VM Audio VMHS511 User manual

5.1 Speaker System
Quick Installation
Guide
VMHS511
VM Audio Tech Support
US / Canada
phone: (855) audio-99 / [phone]
email: [email protected]
Use the supplied cables to connect to audio source (refer to
Setup Section).
• Turn on the Speaker System.
• Set the Volume for each Speaker to the zero position to start.
• Turn on Audio Source and launch media.
• Select USB / SD / AUX /DVD Iput Source from Remote
Control or Subwoofer Front Panel.
• Adjust each Speaker Volume as needed.
EXCLUSIVE FEATURES
USB and SD Card
The VMHS511 will accept USB or SD data drives that contain
MP3 music files. Music playback order can be adjusted from the
Remote Control.
Pro-Logic Surround
The VMHS511 is equipped with a Pro-Logic surround mode that
provides 4.1 channels of sound with conventional Left and Right
Stereo Sources.
• Select PRO mode for Movie Surround Soundtrack
• Disble PRO mode for Music or Game 2-Channel Sound.
| 7 | 8 | 9
Rev. 1
5.1 Speaker System
VMHS511
© VM Audio All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
POWER SWITCH
DVD AUDIO INPUT
AUDIO OUTPUT
AUX AUDIO INPUT
FL
L R
CEN
SL
FR
SW
SR
FL
CEN
FR
SL SR
ON
OFF
AC IN
˜
DVD AUDIO OUTPUT
FL CEN
SL
FR SW SR
| 10
System is not powering on?
• Switch Power Button on and verify if the LED Indicator is
Illuminated.
• Confirm that the AC plug is plugged in and that there is power
to that outlet.
Speaker(s) does not produce sound?
• Verify the system is getting power and check above steps.
• Make sure the volume is turned up to an audible listening level
and/or your PC is not in a mute status.
• Verify that all cables are plugged into the correct jacks.
• Try connecting your system to another audio source or device.
If the system works correctly with the other device, then your
first device is most likely the cause of the problem.
Sound is distorted or is not clear?
• Low quality compressed music files will increase the distortion
and noise that are easily noticed with amplified speakers.
Recheck sound quality with a non-compressed music file.
• Check the audio source level and decrease if necessary. You
should never have your source volume above 90% volume level
to minimize distortion.
6. Troubleshooting Caution & Warning
CAUTION
RISK OF ELECTIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
• Avoid high temperatures. Allow for sufficient heat dispersion
when installed in a rack.
• Keep the bass module free from moisture, water, and dust.
• Do not let foreign objects into the port opening of the subwoofer.
• Handle the power cord carefully. Hold the plug when unplugging
the cord.
• Unplug the power cord when not using the unit for long period
of time.
• Do not let flammable sprays come in contact with the unit.
• Never disassemble or modify the unit in any way.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE
5. OperationSetup (option 2)
1. Use the Stereo RCA Cables (included) to plug into
your DVD or Surround Processor Outputs.
2. Plug the other end of the cable into the Input Section
of the Subwoofer.
DVD / Surround
Processor

POWER SWITCH
DVD AUDIO INPUT
AUDIO OUTPUT
AUX AUDIO INPUT
FL
L R
CEN
SL
FR
SW
SR
FL
CEN
FR
SL SR
ON
OFF
AC IN
˜
RCA-to-RCA Cables
(3 pcs)
5. Power Switch
6. AC Power Cord
7. RCA Aux Audio Inputs
8. RCA Surround Audio Inputs
9. RCA Speaker Outputs
1. Indicator Display
2. Function Buttons
(Input / St. By / Pro-Logic / Vol)
INPUT
VOLVOL - ST.BY
PRO NOR SLEEP USB
AUX DVD IR
PRO-LOGIC
3
7
8
4
2
1
| 1 | 2 | 3 | 4 | 5 | 6
INPUT
PRO-LOGIC
VOL VOL
ST-BY
PRO NOR SLEEP USB
AUX DVD IR
9
POWER SWITCH
DVD AUDIO INPUT
AUDIO OUTPUT
AUX AUDIO INPUT
FL
L R
CEN
SL
FR
SW
SR
FL
CEN
FR
SL SR
ON
OFF
AC IN
˜
Five Satellite Speakers and One Subwoofer
RCA to 3.5mm Cable
(1 pc)
5
6
3. SD Card Input
4. USB Input
MUTE
USB SD AUX
PRO
DVD
SLEEP
SLEEP
FL FL FR FR
CEN
CEN
SW VOL
SL SL SR SR
REPEAT RESET
EQ EQ DISP DISP
1 2 3
456
7 8 9
0
MUTE
PRO
USB
SD
AUX
DVD
SLEEP (-/+)
FL (-/+)
FR (-/+)
SW (-/+)
CEN (-/+)
VOL (-/+)
SL (-/+)
SR (-/+)
0-9 BUTTONS
REPEAT
RESET
EQ (-/+)
DISP (-/+)
----- System Power (On/Off)
----- Temporarily Turns Sound (On/Off)
----- Multi-Channel Sound (On/Off)
----- USB Source Selector
----- SD Source Selector
----- Alternate Source Selector
----- DVD Source Selector
----- Play or Pause
----- Previous Song (USB/SD only)
----- Next Song (USB/SD only)
----- Timer to Turn-off System
----- Front Left Volume Controller
----- Front Right Volume Controller
----- Subwoofer Volume Controller
----- Center Volume Controller
----- Master Volume Controller
----- Surround Left Volume Controller
----- Surround Right Volume Controller
----- Song/Track Selector
----- Song Repeat
----- Volume Reset
----- Equalizer On/Off (USB/SD only)
----- Display Illumination Adjustment
POWER SWITCH
DVD AUDIO INPUT
AUDIO OUTPUT
AUX AUDIO INPUT
FL
L R
CEN
SL
FR
SW
SR
FL
CEN
FR
SL SR
ON
OFF
AC IN
˜
5.1 Speaker System
Quick Installation
Guide
VMHS511
Rev. 1
Quick Guide
4. Setup (option 1)
3. ConnectConnections/ControlsConnections/Controls2. Connections/Controls1. Inside The Box
1. Using the appropriate audio cable (RCA-to-RCA or
RCA-to-3.5m Cable, both included) plug one end of the
cable into the audio output of your choice for source.
2. Plug the other end of the cable into the Input Section
of the Subwoofer.
1. Plug the Speaker Wires from each Satellite Speaker
into the RCA Output jacks on the Subwoofer.
2. Plug the Subwoofer Power Cord into an electrical
outlet.
DVD / Surround Processor
TV
Game Console
Tablet
Smartphone
MP3
Notebook
