H20 POWER STEAMER
TECHNICAL MANUAL
SHARPERTEK
2005 PONTIAC ROAD
AUBURN HILLS, MI. 48326
248-340-0593

H20 POWER STEAMER
TABLE OF CONTENTS:
INTRODUCTION:
* PRECAUTIONS……………………………………………………
* SAFETY SUMMARY………………………………………………
* SERVICE CONNECTIONS………………………………….
INSTALLATION & STARTUP INSTRUCTIONS:
* GENERAL INSTALLATION INSTRUCTIONS…………………
* LOCATING THE STEAM GENERATOR……………………….
OPERATING INSTRUCTIONS:
* PROPER OPERATING INSTRUCTIONS……………………..
TROUBLE SHOOTING:
* EASY TROUBLE SHOOTING STEPS………………………….
PARTS LIST:
* PARTS LIST……………………………………………………….

H20 POWER STEAMER
TECHNICAL MANUAL
INTRODUCTION:
This manual contains installation, operation and repair parts lists for the H20 POWER STEAMER.
The H20 POWER STEAMER is specially designed with continuous attention to quality, performan
c
safety. It is constructed of the highest quality materials and rigorously tested at our factory locate
d
PRECAUTIONS:
It is of vital importance that the owner / purchaser of a H20 POWER STEAMER read, and fully un
d
instructions before operating the machine. It is also the responsibility of the owner / purchaser to
e
personnel who come in contact with this machine understand and comply to all the safety related i
warnings that are contained in this instruction manual.
Throughout this manual, there are NOTES, CAUTIONS, and WARNINGS used to emph
a
and critical instructions.
* NOTE :
A note will indicate operating procedures and conditions.
** CAUTION :
A caution will indicate a hazardous situation which may result in personal in
j
the machine.
*** WARNING :
A
warning will indicate a hazardous situation that has some probability of death or seriou
s
injury.

SAFETY SUMMARY:
The following are general safety precautions that are not related to any specific procedures. The
s
recommended precautions should be understood and applied by all personnel during all phases o
f
maintenance.
***WARNING:
DO NOT OPERATE OR SERVICE THIS MACHINE BEFORE READING AND UNDERSTANDIN
G
INSTRUCTION MANUAL.
*** WARNING:
IT IS THE RESPONSIBILITY OF THE OWNER / PURCHASER OF THIS MACHINERY TO TRAI
N
OPERATING PERSONNEL IN THE PROPER MANNER OF OPERATION. IT IS FURTHERMOR
UNDERSTOOD THAT SHARPERTEK ASSUMES NO RESPONSIBILITY FOR INJURY, DISABIL
DEATH RESULTING FROM THE IMPROPER OPERATION OF, OR REMOVAL FROM OR BY-P
A
THEREOF ANY ELECTRICAL OR MECHANICAL SAFETY DEVICES INCORPORATED IN THIS
MANUFCTURING OF THIS MACHINERY.
*** WARNING:
BEFORE SERVICING THIS MACHINE, DISCONNECT ANY SOURCES OF ELECTRIC POWER.
STEAM GENERATOR AND ALL OTHER COMPONENTS TO COOL.
* NOTE:
WHEN SERVICING THIS MACHINE, USE ONLY APPROVED SHARPERTEK REPLACEMENT
P
* NOTE:
USE DISTILLED WATER ONLY. NON-DISTLLED WATER WILLCAUSE MINERAL DEPOSITS
W
CLOG THE STEAM CHAMBER AND OUTPUT NOZZLE. THIS DAMAGE IS SEVERE.
* NOTE:
KEEP AREA SURROUNDING ALL SIDES OF MACHINE FREE AND CLEAR OF ALL MATERIA
L
PROVIDE PROPER VENTILATION.
* NOTE:
KEEP UNIT AWAY FROM CORROSIVE MATERIALS.

** CAUTION:
DO NOT TOUCH THE STEAM NOZZLE ASSEMBLY DURING USE, OR UNTIL THE
STEAM GENERATOR COOLS. THIS UNIT GETS VERY HOT!
** CAUTION:
DO NOT TOUCH THE STEAM NOZZLE UNTIL UNIT IS COOLED DOWN. IF THE
NOZZLE BECOMES PARTIALLY CLOGEGD, REMOVE ONLY WHEN COOL AND
CLEAN THOROUGHLY.
** CAUTION:
DO NOT RESTRICT THE AIRFLOW AROUND THE UNIT IN ANY WAY UNTIL IT IS
COMPLETELY COOL TO THE TOUCH.
SERVICE CONNECTIONS:
ELECTRIC 120 VAC, 60 Htz, 1 Phase, 15 Amps
MODEL H20 POWER STEAMER
DIMENTIONS:
LENGTH : 12.5 lbs (317mm)
WIDTH: 8.75 lbs (222mm)
HEIGHT: 12.4 lbs (315mm)
SHIPPING WEIGHT: 18.5 lbs (8.4 kg)
MACHINE WEIGHT: 16.3 lbs (7.4 kg)
3

INSTALLATION & STARTUP INSTRUCTIONS:
GENERAL INSTALLATION INSTRUCTIONS:
This section contains instructions for installing and preparing the machine for operation. All
machines are tested and adjusted before leaving the factory.
LOCATING THE STEAM GENERATOR:
•Remove the machine from the shipping container, and remove all protective wrapping
from the steam generator. Check for any shipping damage.
** CAUTION:
DO NOT LIFT THE UNIT BY THE STEAM NOZZLE AS THIS MAY DAMAGE THE UNIT
•Place unit in a clear area where nothing can touch or surround the unit. Proper air
ventilation must be allowed to flow around and through the steam generator. DO NOT
SET ANYTHING ON OR LEAN OBJECTS AGAINST THE UNIT.
•Plug the power cord into a 120 Volt 15 Amp (minimum) receptacle.
•Place the foot pedal on the floor so that it rests conveniently on the left side of the
machine
•Place the end of the clear vinyl water intake hose into a container of distilled water. Make
sure the copper tubing extending from the vinyl is at the bottom of the container.
** CAUTION:
USE DISTILLED WATER ONLY. TAP, SPRING, AND FILTERED WATER CAN SEVERLY
DAMAGE THE STEAM GENERATOR. THE USE OF NON-DISTILLED WATER WILL CAUSE
MINERAL DEPOSITS IN THE STEAM CHAMBER AND OUTPUT NOZZLE. THE DAMAGE
WILL BE SEVERE.
4

OPERATING INSTRUCTIONS:
This section contains instructions and information required to operate the H20 POWER
STEAMER. It is most important that the operating personnel become thoroughly familiar with the
proper operating instructions.
OPERATING INSTRUCTIONS:
•Turn the power switch to the on position and the red light will come on to indicate that the
machine is on.
•The warm up time will be approximately ten minutes, but this may vary. As soon as the
machine is turned on, the pump should be primed. Step on the foot pedal and you
should see distilled water flowing through the vinyl tubing. Continue depressing the foot
pedal until the water reaches the inside of the machine.
•The green "ready" light will come on indicating that the chamber is fully heated and that
the unit is ready for use. During use and throughout the day, the green light will cycle (on
and off) in order to maintain maximum chamber temperature. To make steam, wait until
the green light comes on for the first time, then push the foot pedal for approximately
three to five seconds.
* NOTE:
DO NOT HOLD FOOT PEDAL LONGER THAN FIVE SECONDS OR THIS WILL CAUSE STEAM
CHAMBER TO FILL WITH WATER. WHEN THIS HAPPENS, THE HEATING ELEMENT WILL
HAVE TO REHEAT THE CHAMBER. WHEN THE CHAMBER IS HEATING THE WATER
INSIDE WILL SLOWLY TURN TO STEAM AND ESCAPE THROUGH THE NOZZLE. THE
LIGHT WILL CYCLE BACK TO GREEN WHEN HOT AND CAN BE OPERATED NORMALLY
A
GAIN
•In normal use the steam will always be available. However, for long or extended steam
outputs, the pressure and volume will decrease and in some cases the unit may require a
few moments for the chamber to return to the "ready" temperature.
* NOTE:
DURING NORMAL OPERATION SOME STEAM MAY ESCAPE FROM THE NOZZLE WHEN
NOT BEING USED. THIS IS ONLY SMALL AMOUNTS OF WATER LEFT IN THE CHAMBER
TURNING TO STEAM.
* NOTE:
A
FTER RELEASING THE FOOT PEDAL, THIS UNIT WILL CONTINUE TO STEAM FOR
A
PPROXIMATELY FIFTEEN SECONDS. THIS IS NORMAL OPERATION.
5

TROUBLE SHOOTING:
The following section contains a trouble shooting guide on the H20 POWER
STEAMER.
TROUBLE SHOOTING:
PROBLEM POSSIBLE CAUSE SOLUTION
No power Lights Power switch Check to see if
switch is turned on.
Power plug Check to see if plug is
in wall outlet.
Power / Circuit breaker Check power at 120
Volt receptacle.
Check circuit breaker.
_
_______________
_
_______________________________________________
No steam Vinyl water intake hose Check that the hose is
underwater and at the
bottom of water
container.
Pump motor Check; If not running,
see no power/lights
above.
Steam nozzle Clean thoroughly
only when unit
is cool.
6

PARTS LIST H20 POWER STEAMER:
PART NO. ITEM DESCRIPTION
113285 NOZZLE
0664001 RED LIGHT ASSEMBLY
0664002 GREEN LIGHT ASSEMBLY
0664003 ON & OFF SWITCH ASSEMBLY
0575030 HANDLE ( HARDWARE INCLUDED)
0663295-1 POWER CORD ASSEMBLY
065177 VINYL TUBING 5 FT
75914 FOOT PEDAL ASSEMBLY
0663813 THERMOSTAT
75916 FUSE ASSEMBLY
0145004 SAFETY VALVE
0664015 HEATING ELEMENT
0663816 PUMP
A
P2607 RESTRICTOR
0663816-1 PUMP MOUNTING BRACKET
0764045 RUBBER BUMPER (FOOT)
