Table of Contents
IMPORTANT–Please Read and Follow!
Warnings & Important Information ———————————————————————— 2
Specifications ————————————————————————————————— 3
General Information——————————————————————————————— 4
Parts Included in the Kit ————————————————————————— 4
Cabinet or Wall Cutout—————————————————————————— 4
Electrical Outlet Location ————————————————————————— 4
Installation ——————————————————————————————————— 5
Mounting Template ——————————————————————————— 5
Bottom Duct Assembly—————————————————————————— 6
Mounting Bracket Assembly ——————————————————————— 6
Cabinet Installation ——————————————————————————— 7
Frame Assembly————————————————————————————— 7
Side Decoration Assembly (For Surface Mount Only) ————————————— 8
Over Oven Installation —————————————————————————— 8
Performance Checklist ————————————————————————————— 8
• Before beginning, please read these
instructions completely and carefully.
• Be sure to DISCONNECT THE PLUG of the
microwave oven from the electrical outlet
before installing the built-in trim kit. Remove
the turntable from the oven cavity.
• Because the kit includes metal parts, caution
should be used in handling and installation
to avoid the possibility of injury.
• Do not remove permanently affixed labels,
warnings, or plates from the product. This
may void the warranty.
• Please observe all local and national codes
and ordinances.
• The installer should leave these instructions
with the consumer who should retain for local
inspector’s use and for future reference.
WARNING
This built-in trim kit is designed for use ONLY
with Viking microwave ovens specifying built-
in trim kit RDMTK302 on the rating label on
the left side wall of the oven cavity.

E
3
Microwave Oven Built-In Trim Kit
RDMOS201 RDMTK302
Overall Width 24" (60.9 cm) 29-1/2" (74.9 cm)
Overall Height from Bottom 13-3/8" (33.9 cm) 17-1/4" (43.7 cm)
Overall Depth from Rear 19-1/8" (48.7 cm) NA
Oven Interior Width
Height
Depth
Overall
17-3/8"
10-1/2"
18-5/8"
2.0 cu. ft.
(44.1 cm)
(26.6 cm)
(47. 3 c m)
NA
Electrical Requirements 120VAC/60 Hz NA
Max. Amp Usage 1.5 KW 13 amps NA
Approx. Shipping Wt. 46 lbs. (20.9 kg) 15 lbs. (6.9 kg)
In compliance with standards set by:
FCC – Federal Communications Commission Authorized.
DHHS – Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21,
Chapter I, Subchapter J.
– This symbol on the Rating label means the product is listed by Underwriters
Laboratories, Inc. for use in USA or Canada.
Specifications

4
E
General Information
4
E
14-1/4" (361.95 mm)
Minimum Cutout OpeningWidth 27-3/4" (704.9 mm)
Minimum Cutout Opening Height 16-9/16" (420.7 mm)
Maximum Cutout Opening Height 16-13/16" (427 mm)
Maximum Cutout OpeningWidth 28" (711.2 mm)
Distance between holes A9.1" (231.2 mm)
14" (355.6 mm)
Center Line
Floor Line of Cutout Opening
BUILT-IN TRIM KIT
SURFACE MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVEOVEN
TINSLB008MRR0
1/4"
(6.2mm)
1/4"
(6.2mm)
1. Align the Surface Mounting Template center line with the
centerof the cabinet. Align the Floor Line with the bottom
ofthe cabinet at the desired height. Tape it into place.
2. Predrill 4 holes marked Awith a ¹₁₆" drill bit.
3. Cut the cabinet opening between the minimum and
maximumcutout opening lines. Be careful to cut precisely
alongthe Floor Line of the cutout.
4. Remove template from the cabinet.
3-15/16" (100 mm)
7
4-3/16" (106.4 mm)
FLOOR LINE OF CUTOUT OPENING
BUILT-IN TRIM KIT
FLUSH MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVE OVEN
CABINET CUTOUT LINE
CABINET CUTOUT LINE
CENTER LINE
TINSLB009MRR0
1. Align the Flush Mounting Template center line with the center of the
cabinet. Align the Floor Line with the bottom of the cabinet at the
desiredheight. Tape it in place.
2. Cut the cabinet opening along the three Cabinet Cutout Lines and
theFloor Line.
3. Install two Side Spacers (see FIGURE 1) and one Bottom Spacer (see
FIGURE2) as specified in FIGURE 3. Be sure to offset all three spacers
by1⁹₁₆" from the front surface of the cabinet.
4. Cut out the Side Spacer Templates (R and L) and align the indicated
edge to the corresponding Side Spacer (see FIGURE 3). Be careful to
alignthe Floor Line to the bottom edges of the Side Spacers.
5. Predrill two holes indicated “A“ in Side Spacer - Rwith a ¹₁₆" drill bit.
6. Predrill two holes indicated ”B“ in Side Spacer - Lwith a ¹₁₆" drill bit.
7. Remove template from the cabinet.
SIDE SPACER TEMPLATE - L
SIDE SPACER TEMPLATE - R
FIGURE 1
SideSpacer (2 required)
Mustprotrude from edge of cabinet
cutouttowards center as shown.
AlignSide Spacer-L to this line
AlignSide Spacer-R to this line
CutoutOpening Height 17-5/16" (439.8 mm)
CABINET CUTOUT LINE
Edgesto align Side Spacer Templates (R and L)
BottomSpacer centered with cabinet cutout
1-9/16"(39.7mm)
Bottomand Side
Spacer(R and L) Offset
FIGURE 3
SideSpacer - L SideSpacer - R
14" (355.9 mm)
Distancebetween holes A9.1" (231.2 mm)
Cutout Opening Width 29-5/8" (752.5 mm)
14-13/16" (376.2 mm)
13/16"Min.
15/16Max.
13-1/2"min. height
FIGURE 2
BottomSpacer (1 required) ¹₄" plywood
24"min. width
27-7/8"max. width
1/4"(6.35 mm)1/4"(6.35 mm)
8
2
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
3
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
6
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
1
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
4
5
Parts Included in the Kit
Item Part Name QTY
1Frame Assembly 1
2Bottom Duct 1
3Mounting Bracket 2
4Screw A :1-3/16" length 2
5Screw B: 1-3/4" length 4
6Side Decoration
(Surface Mount Only) 2
7Surface Mounting Template 1
8Flush Mounting Template 1
Electrical Outlet Location
CAUTION
Outlet should NOT be in the shaded area as
indicated on figure 1.
1
figure
4"(10.2 cm)
4"(10.2 cm)
6"(15.2 cm)
NOTES:
• IftheDepth(C)dimensionisgreaterthan21"
(53.3 cm), the outlet location may be in any
areaontherearwall.
• Theooroftheopeningshouldbeconstructed
ofplywoodstrongenoughtosupporttheweight
oftheovenandoorload(approximately100
pounds).Theoorshouldbelevelforproper
operation oftheoven.Besuretocheck the
localbuildingcodeasitmayrequirethatthe
openingbeenclosedwithside,ceilingandrear
partition.Theproperfunctioningoftheoven
doesnotrequiretheenclosure.
Cabinet or Wall Cutout
Cutout Dimensions Flush
Mount
Surface
Mount
Height AMinimum 17-5/16"
(439.8mm)
16-9/16"
(420.7mm)
Maximum N/A 16-13/16"
(427mm)
Width BMinimum 29-5/8"
(752.5mm)
27-3/4"
(704.9mm)
Maximum N/A 28"
(711.2mm)
Depth CMinimum 20"
(503mm)
20"
(503mm)

5E
13/16" min.
15/16" max.
13-1/2" min.
24" min. width
27-7/8" max. width
1-9/16" (39.7 mm)
BOTTOM and SIDE
SPACER (R and L) offset
EDGES TO ALIGN SIDE SPACER
TEMPLATES (R and L)
Side Spacer (L) Side Spacer (R)
BOTTOM SPACER
CENTERED with
CABINET CUTOUT
3
figure
A
SIDE SPACER—2
REQUIRED. Must
protrude from edge of
cabinet cutout towards
center as shown.
B
BOTTOM SPACER—1
REQUIRED. 1/4" plywood.
C
For FLUSH MOUNT, two (2) side spacers and one (1) bottom
spacer are required. Spacers are not included in the kit and
must be fabricated by installer. See figures 3 A and B for
spacer requirements. Make sure that all three spacers are
offset from the front of the cabinet by 1-9/16".
Cut out the Side Spacer Templates (R and L)
from the Flush Mounting Template. Align the
indicated edges to the corresponding right and
left side spacers as shown in figure 3. Make sure
to align the bottom edges of the side spacer
templates to the floor of the cabinet opening.
Predrill two (2) holes marked “A” on Side Spacer
Template – R and two (2) holes marked “B” on
Side Spacer Template – L with 1/16" drill bit.
Remove templates from the cabinet.
Installation
Mounting Template
Determine which mounting method to use
based on the required configuration. See figure
2A for FLUSH MOUNT and 2B for SURFACE
MOUNT.
Align the template corresponding to the required
mounting method to the center of the cabinet.
Make sure that the template is level with the
floor. Tape it into place. Cut the cabinet opening
along the lines specified on the template. Leave
template taped in place.
For SURFACE MOUNT, predrill 4 holes marked “A” with a
1/16" drill bit. Remove template from the cabinet. Go to
Bottom Duct Assembly.
2
figure
A
FLUSH MOUNT CONFIGURATION—
Microwave Oven and Frame Assembly glass
are flush with the cabinet.
B
SURFACE MOUNT CONFIGURATION
—Microwave Oven and Frame Assembly
protrude from the surface of the cabinet.
b. Surface Mount Configuration -
Microwave Oven and Frame Assembly
protrude from the surface of the cabinet.
Illustration 2
a. Flush Mount Configuration -
Microwave Oven and Frame Assembly
glass are flush with the cabinet
Indicated surfaces are flush.

6
E
Installation
Bottom Duct Assembly
4
figure
CENTER THE
BOTTOM DUCT
Illustration 6 - for Flush Mount
SCREW A
BOTTOM DUCT
MAKE BOTTOM FLANGE
FLUSH WITH BOTTOM
SPACER
Place the Bottom Duct in the cabinet opening. For FLUSH
MOUNT, it will rest on the bottom spacer centered with
the cabinet. See figure 4.
5
figure
Illustration 7 - for Surface Mount
CENTER THE
BOTTOM DUCT
SCREW A
BOTTOM DUCT
MAKE BOTTOM FLANGE
FLUSH WITH CABINET
For SURFACE MOUNT, the Bottom Duct will rest on the
floor of the opening. See figure 5.
Align the Bottom Duct to the center of the
opening with the bottom flange securely flush
with the bottom spacer (for FLUSH MOUNT) or
the cabinet (for SURFACE MOUNT).
Secure the Bottom Duct Assembly with the two (2)
SCREWS A. See figures 4and 5respectively.
Mounting Bracket Assembly
Position the mounting brackets to align with the
predrilled holes that were drilled with the mounting
template.
SCREW B
SCREW B
A
B
FLUSH MOUNT BRACKET
figure
figure
6
SURFACE MOUNT BRACKET
The enclosed ends of the mounting brackets should face
inwards. Check that they are vertical and then secure loosely
with four (4) Screws B. See Figure 6.
figure
figure
7
27-1/2"
(698.5mm)
EQ. EQ.

7E
Installation
Align the mounting brackets horizontally by sliding
them back and forth along the screw slots until
the brackets are exactly 27-1/2" apart and equal
distance from the cabinet sides. See figure 7.
Once the brackets are correctly positioned,
securely tighten the four (4) screws B.
Cabinet Installation
Place the oven adjacent to the wall or cabinet
opening. Plug the power cord into the electrical
outlet.
CABINET INSTALL FRAME INSTALL CABINET INSTALL
figure
figure
8
Carefully guide the assembled oven into the prepared
opening. Slide the oven onto the Bottom Duct Assembly.
See figure 8.
figure
figure
9
CABINET INSTALL FRAME INSTALL CABINET INSTALL
BOTTOM
DUCT
ASSEMBLY
FOOT
DUCT RECESS
Avoid pinching the cord between the oven and the wall.
Adjust the position of the oven so that the feet of the oven
are fitted into the recesses of the Bottom Duct Assembly.
S ee figure 9.
Frame Assembly
Turn over FRAME ASSEMBLY to locate the 4 ball
studs.
Position the FRAME ASSEMBLY with the small
stainless decorations on top. Align the 4 ball studs
with the 4 snap attachments at both ends of the
MOUNTING BRACKETS.
Secure the FRAME ASSEMBLY by firmly pushing
it onto the Mounting Brackets engaging the four
(4) snap attachments. See Figure !.
figure
figure
!
SNAP ATTACHMENT LOCATIONS ON
MOUNTING BRACKETS
SMALL STAINLESS DECORATIONS ON TOP
4 BALL STUDS ON BACK OF FRAME ASSEMBLY

Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
[phone]
For product information
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
8
E
Over Oven Installation
figure
figure
#
2" (5.1 CM) FOR 30" W LOWER OVEN
Performance Checklist
1. Make sure the unit has been installed according
to all of the Installation Instructions and the
required Mounting Template.
2. Plug in the power cord.
3. Keep the Use & Care Manual and Installation
Manual.
Installation
Side Decoration Assembly
(For Surface Mount Only)
Peel the backing off the tape on the backside of
the SIDE DECORATIONS. Align the front inner
edge of the side decorations to the front side
edge of the FRAME ASSEMBLY.
Align the top surface of the side decorations to
the top surface of the FRAME ASSEMBLY. Secure
the side decorations by pressing them firmly
against the side of the FRAME ASSEMBLY. See
Figure ".
"
figure
ALIGN TOP
SURFACE OF SIDE
DECORATION TO
TOP SURFACE OF
FRAME ASSEMBLY
FRONT INNER EDGE
OF SIDE DECORATION
FRONT SIDE EDGE OF FRAME ASSEMBLY

Guide d’installation Viking
Kit de garniture à encastrer pour
four à micro-ondes D3

F10
Table des matières
IMPORTANT–Prière de lire et d’observer!
Avertissements et Information importante ————————————————————— 10
Spécifications ————————————————————————————————— 11
Information générale
Pièces comprises dans le kit ——————————————————————— 12
Découpe de l’armoire ou du mur ————————————————————— 12
Emplacement de la prise électrique ———————————————————— 12
Installation —————————————————————————————————— 13
Gabarit de fixation———————————————————————————— 13
Pose du conduit inférieur ————————————————————————— 14
Brides de fixation ———————————————————————————— 14
Installation dansl’armoire ————————————————————————— 15
Cadre de porte ————————————————————————————— 15
Décorations latérales (pour fixation en surface uniquement)—————————— 16
Installation au dessus d’un four —————————————————————— 16
Liste de contrôle du rendement ————————————————————————— 16
• Prière de lire attentivement toutes ces
directives avant de commencer.
• Veiller à DÉBRANCHER LA FICHE du four
à micro-ondes de la prise électrique avant
d’installer la garniture à encastrer. Retirer la
table tournante de la cavité du four.
• Le kit comprend des parties métalliques, il
faut faire attention lors de la manipulation
et de l’installation pour éviter éventuelles
blessures.
• Ne pas retirer de façon permanente les
étiquettes, les mises en garde ou les plaques
fixées au produit. Cela pourrait annuler la
garantie.
• Veuillez observertousles codes etrèglements
locaux et nationaux.
• L’installateur devra laisser ces directives au
client qui devra les conserver pour l’usage
d’un inspecteur local et pour référence
ultérieure.
AVERTISSEMENT
Ce kit à encastrer est conçu pour être utilisé
uniquement avec les fours à micro-ondes
viking spécifiant kit à encastrer RDMTK302 sur
l’étiquette des spécifications nominales sur la
paroi gauche de la cavité du four.

F
11
Specifications
Four à micro-ondes Kit degarniture à
encastrer
RDMOS201 RDMTK302
Largeur hors tout 24 po (609 mm) 29-1/2 po (749 mm)
Hauteur hors tout depuis le bas 13-3/8 po (339 mm) 17-1/4 po (437 mm)
Profondeur hors tout depuis l’arrière 19-1/8 po (487 mm) S/O
Intérieur du four Largeur
Hauteur
Profondeur
Hors tout
17-3/8 po
10-1/2 po
18-5/8 po
2 pi3
(441 mm)
(266 mm)
(473 mm)
(0,04 m3)
S/O
Alimentation électrique 120VAC/60 Hz S/O
Max. Ampèrage max. 1,5 KW 13 amps S/O
Poids approx. à l’expédition. 46 lb. (20,9 kg) 15 lb. (6,9 kg)
En conformité avec les normes établies par :
FCC – Autorisé par la Federal Communications Commission.
DHHS – Conforme au règlement du Department of Health and Human Services (DHHS), CFR, Titre
21, Chapitre I, Souschapitre J.
– Ce symbole sur l’étiquette des spécifications nominales signifie que le produit est sur la liste
des Underwriters Laboratories, Inc. pour une utilisation aux É.-U. ou au Canada.

F12
Information générale
14-1/4" (361.95 mm)
Minimum Cutout OpeningWidth 27-3/4" (704.9 mm)
Minimum Cutout Opening Height 16-9/16" (420.7 mm)
Maximum Cutout Opening Height 16-13/16" (427 mm)
Maximum Cutout OpeningWidth 28" (711.2 mm)
Distance between holes A9.1" (231.2 mm)
14" (355.6 mm)
Center Line
Floor Line of Cutout Opening
BUILT-IN TRIM KIT
SURFACE MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVEOVEN
TINSLB008MRR0
1/4"
(6.2mm)
1/4"
(6.2mm)
1. Align the Surface Mounting Template center line with the
centerof the cabinet. Align the Floor Line with the bottom
ofthe cabinet at the desired height. Tape it into place.
2. Predrill 4 holes marked Awith a ¹₁₆" drill bit.
3. Cut the cabinet opening between the minimum and
maximumcutout opening lines. Be careful to cut precisely
alongthe Floor Line of the cutout.
4. Remove template from the cabinet.
3-15/16" (100 mm)
7
4-3/16" (106.4 mm)
FLOOR LINE OF CUTOUT OPENING
BUILT-IN TRIM KIT
FLUSH MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVE OVEN
CABINET CUTOUT LINE
CABINET CUTOUT LINE
CENTER LINE
TINSLB009MRR0
1. Align the Flush Mounting Template center line with the center of the
cabinet. Align the Floor Line with the bottom of the cabinet at the
desiredheight. Tape it in place.
2. Cut the cabinet opening along the three Cabinet Cutout Lines and
theFloor Line.
3. Install two Side Spacers (see FIGURE 1) and one Bottom Spacer (see
FIGURE2) as specified in FIGURE 3. Be sure to offset all three spacers
by1⁹₁₆" from the front surface of the cabinet.
4. Cut out the Side Spacer Templates (R and L) and align the indicated
edge to the corresponding Side Spacer (see FIGURE 3). Be careful to
alignthe Floor Line to the bottom edges of the Side Spacers.
5. Predrill two holes indicated “A“ in Side Spacer - Rwith a ¹₁₆" drill bit.
6. Predrill two holes indicated ”B“ in Side Spacer - Lwith a ¹₁₆" drill bit.
7. Remove template from the cabinet.
SIDE SPACER TEMPLATE - L
SIDE SPACER TEMPLATE - R
FIGURE 1
SideSpacer (2 required)
Mustprotrude from edge of cabinet
cutouttowards center as shown.
AlignSide Spacer-L to this line
AlignSide Spacer-R to this line
CutoutOpening Height 17-5/16" (439.8 mm)
CABINET CUTOUT LINE
Edgesto align Side Spacer Templates (R and L)
BottomSpacer centered with cabinet cutout
1-9/16"(39.7mm)
Bottomand Side
Spacer(R and L) Offset
FIGURE 3
SideSpacer - L SideSpacer - R
14" (355.9 mm)
Distancebetween holes A9.1" (231.2 mm)
Cutout Opening Width 29-5/8" (752.5 mm)
14-13/16" (376.2 mm)
13/16"Min.
15/16Max.
13-1/2"min. height
FIGURE 2
BottomSpacer (1 required) ¹₄" plywood
24"min. width
27-7/8"max. width
1/4"(6.35 mm)1/4"(6.35 mm)
8
2
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
3
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
6
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
1
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
4
5
Pièces comprises dans le kit
Numéro Nom de pièce Qté
1Cadre de porte 1
2Conduit inférieur 1
3Bride de fixation 2
4Vis A : longueur 1-3/16 po (30,2 mm) 2
5Vis B : longueur 1 3/4 po (44,5 mm) 4
6Décorations latérales (pour fixation
en surface uniquement) 2
7Gabarit de fixation en surface 1
8Gabarit de fixation encastrée 1
Emplacement de la prise
électrique
MISE EN GARDE
La prise NE doit PAS se trouver dans l’aire
ombrée comme indiqué à l’Illustration 1.
1
figure
4 po (102 mm)
4 po (102 mm)
6 po (15,2 mm)
NOTES :
• Silaprofondeur(C)dépasse53,3cm(21po),
l’emplacement de la prise peut être situé
n’importeoùsurlemurarrière.
• Le plancher de l’ouverture doit être en
contreplaquéassezfortpoursupporterlepoids
dufouretsaproprecharge(environ45,5kg
[100lb]).Ildoitêtreà unniveauconvenable
pourl’utilisationdufour.Veilleràvérierle
codelocaldubâtiment,carilpourraitexiger
que l’ouverture soit fermée par une cloison
latérale,arrièreetunplafond.Lefourn’apas
besoind’êtreenclospourfonctionner.
Découpe de l’armoire ou
du mur
Dimensions de la
découpe
Fixation
encastrée
Fixation en
surface
Hauteur AMinimum 17-5/16 po
(439,8 mm)
16-9/16 po
(420,7 mm)
Maximum N/A 16-13/16po
(427 mm)
Largeur BMinimum 29-5/8 po
(752,5 mm)
27-3/4 po
(704,9 mm)
Maximum N/A 28 po
(711,2 mm)
Profondeur CMinimum 20po
(503mm)
20po
(503mm)

F
13
Installation
13/16" min.
15/16" max.
13-1/2" min.
24" min. width
27-7/8" max. width
1-9/16" (39.7 mm)
BOTTOM and SIDE
SPACER (R and L) offset
EDGES TO ALIGN SIDE SPACER
TEMPLATES (R and L)
Side Spacer (L) Side Spacer (R)
BOTTOM SPACER
CENTERED with
CABINET CUTOUT
3
figure
A
ENTRETOISE
LATÉRALE—2. Doit
dépasser du bord de la
découpe de l’armoire
vers le centre comme
illustré.
B
ENTRETOISE INFÉRIEURE—1.
Contreplaqué 1/4 po (6,35 mm)
C
Pour la fixation encastrée, il faut deux (2) entretoises
latérales et une (1) entretoise inférieure. Les entretoises
ne sont pas fournies dans le kit et doivent être fabriquées
par l’installateur. Voir figures 3Aet Bpour les exigences
d'entretoise. Veiller à ce que les trois entretoises dépassent
de 1-9/16 po (39,7 mm) à l'avant de l'armoire.
Découper les gabarits d’entretoise latérale (D et
G) du gabarit de montage encastré. Aligner les
bords indiqués aux entretoises droite et gauche
correspondantes comme l’illustre la figure 3.
Veiller à aligner les bords inférieurs des gabarits
d'entretoise latérale avec le plancher de l'ouverture
de l'armoire. Percer deux (2) trous marqués « A »
sur un gabarit D d'entretoise latérale et deux (2)
trous marqués « B » sur un gabarit G d'entretoise
latérale avec un foret de 1/16 po (1,6 mm).
Enlever les gabarits de l'armoire.
13-1/2 po
(342,9 mm)
min
13/16 po (20,6 mm) min
15/16 po (23,8 mm) max
Largeur min 24 po
(609 mm)
Largeur max 27-7/8 po
(708 mm)
1-9/16 po (39,7 mm)
Déport d’entretoises
Inférieure et Latérales
(D et G)
Entretoise inférieure
Centrée avec la
Découpe de l’armoire
BORDS POUR ALIGNER LES GABARITS
D’ENTRETOISE LATÉRALE (D et G)
Entretoise
Latérale (G)
Entretoise
Latérale (D)
Installation
Gabarit de fixation
Déterminer la méthode de fixation selon la
configuration requise. Voir la figure 2A pour la
fixation ENCASTRÉE et 2B pour la fixation en
SURFACE.
Aligner le gabarit correspondant à la méthode de
fixation requise avec le centre de l'armoire. Veiller
à ce que le gabarit soit horizontal. Coller en place
avec du ruban adhésif. Découper l'ouverture de
l'armoire selon les lignes indiquées sur le gabarit.
Laisser le gabarit en place.
Pour la fixation en surface, percer 4 trous marqués « A »
avec un foret de 1/16 po (1,6 mm). Enlever le gabarit de
l’armoire Aller au conduit inférieur.
2
figure
A
CONFIGURATION POUR FIXATION
ENCASTRÉE—Le four à microondes et le
verre du cadre de porte sont encastrés dans
l’armoire.
B
SURFACE MOUNT CONFIGURATION
—Le four à microondes et le verre du cadre de
porte font saillie de la surface de l’armoire.
b. Surface Mount Configuration -
Microwave Oven and Frame Assembly
protrude from the surface of the cabinet.
Illustration 2
a. Flush Mount Configuration -
Microwave Oven and Frame Assembly
glass are flush with the cabinet
Les surfaces indiquées affleurent.

F14
Installation
Conduit inférieur
4
figure
CENTER THE
BOTTOM DUCT
Illustration 6 - for Flush Mount
VIS A CONDUIT
INFÉRIEUR
FAIRE AFFLEURER LA
BRIDE INFÉRIEURE AVEC
L'ENTRETOISE INFÉRIEURE
Placer le conduit inférieur dans l’ouverture de l’armoire.
Pour le montage encastré, il reposera sur l’entretoise
inférieure centrée dans l’armoire. Voir figure 4.
5
figure
Illustration 7 - for Surface Mount
CENTER THE
BOTTOM DUCT
VIS A
CONDUIT
INFÉRIEUR
FAIRE AFFLEURER LA BRIDE
INFÉRIEURE AVEC L’ARMOIRE
Pour la fixation en surface,le conduit inférieur reposera sur
le plancher de l’ouverture. Voir figure 5.
Aligner le conduit inférieur au centre de l’ouverture
avec la bride inférieure affleurant l’entretoise
inférieure (pour la FIXATION ENCASTRÉE) ou
l’armoire (pour la FIXATION EN SURFACE).
Fixer le conduit inférieur avec deux VIS A
(2-3/16 po [ 55,6 mm]). Voir figures 4et 5
respectivement.
Brides de fixation
Placer les brides de fixation pour les aligner avec
les trous percés à l’aide du gabarit.
VIS B
VIS B
A
B
BRIDE FIXÉE ENCASTRÉE
figure
figure
6
BRIDE FIXÉE EN SURFACE
Les extrémités encastrées des brides de fixation doivent
faire face à l’intérieur. Vérifier qu’elles sont verticales et les
fixer à demi avec quatre (4) VIS B. Voir Figure 6.
figure
figure
7
27-1/2 po
(698,5 mm)
EQ. EQ.
CENTRER LE
CONDUIT
INFÉRIEUR
CENTRER LE
CONDUIT IN-
FÉRIEUR

F
15
Installation
Aligner les brides de fixation horizontalement en
les faisant glisser vers l'avant et l'arrière le long
des fentes de vis jusqu'à ce que les brides soient
exactement séparées de 27-1/2 po (698,5 mm)
et à égale distance des côtés de l'armoire. Voir
figure 7.
Une fois les brides correctement placées, bien les
fixer avec quatre (4) vis B.
Installation dans l'armoire
Placer le four près de l'ouverture du mur ou de
l'armoire. Brancher le cordon d'alimentation dans
la prise électrique.
CABINET INSTALL FRAME INSTALL CABINET INSTALL
figure
figure
8
Guider avec précaution le four assemblé dans l'ouverture
préparée. Faire glisser le four sur le conduit inférieur. Voir
figure 8.
figure
figure
9
CABINET INSTALL FRAME INSTALL CABINET INSTALL
CONDUIT
INFÉRIEUR
PATTE
ÉVIDEMENT DANS
LE CONDUIT
Éviter de pincer le cordon entre le four et le mur. Ajuster la
position du four de façon à ce que ses pattes entrent dans
les évidements du conduit d'évacuation. Voir Figure 9 .
Cadre de porte
Retourner le CADRE DE PORTE pour repérer les
quatre pivots à rotule.
Placer le cadre de porte avec les petites décorations
en acier inox sur le dessus. Aligner les quatre
pivots à rotule avec les fixations à pression aux
deux extrémités des BRIDES DE FIXATION.
Bien fixer le cadre de porte en le poussant
fermement sur les brides de fixation en engageant
les quatre (4) fixations à pression. Voir Figure !.
figure
figure
!
EMPLACEMENT DES FIXATIONS À PRESSION
SUR LES BRIDES DE FIXATION
PETITES DÉCORATIONS EN ACIER INOX SUR LE DESSUS
QUATRE PIVOT À ROTULE À L’ARRIÈRE DU CADRE DE PORTE

F
Installation
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
[phone]
Pour plus d'information sur le produit,
Composer le 1-888-VIKING1 (845-4641)
ou consulter le site Web Viking à
vikingrange.com
Installation au dessus d'un
four
figure
figure
#
5,1 CM (2 po) POUR UN FOUR INFÉRIEUR DE
91,4 CM (30 po) DE LARGE
Liste de contrôle
1. Veiller à ce que l'appareil soit installé selon
les instructions et avec le bon gabarit de
fixation.
2. Brancher le cordon d'alimentation.
3. Conserver le mode d'emploi et d'entretien et
le manuel d'installation
Décorations latérales
(pour fixation en surface uniquement)
Retirer le papier dorsal du ruban au verso des
DÉCORATIONS LATÉRALES. Aligner le bord
intérieur avant des décorations latérales avec le
bord intérieur avant du CADRE DE PORTE.
Aligner la surface supérieure de la décoration
latérale avec la surface supérieure du CADRE DE
PORTE. Fixer les décorations latérales en pressant
fermement contre le côté du CADRE DE PORTE.
Voir Figure ".
"
figure
ALIGNER LA SUR-
FACE SUPÉRIEURE
DE LA DÉCORA-
TION LATÉRALE
AVEC LA SURFACE
SUPÉRIEURE DU
CADRE DE PORTE
BORD INTÉRIEUR
AVANT DE LA DÉC-
ORATION LATÉRALE
BORD INTÉRIEUR AVANT DU CADRE DE PORTE

Guía de instalación Viking
Juego de molduras para empotrado del
Microondas D3

S18
Tabla de Contenido
IMPORTANTE– ¡Lea y siga con atención!
Advertencias e información importante —————————————————————— 18
Especificaciones ———————————————————————————————— 19
Información general——————————————————————————————— 20
Partes incluidas en el juego ———————————————————————— 20
Abertura del gabinete o pared —————————————————————— 20
Ubicación del tomacorriente eléctrico ——————————————————— 20
Instalación ——————————————————————————————————— 21
Plantilla de montaje ——————————————————————————— 21
Conjunto de ducto inferior ———————————————————————— 21
Ensamblaje del soporte de montaje ———————————————————— 22
Instalación en gabinete—————————————————————————— 23
Instalación del marco —————————————————————————— 23
Instalación de la decoración lateral ———————————————————— 24
Instalación de la decoración lateral ———————————————————— 24
Lista de control de ejecución ——————————————————————————— 24
• Antes de comenzar, lea estas instrucciones
completa y detalladamente.
• Asegúrese de DESCONECTAR el horno
microondas del tomacorriente eléctrico
antes de instalar el juego de moldura para
empotrado. Retire el plato giratorio de la
cavidad del horno.
• El juego incluye partes de metal por lo que
debe manipularlo e instalarlo con precaución
para evitar el riesgo de lesiones.
• No retire las etiquetas, advertencias o placas
permanentes del producto. Estopuede anular
la garantía.
• Cumpla todos los códigos y normas locales
y nacionales.
• Elinstaladordebedevolverestasinstrucciones
alclientequiendebe conservarlas parausodel
inspector local y para referencias futuras.
ADVERTENCIA
Este juego de molduras para empotrado
está diseñado para uso exclusivo con hornos
microondas que especifique el juego de
molduras para empotrado RDMTK302 en la
etiqueta de potencia en la cavidad del horno.

S
19
Especificaciones
Horno microondas Juego de molduras
para empotrado
RDMOS201 RDMTK302
Ancho total 24" (60.9 cm) 29-1/2" (74.9 cm)
Altura total desde la parte
inferior
13-3/8" (33.9 cm) 17-1/4" (43.7 cm)
Profundidad total desde la
parte posterior
19-1/8" (48.7 cm) NA
Parte interna del horno Ancho
Altura
Profundidad
Ancho total
17-3/8"
10-1/2"
18-5/8"
2.0 pies
cúbicos
(44.1 cm)
(26.6 cm)
(47. 3 c m)
NA
Requisitos eléctricos 120VCA/60 Hz NA
Cap. máx. en amperios 1.5 KW 13 amps NA
Peso de despacho aprox. 46 lbs. (20.9 kg) 15 lbs. (6.9 kg)
Cumple con las normas establecidas por:
FCC – Autorizada por la Comisión Federal de Comunicaciones.
DHHS – Cumple con la norma del Departamento de Salud y Servicios Humanos (DHHS), CFR,
Título 21, capítulo I, subcapítulo J.
– Este símbolo en la etiqueta de potencia indica que el producto está aprobado por
Underwriters Laboratories, Inc. para uso en los EE.UU. o Canadá.

S20
Información general
14-1/4" (361.95 mm)
Minimum Cutout OpeningWidth 27-3/4" (704.9 mm)
Minimum Cutout Opening Height 16-9/16" (420.7 mm)
Maximum Cutout Opening Height 16-13/16" (427 mm)
Maximum Cutout OpeningWidth 28" (711.2 mm)
Distance between holes A9.1" (231.2 mm)
14" (355.6 mm)
Center Line
Floor Line of Cutout Opening
BUILT-IN TRIM KIT
SURFACE MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVEOVEN
TINSLB008MRR0
1/4"
(6.2mm)
1/4"
(6.2mm)
1. Align the Surface Mounting Template center line with the
centerof the cabinet. Align the Floor Line with the bottom
ofthe cabinet at the desired height. Tape it into place.
2. Predrill 4 holes marked Awith a ¹₁₆" drill bit.
3. Cut the cabinet opening between the minimum and
maximumcutout opening lines. Be careful to cut precisely
alongthe Floor Line of the cutout.
4. Remove template from the cabinet.
3-15/16" (100 mm)
7
4-3/16" (106.4 mm)
FLOOR LINE OF CUTOUT OPENING
BUILT-IN TRIM KIT
FLUSH MOUNTING TEMPLATE
FOR DESIGNER SERIES MICROWAVE OVEN
CABINET CUTOUT LINE
CABINET CUTOUT LINE
CENTER LINE
TINSLB009MRR0
1. Align the Flush Mounting Template center line with the center of the
cabinet. Align the Floor Line with the bottom of the cabinet at the
desiredheight. Tape it in place.
2. Cut the cabinet opening along the three Cabinet Cutout Lines and
theFloor Line.
3. Install two Side Spacers (see FIGURE 1) and one Bottom Spacer (see
FIGURE2) as specified in FIGURE 3. Be sure to offset all three spacers
by1⁹₁₆" from the front surface of the cabinet.
4. Cut out the Side Spacer Templates (R and L) and align the indicated
edge to the corresponding Side Spacer (see FIGURE 3). Be careful to
alignthe Floor Line to the bottom edges of the Side Spacers.
5. Predrill two holes indicated “A“ in Side Spacer - Rwith a ¹₁₆" drill bit.
6. Predrill two holes indicated ”B“ in Side Spacer - Lwith a ¹₁₆" drill bit.
7. Remove template from the cabinet.
SIDE SPACER TEMPLATE - L
SIDE SPACER TEMPLATE - R
FIGURE 1
SideSpacer (2 required)
Mustprotrude from edge of cabinet
cutouttowards center as shown.
AlignSide Spacer-L to this line
AlignSide Spacer-R to this line
CutoutOpening Height 17-5/16" (439.8 mm)
CABINET CUTOUT LINE
Edgesto align Side Spacer Templates (R and L)
BottomSpacer centered with cabinet cutout
1-9/16"(39.7mm)
Bottomand Side
Spacer(R and L) Offset
FIGURE 3
SideSpacer - L SideSpacer - R
14" (355.9 mm)
Distancebetween holes A9.1" (231.2 mm)
Cutout Opening Width 29-5/8" (752.5 mm)
14-13/16" (376.2 mm)
13/16"Min.
15/16Max.
13-1/2"min. height
FIGURE 2
BottomSpacer (1 required) ¹₄" plywood
24"min. width
27-7/8"max. width
1/4"(6.35 mm)1/4"(6.35 mm)
8
2
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
3
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
6
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
1
1) Frame Assembly: QTY 1 2) Bottom Duct Assembly: QTY 1
3) Mouting Bracket: QTY 2 4) SIDE DECORATION: QTY 2
(SURFACE MOUNTING ONLY)
4
5
Partes incluidas en el juego
Artículo Nombre de la parte CANT.
1Conjunto del marco 1
2Conjunto del ducto inferior 1
3Soporte de montaje 2
4Tornillo A :1-3/16” de largo 2
5Tornillo B: 1-3/4” de largo 4
6Decoración lateral (Sólo superficie
de montaje) 2
7Plantilla para montaje en superficie 1
8Plantilla para montaje al ras 1
Ubicación del
tomacorriente eléctrico
PRECAUCIÓN
El tomacorriente NO debe estar en el área
sombreada como se indica en la figura 1.
1
figura
4"(10.2 cm)
4"(10.2 cm)
6"(15.2 cm)
NOTAS:
• Siladimensióndeprofundidad(C)esmayora21”
(53.3cm),la ubicación del tomacorriente puede
estarencualquieráreadelaparedposterior.
• El piso de la abertura debe estar construido de
maderalaminadalosucientementeresistentepara
soportarelpesodelhornoylacapacidaddecarga
(aproximadamente 100libras).El pisodebeestar
nivelado para una correcta operación del horno.
Asegúrese devericarelcódigo deconstrucción
local ya que puede requerir cercar la abertura
con tabiques laterales, superior y posterior. El
funcionamiento apropiado del horno norequiere
delcercado.
Abertura del gabinete o pared
Dimensiones de
recorte
Brindas
Montaje
Superficie
Montaje
Altura AMínimo 17-5/16"
(439.8mm)
16-9/16"
(420.7mm)
Máximo N/A 16-13/16"
(427mm)
Ancho BMínimo 29-5/8"
(752.5mm)
27-3/4"
(704.9mm)
Máximo N/A 28"
(711.2mm)
Profundidad CMínimo 20"
(503mm)
20"
(503mm)
