Vizio VSD210 User manual
MODEL VSD210
QUICK START GUIDE
HIGH DEFINITION
UDIO DOCK
VIZIO
IMPORTNT SFETY INFORMTION
Your Dock is designed and manufactured to operate within defined design limits. Misuse may result in electric shock or fire. To prevent
your Dock from being damaged, the following instructions should be observed for the installation, use, and maintenance of your Dock.
Read the following safety instructions before operating your Dock. Keep these instructions in a safe place for future reference.
To reduce the risk of electric shock or component damage, switch off the power before connecting other components to your Dock.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce
heat.
• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally or has been dropped.
• Unplug the power cord before cleaning your Dock.
• When moving your Dock from an area of low temperature to an area of high temperature, condensation may form in the housing.
Wait before turning on your Dock to avoid causing fire, electric shock, or component damage.
• A distance of at least three feet should be maintained between your Dock and any heat source, such as a radiator, heater, oven,
amplifier etc. Do not install your Dock close to smoke. Operating your Dock close to smoke or moisture may cause fire or electric
shock.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your Dock and
to protect it from overheating, be sure these openings are not blocked or covered. Do not place your Dock in a bookcase or cabinet
unless proper ventilation is provided.
• Never push any object into the slots and openings on your Dock cabinet. Do not place any objects on the top of your Dock. Doing so
could short circuit parts causing a fire or electric shock. Never spill liquids on your Dock.
• Your Dock should be operated only from the type of power source indicated on the label. If you are not sure of the type of power
supplied to your home, consult your dealer or local power company.
• Do not apply pressure or throw objects at your Dock. The manufacturer’s warranty does not cover user abuse or improper
installations.
• When connected to a power outlet, power is always flowing into your Dock. To totally disconnect power, unplug the power cord.
• vDo not overload power strips and extension cords. Overloading can result in fire or electric shock.
• The wall socket should be installed near your Dock and easily accessible.
• Only power of the marked voltage can be used for your Dock. Any other voltage than the specified voltage may cause fire or electric
shock.
• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.
• Unplug your Dock during a lightning storm or when it will not be used for long period of time. This will protect your Dock from
damage due to power surges.
• Do not attempt to repair or service your Dock yourself. Opening or removing the back cover may expose you to high voltages, electric
shock, and other hazards. If repair is required, contact your dealer and refer all servicing to qualified service personnel.
• WARNING: Keep your Dock away from moisture. Do not expose your Dock to rain or moisture. If water penetrates into your Dock,
unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock.
• Do not use your Dock if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your
dealer immediately. Do not try to repair your Dock yourself.
• Avoid using dropped or damaged appliances. If your Dock is dropped and the housing is damaged, the internal components may
function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your Dock may cause
fire or electric shock.
• Do not install your Dock in an area with heavy dust or high humidity. Operating your Dock in environments with heavy dust or high
humidity may cause fire or electric shock.
• Follow instructions for moving your Dock. Ensure that the power cord and any other cables are unplugged before moving your Dock.
• When unplugging your Dock, hold the AC/DC power adapter, not the cord. Pulling on the power cord may damage the wires inside the
cord and cause fire or electric shock. When your Dock will not be used for an extended period of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage the remote
control or injure the operator. Do not expose batteries to excessive heat such as sunshine, fire or the like.
• This apparatus shall not be exposed to dripping or splashing and no objects fill with liquids, such as vases, shall be placed on the
apparatus.
• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
• CAUTION - These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence
of uninsulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electrical shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and servicing instructions in the literature accompanying your Sound Bar.
h
iPad, iPhone, iPod, iPod classic, iPod nano, and iPod
touch are trademarks of pple Inc., registered in the U.S.
and other countries.
DO YOU HAVE QUESTIONS?
LET US HELP!
YOUR PRODUCT INCLUDES FREE LIFETIME TECH SUPPORT
Phone:
Email:
Web:
(877) 878-4946 (TOLL-FREE)
techsupport@VIZIO.com
.VIZIO.com/support
Hours of operation:
Monday - Friday: 5 M TO 9 PM (PST)
Saturday - Sunday: 8 M TO 4 PM (PST)
The VIZIO support team is highly trained
and is based in the United States.
e can help ith:
New Product Setup
Connecting Your Devices
Technical Problems
nd More
We speak English • Se habla Español • Nous parlons Français
PCKGE CONTENTS
High Definition udio Dock Remote ith Battery
This Quick Start GuidePoer dapter 3.5mm udio Cable
CONTROLS & CONNECTIONS
Front
Back
Power / Volume
Press to turn Dock
on or off.
Turn to increase or
decrease volume.
Apple Dock Connector
Place iPod®, iPhone®, or
iPad® here to output
audio to the Dock.
DC IN
Connect poer
adapter here.
Support Bumper Knob
Gently turn to adjust the
Support Bumper.
Adjustable Support
Bumper
Ensures your device is
seated properly.
Source
Press to toggle audio
source (pple Dock
Connector or 3.5mm
Input).
Input
Connect a device using a
3.5mm audio cable.
USING THE REMOTE
Mute
Turn sound off or on.
Power
Turn Dock on or off.
Volume Up
Increase Dock
loudness.
Previous / Rewind
Press to go
to last track.
Press and hold
to reind.
Input
Toggle audio
source (pple Dock
Connector
Volume Down
Decrease Dock
loudness.
Next / Fast Forward
Press to go
to next track.
Press and hold
to fast forard.
If your remote stops responding, you may need to
replace the battery.
To replace the battery, remove the cover from the
back of the remote as shon, then replace the old
battery ith a ne CR2032. Be sure that the +
sign on the battery is facing up.
Play / Pause
Press to play or pause.
For the best results,
point the remote at
the sensor here.
FIRST-TIME SETUP
12
Connect the poer adapter to the DC IN
port on the back of the Dock.
Connect the other end of the poer adapter
to an electrical outlet.
3 4
Place your iPod, iPhone, or iPad onto the pple Dock
Connector.
If you have a protective case on your iPod, iPhone, or
iPad, you may need to remove it first.
Gently pull the plastic tab from the back of the
remote control. (The plastic tab can be thron aay.)
5
Turn the knob on the back of the Dock so that your
iPod, iPhone, or iPad is seated correctly against the
Support Bumper.
Your iPod, iPhone, or iPad should rest against the
Support Bumper as shon above. This allos you to
easily vie and touch your device. It can also prevent
damage to the pple Dock Connector.
5
Turn Knob
Not resting against
Support Bumper
Resting against
Support Bumper
6 7
Press the Power button on the remote
to turn on the Dock. hen the dock is on, the light
on the POWER / VOLUME button is on.
Turn on your iPod, iPhone, or iPad
and play your music or video.
If you do not hear audio from the Dock speakers,
press the Input button on the remote. This toggles
the audio source beteen the 3.5mm input and the
pple Dock Connector.
First-time setup is complete.
Power Input
YOUR DOCK ORKS ITH:
t the time of printing. Go to VIZIO.com for an updated list of supported models.
CONNECTING DEVICE USING THE 3.5MM CBLE
Turn on the Dock and your device.
Press the INPUT button on the remote to toggle the
audio source from the pple Dock Connector to the
3.5mm INPUT port.
Turn off the Dock and your device.
Connect the included 3.5mm cable to the INPUT
port on the back of the Dock.
Connect the other end of the cable to your device.
Set the volume level of your device at medium.
To your device
VIZIO RECOMMENDS
Experience the freedom of wireless music with VIZIO’s High
Performance Bluetooth Stereo Headphones.
Stylish, lighteight, and adjustable, these ireless over-the-ear
headphones free you to do hat you ant, here you ant. Use
the built-in microphone ith voice enhancement to talk to your
friends hile you’re on the go. Do hat you love — ith plenty of
rechargeable battery life, your free time on’t be cut short.
HELP & TROUBLESHOOTING
There is no power.
POWER button on the remote control or the POWER/VOLUME button on the top of
your Dock.
POWER/VOLUME button on the dock is on.
There is no sound.
Volume Up on the remote control or on the top of your Dock.
MUTE on the remote to ensure the Dock is not muted.
INPUT on the remote or SOURCE on the back of the Dock to select a different input
source.
playing audio. If you are using a protective case, you may need to remove it.
securely connected. You may need to increase your device’s volume.
All VIZIO products include FREE lifetime technical support.
The VIZIO support team is highly trained and is based in the United States.
We can help with:
Phone:
Email:
Web:
(877) 698-4946 (TOLL-FREE)
techsupport@VIZIO.com
.VIZIO.com/support
Hours of operation:
Monday - Friday: 5 M TO 9 PM (PST)
Saturday - Sunday: 8 M TO 4 PM (PST)
LEGL / COMPLINCELIMITED RRNTY
ON PARTS AND LABOR
Covers units purchased as new in United States and Puerto Rico Only.
VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and workmanship
for a period of one (1) year of non-commercial usage and ninety (90) days of commercial use. If a Product covered by
this warranty is determined to be defective within the warranty period, VIZIO will either repair or replace the Product
at its sole option and discretion.
To obtain warranty service, contact VIZIO Technical Support via e-mail: T[email protected] or via phone at
877 MY VIZIO (877.698.4946) from 6:00AM to 9:00PM Monday through Friday and 8:00AM to 4:00PM Saturday
and Sunday, Pacific Time, or visit www.VIZIO.com. PRE-AUTHORIZATION MUST BE OBTAINED BEFORE SENDING ANY
PRODUCT TO A VIZIO SERVICE CENTER. Proof of purchase in the form of a purchase receipt or copy thereof is required
to show that a Product is within the warranty period.
Parts and Labor
There will be no charge for parts or labor during the warranty period. Replacement parts and Products may be new
or recertified at VIZIO’s option and sole discretion. Replacement parts and Products are warranted for the remaining
portion of the original warranty or for ninety (90) days from warranty service or replacement, whichever is greater.
Type of Service
Defective Products must be sent to a VIZIO service center to obtain warranty service. VIZIO is not responsible for
transportation costs to the service center, but VIZIO will cover return shipping to the customer. PRE-AUTHORIZATION
IS REQUIRED BEFORE SENDING ANY PRODUCT TO A VIZIO SERVICE CENTER FOR WARRANTY SERVICE.
Product returns to VIZIO’s service centers must utilize either the original carton box and shipping material or
packaging that affords an equal degree of protection. VIZIO Technical Support will provide instructions for packing
and shipping the covered Product to the VIZIO service center.
Limitations and Exclusions
VIZIO’s one-year limited warranty only covers defects in materials and workmanship. This warranty does not cover,
for example: cosmetic damage, normal wear and tear, improper operation, improper voltage supply or power surges,
signal issues, damages from shipping, acts of God, any type of customer misuse, modifications or adjustments, as
well as installation and set-up issues or any repairs attempted by anyone other than by a VIZIO authorized service
center. Products with unreadable or removed serial numbers, or requiring routine maintenance are not covered. This
one year limited warranty does not cover Products sold “AS IS”, “FACTORY RECERTIFIED”, or by a non-authorized
reseller.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED OR DESCRIBED ABOVE. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET FORTH ABOVE. VIZIO’S TOTAL LIABILITY FOR
ANY AND ALL LOSSES AND DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER INCLUDING VIZIO’S NEGLIGENCE,
ALLEGED DAMAGE, OR DEFECTIVE GOODS, WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN
NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCT. VIZIO SHALL NOT BE RESPONSIBLE FOR LOSS OF USE,
LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INCIDENTAL
OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT
NOTICE. CHECK WWW.VIZIO.COM FOR THE MOST CURRENT VERSION.
FCC Class B Radio Interference Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Notice
The changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this
equipment. It is the responsibilities of the user to correct such interference.
FCC warning
Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could
void the user’s authority to operate this equipment.
Caution
Always use an AC/DC power adapter that is properly grounded. Use the AC cords listed below for each area.
USA: UL
Canada: CSA
Germany: VDE
UK: BASE/BS
Japan: Electric Appliance Control Act
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to
connect specifi cally to iPod, iPhone, or iPad, respectively, and has been certifi ed by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device or its compliance with safety and
regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless
performance.
110810ST-NC
© 2011 VIZIO INC. ALL RIGHTS RESERVED.
Table of contents
Other Vizio Docking Speakers manuals
