Vizio VM60P HDTV10A User manual

Service Manual
V, Inc
320A Kalmus Drive Costa Mesa, CA 92626
TEL : [phone] FAX :[phone]
Top Confidential
Model #: VIZIO VM60P HDTV10A

VIZIO VM60P HDTV10A HDTV Service Manual
Table of Contents
CONTENTS PAGE
Sections
1. Features 1-1
2. Specifications 2-1
3. On Screen Display 3-1
4. Factory Preset Timings 4-1
5. Pin Assignment 5-1
6. Main Board I/O Connections 6-1
7. Theory of Circuit Operation 7-1
8. Waveforms 8-1
9. Trouble Shooting 9-1
10. Block Diagram 10-1
11. Spare parts list 11-1
12. Complete Parts List 12-1
Appendix
1. Main Board Circuit Diagram
2. Main Board PCB Layout
3. Assembly Explosion Drawing
Block Diagram

VINC Service Manual
VIZIO VM60P HDTV10A
VIZIO VM60P HDTV10A HDTV Service Manual
COPYRIGHT © 2000 V, INC. ALL RIGHTS RESERVED.
IBM and IBM products are registered trademarks of International Business Machines
Corporation.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
VINC and VINC products are registered trademarks of V, Inc.
VESA, EDID, DPMS and DDC are registered trademarks of Video Electronics Standards
Association (VESA).
Energy Star is a registered trademark of the US Environmental Protection Agency (EPA).
No part of this document may be copied, reproduced or transmitted by any means for any
purpose without prior written permission from VINC.
FCC INFORMATION
This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that the interference will not occur in a particular installation. If this equipment
does cause unacceptable interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures -- reorient or relocate the receiving
antenna; increase the separation between equipment and receiver; or connect the into an
outlet on a circuit different from that to which the receiver is connected.
FCC WARNING
To assure continued FCC compliance, the user must use a grounded power supply cord and
the provided shielded video interface cable with bonded ferrite cores. Also, any unauthorized
changes or modifications to Amtrak products will void the user’s authority to operate this
device. Thus VINC Will not be held responsible for the product and its safety.
CE CERTIFICATION
This device complies with the requirements of the EEC directive 89/336/EEC with regard to
“Electromagnetic compatibility.”
SAFETY CAUTION
Use a power cable that is properly grounded. Always use the AC cords as follows – USA (UL);
Canada (CSA); Germany (VDE); Switzerland (SEV); Britain (BASEC/BS); Japan (Electric
Appliance Control Act); or an AC cord that meets the local safety standards.

CONFIDENTIAL – DO NOT COPY Page 1-1
File No. SG-0214
Chapter 1 Features
yWall-mountable
yNew WIDE HD Plasma Panel:1366 x 768 (H x V)
yTruSurround XT sound system and DCDi by Faroujia video image
yHigh definition digital interface – HDMI
yHDCP supportive
yMultiple-screen display (picture-on-picture/picture-in-picture)
ySelectable picture mode
y3-language On Screen Display
y2 S-video and Composite video inputs
y2 Component video inputs
y4 HDMI inputs
ySupporting DVI converted to HDMI
yClosed caption
yCopper metal front bezel

CONFIDENTIAL – DO NOT COPY Page 2-1
File No. SG-0214
Chapter 2 Specification
1. Optical Characteristics
Item Specification Note
Display Pixels 1366 (H) x 768 (V) pixels
Display Cells 1319.6 (H) x 741.9 (V) cells
Pixel Pitch 0.966 mm (H) X 0.966 mm (V)
Pixel Type RGB Closed type
Color Depth 256 (R) x 256 (G) x 256 (B) colors
Active Display Area 1319.6 mm (H) x 741.9 mm ±0.5 (V)
Brightness (panel spec) 1200 cd/m2(Typical)
w/Glass Filter Min.250 cd/m21
Min. 40 cd/m2Full white
Contrast ratio (panel spec) 7000:1 (Typical, dark room)
Color Coordinates (typical)
White (w/Glass Filter) x=0.250±0.03, y=0.270±0.03
White (wo/Glass Filter) x=0.280±0.03, y=0.290±0.03
80% White (w/glass filter) Warm (5400K)
Standard (6500K)
Cool (9300K)
Viewing Angle Free

CONFIDENTIAL – DO NOT COPY Page 2-2
File No. SG-0214
2. INPUT SOURCE
RF Connector
RGB Connector
a. Type: Analog
b. Frequency: H: 30-80KHz V: 60-85Hz
c. Signal level: 0.7Vp-p
d. Impedance: 75ȍ
e. Synchronization H/V separate sync: TTL
H/V composite sync: Sync on Green TTL
f. Video bandwidth: 135MHz
g. Connector type: 15-pin D-Sub, female

CONFIDENTIAL – DO NOT COPY Page 2-3
File No. SG-0214
ˈ
˄˄
˄
ˉ˄˃
˄ˈ
ˈ
˄˃
˄ˈ
˄
ˉ
˄˄
Pin Pin Assignment Pin Pin Assignment
1 Red video input 9 +5V
2 Green video input 10 Ground
3 Blue video input 11 No connection
4 Ground 12 (SDA)
5 Ground 13 Horizontal sync (Composite sync)
6 Red video ground 14 Vertical sync
7 Green video ground 15 (SCL)
8 Blue video ground
HDMI Connector
a. Frequency: H: 15.734KHz V: 60Hz
H: 31KHz V: 60Hz
H: 45KHz V: 60Hz
H: 33KHz V: 60Hz
H:67.5KHz V:60Hz
b. Polarity: Positive or Negative
c. Type: Type A
d. Pin Assignment: Please see below

CONFIDENTIAL – DO NOT COPY Page 2-4
File No. SG-0214
Pin Signal Assignment Pin Signal Assignment
1TMDS Data2+ 2TMDS Data2 Shield
3TMDS Data2- 4TMDS Data1+
5TMDS Data1 Shield 6TMDS Data1-
7TMDS Data0+ 8TMDS Data0 Shield
9TMDS Data0- 10 TMDS Clock+
11 TMDS Clock Shield 12 TMDS Clock-
13 CEC 14 Reserved (N.C. on device)
15 SCL 16 SDA
17 EDID/CEC Ground 18 +5V Power
19 Hot Plug Detect
Pin 1
Pin 19
Pin 2

CONFIDENTIAL – DO NOT COPY Page 2-5
File No. SG-0214
RCA-type (Yellow) Composite Video Connector
a. Frequency: H: 15.734KHz RCA jack (NTSC)
b. Signal level: 1Vp-p V: 60Hz 0.3V below Video (Y+C)
c. Impedance: 75ȍSync (H+V):
d. Connector type: RCA jack
S-Video Connector
a. Frequency: H: 15.734KHz V: 60Hz (NTSC)
b. Signal level: Y: 1Vp-p C: 0.286Vp-p
c. Impedance: 75ȍ
d. Connector type: 4-pin mini DIN
443
21
1, 2 = GND
3 = Luminance (Y)
4 = Chrominance(C)

CONFIDENTIAL – DO NOT COPY Page 2-6
File No. SG-0214
Y-Cb/Pb-Cr/Pr Component video signal
a. Frequency: H: 15.734KHz V: 60Hz (NTSC-480i)
H: 31KHz V: 60Hz (NTSC-480p)
H: 45KHz V: 60Hz (NTSC-720p)
H: 33KHz V: 60Hz (NTSC-1080i)
H: 67.50KHz V: 60Hz (NTSC-1080p)
b. Signal level: Y: 1Vp-p Pb: r0.350Vp-p Pr:
r0.350Vp-p
c. Impedance: 75ȍ
d. Connector type: RCA jack
PC audio in
a. Signal level: 1Vrms
b. Impedance: 47Kȍ
c. Connector type: 3.5 Imini jack
Video audio in
a. Signal level: 0.7Vrms
b. Impedance: 47Kȍ
c. Frequency Response: 20Hz-20KHz
d. Connector type: RCA L/R:

CONFIDENTIAL – DO NOT COPY Page 2-7
File No. SG-0214
3. INPUT CONNECTORS
Inputs I/Os
Wording on
the input OSD Wording on the rear
ʳ
A
V1 (1x Composite Video (1x RCA) + 1x
S-Video (1x 6-Pin DIN)+ 1x Stereo
Audio (RCA L/R) )
AV1 (S-VIDEO)/AV1
(VIDEO) AV1
ʳ
A
V2 (1x Composite Video (1x RCA) +1x
S-Video (1x 6-Pin DIN) + 1x Stereo Audio
(RCA L/R) )
AV2 (S-VIDEO)/AV2
(VIDEO) AV2
ʳ
Component1 (1x Component (3x RCA,
YPbPr Video) (1080p) + 1x Stereo
Audio (RCA L/R) ) COMPONENT 1 COMPONENT 1
ʳ
Component2 (1x Component (3x RCA,
YPbPr Video) (1080p) + 1x Stereo
Audio (RCA L/R) ) COMPONENT 2 COMPONENT 2
ʳHDMI (4x HDMI + 1x Stereo Audio (RCA
L/R) , HDCP & DVI support ) HDMI HDMI
ʳDTV
ʳ
TV (Combo RF tuner, for internal
NTSC/ATSC/QAM)
TV
DTV/TV - CABLE /
ANTENNA
ʳVGA (1x Analog RGB (1x 15-Pin
D-Sub) ) + 1x Stereo Mini Jack) ) RGB RGB PC
Service
interface
2x RJ11 (one for analog, one for DTV)
ʳ
SERVICE 1
(GNSS & 8051)
SERVICE 2 (MTK)
4. OUTPUT CONNECTORS
a. SPDIF Digital Audio Out (Optical)
b. Audio output
5. POWER SUPPLY
Consumption: 650W MAX Power OFF: less than 3W
6. SPEAKER
Output 20W (max) X2

CONFIDENTIAL – DO NOT COPY Page 2-8
File No. SG-0214
7. ENVIRONMENT
Operating
a. Temperature: 0~40к
b. Relative humidity: 20%~80% RH
c. Altitude: 0~6,560 ft
Non-operating
a. Temperature: -20~60к
b. Relative humidity: 10%~90% RH
c. Altitude: 0~9,840 ft
8. DIMENSIONS
Display Module (A) Display Module(A) +
Audio Deflector (B)
Display Module(A) +
Audio Deflector (B) +
Base (C)
Height 877mm 907.1mm 904.1mm
Width 1429mm 1429mm 1429mm
Depth 124mm 124mm 330mm
9. WEIGHT
a. Net 185 +/- 1.5 lbs
b. Gross 218 +/- 2.2 lbs

CONFIDENTIAL – DO NOT COPY Page 3-1
File No. SG-0214
Chapter 3 On Screen Display
Main unit button
Buttons 1 2 3 4 5 6 7
Name MENU CH+/ŸCH-/źVOL+/ŹVOL-/ŻINPUT
OSD Adjustment
Main OSD Tree
Mode ʳʳʳʳ
Video Settings
ҲҥҠҡҫ Picture Mode(Custom, Vivid,
Movie, Game, Sport)
ʳʳʳ
ҲҥҠҡҫ Brightness(O~100) ʳʳʳ
ҲҥҠҡҫ Contrast(O~100) ʳʳʳ
ҲҥҠҡҫ Saturation(OД100) ʳʳʳ
ҲҥҠҡҫ Hue(-50~50) ʳʳʳ
ҲҥҠҡҫ Sharpness(O~24) ʳʳʳ
ҲҥҠҡҫ Advanced ʳʳʳ
ҲҥҠҡҫ ʳNoise Reduction ʳʳ
ҲҥҠҡҫ
ʳʳ
Motion(High,
Medium, Low,
OFF, Adaptive)
ʳ
ҲҥҠҡҫ ʳʳDigital(O~64) ʳ
ҲҥҠҡҫ ʳFleshtone (Off, Low, ʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-2
File No. SG-0214
Mode ʳʳʳʳ
Medium, High)
ҲҥҠҡҫ
ʳ
Dynamic Contrast(0, 1,
2, 3, 4)
ʳʳ
ҲҥҠҡҫ ʳColor Temp ʳʳ
ҲҥҠҡҫ ʳʳWarm ʳ
ҲҥҠҡҫ ʳʳStandard ʳ
ҲҥҠҡҫ ʳʳCool ʳ
ҲҥҠҡҫ ʳʳCustom ʳ
ҲҥҠҡҫ ʳʳʳRed(0~100)
ҲҥҠҡҫ ʳʳʳ Green(0Д100)
ҲҥҠҡҫ ʳʳʳBlue(0~100)
ҲҥҠҡҫ ʳʳʳʳ
Ҭҟ ʳAuto Adjustment ʳʳ
Ҭҟ
ʳ
Position(-100~+100hor
izontal,
-31~+31vertical)
ʳʳ
Ҭҟ ʳPhase (0~100) ʳʳ
Ҭҟ ʳClocks / Line(0~100) ʳʳ
Ҭҟ ʳColorTemp ʳʳ
Ҭҟ ʳʳWarm ʳ
Ҭҟ ʳʳStandard ʳ
Ҭҟ ʳʳCool ʳ

CONFIDENTIAL – DO NOT COPY Page 3-3
File No. SG-0214
Mode ʳʳʳʳ
Ҭҟ ʳʳUser ʳ
Ҭҟ ʳʳʳRed(0~100)
Ҭҟ ʳʳʳ Green(0Д100)
Ҭҟ ʳʳʳBlue(0~100)
Ҭҟ
ʳ
Power
saving(ON/OFF)
ʳʳ
ʳReset ʳʳʳ
Audio Settings
ʳBass(O~20) ʳʳʳ
ʳTreble(O~20) ʳʳʳ
ʳBalance(-10~10) ʳʳʳ
ʳSRSTSXT(On,Off) ʳʳʳ
ʳAuto Volume(On,Off) ʳʳʳ
ʳAudio Out(Fixed VolumeΡ
Variable Volume)
ʳʳʳ
ʳSpeakers(OnΡOff) ʳʳʳ
ʳReset ʳʳʳ
Parental Controls
ҲҥҠҡҫ Parental Lock Enable (No,
Yes)
ʳʳʳ
ҲҥҠҡҫ TV Rating ʳʳʳ
ҲҥҠҡҫ ʳTV Youth ʳʳ
ҲҥҠҡҫ ʳTV Youth 7 ʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-4
File No. SG-0214
Mode ʳʳʳʳ
ҲҥҠҡҫ ʳTV G ʳʳ
ҲҥҠҡҫ ʳTV PG ʳʳ
ҲҥҠҡҫ ʳTV 14 ʳʳ
ҲҥҠҡҫ ʳTV MA ʳʳ
ҲҥҠҡҫ Movie Rating ʳʳʳ
ҲҥҠҡҫ ʳMovie G ʳʳ
ҲҥҠҡҫ ʳMovie PG ʳʳ
ҲҥҠҡҫ ʳMovie PG-13 ʳʳ
ҲҥҠҡҫ ʳMovie R ʳʳ
ҲҥҠҡҫ ʳMovie NC-17 ʳʳ
ҲҥҠҡҫ ʳMovie X ʳʳ
ҲҥҠҡҫ Blocked Unrated(Yes,No) ʳʳʳ
ҲҥҠҡҫ Change Password ʳʳʳ
ҲҥҠҡҫ
ʳ
Please enter new
password
ʳʳ
ҲҥҠҡҫ
ʳ
Please re-enter new
password
ʳʳ
ҲҥҠҡҫ ʳʳʳʳ
Tuner Settings
ATV Cable/Air(Cable, Air) ʳʳʳ
ATV Scan ʳʳʳ
ATV Channel Skip ʳʳʳ
ATV MTS(Mono, Stereo, SAP) ʳʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-5
File No. SG-0214
Mode ʳʳʳʳ
DTV DTV Menu ʳʳʳ
ʳʳ ʳ ʳ ʳ
ʳʳ ʳ ʳ ʳ
ʳʳ ʳ ʳ ʳ
Setup
ʳLanguage(English, Français,
Español)
ʳʳʳ
VIDEO Aspect Ratio(16:9, Zoom,
4:3, Panoramic)
ʳʳʳ
PC Aspect Ratio(16:9, 4:3) ʳʳʳ
ʳPIP ʳʳʳ
ʳ
ʳ
PIP Mode(Off, Large
PIP, Small PIP, POP)
ʳʳ
ʳ
ʳ
PIP Position(Top-Left,
Top-Right,
Bottom-Left,
Bottom-Right)
ʳʳ
ʳʳ PIP Input ʳʳ
AV/ATV Closed Caption ʳʳʳ
AV/ATV
ʳ
Display(Off, CC1, CC2,
CC3, CC4, TEXT1,
TEXT2, TEXT3,
TEXT4)
ʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-6
File No. SG-0214
Mode ʳʳʳʳ
PDP Image Cleaner ʳʳʳ
ʳʳʳʳ
Ҙǵ DTV Menu
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5
DTV Tuner
Setup ʳʳʳʳ
ʳTime Zone ʳʳʳ
ʳʳ Hawaii ʳʳ
ʳʳ
Eastern
Time ʳʳ
ʳʳ Indiana ʳʳ
ʳʳ Central Time ʳʳ
ʳʳ
Mountain
Time ʳʳ
ʳʳ Arizona ʳʳ
ʳʳ Pacific Time ʳʳ
ʳʳ Alaska ʳʳ
ʳCable/Air/Auto ʳʳʳ
ʳʳ Cable ʳʳ
ʳʳ Air ʳʳ
ʳʳ Auto ʳʳ
ʳScan ʳʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-7
File No. SG-0214
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5
ʳManual Scan ʳʳ
ʳʳ Scan Mode ʳʳ
ʳʳ ʳ
Add-on
Mode ʳ
ʳʳ ʳ
Range
Mode ʳ
ʳʳ ʳ ʳ From Channel
ʳʳ ʳ ʳ To Channel
ʳChannel Skip ʳʳʳ
ʳ
Digital Audio
Out ʳʳʳ
ʳʳ PCM ʳʳ
ʳʳ OFF ʳʳ
ʳʳ Dolby Digital ʳʳ
ʳʳ ʳ ʳ ʳ
Closed
Caption ʳʳʳʳ
ʳ
Analog Closed
Caption
CC1~CC4Ε
OFF ʳʳ
ʳ
Digital Closed
Caption
Service
1~Service
6ΕOFF ʳʳ
ʳDigital Caption ʳʳʳ

CONFIDENTIAL – DO NOT COPY Page 3-8
File No. SG-0214
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5
Style
ʳʳ
As
Broadcaster ʳʳ
ʳʳ Custom ʳʳ
ʳʳ ʳ Font Size ʳ
ʳʳ ʳ ʳ Lagrge
ʳʳ ʳ ʳ Small
ʳʳ ʳ ʳ Medium
ʳʳ ʳ Font Color ʳ
ʳʳ ʳ ʳ Black
ʳʳ ʳ ʳ White
ʳʳ ʳ ʳ Green
ʳʳ ʳ ʳ Blue
ʳʳ ʳ ʳ Red
ʳʳ ʳ ʳ Cyan
ʳʳ ʳ ʳ Yellow
ʳʳ ʳ ʳ Magenta
ʳʳ ʳ
Font
Opacity ʳ
ʳʳ ʳ ʳ Solid
ʳʳ ʳ ʳ Translucent
ʳʳ ʳ ʳ Transparent
ʳʳ ʳ Background ʳ
