Viglen Futura Durus User manual

U
Us se er r’ ’s sM Ma an nu ua al l
Futura Durus Notebook

Table of Contents
i
Table of Contents
CHAPTER 1 ...........................................................................................................1
INTRODUCTION ..................................................................................... 1
Getting Started ...........................................................................................2
Inventory.....................................................................................................4
Safety and Maintenance .............................................................................5
Check lists ..................................................................................................6
Features......................................................................................................7
Where to Look For Information .................................................................6
Quick Start..................................................................................................7
Loading Windows.......................................................................................8
Adjusting the Volume................................................................................10
Adjusting the Brightness........................................................................... 10
Turning off Your Computer ......................................................................11
Making a Startup Disk.............................................................................. 10
Tips for New Owners................................................................................12
CHAPTER 2 ......................................................................................................... 13
GETTING STARTED............................................................................. 13
Hardware and Software ...........................................................................15
Front View................................................................................................15
Right View ................................................................................................16
Left View................................................................................................... 17
Bottom View .............................................................................................18
LED Status Indicators ..............................................................................19
Power Indicators ...................................................................................... 20
Function Keys...........................................................................................20
Numeric Keypad....................................................................................... 21
Touchpad..................................................................................................22
The Optical Drive.....................................................................................24
Connecting the Printer .............................................................................25
The Express Card Slot..............................................................................25
The Graphics System ................................................................................ 26
Communication Components....................................................................29
Information about the Wireless LAN button.............................................31
Information about 3G function (Optional) ...............................................32
Information aboutBluetooth function (Optional)......................................33
CHAPTER 3 ......................................................................................................... 34
MAKING CONNECTIONS ...................................................................... 34
Making Connections................................................................................. 35

ii
Left Side Connectors ................................................................................35
Right Side Connectors .............................................................................. 36
Front Side Connectors..............................................................................37
CHAPTER 4 ......................................................................................................... 39
POWER MANAGEMENT ....................................................................... 39
Power Management..................................................................................40
Monitoring Battery Power........................................................................41
Power Saving Modes................................................................................42
Power Saving Tips.................................................................................... 43
When to Replace the Battery ....................................................................43
Heat Considerations................................................................................. 44
Battery Hot Swappable function (Optional)............................................. 44
CHAPTER 5 ......................................................................................................... 46
USING THE BIOS SETUP UTILITY........................................................ 46
Using the BIOS Setup Utility....................................................................46
Change User Password ............................................................................53
APPENDIX A........................................................................................................ 54
SPECIFICATIONS ................................................................................. 54
Specifications ...........................................................................................55
APPENDIX B........................................................................................................ 61
FAQ & STATEMENT ........................................................................... 65

C
Ch ha ap pt te er r1 1
I
In nt tr ro od du uc ct ti io on n

Chapter 1
2
Getting Started
Congratulations on your purchase of the Notebook computer! Your
new notebook features the most innovative advances in portable
computing technology. It combines state-of-the-art ergonomics with
sophisticated architecture to provide you with a personal computer that
is compact, powerful, and easy to use. Designed for a wide range of
general, business, and personal productivity applications, the
notebook is an ideal choice for use in the office, at home, and on the
road.
For maximum expandability without compromising portability, the
notebook accommodates a number of modules, including Optical
Drive, three USB ports, one Express card and one 4 in 1 card slot. The
high capacity hard disk drive provides you with plenty of storage space
for multimedia files and applications.
This Manual contains all the information you need to set up and use
your new notebook. It describes all the features of the notebook in an
easy-to-read yet thorough manner.
COPYRIGHTS AND TRADEMARKS
Please note
The material in this manual is subject to change without notice.
Trademarks
Microsoft, Windows, Windows NT, MS-DOS, Windows 95,Windows
98, Windows ME, Windows 2000 Pro, Windows XP Pro and Windows
Vista are registered trademarks of Microsoft Corporation. IBM PC, XT,
AT and PS/2 are trademarks of International Business Machines
Corporation. Pentium and Pentium Pro are registered trademarks of
Intel Corporation. AMI BIOS is a registered trademark of American
Megatrends. All other trademarks are acknowledged. JAC-UP, Genie,
Contender, Dossier, Futura Vig, Viglen, and Envy are trademarks of
Viglen Limited

Chapter 1
3
Copyright and Patents
This manual and all accompanying software and documentation are
copyrighted and all rights reserved. This product, including software
and documentation, may not, in whole or in part, be copied,
photocopied, translated or reduced to any electronic or machine-
readable form, without prior written consent except for copies retained
by the purchaser for backup.
© Copyright 2007 Viglen Limited
All Rights Reserved
Futura Durus Manual Version 1.0
Created in the United Kingdom
Liability
No warranty or representation, either expressed or implied, is made
with respect to this documentation, its quality, performance,
merchantability or fitness for a particular purpose. As a result the
documentation is licensed as is, and you, the licensee, are assuming
the entire risk as to its quality and performance. The vendor reserves
the right to revise this operation manual and all accompanying
software and documentation and to make changes in the content
without obligation to notify any person or organization of the revision or
change.
In no event will the vendor be liable for direct, indirect, special,
incidental or consequential damages arising out of the use or inability
to use this product or documentation, even if advised of the possibility
of such damages. In particular, the vendor shall not have liability for
any hardware, software or data stored or used with the product,
including the costs of repairing, replacing or recovering such
hardware, software or data.

Chapter 1
4
Inventory
This computer system is designed for years of productive and
pleasurable computing. Use this section to keep details of your
purchase. This information will be required should you need to make
repairs to your notebook during the warranty period. Update this
section when you add new options.
DATE OF PURCHASE:
PLACE OF PURCHASE:
DEALER'S NAME:
DEALER'S ADDRESS:
TELEPHONE:
E-MAIL ADDRESS/WWW:
CONTACT PERSON:
MODEL NUMBER:
SERIAL NUMBER:
BIOS VERSION:
The serial number is on the label (with a bar code) on the bottom side
of the computer. The BIOS revision number will appear briefly on the
screen after turning on the computer, before the graphic BIOS screen
appears. Press the Del key to enter BIOS setup screen.

Chapter 1
5
Safety and Maintenance
You can use your computer under a wide range of environmental
conditions. However, to ensure long use and continued high
performance, consider the following factors when setting up your
computer:
Follow all warnings and instructions noted in this documentation
and in the Windows Help program.
The first time you use your computer, we recommend that you
carefully read the Making Connections section of this manual
and initialize the battery to ensure optimum battery performance.
Unplug the computer from the power outlet before cleaning. Use
a damp cloth for cleaning. Do not use aerosols, solvents, or
strong detergents.
Do not use the computer near open water or other liquids. Never
spill liquid onto the computer.
Do not place the computer in an unstable location where it might
slip or be knocked over. Serious damage could result from a fall.
Slots and openings in the system cabinet are for ventilation
purposes. Do not block or cover these openings or the system
could overheat. Do not use or store the computer near a source
of heat or dust.
On the base or rear panel of this notebook, there is a label with
information on the power requirements of this system. These
requirements must be followed. If you are unsure of your local
power supply, consult your dealer or local Power Company.
Do not step on or place anything on the power cord.
If you use the computer with an extension cord, ensure that the
total ampere ratings of all the devices sharing the extension do
not exceed the rating of the extension cord or the rating of the
wall outlet.
Never push foreign objects into the computer through any of the
slots or openings. Dangerous voltages are present, which could
cause electric shock or fire, or damage sensitive components.
For best results, use a power strip with a built-in surge protector.
Do not use inferior extension cords as this may result in damage
to your computer.

Chapter 1
6
Set the computer on a flat, stable surface. To prevent damage to
the computer’s hard disk drive, avoid using the computer where
it will be exposed to strong vibration.
Check lists
After opening the package, carefully inspect the contents. If any of the
items is missing or appear damaged, contact your dealer. The
shipping carton should contain the following:
STANDARD
A notebook computer with a hard disk drive
An internal battery
An Optical drive
An AC adapter with power cord
OPTIONS
The following items are normally optional, but some vendors may
include them in the standard package. Some items may not be
available in some countries, or some vendors may choose not to carry
all the items.
512 MB, 1GB or 2GB DDRII SODIMM memory modules
Caution: When purchasing any of the accessories listed above,
purchase only those accessories that are approved for use with your
computer. The above accessories are proprietary items. Your system
vendor can obtain these approved accessories. If you use items that
are not approved for use with this computer, you may cause your
computer to malfunction, or to emit or receive electro-magnetic
radiation in excess of local regulations. For non-proprietary
accessories such as PC cards or printers, ensure that the accessory
functions properly in your computer before making the purchase.
Your system vendor may be able to recommend reliable brands and
models.
