Vimtag B1-C Series User manual

Smart Cloud Camera
B1-C Series
Lens
Lens
IR LEDS
IR LEDS
Wired Network
Status Light
Wired Network
Status Light
Light Sensor
Light Sensor
Wi-Fi Network
Status Light
Wi-Fi Network
Status Light
Power
Power
Ethernet
Ethernet
Wi-Fi Antenna
Wi-Fi Antenna
Reset
RESET
Description Introduction Description Introduction
Infrared light adjustment.
Additional light in low-light conditions.
External power supply .
External Ethernet supply.
Green light flashes shows positive connectivity.
Green light flashes 3 times shows successful
Wi-Fi connection.
Long-press button when device is running normal.
The device will restore factory settings.
Capture videos.
Connect to Wi-Fi.
Quick installation Guide
Thank you for using Vimtag Smart Cloud Camera,
Please follow these steps.
Product Diagram Install vimtag App
Mobile Phone App
Connect Camera
After connecting power, downloading the 'Vimtag' APP and registering your
account on your phone, please login APP and enter 'Device List' interface.
Click '+' at the left top of the interface, a QR Code scanning interface will
appear. Scan the QR code at the bottom of the camera or enter ID account
manually and then choose WiFi or Ethernet connection.
Power
Router
Phone
Router
Power
Click the Ethernet connection icon and connect Ethernet cable.
After 50 seconds, if the wired network indicator will flash green
3 times every 3 seconds, that means connection is successful.
Method 1: Ethernet connection
Click the Wi-Fi icon, input Wi-Fi name and password, and then click
'Next Step'. Wait a few seconds, Wi-Fi connection will be
successful.
* Smartphone must be connected to the Wi-Fi network in this
situation, because camera will connect to the Wi-Fi network via
smartphone.
Method 2: Wi-Fi connection
About
Micro SD card
Schedule recording
Network
Motion andNotication
Support up to
64 GB micro SD
card storage
Could be storaged
with Cloud Box
Storage Device
Add device
Alarm
messages
App settings
Add your cloud
camera to your
account through
the icon.
When camera has
set the motion
detection alarm,
you can receive the
alarm message.
You can change your
user admin and guest
password and check
the app software
version.
Device list View the video Check the video and alarm message
When you login to the account and access the device list,
it will show multiple cameras you have added at the same time.
You can also use "Add device" setting and check
the "alarm message" on the interface.
Click the camera icon so that you can view the camera video,
after you login to the device list, you can skip the screen to
control horizontal and vertical rotation.
You can also operate the "video photo", "Two-way audio" and
setting.
Include "device" and "local"  Two ways you can view
the recorded video and alarm messages at any time.
Click the "device" you can view the videos on the Micro SD
card.
Click the "local" you can view the videos on your phone.
Device Local
Check the video and
alarm messages of
both camera and
Micro SD card.
Note: Camera can
only record the
alarm message.
Sign in
Sign up
Create Username & Sign in
New Account - Select Sign up from the Home Screen,
input a username and password of your choice,
conrm the password. Select Sign up.
Existing Account  Input existing Username and password.
Press Sign in.
Click to register the
username.
Login your existing
username.
Local video Screen setting
Two-way audio
Resolution
Photograph
View the video
records and
alarm messages
Voice
Speak when
pressing
the two-way
audio button.
Select different
resolutions
to view the video
according to
network conditions
Can take a real time
photo when
viewing the video.
Click the icon to view
the video recording
and alarm message.
Turn on the mic and
speaker then speak.
Device settings
It provides
personalized
settings.
Adjust the camera mode,
brightness, contrast,
saturation, sharpness.
Device settings
Access the settings interface, you can set all specications
and functions of the camera. Such as: check camera details,
change your password or congure the camera network.
You can manage the specications and functions based on
your requirements.
