NA130SS
Telescope
Design
Chromatic aberration of achromatic
refractors increases as their aperture
increases. This becomes especially
apparent for achromatic refractors with
short focal lengths (less than f/8) with
apertures larger than 120mm.
To compensate for this, Vixen’s “Neo-
Achromatic” refractor has an additional
two-element objective lens behind the
primary objective lens, to give a bright
image with excellent color correction
when compared to conventional
achromatic refractors with the same
aperture.
Sharp &Contrasty Planetary Viewing
•Fully Coated Optics
•0.89 arc-sec resolution
•Less chromatic aberration than
conventional achromats
Neo-Achromat:130mm/5.1” @ f/6.2
4-elements in 2-groups
NA130SSWT-SXW "SPHINX"
The NA130SS optical tube comes on the new
“SPHINX” (SX) mount with the SX HAL110 tripod
(adjustable from 70cm to 110cm). A 7x50 finder
scope, 20mm & 5mm LV eyepieces, 2" eyepiece
adapter, flip mirror diagonal, half pillar and extra
1.9 kg counterweight all come standard with the
package.
Model # TS
-
PR
-
2725
Wt:
23.7 kg / 52.3 lbs
GP-DX NA130SS A.T.
For added precision and strength, the NA130SS
optical tube comes on the sturdy GP-DX mount
with a heavy duty aluminum tripod (adjustable
from 70cm to 110cm). Accessories include a 7x50
finderscope, 20mm LV eyepiece, diagonal prism &
triangle accessory tray. Motor drives and a wide
range of accessories are available to outfit the
mount and telescope to your needs. (Above shown
with optional Sky Sensor 2000 Goto system.)
Model # TS-PR-3150 Wt: 29.6 kg / 65.1 lbs
