Viliv S7 User manual

S7
This guide may be changed for product improvement without prior notice.
User’s Manual
Mobile Internet Device

Thanks for purchasing viliv.
Please read the precautions
throughly before using the product.

Copyright
Yukyung Technologies Corp. has the copyright for this guide.
Contents of this manual may not be copied or produced in any form or means without prior
authorization from Yukyung Technologies Corp.
©2009 Yukyung Technologies Corp. All rights reserved.
Certication
This device has acquired EMC certication for home use (Class B)
and is designed not only for use in residential area but anywhere.
Registered Trademark
viliv is the registered trademark of Yukyung Technologies Corp.
Windows 2000, Windows XP and Windows CE are the registered trademarks of Microsoft
Corporation.
Liability Disclaimer
Infringement of Intellectual Property Rights: Playing, copying or distributing any part or all of
any copyrighted contents such as software, music or video with this device may infringe on a third
party’s legitimate intellectual property rights or violate copyright law. All legal responsibilities for
the infringement of copyright or intellectual property rights from the use of this device lie with the
user.
Improper Use: The manufacturer of this device is not liable for any damage or improper use and
operation by using this device and infringement of copyright and portrait right by user when taking
photos In addition, the manufacturer is not liable for bodily injury or property damage that may
occur arising from inappropriate use other than operation standards or conditions.
Data Loss: Any audio, video or photo les stored in this device may be deleted due to
damage or operational error caused by user’s careless handling or unknown failure or when the
device undergoes warranty repair. Therefore, the les must be backed up in a separate place.
In these cases, the manufacturer is not liable for the loss or damage of data stored in the device.
Specication Change: The standards, accessories, embedded software and manual contents of
this device may be changed without user's prior consent or prior notice to the user.
Grade B Device
(Broadcast Communication Device for Residential Area)

Contents
Safety Precautions for Use................................................. 4
Names of Parts................................................................... 7
Basic Components ..........................................................................7
Front View .......................................................................................8
Keyboard .........................................................................................9
Left/Right View ..............................................................................10
Rear View ..................................................................................... 11
Installation and Cable Connection.................................... 12
Connecting Earphone and Microphone.........................................12
Power Connection (Charging Adaptor)..........................................12
USB Data Link Connection............................................................13
USB Connection............................................................................13
Rotating LCD Screen ....................................................................14
Separating · Attaching Battery.......................................... 15
Separating Battery.........................................................................15
Attaching Battery ...........................................................................15
Basic Operation................................................................ 16
Turning the Power On/Off..............................................................16
Setting/Cancelling Hold Function ..................................................16
Using MENU Function .................................................................17
Using PIVOT Function ..................................................................17
Touch Screen ................................................................................17
Set Up for villv Manager ..............................................................18
Using for the First Time .................................................... 19
Using for the First Time .................................................................19
Recovery Solution (AMI Rescue) Guide........................... 21
Way to Use Recovery Solution (AMI Rescue)...............................21
Specications ................................................................... 22
General Specifications ..................................................................22

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
4English
MID
Safety Precautions for Use
The precautions below are provided to prevent bodily injury or property damage by using this product
correctly. Please observe the precautions.
Do not touch the power adapter with wet hands. ■
Plug the power cord into an outlet with grounded jack.■
Be sure the plug goes in all the way and is not loose. ■
Do not use your device if it is damaged, including an exposed or peeled power cord.■
If lightning occurs nearby or if you are absent for a long time, unplug the plug from the■
outlet.
Do not apply strong impacts or make a hole with a sharp object. ■
Do not leave the battery in a hot place such as sauna or bathroom or otherwise heat it. ■
Do not let the battery become wet or immersed in liquid. ■
Do not allow children or pets to bite or suck the battery. ■
Keep the battery charging port away from metals.■
When disposing of the battery, do not burn it or throw it away in domestic trash.■
Dispose of the battery at the nearest disposal place for batteries after contacting your
local water disposal agency.
Precautions on Battery
Avoid exposing to direct sunlight and do not leave in a closed car. ■
Do not leave the device in a dusty place or a humid place such as a bathroom. ■
Keep the device away from credit cards, bankbooks, or a communication ticket.■
Do not use accessories that are not provided with this device. ■
Do not touch the LCD screen with a sharp object. ■
Precautions for the Device
Do not listen to music at a high volume for a long time. ■
Do not watch the video for too long a time. ■
Do not use headphones/earphones while driving, walking or using public transport. ■
Do not apply strong impacts on the LCD. ■
If the device begins to smoke or become deformed by heating, stop using it immediately■
and contact your nearest Customer Service.
Do not use the device in a hospital, on board a plane or while driving.■
Do not directly put and use the device frame or the power adapter on your bare skin for ■
a long time. The temperature of the station may rise even during normal operation.
If you continue to use the device on your bare skin (in particular, when the adapter is
connected), you may feel uncomfortable or receive a burn.
Precautions in Use
If the device is wet, do NOT turn on the power. Separate the battery and wipe it with a ■
soft dry cloth. After that, contact Customer Service.
When cleaning the device, wipe it with a soft dry cloth and do NOT use chemicals, such ■
as benzene or thinner.
Do not repair, disassemble or alter in any manner. ■
Do not allow any liquid or foreign materials to get inside the device. ■
Do not drop the device. ■
Other Precautions
Precautions on Power

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
5English
MID
Safety Precautions for Use
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ tv technician for help.
Information to User
In August 1996 the Federal Communications Commission(FCC) of the United States with its action in Report and
order 96-326 adopted an updated safety standard for human exposure the ra-dio frequency electromagnetic energy
emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by
both U.S. and international standards bodies. The design of ‘S7’ complies with the FCC guidelines and those
international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modications, or
attachments could impair call quality, damage your ‘S7’, or result in violation of FCC regulations.
‘S7’ was tested for typical body-wom operation using the optional belt-clip / holster placed touch(0cm) from the
body. The use of non-tested accessories or other body-wom operations may not comply with FCC exposure
requirements and should be avoided.
FCC RF Exposure Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
FCC Compliance Information
Modications not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
Caution
If the battery can be seen to be swollen, there may be■
imminent danger. Immediately contact the manufac-
turer or sales representative.
Only use an eligible specied charger.■
Keep the device away from open ames. (Do not put ■
it in a microwave.)
Do not leave the device in a car in summer.■
Do not store or use the device in a hot and wet place ■
like a bathroom.
Do not put the device on bedclothes, electric mattress ■
or carpet and use it for a long time.
Do not store the device powered on in a closed ■
space.
Do not allow metal products, such as a necklace, coil, ■
key or watch, to touch the battery port.
Use a lithium secondary battery guaranteed by a■
portable device manufacturer.
Do not disassemble or pierce the device and do not ■
apply excessive strength.
Do not apply excessive impact like dropping the ■
device from a high place.
Do not expose the device to high temperatures of ■
60°C or higher.
Avoid humidity.■
Warning Please observe the instructions below. Failure to do may cause heating, re, explosion, etc.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
6English
MID
Safety Precautions for Use
The device functions vary depending on model.
Read the relevant precautions for the provided function before using the device.
Precautions for GPS
When initially operating this device, it is recommended you warm it up for over 15■
minutes under a clear open sky and open area.
If the vehicle equipped with this device is not used for 7 days or longer, the data storage■
recharger inside the GPS may be discharged and require warming up time of over 15
minutes.
GPS signals are high frequencies around 1575 MHz so they may be affected by bad ■
weather, such as rain and fog, and electromagnetic interference and the reception rate
of the GPS may deteriorate.
When the GPS receiver is under an elevated road, inside a tunnel, in a densely built-up ■
area or near a high-voltage line, it is difficult to receive radio waves so GPS reception
may fail.
The GPS receiver may not work normally in some vehicles with UV coating, sun-block ■
coating or electromagnetic interference.
The operational temperature of the GPS receiver is between 0°C and 50°C. Problems ■
may occur in midsummer or severe winter so maintain an appropriate temperature.
On some roads running parallel to a driveway or an elevated road, the information on ■
speed limits or dangerous sections for speeding may not be accurate.
Precautions for the Bluetooth
Do not attempt to operate the Bluetooth while driving. Accidents caused by such ■
improper handling are the sole responsibility of driver.
To prevent electromagnetic problems or other dangers, turn off the Bluetooth setting ■
wherever the use of Bluetooth is inhibited.
If you use a certain medical device, such as a pacemaker or a hearing aid, ask the■
manufacturer of the relevant device if it is correctly cut off from energy sources before
using it. If necessary, you may ask for some assistance from your regular doctor.
This device satises Bluetooth standards 2.0. Some Bluetooth devices may not be fully ■
compatible with this device. For detailed information on compatibility, contact the
manufacturer of the relevant device or our Customer Service.
This wireless equipment may experience electromagnetic interference, so it is not ■
permitted for use by a life-saving service.
Precautions for Navigation
Placing the device where it blocks the driver’s view or is within the driver’s operation■
range for driving may cause an accident. Adjust the volume to an appropriate level so
that it does not disturb while driving.
Fix the device rack onto the windshield securely so that it will not fall or move while ■
driving.
If the rack is attached onto the windshield for a long time, its adhesion may become■
weak and it may fall. Therefore, if you are not going to use the device for a long time,
separate it and keep in a safe place.
Do not disassemble and attach it inside a vehicle in any manner. To do so may affect the ■
electrical system and GPS reception sensitivity and lead to a re.
Do not separate the cigar jack from the vehicle while using the device. To do so may ■
cause a malfunction.
Set the device up where it does not block the driver’s view or is not in the way of the■
airbag’s operation.
WiFi and 3G Modem (or HSDPA, HSUPA) do not operate simultaneously.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
7English
MID
Names of Parts
The appearance of the components below may differ from the actual components and some
components are subject to change.
Basic Components
Main Body
AC/DC Power Adapter
User’s Manual
Standard Removable Battery
USB Cable

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
8English
MID
Names of Parts
Front View
1WEBCAM Equipped with webcam.
2Built-in Speakers Equipped with stereo speakers.
3MENU Button Runs Windows START menu.
4PIVOT Button Rotates the Windows screen 90 degrees counterclockwise.
5TFT LCD/Touch Screen Users can operate the device using the touch screen.
6Operation Indicators Power/Battery Charging Indicator
Hard Disk Drive LED Turns on when the system accesses the hard disk drive.
Wireless LAN/Bluetooth LED Shows ON/OFF status of Wireless LAN/Bluetooth device.
7
Touchpad Touchpad has the same function as PC mouse. Users can move the pointer by
moving the nger on the pad.
Left Button Same function as left click with mouse.
Right Button Same function as right click with mouse.
8Keyboard Status Indicators Indicates the status of Num Lock, Caps Lock, and Scroll Lock.
9Internal Microphone Mono microphone is included.
1
2
3
2
5
4
6
9
7
8

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
9English
MID
Names of Parts
Keyboard
The keyboard may be different for each country.
1Function Keys (F1~F12) Usages are different depending on the operating system used and
application program.
2Fn Key This key is used together with function keys.
3Characters and Numbers There are keys for entering characters, a space key for entering
space, number keys from 0 to 9, and other special symbol keys.
4Cursor Moving Keys These are to move the cursor while using programs.
Edit keys PgUP/PgDn/Home/End Keys for moving pages while using programs.
5Esc Key It is usually used for terminating or interrupting programs.
6Caps Lock Key English characters will be in upper case when entered with Caps Lock light
on. Pressing this key one more time will turn off the light. This key has no
effect when entering Korean.
7Shift Key This key is used when entering the character shown on the upper part of each key,
upper or lower case of English characters, or hot keys.
8Windows Key It is a Start Menu button provided by Microsoft Windows, and pressing the
button will display Start Menu.
9
Enter Key Enter key is used to indicate to the computer that one command input is
completed, and it is also used for making a new line.
10 PrtSc Key (Print Screen) This key is used for printing the screen or temporarily saving the
screen.
1 105
2 8 3 4
6
7
9

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
10 English
MID
Names of Parts
Left/Right View
1
2
3
4
5
6
9
9
10
7
8
1D-SUB It is used to connect an external screen such as monitor or projector.
2Multi I/O Port It is used for connecting external video output (component, composite, s-video)
and expansion pack.
3Microphone Port For connecting a microphone.
4
Earphone Port For connecting earphone.
5Power Adapter Port For connecting power adapter or charging the battery.
63G Modem Built-in antenna. (Optional)
7SD Card Slot For using SD/SDHC card.
8USB Link Port For connecting to a computer.
9USB Port For connecting to external devices with USB port.
10 Power/Hold Switch For turning on, turning off, and locking the entire functions.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
11 English
MID
Names of Parts
Rear View
The gure below shows the rear side of the main body without the battery. (Refer to Page 15 for
Separating/Attaching battery.)
1
2
2
3
1Separating/Attaching Battery Push the battery downward to separate the battery, as shown
in the gure above.
2Battery Charging Port Connection part of battery terminal.
3Battery

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
12 English
MID
Installation and Cable Connection
Connecting Earphone and Microphone
Connect earphone and microphone to the ports located on the left of the device.
When connecting external speakers, be sure to connect the standard 3.5-pi stereo cable of the
speakers to the earphone jack.
Notice
Power Connection (Charging Adaptor)
The charger is connected to the power adapter terminal on the left side of the station.
Battery charging status indicator
While charging (using AC adapter)  Red: charging / Blue: fully charge
Notice

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
13 English
MID
Installation and Cable Connection
USB Data Link Connection
A USB cable is connected to the USB Data Link port on the right side of the station.
USB Connection
This is used for the connection of external devices, such as digital camera, external HDD, etc.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
14 English
MID
Installation and Cable Connection
Rotating LCD Screen
LCD screen can be rotated for the convenience of the user. It can be rotated up to 180 degrees
in a clockwise direction.
Take care not to use excessive force to rotate the screen more than the allowed 180 degrees,
otherwise it may result in a malfunction.
Take care not to rotate the screen while the LCD lies at as it might cause a malfunction.
Notice

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
15 English
MID
Separating · Attaching Battery
Separating Battery
Press the battery separation/lock button on the right of the device in the direction shown in the
gure below. Remove the battery.
Attaching Battery
Align the battery in the groove and press it down until a clicking sound is heard.
Separate the charger after turning the power of the station off.
If not, you may receive an electric shock by a short circuit in the battery power part.
Notice
If the battery is misaligned with the groove and you attempt to mount the battery, the device may
be damaged.
Notice

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
16 English
MID
Basic Operation
Turning the Power On/Off
Setting/Cancelling Hold Function
Turning the power on
Move the power button on the right up while the
device is off to turn on the power.
The LCD screen turns on and the main screen isZ
displayed.
Setting Hold mode
Move down the hold button on the right.
Screen touch and all buttons are disabled when holdZ
mode is activated.
Cancelling Hold mode
Move up the hold button on the right only to half
way.
Screen touch and all buttons are enabled when HoldZ
mode is released.
Turning the power off
Use the “Shutdown” menu in the Start Menu to
turn off the device while Windows is running.
When the device is locked up while using
programs, moving the power button on the right
up and holding the position for more than four
seconds will turn off the device.
Avoid turning off by using the button as the workingZ
les may not be saved.
Turning off the power with the button works dependingZ
on the power option conguration of Windows.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
17 English
MID
Basic Operation
Using PIVOT Function
Users can change the orientation of the screen to horizontal or vertical for a convenient working
environment.
Using MENU Function
MENU
To run Start Menu of Windows.
Touch Screen
Touch
Touch the desired location on LCD screen.
Touching one location for a long time has the sameZ
effect as a right click.
Double Touch
It has the same effect as a double-click of a PC mouse.
Touch the desired location twice consecutively.
Drag
Touch the desired location, move to the desired
location while holding the nger on the screen,
and release at the nal destination.
It has the same effect as the drag function with a PC mouse.Z
PIVOT
Press the PIVOT button on the right of the monitor
while the device is on.
Pressing the key will rotate the screen by 90 degreesZ
counterclockwise each time.
This function is effective only when Windows is bootedZ
up and running.

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
18 English
MID
Set Up for villv Manager
viliv Manager is executed by double touching vilivManager on the screen.
1Wireless LAN Power
Turn on/off self-powered wireless LAN function.
2Camera Power
Turn on/off self-powered Camera function.
3Modem Power
Turn on/off self-powered Modem function.
4 Windows Booting Option
1. OFF: Always start with OFF status.
2. Last Status: Start with the last status.
3. ON: Always start with ON status.
5Brightness of LCD
Adjust by status bar or -, + button.
6 Setting Vibration
1. No Use: Do not use vibration function.
2. When using soft keyboard: Operate only if soft
keyboard is used.
3. Always Use: Operates when operating for all
touches.
7 Set Up for Windows Start Program
1. Set whether or not to execute Cube UI automatically.
2. Set whether or not to execute viliv Manager
automatically.
1 4
2
3
5
6
7
Basic Operation

S7
M
o
b
i
l
e
I
n
t
e
r
n
e
t
D
e
v
i
c
e
19 English
MID
Using for the First Time
Using for the First Time
For each Windows installation process, the installation time may vary depending on the
process. Please wait until the installation is complete.
Along with the start of Microsoft Windows XP
Home, the preparation screen for starting
Windows appears as in the following gure.
The Windows start screen for setting up
computer appears.
Click next to continue.
The agreement for end user’s right of use
appears on the screen. Read it carefully, and
select “Yes, I agree. (Y)” if you agree, and
then click next.
1
2
3
