VM Audio EXMS510 User manual

5.1 Speaker System
Quick Installation
Guide
EXMS510
VM Audio Tech Support
US / Canada
phone: (855) audio-99 / [phone]
email: [email protected]
Use the supplied cables to connect to audio source (refer to
Setup Section).
• Turn on the Speaker System.
• Set the Volume for each Speaker to the zero position to start.
• Turn on Audio Source and launch media.
• Select Input Source from Remote Control or Subwoofer Front
Panel.
• Adjust each Speaker Volume as needed.
EXCLUSIVE FEATURES
Pro-Logic Surround
The Multimedia System is equipped with a Pro-Logic surround
mode that provides 5.1 channels of sound with conventional Left
and Right Stereo Sources.
• Select PRO mode for Movie Surround Soundtrack
• Disble PRO mode for Music or Game 2-Channel Sound.
| 7 | 8 | 9
Rev. 1
5.1 Speaker System
EXMS510
© VM Audio All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
| 10
System is not powering on?
• Switch Power Button on and verify if the LED Indicator is
Illuminated.
• Confirm that the AC plug is plugged in and that there is power
to that outlet.
Speaker(s) does not produce sound?
• Verify the system is getting power and check above steps.
• Make sure the volume is turned up to an audible listening level
and/or your PC is not in a mute status.
• Verify that all cables are plugged into the correct jacks.
• Try connecting your system to another audio source or device.
If the system works correctly with the other device, then your
first device is most likely the cause of the problem.
Sound is distorted or is not clear?
• Low quality compressed music files will increase the distortion
and noise that are easily noticed with amplified speakers.
Recheck sound quality with a non-compressed music file.
• Check the audio source level and decrease if necessary. You
should never have your source volume above 90% volume level
to minimize distortion.
6. Troubleshooting Caution & Warning
CAUTION
RISK OF ELECTIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
• Avoid high temperatures. Allow for sufficient heat dispersion
when installed in a rack.
• Keep the bass module free from moisture, water, and dust.
• Do not let foreign objects into the port opening of the subwoofer.
• Handle the power cord carefully. Hold the plug when unplugging
the cord.
• Unplug the power cord when not using the unit for long period
of time.
• Do not let flammable sprays come in contact with the unit.
• Never disassemble or modify the unit in any way.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE
5. OperationSetup (option 2)
1. Use the Stereo RCA Cables (included) to plug into
your DVD or Surround Processor Outputs.
2. Plug the other end of the cable into the Input Section
of the Subwoofer.
DVD / Surround
Processor
R
L
FR FRSR SR
SL SLFL FL
SW CEN
CEN
AUX AUDIO INPUT DVD AUDIO INPUT AUDIO OUTPUT
POWER SWITCH
ON
OFF
AC IN
DVD AUDIO OUTPUT
FL CEN
SL
FR SW SR

R
L
FR FRSR SR
SL SLFL FL
SW CEN
CEN
AUX AUDIO INPUT DVD AUDIO INPUT AUDIO OUTPUT
POWER SWITCH
ON
OFF
AC IN
INPUT SET
MASTER VOLUME
RCA-to-RCA Cables
(3 pcs)
4. Power Switch
5. AC Power Cord
6. RCA Aux Audio Inputs
7. RCA Surround Audio Inputs
8. RCA Speaker Outputs
1. Power Button
2. Power L.E.D.
3. Function Buttons
3
7
8
4
2
1
| 1 | 2 | 3 | 4 | 5 | 6
Five Satellite Speakers and One Subwoofer
RCA to 3.5mm Cable
(1 pc)
5
6
R
L
FR FRSR SR
SL SLFL FL
SW CEN
CEN
AUXAUDIO INPUT DVDAUDIO INPUT AUDIO OUTPUT
POWER SWITCH
ON
OFF
AC IN
5.1 Speaker System
Quick Installation
Guide
EXMS510
Rev. 1
Quick Guide
4. Setup (option 1)
3. ConnectConnections/ControlsConnections/Controls2. Connections/Controls1. Inside The Box
1. Using the appropriate audio cable (RCA-to-RCA or
RCA-to-3.5m Cable, both included) plug one end of the
cable into the audio output of your choice for source.
2. Plug the other end of the cable into the Input Section
of the Subwoofer.
1. Plug the Speaker Wires from each Satellite Speaker
into the RCA Output jacks on the Subwoofer.
2. Plug the Subwoofer Power Cord into an electrical
outlet.
DVD / Surround Processor
TV
Game Console
Tablet
Smartphone
MP3
Notebook
R
L
FR FRSR SR
SL SLFL FL
SW CEN
CEN
AUXAUDIO INPUT DVD AUDIO INPUT AUDIO OUTPUT
POWER SWITCH
ON
OFF
AC IN
ON / STANDBY MUTE
INPUT
PRO-LOGIC
RESET
SLEEP (-/+)
FL (-/+)
FR (-/+)
SW (-/+)
CEN (-/+)
MASTER VOL (-/+)
SL (-/+)
SR (-/+)
----- System power (On/Off) / Mute
----- Audio source selector
----- Multi-channel sound (On/Off)
----- Volume reset
----- Automatic system turn off
----- Front left volume controller
----- Front right volume controller
----- Subwoofer volume controller
----- Center volume controller
----- Master volume controller
----- Surround left volume controller
----- Surround right volume controller
FL
FR
VOL
VOL
VOL VOL
SLEEP
VOL
VOL
VOL
VOL
VOL
VOL
VOL
VOL
SW CEN.
SL
SR
INPUT PRO-LOGIC RESET
ON/STANDBY
MUTE
MASTER
VOL
Front Panel Top Panel
