Vissani MDTF18WH User manual

设 计
DESIGN
黄志胜
2020.08.19
校 对
CO.BY
图号/物料编码 PART NO.
标准化
STANDARD
图纸名称 PART NAME
MDTF18WH MDTF18SS
UR-BCD510WE
说明书
业务
seller 陈路
曾磊
图样标记
REL
版本号
REV.NO.
重量(g)
WEIGHT
比例
scale
材料 MATERIAL
80g双胶纸
批 准
AUTHORI
ZE
共 页
TOTAL SHEETS
第 页
NO. OF SHEETS
美的冰箱事业部
MIDEA REFRIGERATION
DIVISION
标记
MARKER
01:1
变更内容 修改日期 签名
技术要求
16131000A39271
1.尺寸：216*279mm，40P
2.印刷颜色：单色（灰度印刷）
3.制件必须符合QMB-J036.1008 产品说明书及其它类似印刷件技术规范；
4.除客户特别要求外均参照美的冰箱最新版相关企业标准执行;

THANK YOU
We appreciate the trust and confidence you have placed in Vissani through the purchase of this refrigerator. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Vissani!
USE AND CARE GUIDE
Refrigerator-Freezer
Questions, problems, missing parts? Before returning to the store,
call THD Customer Service
Mon-Fri 8:00 AM to 8:00 PM (EST) , Saturday 8:00 AM to 6:00 PM (EST)
1-866-646-4332
HOMEDEPOT.COM
Item #1005673850
Model #MDTF18WH
Item #1005673852
Model #MDTF18SS

2
Table of Contents
Table of Contents ................................... 2
Safety Information .................................. 2
Warning... ......................................2
Electricity related warnings..........................3
Warnings for using.................................4
Warnings for placement ............................4
Warnings for energy ...............................5
Warnings for disposal ..............................5
Warranty .......................................... 6
Pre-Installation..................................... 7
Placement .......................................7
Levelling feet.....................................8
Reverse the door swing .............................8
Installing the door handle ...........................12
Installing an optional ice maker.......................12
Starting .........................................12
Energy saving tips .................................12
Overall cleaning ...................................15
Defrosting .......................................15
Changing the light .................................15
Out of operation ...................................15
Key components ..................................13
Functions ........................................14
Assembly..........................................13
Maintenance and Cleaning ...........................15
Troubleshooting ....................................16
Safety Information
WARNING
□
□
□
□
□
□
□
□
□
□
□
□
□
DANGER: Indicates a hazardous situation which,
if not avoided, will result in death or serious injury.
Limit the use of this hazard statement to the most
extreme situations.
WARNING: Indicates a hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation which,
if not avoided, could result in minor or moderate injury.
NOTICE: Is the preferred signal word to address practices not
related to personal injury.
This appliance is intended to be used in household and similar
applications such as staff kitchen areas in shops, ofces and
other working environments; farm houses and by clients in
hotels, motels and other residential type environments; bed and
breakfast type environments; catering and similar non-retail
applications.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.
The appliance has to be unplugged after use and before carrying out user maintenance on the appliance.
WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
WARNING: Please abandon the refrigerator according to local regulators for it use ammable blowing gas and refrigerant.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
Do not use extension cords or ungrounded (two prong) adapters.

3 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
Safety Information
ELECTRICITY RELATED WARNINGS
□
□
□
□
□
□
□
□
DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:
- Take off the doors.
- Leave the shelves in place so that children may not easily climb inside.
The refrigerator must be disconnected from the source of electrical supply before attempting the installation of accessory.
Refrigerant and cyclopentane foaming material used for the appliance are ammable. Therefore, when the appliance is scrapped, it
shall be kept away from any re source and be recovered by a special recovering company with corresponding qualication other than
be disposed by combustion, so as to prevent damage to the environment or any other harm.
Children should be supervised to ensure that they do not play with the appliance.
WARNING: To avoid a hazard due to instability of the appliance, it must be xed in accordance with the instructions.
WARNING: Connect to potable water supply only. (Suitable for ice making machine)
To prevent a child from being entrapped, keep out of reach of children and not in the vicinity of freezer (or refrigerator). (Suitable for
products with locks)
□
□
Do not pull the power cord when pulling the power plug of the refrigerator. Please rmly grasp the plug and
pull out it from the socket directly.
To ensure safe use, do not damage the power cord or use the power cord when it is damaged or worn.
□
□
Please turn off the valve of the leaking gas and then open the doors and windows in case of leakage of gas
and other ammable gases.
Do not unplug the refrigerator and other electrical appliances considering that spark may cause a re.
□Do not use electrical appliances on the top of the appliance, unless they are of the type recommended by
the manufacturer.
□
□
□
Please use a dedicated power socket and the power socket shall not be shared with other electrical
appliances.
The power plug should be rmly contacted with the socket or else res might be caused.
Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line.
WARNING: Risk of re / ammable materials

4
Safety Information
WARNINGS FOR USING
□
□
Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the refrigerant circuit;
maintenance of the appliance must be conducted by a specialist.
Damaged power cord must be replaced by the manufacturer, its maintenance department or related
professionals in order to avoid danger.
□
□
Do not place heavy objects on the top of the refrigerator considering that objectives may fall when close or
open the door, and accidental injuries might be caused.
Please pull out the plug in case of power failure or cleaning. Do not connect the freezer to power supply
within ve minutes to prevent damages to the compressor due to successive starts.
□Do not allow any child to get into or climb the refrigerator; otherwise suffocation or falling injury of the child
may be caused.
□
□
The gaps between refrigerator doors and between doors and refrigerator body are small, be noted not to
put your hand in these areas to prevent from squeezing the nger. Please be gentle when close the
refrigerator door to avoid falling articles.
Do not pick foods or containers with wet hands in the freezing chamber when the refrigerator is running,
especially metal containers in order to avoid frostbite.
WARNINGS FOR PLACEMENT
□
□
Do not put ammable, explosive, volatile and highly corrosive items in the refrigerator to prevent damages
to the product or re accidents.
Do not place ammable items near the refrigerator to avoid res.
□The refrigerator is intended for household use, such as storage of foods; it shall not be used for other
purposes, such as storage of blood, drugs or biological products, etc.
□Do not store beer, beverage or other uid contained in bottles or enclosed containers in the freezing
chamber of the refrigerator; otherwise the bottles or enclosed containers may crack due to freezing to
cause damages.
Freezing chamber

5 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
Safety Information
WARNINGS FOR ENERGY
WARNINGS FOR DISPOSAL
□
□
□
□
□
□
Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the
frozen food compartment) when sited for an extended period of time below the cold end of the range of temperatures for which the
refrigerating appliance is designed.
The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or in low-temperature compartments or
cabinets, and that some products such as water ices should not be consumed too cold;
The need to not exceed the storage time(s) recommended by the food manufacturers for any kind of food and particularly for
commercially quick-frozen food in food-freezer and frozen-food storage compartments or cabinets;
The precautions necessary to prevent an undue rise in the temperature of the frozen food while defrosting the refrigerating appliance,
such as wrapping the frozen food in several layers of newspaper.
The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or cleaning could shorten the storage life.
The necessity that, for doors or lids tted with locks and keys, the keys be kept out of the reach of children and not in the vicinity of the
refrigerating appliance, in order to prevent children from being locked inside.
Refrigerant and cyclopentane foaming material used for the refrigerator are ammable. Therefore, when the refrigerator is
scraped, it shall be kept away from any re source and be recovered by a special recovering company with corresponding
qualication other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
When the refrigerator is scraped, disassemble the doors, and remove gasket of door and shelves; put the doors and shelves in
a proper place, so as to prevent trapping of any child.
Correct disposal of this product：
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental safe recycling.

Your product is protected by this Limited Warranty:
Warranty service must be obtained from VISSANI Consumer Services or an authorized VISSANI servicer.
Warranty
• One year Limited Warranty from original purchase date.
VISSANI, through its authorized servicers will:
• Pay all costs for repairing or replacing parts of this appliance which prove to be defective in materials or workmanship.
Consumer will be responsible for:
• Diagnostics, removal, transportation and reinstallation cost required because of service.
• Costs of service calls that are a result of items listed under NORMAL RESPONSIBILITIES OF THE CONSUMER**
VISSANI replacement parts shall be used and will be warranted only for the period remaining on the original warranty.
6
Warranty
REFRIGERATOR LIMITED WARRANTY
This warranty applies only to products in ordinary household use, and the consumer is responsible for the items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Routine maintenance and cleaning necessary to keep the good working condition.
3. Proper installation by an authorized service professional in accordance with instructions provided with the appliance and in accordance
with all local plumbing, electrical and / or gas codes.
4. Proper connection to a grounded power supply of sufcient voltage, replacement of blown fuses, repair of loosened connections or
defects in house wiring.
5. Expenses for making the appliance accessible for servicing.
6. Damages to nish after installation.
NORMAL RESPONSIBILITIES OF THE CONSUMER**
This warranty does not cover the following:
1. Failure caused by damage to the unit while in your possession (other than damage caused by defect or malfunction), by its improper
installation, or by unreasonable use of the product, including without limitation, failure to provide reasonable and necessary
maintenance or to follow the written Installation and Operating Instructions.
2. Products purchased “as-is” or refurbished are not covered by this warranty.
3. Food loss caused by refrigerator or freezer failure.
4. Service calls to repair or replace consumables such as water lters, light bulbs air lters etc., or handles, knobs and other cosmetic
parts.
5. Product that has been transferred from its original owner.
6. Interior or exterior rust on the unit.
7. Damages caused by services performed by persons other than authorized VISSANI servicers; use of parts other than VISSANI
replacement parts; obtained from persons other than such VISSANI customer service; or external causes such as abuse, misuse,
inadequate power supply or acts of God.
8. Service calls resulting from improper installation of your product.
9. Service calls to instruct you on the use of your product.
10. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense
for service calls to remote areas, including the state of Alaska.
11. If the unit is put to commercial, business, rental, or other use or application other than for consumer use, we make no warranties,
express or implied, including but not limited to, any implied warranty of merchantability or tness for particular use or purpose.
12. Product that has been removed outside the USA or Canada.
13. Products without original serial numbers or products that have serial numbers which have been altered or cannot be readily
determined.
EXCLUSIONS
NOTICE: Some states do not allow the exclusion or limitation of incidental or consequential damages. So this limitation or exclusion
may not apply to you.

□Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the
refrigerator; tear off the protective lm on the doors and the refrigerator body.
□
□
Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to
prevent rust or reduction of insulating effect.
Do not spray or wash the refrigerator; do not put the refrigerator in moist places easy to be splashed with
water so as not to affect the electrical insulation properties of the refrigerator.
□The refrigerator is placed in a well-ventilated indoor place; the ground shall be at, and sturdy (rotate left
or right to adjust the wheel for levelling if unstable).
□The top space of the refrigerator shall be greater than 1.2 in, and The refrigerator should be placed against
a wall with a free distance more than 0.4 in to facilitate heat dissipation.
□Spare enough space for convenient opening of the doors and drawers or statement by the distributor.
Keep your bill of sale, delivery slip, or some other appropriate payment record. Should service be required, the date on the bill establishes
the warranty period commencement date.
If service is performed, it is in your best interest to obtain and keep all receipts.
This written warranty gives you specic legal rights. You may also have other rights that vary from state to state.
Service under this warranty must be obtained by:
Contact the Customer Service Team at 1-866-646-4332.
Warranty
IF YOU NEED SERVICE
7 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
Pre-Installation
PLACEMENT
1.2 in.
0.4 in.
0.4 in.
29.5 in.
50.0 in.
27.8 in.
50.7 in.
135°
WARNING: Information in the Instruction Manual is only for reference. The physical product may differ.
Before installation and adjusting of accessories, it shall be ensured that the refrigerator is disconnected from power.

Schematic diagram of the levelling feet.
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
8
Pre-Installation
LEVELLING FEET
REVERSE THE DOOR SWING
NOTE:
When reversing the door swing.
• Read the instructions all the way through before starting.
• Handle parts carefully to avoid scratching paint.
• Set screws down by their related parts to avoid using them in the wrong places.
• Provide a non-scratching work surface for the doors.
• It is recommended that 2 people perform this task.
IMPORTANT: Once you begin, do not move the cabinet until door-swing reversal is completed.
These instructions are for changing the hinges from the right side to the left side—if you ever want to change the hinges back to the right side,
follow these same instructions and reverse all references to left and right.
Tools Required
5/16 in. Socket driver Phillips screwdriver Putty knife or thin-blade screwdriver
WARNING: Follow all steps when reversing the door swing. Failure to follow these instructions, leaving off parts,
or overtightening screws, can lead to the door falling off and result in injury and property damage.

9 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
1
WARNING: Unplug the refrigerator from its electrical
outlet. Empty all door shelves.
□
□
2
Remove the hole cover and the right top hinge cover,
then unscrew screws and remove the right top hinge.
Keep the screws to reuse.
Lift the freezer door up and away from your refrigerator.
□Unscrew screws of middle hinge, remove the hinge, then lift
the refrigerator door up and away from your refrigerator.
Save the screws to reuse.
Part Description Quantity
A Hole cap 1
1
1
1
1
1
B Right top hinge cover
C Top Right hinge
D Right door self-locking block
E Right door open stopper
F Middle right hinge
AB
C
D
E
F
Pre-Installation

Part Description Quantity
G Hinge shaft 1
1
1
1
H Bottom hinge
I
J
Left door self-locking block
Left door open stopper
K Top sleeves 1
1
1
1
L Hole cap
M
N
Sleeves
Bottom stopper
10
3
□
□
4
Unscrew screws of the bottom hinge, then remove the
bottom hinge from the bottom right side of the
refrigerator.
Unscrew the hinge shaft from the right side of the bottom
hinge and move it to the left side, then secure the bottom
hinge to the bottom left side of the refrigerator, using the
screws you removed previously.
□
□
Remove the sleeves from the top right of doors and hole cap
from top left of doors, and assemble them on the opposite
sides.
Remove the refrigerator door open bottom stopper and
install it other side of the door. Remove the freezer right
door self-locking block and right door open stopper and
save. Them to reuse take out the left freezer self-locking
block and left door open stopper from the accessory bag in
the refrigerator and installed on the left of freezer door.
G
H
N
M
K
L
I
J
Pre-Installation

11 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
5
□
6
Install the refrigerator door vertically onto the bottom
hinge. Take out the middle left hinge from the accessory
bag then assemble the middle left hinge on the left side
of the refrigerator.
□Install the freezer door vertically into the center hinge. Take
out the left top hinge and left top hinge cover from
accessory bag, assembly left top hinge, left top hinge cover
and hole cover.
Part Description Quantity
O Middle left hinge 1
1
1
1
P Left top hinge cover
Q Top left hinge
A Hole cap
O
A
P
Q
Pre-Installation

INSTALLING THE DOOR HANDLE
□Parts included with the handle kit:
STARTING
□
□
Before initial start, keep the refrigerator still for half an hour before connecting it to power supply.
Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4 hours in summer when the ambient
temperature is high.
INSTALLING AN OPTIONAL ICE MAKER
□The refrigerator comes set up for ice maker installation, This refrigerator is compatible with Midea IM1800MD ice maker. Please refer to
individual ice maker installation instruction manual.
ENERGY SAVING TIPS
□
□
□
□
□
The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the
direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the compressor to run longer.
Foods that freeze too slowly may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down on frost build-up inside
the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with cold air circulation,
making the appliance less efcient.
Organize and label food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the
door as soon as possible.
12
Pre-Installation
Screws (4) Allen wrenchHandle assembly Allen wrench
caps (4)
Allen wrench
screws (4)
You will need: A Phillips screwdriver and the included Allen wrench.
1. Insert the two Phillips-head screws into the refrigerator door on the side you prefer, then tighten.
2. Align the door handle with the screws.
3. Insert the two Allen-head screws through the side of the door handle and tighten with the Allen wrench.
4. Place the screw caps on the screws.

KEY COMPONENTS
Refrigerating chamber
□
□
□
□
□
□
The refrigerating chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term.
Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
Foods are recommended to be sealed up before putting into the refrigerator.
The shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
Freezing chamber
□The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to store frozen foods and making ice.
The freezing chamber is suitable for storage of meat, sh, rice balls and other foods not to be consumed in short term.
Chunks of meat are preferably to be divided into small pieces for easy access. Please be noted food shall be consumed within the shelf
time.
13 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
Part Description Quantity
A Freezer shelf 1
1
1
1
3
2
B Freezer control
C Refrigerator control
D LED lighting
E Fresh food shelves
F Vegetable crisper
Part Description Quantity
G Leveling legs 3
2
1
2
2
H Freezer door racks
I Dairy rack
J Refrigerator door racks(small)
K Refrigerator door racks(large)
NOTICE: Storage of too much food during operation after the initial connection to power may adversely affect the freezing effect of the
refrigerator.
H
K
J
I
A
B
C
F
G
D
E
Assembly

1. DISPLAY
Once initially powered on, the display screen is on full display for 3 seconds. The refrigerator default setting is medium, and the LED 3
indicator will be illuminated. This is normal operation display in case of a failure, the appropriate LED light will ash in sequence.
In case of no failures, the current temperature setting of the refrigerator will be on display.
2. TEMPERATURE SETTING
Each time the temperature setting is pressed once, the temperature setting changes one time.
After the temperature setting has been completed, the refrigerator will run according to the set value after 25s.
From left to right, the temperature is lower.
The order of coldness settings is as follows:
3. STANDBY MODE
To enter standby mode, press the setting for 3 seconds when the refrigerator is running. In standby mode, the compressor will not
operate and the standby indicator light will be illuminated. To resume normal operation, just press the setting momentarily.
4. SETTING THE FREEZER TEMPERATURE
Turn the controls to adjust the freezer temperature.
Place frozen food into the freezer as quickly as possible after purchase. Pay attention to the storage time on the food packaging
instructions. The storage life of frozen foods varies and the recommended storage time should not be exceeded.
FUNCTIONS
14
A. Setting button
B. LED1 COOL indicator
C. LED2 indicator
D. LED3 indicator
E. LED4 indicator
F. LED5 COOLEST indicator
G. LED6 STANDBY mode
A
COLD
SET
COLDEST
STANDBY
Hold SET-button for 3-sec
for standby
Temperature
Control
B C D E F G
LED1 LED2 LED3 LED4 LED5
Mid
COLD COLDER
TEMP.
CONTROL
Assembly

□
OVERALL CLEANING
DEFROSTING
□
□
□
□
Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. The interior of
the refrigerator should be cleaned regularly to avoid odor.
Soft towels or sponge dipped in water and non-corrosive neutral detergents are suggested for cleaning. The freezer of shall be nally
cleaned with clean water and dry cloth. Open the door for natural drying before the power is turned on.
Do not use hard brushes, clean steel balls, wire brushes, abrasives, such as toothpastes, organic solvents (such as alcohol, acetone,
banana oil, etc.), boiling water, acid or alkaline items clean refrigerator considering that this may damage the fridge surface and
interior.
Do not rinse with water so as not to affect the electrical insulation properties.
The refrigerator is made based on the air-cooling principle and thus has automatic defrosting function. Frost formed due to change of
season or temperature may also be manually removed by disconnection of the appliance from power supply or by wiping with a dry
towel.
CHANGING THE LIGHT
1. Unplug the refrigerator.
2. The light bulb is located at the top of the refrigerator cabinet.
3. Using a screwdriver, remove the screw securing the light cover, then remove the light cover.
4. Replace the LED with a new LED, input rating: 115V AC 3.5W.
5. Replace the light cover.
6. Plug the refrigerator back in and resume normal functioning.
□
□
□
OUT OF OPERATION
Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for several hours; during the
power failure, the times of door opening shall be reduced, and no more fresh food shall be put into the appliance.
Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left open to prevent odor.
Moving: Before the refrigerator is moved, take all objects inside out, x the glass partitions, vegetable holder, freezing chamber drawers
and etc. with tape, and tighten the leveling feet; close the doors and seal them with tape. During moving, the appliance shall not be laid
upside down or horizontally, or be vibrated; the inclination during movement shall be no more than 45°.
15 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
WARNING: Please unplug the refrigerator for defrost and cleaning.
NOTICE: The appliance shall run continuously once it is started. Generally, the operation of the appliance shall not be interrupted;
or otherwise the service life may be impaired.
Maintenance and Cleaning

16
NOTICE: You may try to solve the following simple problems by yourself. If them cannot be solved, please contact the after-sales
department.
Problem Possible Cause & Solution
Check whether the appliance is connected to power or whether the plug is in well contact;
Check whether the voltage is too low;
Check whether there is a power failure or partial circuits have tripped;
Failed operation
Odorous foods shall be tightly wrapped;
Check whether there is any rotten food;
Clean the inside of the refrigerator;
Odor
Long operation of the refrigerator is normal in summer;
When the ambient temperature is high;
It is not suggestible having too much food in the appliance at the same time;
Food shall get cool before being put into the appliance;
The doors are opened too frequently;
Long-time operation
of the compressor
Check whether the refrigerator is connected to power supply and whether the illuminating light is damaged;
Have the light replaced by a specialist;
Light fails to get lit
The door is stuck by food packages Too much food is placed;
The refrigerator is tilted;
Doors cannot be
properly closed
Check whether the oor is level and whether the refrigerator is placed stably;
Check whether accessories are placed at proper locations;
Loud noise
Remove foreign matters on the door seal;
Heat the door seal and then cool it for restoration (or blow it with an electrical drier or use a hot towel for
heating);
Door seal fails to be
tight
There is too much food in the chamber or food stored contains too much water, resulting in heavy defrosting;
The doors are not closed properly, resulting in frosting due to entry of air and increased water due to defrosting;
Water pan overows
Heat dissipation of the built-in condenser via the housing, which is normal;
When housing becomes hot due to high ambient temperature, storage of too much food or shutdown of the
compressor is shut down;
Provide sound ventilation to facilitate heat dissipation;
Hot housing
Condensation on the exterior surface and door seals of the refrigerator is normal when the ambient humidity is too
high;
Just wipe the condensate with a clean towel;
Surface condensation
Buzz: The compressor may produce buzzes during operation, and the buzzes are loud particularly upon start or
stop. This is normal.
Creak: Refrigerant owing inside of the appliance may produce creak, which is normal.
Abnormal noise
Fault Code Fault Description
LED1 indicator and LED2 indicator Refrigerator temperature sensor circuit
LED1 indicator and LED3 indicator Freezer defrost sensor
LED1 indicator and LED4 indicator Ambient temperature sensor
ERROR CODES
Troubleshooting

Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store,
call THD Customer Service
Mon-Fri 8:00 AM to 8:00 PM (EST) , Saturday 8:00 AM to 6:00 PM (EST)
1-866-646-4332
HOMEDEPOT.COM

GUÍA DE USO Y CUIDADO
_________________
Refrigerador-Congelador
¿Preguntas, problemas, piezas faltantes? Llame al Servicio de Atención al Cliente de THD antes de
regresar a la tienda.
Lunes-viernes: 8:00 AM a 8:00 PM (EST), sábado: 8:00 AM a 6:00 PM (EST)
1-866-646-4332
HOMEDEPOT.COM
GRACIAS
Apreciamos la confianza que ha depositado en Vissani a través de la compra del presente refrigerador.
Nos esforzamos por crear continuamente productos de calidad diseñados para mejorar su hogar.
Visítenos en línea para ver nuestra línea completa de productos disponibles para sus necesidades de
mejoras del hogar.
¡ Gracias por elegir Vissani!
Ítem #1005673850
Modelo #MDTF18WH
Ítem #1005673852
Modelo #MDTF18SS

2
Tabla de Contenidos
Tabla de Contenidos.................................................................. 2
Información de Seguridad......................................................... 2
ADVERTENCIA......................................................................2
ADVERTENCIAS RELACIONADAS CON LA
ELECTRICIDAD..................................................................... 4
ADVERTENCIAS PARA EL USO...........................................5
ADVERTENCIAS PARA LA COLOCACIÓN.......................... 5
ADVERTENCIAS PARA LA ENERGÍA.................................. 6
ADVERTENCIAS PARA EL DESECHO.................................6
GARANTÍA.................................................................................. 7
GARANTÍA.................................................................................. 8
Preinstalación ............................................................................ 9
COLOCACIÓN ....................................................................... 9
PATA NIVELADORA............................................................10
INVERTIR EL GIRO DE LA PUERTA.................................. 10
INSTALAR LA MANIJA DE LA PUERTA..............................14
INSTALAR UNA HELADORA OPCIONAL ...........................14
ARRANQUE..........................................................................14
CONSEJOS PARA AHORRAR ENERGÍA...........................14
Ensamblaje ...............................................................................15
COMPONENTES CLAVE.....................................................15
Ensamblaje ...............................................................................16
FUNCIONES.........................................................................17
Mantenimiento y Limpieza.......................................................19
LIMPIEZA GENERAL ...........................................................19
DESCONGELACIÓN............................................................19
REEMPLAZO DE LA LUZ.....................................................19
FUERA DE FUNCIONAMIENTO..........................................19
Resolución de problemas........................................................20
Información de Seguridad
ADVERTENCIA
□Este aparato está destinado a ser
utilizado en aplicaciones domésticas y
similares, como áreas de cocina del
personal en tiendas, oficinas y otros
entornos de trabajo; casas de campo y
clientes en hoteles, moteles y otros
entornos residenciales; ambientes de tipo
cama y desayuno; cáterin y aplicaciones
similares no minoristas.
□Este aparato no está diseñado para ser
usado por personas (niños incluidos) con
capacidades mentales, físicas o
sensoriales reducidas o limitadas, o
carentes de experiencia y conocimiento, a
no ser que hayan recibido formación o
supervisión sobre el uso del aparato por
una persona responsable de su
seguridad.
□Si el cable de alimentación estádañado,
debe ser reemplazado por el fabricante,
su servicio técnico u otra persona de
cualificación similar, para evitar peligros.
PELIGRO: Indica una situación
peligrosa que, si no se evita, provocará
la muerte o lesiones graves. Limite el
uso de dicha declaración de peligro a
las situaciones más extremas.
ADVERTENCIA: Indica una situación
peligrosa que, si no se evita, podría
provocar la muerte o lesiones graves.
PRECAUCIÓN: Indica una situación
peligrosa que, si no se evita, podría
provocar lesiones leves o moderadas.
AVISO: Es la palabra de advertencia preferida
para indicar prácticas sin relación con lesiones
personales.
□No almacene sustancias explosivas como latas de aerosol con un propulsor inflamable en este
aparato.
□El aparato debe desenchufarse después de su uso y antes de realizar el mantenimiento en el
aparato por parte del usuario.
□ADVERTENCIA: Mantenga abierta la ventilación, sin obstrucciones en la carcasa del aparato o en la
estructura incorporada.
□ADVERTENCIA: No utilice dispositivos mecánicos u otros medios para acelerar el proceso de
descongelación, que no sean los recomendados por el fabricante.
□ADVERTENCIA: No dañe el circuito refrigerante.
□ADVERTENCIA: No utilice electrodomésticos dentro de los compartimentos de almacenamiento de
alimentos del aparato, a menos que sean del tipo recomendado por el fabricante.
