vitantonio VWH-500A User manual

Contents
Important Safeguards ……………… 17-18
Before First Use ……………………… 19
Parts …………………………………… 20
Installing Baking Plates …………… 21-22
Making Waffles ……………………… 23-24
Making Hot Sandwiches / Panini … 25-26
How to Clean…………………………… 27
Troubleshooting ……………………… 28
Warranty and Services………………… 29
Terms and Conditions ………………… 30
Warranty Registration ………… Back Cover
User Manual
Household Use Only
Warranty Registration
VWH-500A / 50A
USE IN 220-240V ONLY. WARRANTY SERVICES LIMITED TO
HONG KONG, MACAU, SINGAPORE LOCAL PURCHASE ONLY.
Thank you for choosing Vitantonio Waffle & Hot Sandwich
Baker. Please read this user manual carefully before using
for the first time and keep it for future reference.
Warranty registration details are inside this manual.
Read this instruction manual before use.
電源
5
加熱
OFF
VWH-500A
電源
5
加熱
OFF
VWH-50A
WAFFLE&HOTSANDWICH…BAKER

Important Safeguards
17
VWH-500A / VWH-50A
17
Important Safeguards
** Please read this manual in a quiet area and keep it well for future reference.
• Please read this Important Safeguards carefully before you use the appliance and keep it
well for future reference.
• Please read all instructions before use.
• Potential property damages include: furniture, pets, body damage.
• Please note the below signs classifying the prohibited and required actions.
• Never attempt to repair or disassemble the appliance.
• Never immerse the appliance in water or any liquid.
• If the mains cord is damaged, it must be replaced by manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
• Do not use the appliance if the plug, the mains cord or other parts are damaged
or not functioning properly.
• Do not twist, pull or abuse the mains cord.
• Do not leave the mains cord within the reach of children, close to or in contact
with the hot parts of your appliance, close to a heat source or a sharp edge, or in
contact with the blades.
• Do not let the powercord hang over the edge of table or worktop or touch hot
surfaces.
• Do not plug into mains voltage other than 220-240V. Warranty will be void if
product is damaged plugging into the wrong mains.
• Do not use for commercial purposes. Any inappropriate use or failure to comply
with the instruction, the manufacturer would not accept responsiblity and warranty
is void.
• Children should be supervised to ensure that they do not play with the appliance.
Forbiddened Actions Necessary Actions
Could result in
death or serious
injury.
Could result in
injury or damage in
property.
Warning
Caution
Warning

Important Safeguards
18
VWH-500A / VWH-50A
18
Important Safeguards
• Check if the voltage indicated on the appliance (220-240V) corresponds to
the local mains voltage before you connect the appliances.
• Always unplug the appliance when not in use or before cleaning.
• Always unplug the appliance before you assemble, disassemble or move the
blenders or accessories.
• Always place the appliance on a flat and stable work surface. Do not move
the apliance during operation.
• Do not touch hot surfaces, and beware of steam which may escape from the
appliance during operation.
• Do not use metal objects, knives, forks or other hard and abrasive objects as
this could damage the plates.
• The baking plates must be installed before plugging in.
• Do not use for a prolonged period of time. Let it cool down after one hour.
• Do not bake non-food items.
• The sandwich baker surface and the plate catches are very hot during and
right after baking. Please handle with extreme care and let it cool down for
30 minutes before cleaning or disassembling the plates
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unelss they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Never use unauthorized accessories that are not supplied by Vitantonio or the
local agent.
• Do not leave the appliance run unattended.
Warning
Caution

Before First Use
19
VWH-500A / VWH-50A
19
Before First Use
Do not let the appliance
stand on the side.
Notice of smoke haze
and smell
To clean the baking
plates
To protect the baking
plates
The hinge and clip is
too loose.
Storage and transport
Do not use continuously
for a long time.
This appliance is not designed to stand on the side. There is a risk of
dropping and thus damaging the appliance.
When using the product for the first time you notice a fine haze of smoke
and some smell, which comes from the evaporation of the protective oil
applied during production under high heat. The effect becomes less after
a few times of use.
Before using for the first time. Do not add any ingredents on the baking
plates and turn on the baker for 5 minutes.
Wipe the baking plates with a soft sponge with mild detergent. Dry
thoroughly afterwards.
• Do not use metal objects like forks to touch the plates.
• Do not use abrasive detergent.
• Clean the baking plates properly after use since there is a possiblity
the remains could erode the plate coating.
• Do not use in a dishwasher.
The hinge between the top and lower body is designed to have some
gaps to accomodate the baking ingredients when baking with different
types of plates. Closing the lid without ingredients you will notice some
space between the plates, but this will get filled up after putting in food
ingredients. The clip cannot lock up tightly in some types of plates due to
product design (like waffle plates).
When storing or transporting this appliance, there is a risk that the baking
plates could rub each other and damage the coating if no proper care is
taken. Please put a think layer of newspaper between the plates during
transportation.
You are also suggested to keep the original packaging, which provides the
best protection.
Rest the machine after every hour of use.
Do not add in too much
batter or oil
Putting in too much batter or too much oil in the batter could result in spilling
out while baking. The spilled oil could potentially drip into the heating
elements or inside the main unit. It becomes uneasy to clean or potentially
product damage. During the first few times of use, please start with a
smaller volume of batter to allow you to have a firm grasp of the proper
amount. If baking consecutively, please use a kitchen paper of absorb
excessive oil on the baking plates.
** It is considered product misuse and warranty is void if the product is
damaged due to excessive oil drips into the appliance.

Parts
20
VWH-500A / VWH-50A
20
Parts
電源
5
加熱
OFF
Do not twist the powercord
when the appliance is turned on.
OFF
5
10
Ready
Power
The appliance is turned on when you start
turning the dial. The power light will turn Red.
Turn anti-clockwise to OFF to turn off the
appliance.
*The appliance is turned on
when you start turning the dial.
* Before first use, check the parts below are included.
* Wash the plates and wipe dry before use.
* The unit of measurement is "minute".
* If the required baking time is 5min or below,
turn to 6min or above then turn back to
your required time.
Timer Dial
Mains…Cord
Waffle Plates
Cord Compartment
Wind…the…cord…as…indicated…before…
putting…for…storage.
Insulation
cover
Multi Sand Plates
Side
Cannot stand on
this side
Clip
Handle
Plate Catch
Plug
Plate Catch
Heating
Elements
Ready Light - Green
Power Light - Red
** Lights up when plate
temperature is ready for baking.
** The light turns on and off
regularly during operation.
** Lights up when connected to
power, and turned on the switch.
* This appliance cannot open 180°.

It must be correctly installed to avoid the hot plates being dislocated while baking.
Installing Baking Plates
21
2
Push down the plates until you hear a “click”
sound indicating the plate catch locked into the
metal hedge, as shown in B.
2
Push the plates into the appliance until you hear a “click”
sound indicating the plate catch locked into the metal
hedge, as shown in B.
1
Slide the tabs of the plates into the tab slots A.
1
Slide the tabs of the plates into the tab slots A.
Installing Lower Plates Installing Upper Plates
VWH-500A / VWH-50A
21
Installing Baking Plates
Tabs
Hedge
The structures and locations of the tabs and
hedges are the same on all Vitantonio baking
plates.
A
A
B
B

Removing Baking Plates
22
The baking plates and the plate catches are extremely hot in operation. Please make sure the
unit is completely cooled down before taking out the baking plates.
2
Lift up the plate handles
on the sides and pull it
towards yourself.
2
Lift up the plate handles
on the sides to remove
the plates.
1
Slide the plate catch in the direction as shown on picture
C. The plate will pop up.
1
Slide the plate catch in the direction as shown on picture
C. The plate will pop up.
Removing Lower Plates Removing Upper Plates
VWH-500A / VWH-50A
22
Removing Baking Plates
C
C

Making Wafes
23
VWH-500A
23
Making Waes
Install the Waffle plates on the baker. Make sure they
are installed properly.
Close the lid. Plug into the mains socket, and turn on the
timer dial clockwise.
• Turn the timer dial to 5min or above.
• As soon as you plugged in and turned on, the power
light (red) will grow showing the baking plates being
heated up.
Wait until the ready light (Green) is on, signaling the baking
plates have reached the desired temperature. You may put
in the batter.
• The ready light should be on in around 4 to 5 minutes.
• Please hold the handle tightly when opening the lid.
Put the batter on the lower plate and close the lid.
Use wooden chopsticks or bamboo sticks to remove
the waffle.
• Baking time around 4-5 minutes.
• You may adjust the cooking time for different
recipes or to your taste.
DO NOT touch the appliance and the plates
directly as they are extremely hot.
• Avoid putting in too much batter to
avoid spilling out.
(Approx. 80ml for each wae)
• The steam escaping from the sides is
very hot. Open the lid carefully.
• DO NOT use metal objects such as forks
to remove the wae. This could damage
the plates.
• TURN OFF and UNPLUG after use.
• DO NOT use continuously over one hour.
** Spread a layer of butter or olive oil on the
plate before baking the next wae.
1
2
3
4
5
Caution
Caution
Caution
Power
5
Ready
OFF
Power
5
Ready
OFF
Ready Light / Green
Power Light / Red Timer Dial

Making Wafes
24
VWH-500A / VWH-50A
24
Making Waes
• If the batter has the mix of sugar and chocolate, or high level of sugar, the waffle could get burnt easily so
please take extra care in baking.
• When the baking is done, do not add sugar, syrup, or honey and bake the same waffle again. This could
damage the baking plates.
• After use please clean the plates thoroughly and remove the remains. Keeping the remains on the plates for a
long time could damage the plates.
• DO NOT add too much batter on the plate, as it could expand under heat and spill out. This could cause
damage to the appliance.
Important
Sift the bread flour. Mix in sugar, honey, salt. Add in
eggs and mix with the help of a hand mixer.
Mix in milk, dry yeast.
Mix in butter and beat until smooth.
Leave the batter for fermentation in a 30°C
environment for 40 minutes.
When the ready light (green) is on, pour in the batter
for baking.
1
2
3
4
Sift the bread flour. Mix in sugar, salt, skimmed milk.
Add in the water and dry yeast. Fold in eggs.
Add in softened butter.
Allow the mixture to ferment for 30 min under 30°C.
This recipe can make 6pcs of Liège waffles.
When the ready light (green) is on, pour in the batter
for baking.
Remove the waffle. Add topping like honey or syrup.
1
2
3
4
5
6
7
Brussels Wae (8-10pcs)
Ingredients
bread flour 50g sugar 30g
flour 50g honey 15ml
butter 25g salt 1g
milk 30ml egg 1pc
dry yeast 3g milk 100ml
Preparation
• Mix the bread flour and flour.
• Soften and melt the butter.
• Leave the 30ml milk to room temperature. Mix in dry yeast.
Liège Wae (10pcs)
Ingredients
butter 30g skimmed milk 10g
bread flour 200g water 75ml
sugar 45g dry yeast 6g
salt 2g egg 1 pc
Preparation
• Cut the butter into cubes and soften it.
5
Sift the flour. Mix in sugar, honey, salt. Fold in eggs
and mix with the help of a hand mixer.
Mix with milk.
Mix in the melted butter. Put the batter into the
preheated waffle plates. Each waffle takes around
80ml of batter. Bake for 3-4 minutes.
Add some toppings like butter or jam to your liking.
11
2
3
4
American Wae (8pcs)
Ingredients
flour 100g honey 10g
baking powder 5g salt 1g
butter 30g egg 1pcs
sugar 20g milk 100ml
Preparation
• Mix in flour and baking powder.
• Cut the butter into pieces and melt it.

Making Panini
Making Panini
25
VWH-500A / VWH-50A
25
• After use, make sure it is properly cleaned up otherwise continuous
heating up the remains could damage the non-stick surface.
• Recommended thickness of the toast is 2cm. If the toasts come with
toast skins, you are suggested to bake one set of toast at a time.
• You may make toasts with bread slices or baguette:
* Recommended toast slice thickness is 2cm (6 cut).
* Thick toast slice (3cm or 4 cut), the toast will be slightly pressed flat.
* For thin toast slice (1.5cm or 8 cut), the surface would not be
browned.
Install the Panini plates.
Close the lid. Plug into the mains socket, and turn on the timer
dial clockwise.
• Turn the timer dial to 5min or above.
• As soon as you plugged in and turned on, the power light
(red) will grow showing the baking plates being heated up.
Wait until the ready light (Green) is on, signaling the baking
plates have reached the desired temperature. You may put in
the sandwich for toasting.
• The ready light should be on in around 4 to 5 minutes.
• Please hold the handle tightly when opening the cover.
Place the sandwiches with fillings on the lower grill plates.
Close the lid and the clip.
Use wooden chopsticks or bamboo sticks to remove the
sandwich.
• Baking time around 4-5 minutes.
• You may adjust the cooking time for different recipes or
to your taste.
DO NOT touch the appliance and the plates directly as
they are extremely hot.
• DO NOT use metal objects such as forks to pick
up the toast. This could damage the plates.
• TURN OFF and UNPLUG after use.
• DO NOT use continuously over one hour.
** Spread a layer of butter or olive oil on the plate
before baking the next wae.
1
2
3
4
5
Caution
Power
5
Ready
OFF
Power
5
Ready
OFF
CLICK
Ready Light / Green
Power Light / Red Timer Dial
Caution

Making Panini
Making Panini
26
VWH-500A / VWH-50A
26
1. Spread grain mustard on toast.
2. Put in pastrami and chedder on toast.
3. Put in pickles and add a pinch of pepper.
4. Cover by another slice of toast.
5. Install the Multi Sand plates. When the ready
light is on, put the sandwich to bake.
1. Spead yellow mustard on toast.
2. Place the mix of mayonnaise and tuna, and put
some lettuce on top.
3. Cover with another slice of toast.
4. When the ready light is on, put the sandwich into
the plates.
1. Spead peanut butter on toast.
2. Place banana slices and add a pinch of cinnamon
powder.
3. Cover with another slice of toast.
4. When the ready light is on, put the sandwich into
the plates.
Pastrami Chedder Hot Sandwich / Panini
Ingredients
15mm toast 4 pcs pastrami 2pcs
pickle a few pieces chedder 2pcs
pepper pinch grain mustard pinch
Preparation
• Cut off the toast skins.
• Slice the pickle into slices of 2-3mm each
Teriyaki Chicken Hot Sandwich / Panini
Ingredients
15mm toast 4 pcs teriyaki chicken 1/2 pc
lettuce 1pc cucumber slices
mustard pinch mayonnaise pinch
Preparation
• Cut off the toast skins.
• Slice the cucumber into slices of 2-3mm each
Tuna Avocado Hot Sandwich / Panini
Ingredients
15mm toast 4pcs tuna (canned) 1 can
mayonnaise 1 tablespoon avocado 1/2 pc
butter pinch pepper pinch
Preparation
• Cut off the toast skins.
• Open the can of tuna. Drip off excess oil.
Blend in mayannaise.
• Slice the avocado.
Banana Peanut Butter Hot Sandwich / Panini
Ingredients
15mm toast 4pcs banana 1pc
peanut butter 4 tablespoon cinnamon powder pinch
Preparation
• Cut off the toast skins.
• Slice the banana into slices of 5mm.
1. Spread mustard and mayonnaise on toast.
2. Put in cucumber and lettuce.
3. Put in teriyaki chicken.
4. Cover by another slice of toast.
5. Install the Multi Sand plates. When the ready
light is on, put the sandwich to bake.

How to Clean
27
VWH-500A / VWH-50A
27
How to Clean
This appliance has dierent types of option plates and you are welcome to purchase.
OPTIONAL PLATES
Exterior, heating elements,
insulation covers.
Protecting the baking
plates
• DO NOT clean the appliance under running water.
• DO NOT use abrasive detergents, sand paper, metal objects or chemical substances to
clean the plates.
• DO NOT put into dishwasher.
Baking plates
Clean only when the appliance is unplugged and fully cooled down. Be careful as the appliance is extremely
hot during and right after baking.
Wipe the appliance with a damp cloth with mild detergent. Dry thoroughly afterwards. Do
not immerse in water.
• DO NOT use metal objects like forks to touch the plates.
• DO NOT use abrasive detergent.
• Clean the baking plates properly after use since the remains could erode the plates.
• Use a soft brush to clean the dirts and remains on the plates.
• Use a sponge and clean with water and mild detergent.
• If the dirt is difficult to remove, soak the plates in water for a few hours and wipe with
a sponge.
• Do not use metal objects, abrasive detergents, nylon brush as this could damage the
non-stick surface.
The baking plates are consumable parts.
The baking plates have a non-stick coating, which complies with the Japanese strictest regulations on food safety, and
offers an advantage that the food ingredients do not stick on the plates easily. However this layer of coating could be worn
out slowly over time depending on the usage pattern. When you realise the plates started to lose the coating or baking
starts turning out uneven, you are suggested to buy another set of plates for replacement.
Caution
Wa󽘃e
PVWH-10-WF
Multi Sand
PVWH-10-MS
Hot Sandwich
PVWH-10-HT
Poisson
PVWH-10-PO
Donut
PVWH-10-DT
Pizzelle
PVWH-10-PZ
Tartelette
PVWH-10-TR
Pinini
PVWH-10-PN
Madeleine
PVWH-10-MD
Panini
PVWH-10-PK
Heart Wa󽘃e
PVWH-10-HW
Square Hot Sandwich
PVWH-10-SH
Cupcake
PVWH-10-CC
Financier
PVWH-1-FC
Mini Tart (1pc only)
PVWH-10-MTU

Troubleshooting
28
VWH-500A / VWH-50A
28
Troubleshooting
Problems Causes Solutions
The batter stuck on
the baking plates.
Notice a ne smoke
haze and smell
Ready light (Green)
does not glow.
Ready light (Green)
turns on and o
regularly during
operation.
The clip is too loose
when locked.
Did not spread a thin layer of oil on
baking plates before baking.
Have used continuously for a long
time.
When using the product for the
first time you notice a fine smoke
haze being emited. This is normal
and due to heating of the internal
components.
The green light is not as obvious
as the red light. Simply look from
another angle can solve the problem.
The ready light (Green) glows in 5 minutes when connected to the mains. Afterwards the
light would glow on and off during baking. This is normal.
The hinge between the top and lower body is designed to have some gaps to accomodate
the baking ingredients of different types of plates. If you close the lid without ingredients
you notice some space between the plates but this will get filled up in baking.
For some recipes if not speading some oil on the
plates before baking, the batter could get stuck
on surface. Spead a thin layer of oil before baking
could solve the problem.
The non-stick coating on the plates could wear off
over a long period of time depending on the usage
pattern. If adding a layer of oil before baking still
make the batter stick on the surface. The plates
might need to be replaced.
Before using for the first time. Do not add any
ingredents on the baking plates and turn on the
baker for 5 minutes.
If the ready light is not able to turn on at all,
please contact the service center.
Power light (Red)
does not glow.
The power light (red) indicates the product has plugged into electricity and switched on. If
the indicator light is off, please make sure it has been plugged into the mains socket and
turn it on again.
Exccessive oil or
batter dripped into
the machine or
heater
Putting in too much batter or too much oil in the batter could result in spilling out while
baking. The spilled oil could potentially drip into the heating elements or inside the main
unit. It becomes uneasy to clean or potentially product damage. During the first few times
of use, please start with a smaller volume of batter to have a firm grasp of the proper
amount. If baking consecutively, please use a kitchen paper of absorb excessive oil on
the baking plates.
** It is considered product misuse and warranty is void if the product is damaged
due to excessive oil drips into the appliance.

Warranty and Services
29
VWH-500A / VWH-50A
29
Warranty and Services
1. If you have followed the instructions on
this user manual but still have problem in
using the appliance, please contact the
local distributors accordingly.
2. Please register your appliance online
within 7 days after purchase, or you may
register by fax or email by following the
procedures at the final page of the user
manual.
3. You must retain and present the
purchase receipt as proof of purchase
when requesting for warranty service.
4. Warranty covers the purchases in Hong
Kong and Macau only.
5. Warranty is one year, counting from the
purchase date as shown on the purchase
receipt from authorized dealers.
6. Customers are required to bring in the
appliance to service center for service.
7. The warranty is VOID if the product
is damaged under the below circumstances:
a. not used properly and did not follow the
guidelines in this user manual.
b. found to have been dismantled without prior
authorization.
c. damaged due to misuse or negligence.
d. damaged due to force majeure like
earthquake, thunder, flood, war.
e. used for commercial purpose or under
anbnormal hosuehold use situations.
f. improper care, like never cleaning the product.
g. do not revise this user manual
h. warranty does not cover consumable parts
香港澳門代理 Hong Kong & Macau Distributor
Ace Kitchen Limited
Tel: [phone] | www.acehomehk.com | [email protected]
If you are sending in your product for servicing, kindly make an appointment via
phone or email in advance.
Please register your warranty at warranty.acehomehk.com.

Terms and Conditions
30
SPECIFICATION
VWH-500A / VWH-50A
30
Terms and Conditions
Model: VWH-500A / VWH-50A
Description: Vitantonio Variety Sandwich Baker
Power AC 220-240V, 50/60Hz
Wattage 900W - 1,050W
Weight approx. 2.5kg (with waffle plates)
Product Size 251mm (W) × 246mm (L) × 98mm (H)
Cord Length approx. 1.6 m
Accessories Waffle plates, Multi Sand plates
Country of Origin China
新加坡代理 Singapore Distributor
Maison Ace Pte Ltd
Contact: [phone] (Mon - Fri: 10am - 6pm)
Email: [email protected]
1) This warranty is applicable only against manufacturing faults for one year from date of
purchase fromauthorised dealers/ resellers in Singapore.
2) Please retain the original purchase receipt as you will need to present the receipt at
point of servicing.
3) If you are sending in your product for servicing, kindly make an appointment via phone
or email in advance.
Please register your warranty at www.maisonace.com.
