and OFF for ALC.
In the EE mode, a continuously variable electronic shutter is employed to automatically
control the exposure time of the CCD image sensor according to the incoming light
level. With this mode selected, a fixed or manual iris lens can be used instead of an
autoiris lens. In the AI mode, the CCD shutterspeed is fixed to 1/60 (1/50) sec,and
the incoming light level iscontrolled by the autoiris lens.
To use a video-drive type or the DC-drive type of autoiris lens, set this switch to the
ALC position.

Cautions:
1. Under bright lighting conditions such as outdoors, use an autoiris lens because the ELC control
range is not wide enough under these conditions.
2. Under certain unique lighting conditions, the following phenomena may appear:
•Strong smear and/or blooming on high light objects such as spotlights or windows.
•Noticeable flicker in the picture and/or color rendition variations.
To avoid this, use an autoiris lens.
3. When operating in ELC mode with a manual iris lens, the depth of field of the image may be less
than that obtained by using an ALC lens. Depth of field varies inversely with the iris opening. Thus,
using this camera in ELC mode with the manual iris lens fully opened may result in less depth of field
and the distant objects in picture may be seen out of focus.
4. Fixed iris or manual iris lenses may be used with the linear shutter (ELC mode) where the scene
brightness varies over a limited range.
5. Do not use the ELC mode when an autoiris lens is installed.
5. AWB/ATW select switch
This camera has an AUTO WHITE BALANCE (ATW) and MANUAL WHITE BALANCE (AWB)
function.
The camera is automatically adjusted to the best condition in the ATW mode.
In the AWB mode, it can be adjusted for the best color manually by pushing the AWB HOLD button
((). Pole 5 is set to ON for ATW and OFF for AWB.
6. AGC ON/OFF switch
This switch is provided for the AGC circuit.
The AGC circuit incorporated into the camera boosts the sensitivity automatically when the scene
illumination is insufficient.
7. HI GAIN ON/OFF switch
The automatic MORE-GAIN function automatically adjusts picture gain in accordance with the
brightness of the subject. This function is enabled when Pole 6 is set to ON.

Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name
of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 631-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 631-951-CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Europe Ltd.
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection.
Mark the R.A. number on the outside of the carton on the shipping label.








DSP CAMERA
SPECIFICATIONS
MODEL VC355-DSP VC365-DSP
VC355C-
DSP VC365C- DSP
1/3” interline transfer CCD
IMAGE DEVICE 510(H) * 492(V) 768(H) * 494(V) 500(H) * 582(V) 752(H) * 582(V)
TV SYSTEM NTSC standard, 2:1 interlace PAL standard, 2:1 interlace
SYNCHRONIZING SYSTEM Line Lock / Internal
HORIZONTAL RESOLUTION 330 TV lines 480 TV lines 330 TV lines 480 TV lines
VIDEO OUTPUT LEVEL 1 V p-p VBS/75ohm
S/N RATIO More than 48 dB (AGC OFF)
NORMAL 0.03 fc
(0.3 lux) 0.05 fc (0.5 lux) 0.03 fc (0.3 lux) 0.05 fc (0.5 lux)
MIN.
ILLUMINATION
(at 25 IRE F1.2) HI-GAIN 0.02 fc
(0.2 lux) 0.04 fc (0.4 lux) 0.02 fc (0.2 lux) 0.04 fc (0.4 lux)
ELECTRONIC IRIS 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec
AUTO WHITE BALANCE 2,500°K ~ 7,500°K
LINE LOCK RANGE 60 Hz ±1.0Hz 50 Hz ±1.0Hz
BACK LIGHT COMPENSATION Center Weighted Zone
EXTERNAL CONTROLS
•INT / LL SELECT
•FLICKERLESS ON/OFF
•BLC ON/OFF
•ALC / ELC SELECT
•AWB / ATW SELECT
•AGC ON/OFF
•HI-GAIN ON/OFF
•VIDEO / DC DRIVE LENS SELECT
CAMERA MOUNT Flush mount type (top or bottom selectable)
MOUNT C or CS mount
LENS AUTO IRIS DC and VIDEO drive type with 4-pin connector
POWER REQUIREMENT 24 VAC ±20 % 300 mA max., full isolation
OPERATING CONDITION 14 ° to 122 °F (-10° ~ 50°C) with 85% relative humidity
NET WEIGHT WITHOUT LENS Approx 0.35 lb (158 g)
DIMENSIONS (W x H x D) 2.2 in. (55 mm) x 2.6 in. (67.0 mm) x 2.9 in. (74.8 mm)
Technical Information










DIMENSIONS







1. Simplest: one monitor system with one camera

EXAMPLES OF CONNECTIONS
CAMERA
VIDEO COAXIAL CABLE
AC-24V INPUT







2. One monitor system with two or more cameras







EXAMPLES OF CONNECTIONS - continued
CAMERA
VIDEO COAXIAL CABLE
AC-24V INPUT
AC-24V INPUT
CAMERA
AC-24V INPUT
CAMERA SEQUENTIAL
SWITCHER
OR
QUAD SPLITTER
VIDEO COAXIAL CABLE
VIDEO COAXIAL CABLE
VIDEO COAXIAL CABLE

Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, New York 11788
631-952-CCTV (2288) 800-645-9116
Fax: 631-951-CCTV (2288)
Vicon Europe
Headquarters
Brunel Way
Fareham, PO15 5TX
United Kingdom
[phone]
Fax: [phone]
Brussels Office
Planet II - Unit E
Leuvensesteenweg 542
B-1930 Zaventem
Belgium
[phone]
Fax: [phone]
Far East Office
Unit 5, 17/F, Metropole Square
2 On Yiu Street, Shatin
New Territories,
Hong Kong
(852) 2145-7118
Fax: [phone]
Internet Address: www.vicon-cctv.com
