Victory GFS-1-S7 User manual

Remote
Model Available (Two Section Models Only)
Griddle Stand Freezers
Cabinet:
The cabinet front and drawers are
constructed of heavy gauge polished
stainless steel to maintain an attractive
appearance after years of heavy use.
Foamed-in-place polyurethane insulation
throughout the cabinet and drawers
ensures the ultimate in energy efficiency.
Drawers:
Easy glide drawers are mounted on heavy-
duty 250 pound test tracks and have self-
adjusting magnetic gaskets for positive
sealing action. Humidity control wires
located around the drawer opening prevent
condensation from forming on the cabinet
front and are concealed by a high impact,
non-conductive thermal breaker strip. The
drawer and liner are constructed of
stainless steel, which resists denting and
scratching and is easy to clean.
Refrigeration System:
All components of the self-contained
refrigeration system are contained within a
side mounted housing and concealed behind
a louvered grille. All condensate water is
disposed of automatically by the energy
efficient condensate evaporator, no plumbing
is required.
Standard Features
• Dial Thermometer
• Stainless Steel Case Front, Drawers and
Sides
• Heavy-Duty Drawer Track - 250 lb. Test
• Adjustable Stainless Steel Legs
• Safety Grip Handles
• One Piece Self-Adjusting Magnetic Gaskets
• Condensate Automatically Evaporated
• Energy Efficient Refrigeration System
• Environmentally Friendly R-404A Refrigerant
• Stainless Steel Sub Top
Optional Features and Accessories
• Stainless Steel Top and Back
• 5" Diameter Heavy-Duty Swivel Casters
• Remote Models
Note: Drawer pans by others (Each drawer
frame will accept two 12 x 10”pans up to 4”
deep.)
GFS MODELS —
Stainless steel
exterior and
interior.
GFS-1-S7
GFS-2-S7
GFS-22-SS7
Stainless
Steel Tops are Optional
Victory Refrigeration, Inc. I 110 Woodcrest Road I Cherry Hill, NJ 08003 USA I Phone: [phone] I Fax: [phone] I E-mail: [e-mail]
Victory Refrigeration specification sheets
are available online at www.victory-refrig.com.
Approvals:
Project:
Location:
Item #:
Quantity:

Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include
standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.
Continuous product development may necessitate specification changes and design without notice.
Victory
Refrigeration, Inc. Griddle Stand Freezers
FOR REMOTE MODELS– Substitute an “R” for the “S” in suffix. For
example: Model GFS-1D-S7 (self-contained) would be GFS-1D-R7
remote cabinet. Air circulating fans, expansion valve and plasticized
coil are provided. Condensing units not supplied. The following units
are recommended with
1/2
” O.D. Suction line,
1/4
” O.D. Liquid line.
Dimensional tolerance ± 1/4” Metric dimensions (MM)
REMOTE REFRIGERATION
Cond. Unit BTUH Cabinet Amps
One Section
1/3
H.P. 1380 115/60/1 5.8
Two Section
1/3
H.P. 1380 115/60/1 5.8
Copyright January 2004
Printed in U.S.A. 010437
PART OF AGA FOODSERVICE GROUP
SELF CONTAINED
LEFT END SIDE VIEW
REMOTE
LEFT END SIDE VIEW
50.12
(1273)
19.50
(495)
6.00 (152)
30.87
(784)
2.00
(51)
19.81
(503)
30.87
(784)
15.75
(400)
MACHINE
COMPARTMENT
3.00
(76)
5.00 (127) 6.00 (152)
7.75
(197)
6.00 (152)
8.12
(206)
3.62
(92)
3.62
(92)
ELEC.
CONN.
CONDENSATE
VAPORIZER
REFRIGERATION
LINE CONN.
ELEC.
CONN.
DRAIN
CONN.
77.25
(1962)
19.81
(503)
6.00 (152)
19.50
(495)
19.81
(503)
8.12
(206)
NOTE: If cabinet is located directly against
wall and/or under low ceiling, a minimum
clearance of 2” is required.
We reserve the right to change
specifications and product design
without notice. Such revisions do not
entitle the buyer to corresponding
changes, improvements, additions or
replacements for previously purchased
equipment.
CHARACTERISTICS ONE TWO
ONE TWO SECTION SECTION
SECTION SECTION REMOTE REMOTE
Width, Overall 50 1/877 1/433 3/860 1/2
Depth, Overall (incl. drawers) 32 7/832 7/832 7/832 7/8
Height, Case (incl. adj. legs) 25 1/225 1/225 1/225 1/2
Height, Case with
Stainless Steel Top incl. adj. legs) 26 1/426 1/426 1/426 1/4
Capacity Net (cubic feet) 6.0 12.0 6.0 12.0
No. of Drawers 2 4 2 4
No. of 12 x 20 Pans (not furnished) 4 8 4 8
Cabinet Voltage 115/60/1 115/60/1 115/60/1 115/60/1
Feed Wires 2 2 2 2
Condensing Unit Voltage 115/60/1 115/60/1 ------ ------
Condensing Unit Size (HP) 1/31/3------ ------
Total Amperes 11.6 11.8 ------ ------
Crated dim. & wts.
Ht. Width Depth Cu. Ft. Lbs
One Section 34 1/456 1/436 3/443.1 430
Two Section 34 1/483 1/438 3/463.9 510
