Viking VMOC206SS User manual

R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
Both ovens include
• Capacity—1.5 cu. ft. interior cavity
o 16-1/ ”W. x 9-5/ ”H. x 16-1/ ”D.
o 15-3/ ” diameter turntable
• Commercial-type styling and design
• Instant sensor settings for cooking,
reheating, and popping popcorn
• Four convection settings use high-
speed fan that circulates air past the
heat source and around the food;
allows multiple-rack baking
o ConvecBroil
o ConvecRoast
o ConvecBake
o Manual convection
• Low Mix Bake and High Mix Roast
settings offer use of convection heat
to seal and brown outside of foods
while using microwave energy to
ensure the interior is cooked
• Add-A-Minute allows you to add a
minute of extra cooking time with the
touch of one button
• Child Lock safety feature locks the
control panel to prevent unwanted
operation
• Cookbook included
• Interior light
• Suitable for placement on counter-
top, or installed as a built-in using a
trim kit. (Trim kits sold separately—
see Installation Notes &
Accessories for part numbers.)
FINISH DETAILS FOR PROFESSIONAL MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP),
Biscuit (BT), Cotton White (CW), Oyster
Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue (IB),
Viking Blue (VB), Pumpkin (PM), Racing
Red (RR), Apple Red (AR), Burgundy
(BU), Plum (PL), Chocolate (CH), and
Cobalt Blue (CB).
Standard Features & Accessories
Model Options
COOKING
Professional Custom Convection Microwave Oven
*Shown with tri kit. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First specify model number, and then color code (VMOC206SS).
VMOC206
Professional Custo
Convection Microwave Oven
VMOC206*
w/Tri Kit

PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Professional Custom Convection Microwave Oven
✪
Please see
Installation Notes
and Accessories for
important information,
including trim kits.
All models
Overall width 2 -5/8” (62.5 cm)
Overall height from bottom) 1 -7/8” (37.7 cm)
Overall depth from rear) 19” ( 8.3 cm)
Interior each oven)
Width 16-1/8” ( 0.9 cm)
Height 9-5/8” (2 . cm)
Depth 16-1/8” ( 0.9 cm)
Approx. ship weight 60 lbs. (27.2 kg)
Dimensions & Specifications
PRODUCT DIMENSIONS
19”
(48.3cm)
24-5/8”
(62.5cm)
14-7/8 ”
(37.7cm)
VMOC206
Professional Custo
Convection Microwave Oven
VMOC206
w/Tri Kit
PROFESSIONAL
CUSTOM

PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
18-11/16”
(47.5cm)min.
18-11/16”
(47.5cm)min.
11-1/2”
(29.2cm)
11-1/2”
(29.2cm)
25”
(63.5cm)min.
20-1/8”
(51.1cm)min.
5”
(12.7cm)
5”
(12.7 cm)
5”
(12.7cm)
Outlet
location
area
All Models
Cutout width 25” (63.5 cm) min.
Cutout height 18-11/16” ( 7.5 cm) min.
Cutout depth 20-1/8” (51.1 cm) min.
COOKING
Professional Custom Convection Microwave Oven
UTILITY
REQUIREMENTS
GAS
•Not applicable
ELECTRICAL
• 3.5-foot power cord
included
• 120 VAC/60 Hz
• Maximum amp
usage—
13 (1.55 kW)
PLUMBING
Not applicable
Installation Requirements
ACCESS REQUIREMENTS
VMOC206
Professional Custo
Convection Microwave Oven
VMOC206
w/Tri Kit

COOKING
Professional Custom Convection Microwave Oven
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Built-In Trim Kits
• Stainless Steel (SS)
• Designed to match with corresponding ovens and warming drawers
•Trim gives finished look to ovens installed as built-in units
• Kit includes frame assemblies, exhaust duct assembly, and metal fasteners
Compliance Information
WARRANTY INFORMATION*
• Three-year full warranty—complete product (Professional Series)
• One-year full warranty—complete product (Designer Series)
• Five-year limited warranty—magnetron tube (Professional and Designer)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg))
VMTK277 26-1/2”W./19-13/16”H. Professional microwave trim 14 6.5)
VMTK307 29-1/2”W./19-13/16”H. Professional microwave trim 15 6.9)
VMTK367 35-1/4”W./19-13/16”H. Professional microwave trim 16 7.2)
