Vixen VC200L User manual

VIXEN
VC200L VMC200L


Vixen Optics a Division of MrStarGuy, Inc. www.vixenoptics.com
MrStarGuy, Inc.


PREFACE ThankyouverymuchforyourpurchaseofaVixenastronomicaltelescope
ThismanualappliestotheVC200LandVMC200Ltelescopes.Youmayoccasionallyfinddescriptionsin
thetextnotrelevanttoyourparticularmodel.Readtheinstructionsforyourmountalongwiththis
manualifyoupurchasedthetelescopeasacompletepackage.

WARNING! Neverlookdirectlyatthesunwiththetelescopeoritsfinderorguidescope.
Permanentandirreversibleeyedamagemayresult.

CAUTIONDonotleavetheopticaltubeuncappedinthedaytime.Sunlightpassingthroughthe
telescopeorfinderscopemaycauseafire.
Donotusetheproductwhilemovingorwalking,injuriescouldresultfromacollision
withobjectsorfromstumblingorfalling.
Keepsmallcaps,plasticbags,orplasticpackingmaterialsawayfromchildren.These
maycauseadangerofswallowingorsuffocation.
Donotusetheproductinawetenvironmentanddonothandlewithwethands.

HANDLING AND STORAGE
Donotleavetheproductinsideacarinbrightsunshineorinotherhotplaces.Keep
anystrongheatsourcesawayfromtheproduct.
Whencleaning,donotusesolventssuchaspaintthinnerorsimilarproducts.
Donotexposetheproducttorain,water,dirtorsand.
Avoidtouchinganylensormirrorsurfacesdirectlywithyourhands.Incasealensor
mirrorbecomesdirtywithfingerprintsorgeneralsmears,gentlywipeitusinga
commerciallyavailablelenscleanerandalenscleaningpaperorcloth,orconsultyour
localVixenOpticsdealer.
Blowoffdustonlensesusingacommerciallyavailableblowerbrush.Donotuse
compressedair.
Forstorage,keeptheproductinadryplaceanddonotexposetodirectsunlight.

SETTING UP THE TELESCOPE-Refertoyourmountinstructionsalongwiththismanual.
ATTACHING THE TELESCOPE TUBE TO THE MOUNT
Loosenboththedovetail‐platelockscrewand
safetyscrewuntilthetipsofthesescrewsnolonger
extendedintotheinnerpartofthedovetailblock.
Slidethedovetailmountedscopeintothedovetail
mountingblockasshowninthefigure.Tightenthe
dovetaillockscrew(centeredonthenotch)onto
thedovetailtubeplateuntilsnug.
Thentightenthesmallchromesafetyscrewonto
thedovetailmountingblockuntilsnug.
(SXmountandVMC200Lopticaltubeshownhere.)
Page1
MrStarGuy, Inc.




ATTACHING THE FINDER SCOPE
Loosenthefinderbracketlockscrewonthetelescope’sfinderbracketshoe.Attachthefinderscopeas
showninthefigureandtightenthefinderbracketlockscrewsecurely.

ACCESSORY CHART
Youmayneedaneyepieceassoldseparately.Thetelescopedoesnotcomewiththeeyepieceas
standardaccessoryunlessyoupurchasedapackage.
VISUAL CONFIGURATION

Magnificationof
theTelescope
Whenusingan
eyepiecewith
shortfocallength
(smallnumberin
millimeters),the
imagewillbedim
andtherangeof
sharpfocuswill
besmall.The
imagewillbe
hardertoseeso
beginwithan
eyepiecewith
longfocallength.
Dividingthefocal
lengthofthe
telescopebythe
focallengthof
theeyepiece
givesthe
magnification.

Example:Calculatingtheeyepiecemagnificationofatelescopewith1035mmfocallength.

EyepieceFocallengthoftelescopeFocallengthofeyepieceMagnification
PL20mm1800mm20mm90x
PL5mm1800mm   5mm360x


Page2
MrStarGuy, Inc.


PHOTOGRAPHIC CONFIGURATION
PrimefocusPhotography
EyepieceProjectionPhotography
PhotographywithDigitalCamera
PhotographywithCMOScopeorCCDVideoCamera
SomeoftheoptionalaccessoriesshowninthischartwillbeneededifyoutakepictureswithanSLR
camera,digitalcameraorCCDvideocamera.
SpecificationsVC200L VMC200L
Item#2632 2733
OpticalDesignModifiedCassegrain(VISAC) ModifiedCassegrain
EffectiveAperture200mm 200mm
FocalLength1,800mm(f/9.0) 1,950mm(f/9.75)
ResolvingPower.58 arc.;13.3 .58arcsec;13.3
LightGatheringPower816x 816x
TubeDiameter,Length&Weight232mmx620mm;6kg 232mmx535mm;5.9kg
Finderscope7x50mm (field6.8) 7x50mm(field6.8)
Threads60mm,42mmthreadedforT‐ring/50.8mm,
31.7mmpush‐fit
60mm,42mmthreadedforT‐
ring/50.8mm,31.7mmpush‐
fit
MagnificationLV20mm(90x),LV9mm(200x) LV20mm(90x),LV9mm(200x)
AccessoriesFlipMirror,7x50FinderScope FlipMirror,7x50FinderScope
PhotographyPrimeFocusandEyepieceProjection PrimeFocusandEyepiece
Projection
TotalWeight22.0kg 21.9kg
Thespecificationsaresubjecttochangewithoutnotice.
RE-COLLIMATION -PleasecontactaVixenOpticsdealerinyourareaforrepairifyourVixen
telescopeisoutofcollimationordownloadspecificinstructionsfromwww.vixenoptics.com
 CollimatedProperly Mis‐collimated

InFocusOutofFocus InFocusOutofFocus

Page3MrStarGuy,Inc;1010CalleCordillera,Suite106;SanClemente,CA92673(949)429‐6363
