Viozon ZB-2 User manual

≥0.79” - ≤2.76”
3.15”
ATTACH MOUNT TO WORK SURFACE
INSTALL THE ACCESSORY TO THE MAIN POLE
As the picture shows,
install VESA mount on
monitor. Be careful to
leave the slide clip
upwards.
VESA standard:
75*75mm
100*100mm
Using the hex wrench remove the Screw(A) from the Parallel
Connector, place the Arm(β) inside, then tighten the
Screw(A).
Install on open edge of work
surface:
Slide the Base Stem against
work surface edge and fully
tighten clamp Screw(A).
INSTALLING LAPTOP PLATE:
Insert the VESA
connector into the
groove, when heard
a click sound means
done.
INSTALLING MONITOR:
Insert the Laptop Plate into the
groove, when heard a click
sound means done.
Remove the screws
from the adapter by the
hex wrench.
5MM
Scan QR code
get install video
As the picture shows,
put the Clip Arm(α)
Clip Arm(β)
Parallel Connector into the Pole
cover the Post Cap ,
then, tighten the screw.
Note:If you prefer
lower height,
please detach the
arm bracket firstly.
Then insert arm as
picture.
As the picture shows, put
the accessories at the
arm(α),tighten the screw.
INSTALLING RING FILL LIGHT:
INSTALLING ADAPTOP:
As the picture shows,
use the hex wrench to
remove screws on
arm(β)
Place the microphone main stand at the inside hole of the parallel
connector, tighten the screw which is at behind of the parallel
connector. then put the microphone holder.
INSTALLING TABLET HOLDER:
5MM
If you want to get taller
height-using, you
could install the
extension rod between
the universal ball head
and the phone holder.
INSTALLING PHONE HOLDER:
Install the
universal ball
head at the
arm(β) at first,
then install the
phone holder.
a
Remove the screws
from the holder
adapter by the hex
wrench.
As the picture shows,
put the accessories at
the aparted arm, put
the screw back then
tighten it.
INSTALLING MICROPHONE HOLDER:
5MM
Clip
Arm(α)
Arm(β)
Arm(β)
Post Cap
Parallel Connector
Screw(A)
Base Stem
A
If you want to get taller
height-using, you could
install the extension rod
between the universal ball
head and the ring fill light.
Install the
universal ball
head at the arm(β)
at first, then install
the ring fill light.
a

Make sure to read the manual before installation and fully
understand how to install, if you have any questions, please visit
our website or contact the televant after-service.
Please make sure the desktop could bear the weight of mount and
monitor before installation.
This product contains small parts, keep these away from children.
WARRANTY SERVICE
FEEDBACK
Never worried when you choose viozon products
We offer the best after-sale service to our customer,
it only takes few minutes.
And then you will get complete service such as installation
guide, technical support, new product reminder, privilege of
purchasing similar products, promotions and warranty service
from Viozon.
Viozon is focusing on high-standard products, we believe
that customers’ feedback drives us upgrading products.
Writing a review which sharing your experience will help
other customers. Also, your review will give us great
encouragement and confidence for future improvement. If
you have any questions, please feel free to contact us
without hesitation.
Share it?
Let us know with a customer review.
Just send you name and order number to
[email protected]
Facebook: Viozon [email protected]
FOR HELP PLEASE CONTACT US:
www.vio-zon.com Scan QR code
to get install video
Scan QR code below for
more products from viozon
ZB-2
