Vip-Vision VSIP8MPFBIRM User manual
FBIR Series
Camera Quick Install Guide
Version 290517
Available in 2.0MP, 4.0MP, 8.0MP and 12.0MP WDR variants
Applicable Models
VSIP4MPFBIRM 4.0MP WDR Infrared Motorised Bullet
VSIP8MPFBIRM 8.0MP Infrared Motorised Bullet
VSIP12MPFBIRMV2 12.0MP Infrared Motorised Bullet
VSIP2MPFBIRL 2.0MP Ultra Low Light Infrared Motorised Bullet
VSIP2MPFBIRT 2.0MP Number Plate Enhancement Motorised Bullet
Thank you for purchasing a FBIR Series CCTV Surveillance Camera.
This Quick Install Guide covers basic setup, installation and use of your surveillance system.
For the full user manual, instructional videos, tips on using your surveillance system &
warranty information, please visit: www.vip-vision.com
2Crucial evidence. Always.
FBIR Series | Surveillance Cameras
Electrical safety
• All installation and operation here should conform to your local electrical safety codes.
• Check that the power supply is correct before operating the camera.
• Ensure the power supply conforms to the requirement in the SELV (Safety Extra Low Voltage) and the
Limited power source is rated DC 12V or AC 24V in the IEC60950-1. (Power supply requirement is subject
to the device label).
• Do not install wiring while the camera is powered on.
• Prevent the power cable from being trampled or pressed, especially the plug, power socket and junction.
• We assume no liability or responsibility for any res or electrical shock caused by improper handling or
installation.
• We assume no liability or responsibility for any problems caused by unauthorized modication or
attempted repair.
Environment
• Do not aim the camera at strong light (such as lighting, sunlight, etc) to focus; this may cause overexposure,
which will aect the longevity of the CCD and/or CMOS.
• Transport, use and store the camera within the specied range of humidity and temperature.
• Do not store the camera in a wet, dusty, extremely hot, or extremely cold location, or in an area with
strong electromagnetic radiation or unstable lighting.
• Do not allow water or other liquids to fall into the camera; this may damage internal components.
• Do not allow water or other liquids to make contact with indoor cameras (cameras with no IP rating); this
may damage the camera or cause re/electrical shocks.
• Keep the camera well ventilated in case of heat accumulation.
• Pack the camera with the included factory packaging (or material of similar quality) while transporting
to prevent damage.
• While being transported, stored or installed, ensure the camera does not experience heavy stress, strong
vibration or liquid contact .
Warning
• Change the default password after login in order to avoid unauthorised access.
• Install the camera using the standard accessories provided by the manufacturer and make sure the
device is installed and xed by professionals.
• Keep the camera away from laser beams while using a laser device.
• Do not connect two power sources to the device at the same time; this may result in damage to the
camera.
Statement
• Refer to the actual product for more details; the manual is just for reference.
• The manual will be regularly updated as the product updates; the updated content will be added to the
manual without prior announcement.
• Contact the supplier or customer service if there is any problem occurred camera using the camera.
• Contact the supplier or customer service for the latest procedure and supplementary documentation.
• Actual value of some data and the value provided in the manual may dier due to environmental
dierences, etc.
• VIP Vision is not liable for any damages caused by operation which is not followed in the manual.
Safety Information
3
www.vip-vision.com
FBIR Series | Surveillance Cameras
FCC information
Operation and Daily Maintenance
• Do not touch the heat dissipation component of the camera directly in order to avoid burns.
• Do not dismantle the device; there is no component which can be xed directly by users in the camera.
Contact the supplier to replace desiccant if it becomes green.
• Grounding the camera is recommended to enhance the reliability of it.
• Do not touch the CCD (CMOS) optic component directly. Use an air duster to clean dust or dirt on the lens
surface, or use a cloth lightly wet with alcohol to wipe away dust gently.
• Use a dry soft cloth to clean the camera. If there’s a large amount of dust, use a mild detergent diluted
with water rst. Don’t use volatile solvents such as alcohol, benzene, thinner or strong detergents, as this
may damage the surface coating or damage the camera.
• To clean the lens, use a dry soft cloth to wipe water or oil gently until dry, then use an oil-free cotton cloth
or paper soaked with alcohol/detergent to wipe from the centre of the lens outwards.
FCC conditions
• This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired
operation.
FCC compliance
• This equipment has been tested and found to comply with the limits for a digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communication. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced technician for help.
Note: Refer to the disk for more details, check and download corresponding user’s manual and tool.
Before installation, open the package and check that all components are included. If any components are
broken, contact your local supplier.
4Crucial evidence. Always.
FBIR Series | Surveillance Cameras
Connection ports
Port Name Function
1 AUDIO OUT Audio output port (RCA connector)
2 AUDIO IN Audio input port (RCA connector)
3 LAN Network port (Ethernet connector)
4 I/O I/O port
5Power Power input port (optional)
Dimensions
Included components
1. Pre-install Information
1 x FBIR Series IP Camera
1 x Quick Start Guide
1 x
Installation Accessories Bag:
• Position installation map
• Expansion bolts
• Locking screws
• Screwdriver
1 x CD
5
www.vip-vision.com
FBIR Series | Surveillance Cameras
Here we will walk you through the installation process of your “FBIR Series” camera. We will show
you how to set up and adjust your camera, insert your microSD card, waterproof your network cable
and setup your alarm. Be sure to check the Pre-install Information to have an understanding of the
included components, dimensions, and connection ports.
2. Camera Installation
2.1 Position the camera
1. Install the microSD card. (Optional, see 1.2 Accessing the microSD card slot).
2. Position the installation map to a wall or ceiling and drill holes where marked.
3. Insert the expansion bolts into the drilled holes.
4. Tighten locking screws to x the camera to the surface.
5. Plug in the external cables according to usage requirements.
6. Adjust monitoring direction of the device (See 1.3 Adjusting the camera angle).
7. Apply waterproong to network cable (See 1.4 Waterproong the camera).
8. Setup your alarm system (See 1.5 Alarm setup).
9. Setup is complete!
6Crucial evidence. Always.
FBIR Series | Surveillance Cameras
1.2 Accessing the microSD card slot (optional)
1.2.2 Advantages of the microSD
1. Locate the lower cover on the bottom of the camera and open it.
2. Install the microSD card into its dedicated slot, making sure it’s properly secured.
3. Replace the lower cover.
1.2.1 Installing the microSD card
Note: Having a standalone microSD card will not ensure that you have the same quality playback, nor
the capacity compared to a separate NVR or storage device.
The microSD card is useful for anyone who wishes to have another way to back up storage, or is on a
budget and doesn’t have a recorder. The microSD card is placed inside of the camera, and can hold
a set amount of storage (dependent on size of card) for any intended use, such as: video playback,
storage, backup etc.
The microSD card utilises “Edge Recording”. This is when the camera records video directly onto the
installed card in the camera, instead of a separate NVR or storage device. This gives the user more
exibility in recording video.
7
www.vip-vision.com
FBIR Series | Surveillance Cameras
1. Use screwdriver found in accessories bag to loosen screw.
2. Adjust the camera and set its monitoring direction as required.
3. Tighten screw(s) until rmly secured.
1.3 Adjusting the camera angle
1.4 Waterproong the camera
1. Install the rubber ring into the network port, keeping the smaller hole of the rubber ring facing
outwards and xing the rubber ring onto the main body of the waterproof cable.
2. Pull the network cable (without the crystal head) through the main body of the waterproof
connector. Fix the rubber ring and waterproof locking cover, attach the crystal head of network
cable, and insert it into the network cable.
3. Put the main body of the waterproof connector on the network port and rotate it clockwise to
lock the network port and waterproof connector rmly.
4. Put the waterproof cover on the main body of the waterproof connector and rotate it clockwise
to lock them rmly together.
8Crucial evidence. Always.
FBIR Series | Surveillance Cameras
1.5 Alarm setup
1. Connect the alarm input device to the alarm input of I/O cable.
2. Connect the alarm output device to the alarm output of I/O cable.
3. Open the WEB and set the alarm input and output. Alarm input on WEB corresponds to I/O cable
on device.When there is an alarm, the input device will generate a signal. Set corresponding NO
and NC inputs.
Port Name Function
1 ALARM_NO
Alarm output port
NO: Normal open alarm output port
Must be used with ALARM_COM
2 ALARM_COM Alarm output public port
3 ALARM_IN1 Alarm input port 1
4 ALARM_IN2 Alarm input port 2
5 GND Ground port
www.vip-vision.com
Note:
This quick install guide is for reference only. Slight dierence may be found in user interface.
All the designs and software here are subject to change without prior written notice.
Please visit our website or contact your local service engineer for more information.
For the full user manual, instructional videos, tips for using your surveillance system and
warranty information, please visit:
