VocoPro JAMCUBE User manual

owner's manual
JAMCUBE
4-Channel Portable P.A. System with Multi-Format Player

2
FCC Information ...................................................... 3
Listening for a Lifetime ............................................. 4
Safety Instructions ................................................... 5
Welcome ............................................................... 6
Features and Specifications ...................................... 7
Before Getting Started ............................................. 8
Getting Started ....................................................... 9
Getting Connected
Connecting to an Mp3 Player ............................... 11
Connecting an External Player .............................. 11
Connecting to an External Powered Speakers ........ 11
Connecting a Microphone or Instrument ................. 12
Connecting a Digital Receiver ................................ 12
Connecting a TV or Monitor .................................. 13
Descriptions and Functions
Front/Top Panel .................................................. 14
Rear Panel ......................................................... 17
Remote Control ................................................... 18
SDR-3 (optional accessory) ................................... 21
VM-1 Receiver (optional accessory) ........................ 23
VM-1 Microphone (optional accessory) ................... 25
General Operations ................................................ 26
System Setup Menu .............................................. 29
Troubleshooting .................................................... 32
Table of Contents

3
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS
UNIT!: This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Vocopro may void your authority, granted by the FCC,
to use this product.
2. IMPORTANT: When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable(s) supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your
FCC authorization to use this product in the U.S.A.
3. NOTE: This product has been tested and found to
comply with the requirements listed in FCC Regulations,
Part 15 for Class "B" digital devices. Compliance with
these requirements provides a reasonable level of
assurances that your use of this product in a residential
environment will not result in harmful interference with
other electronic devices. This equipment
generates/uses radio frequencies and, if not installed
and used according to the instructions found in the
owner's manual, may cause interference harmful to the
operation of other electronic devices. Compliance with
FCC regulations does not guarantee that interference
will not occur in all installations. If this product is found
to be the source of interference, which can be
determined by turning the unit "Off" and "On", please try
to eliminate the problem by using one of the following
measures:
Relocate either this product or the device that is being
affected by the interference.
Use power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter(s).
In the case of radio or TV interference, relocate/reorient
the antenna. If the antenna lead-in is 300-ohm ribbon
lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory
results, please contact your local retailer authorized to
distribute Vocopro products. If you can not locate the
appropriate retailer, please contact Vocopro, 1728
Curtiss Court, La Verne, CA 91750.
1. To ensure the finest performance, please read this
manual carefully. Keep it in a safe place for future reference.
2. Install your unit in a cool, dry, clean place - away from
windows, heat sources, and too much vibration, dust,
moisture or cold. Avoid sources of hum (transformers, v
motors). To prevent fire or electrical shock, do not expose to
rain and water.
3. Do not operate the unit upside-down.
4. Never open the cabinet. If a foreign object drops into the
set, contact your dealer.
5. Place the unit in a location with adequate air circulation.
Do not interfere with its proper ventilation; this will cause the
internal temperature to rise and may result in a failure.
6. Do not use force on switches, knobs or cords. When
moving the unit, first turn the unit off. Then gently disconnect
the power plug and the cords connecting to other
equipment. Never pull the cord itself.
7. Do not attempt to clean the unit with chemical solvents:
this might damage the finish. Use a clean, dry cloth.
8. Be sure to read the "Troubleshooting" section on common
operating errors before concluding that your unit is faulty.
9. This unit consumes a fair amount of power even when the
power switch is turned off. We recommend that you unplug
the power cord from the wall outlet if the unit is not going to
be used for a long time. This will save electricity and help
prevent fire hazards. To disconnect the cord, pull it out by
grasping the plug. Never pull the cord itself.
10. To prevent lightning damage, pull out the power cord
and remove the antenna cable during an electrical storm.
11. The general digital signals may interfere with other
equipment such as tuners or receivers. Move the system
farther away from such equipment if interference is
observed.
NOTE:
Please check the copyright laws in your country
before recording from records, compact discs,
radio, etc. Recording of copyrighted material may
infringe copyright laws.
CAUTION
The apparatus is not disconnected from the AC power
source so long as it is connected to the wall outlet,
even if the apparatus itself is turned off. To fully ensure
that the apparatus is indeed fully void of residual power,
leave unit disconnected from the AC outlet for at least
fifteen seconds.
CAUTION:
READ THIS BEFORE OPERATING YOUR UNIT
Voltage Selector (General Model Only)
Be sure to position the voltage selector to match the
voltage of your local power lines before installing the
unit.
240V
120V

4
Listening for a lifetime
Selecting fine audio equipment such as the unit youʼve just purchased is only the start of your
musical enjoyment. Now itʼs time to consider how you can maximize the fun and excitement your
equipment offers. VocoPro and the Electronic Industries Associationʼs Consumer Electronics
Group want you to get the most out of your equipment by playing it at a safe level. One that lets
the sound come through loud and clear without annoying blaring or distortion and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to a higher volume of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
• Pay attention to the different levels in various recordings.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all,
we want you listening for a lifetime.
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and
the Electronic Industries Associationʼs Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise. This list of sound levels is included for your protection.
Some common decibel ranges:
Level
30
40
50
60
70
80
Example
Quiet library, Soft whispers
Living room, Refrigerator, Bedroom away from traffic
Light traffic, Normal Conversation
Air Conditioner at 20 ft., Sewing machine
Vacuum cleaner, Hair dryer, Noisy Restaurant
Average city traffic, Garbage disposals, Alarm clock at 2 ft.
The following noises can be dangerous under constant exposure:
Level
90
100
120
140
180
Example
Subway, Motorcycle, Truck traffic, Lawn Mower
Garbage truck, Chainsaw, Pneumatics drill
Rock band concert in front of speakers
Gunshot blast, Jet plane
Rocket launching pad
-Information courtesy of the Deafness Research Foundation

5
CAUTION
RISK OF SHOCK
CAUTION: To reduce the risk of electric shock, do
not remove cover (or back). No user-serviceable
parts inside. Only refer servicing to qualified service
personnel.
WARNING
To reduce the risk of fire or electric shock, do not
expose this unit to rain or moisture.
Explanation of Graphical Symbols
The lightning flash & arrowhead symbol,
within an equilateral triangle, is intended
to alert you to the presence of danger.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and servicing instructions.
1. Read Instructions - All the safety and operating
instructions should be read before the appliance is
operated.
2. Retain Instructions - The safety and operating
instructions should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in
the operating instructions should be adhered to.
4. Follow Instructions - All operating and use
instructions should be followed.
5. Attachments - Only use attachments/accessories
specified or provided by the manufacturer (such as
the exclusive supply adapter, battery etc.)
6. Water and Moisture - Do not use this unit near water.
For example, near a bathtub or in a wet basement and
the like.
7. Carts and Stands - Use only with the cart, stand,
tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart or rack is
used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
7 A. An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause an overturn.
8. Ventilation - The appliance should be situated so its
location does not interfere with its proper ventilation.
For example, the appliance should not be situated on a
bed, sofa, rug, or similar surface that may block the
ventilation slots.
9. Heat - The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers)
that produce heat.
10. Power Sources - The appliance should be
connected to a power supply only of the type
described in the operating instructions or as marked
on the appliance.
11. Grounding or Polarization - Precautions should be
taken so that the grounding or polarization means of
an appliance is not defeated. A polarized plug has
two blades with one wider than the other. A grounding
plug has two blades and and third grounding prong.
The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
12. Power-Cord Protection - Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the appliance.
13. Cleaning - Unplug this unit from the wall outlet
before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a dry cloth for cleaning.
14. Power lines - An outdoor antenna should be
located away from power lines.
15. Nonuse Periods - The power cord of the appliance
should be unplugged from the outlet when left unused
for a long period of time.
16. Object and Liquid Entry - Care should be taken so
that objects do not fall and liquids are not spilled into
the enclosure through openings.
17. Damage Requiring Service - The appliance should
be serviced by qualified service personnel when:
A. The power supply cord or plug has been damaged; or
B. Objects have fallen into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally
or exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure
damaged.
18. Servicing - The user should not attempt to service
the appliance beyond that described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
Note:
To CATV system installer's (U.S.A.): This reminder is
provided to call the CATV system installer's attention to
Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the
cable ground shall be connected as close to the point of
cable entry as practical.
Safety Instructions

6
And thank you for purchasing the DVD SOUNDMAN from VocoPro, your ultimate
choice in Karaoke entertainment! With years of experience in the music entertainment
business, VocoPro is a leading manufacturer of Karaoke equipment, and has been
providing patrons of bars, churches, schools, clubs and individual consumers the
opportunity to sound like a star with full-scale club models, in-home systems and mobile
units. All our products offer solid performance and sound reliability, and to reinforce our
commitment to customer satisfaction, we have customer service and technical support
professionals ready to assist you with your needs. We have provided some contact
information for you below.
VocoPro
1728 Curtiss Court
La Verne, CA 91750
Toll Free: 800-678-5348
TEL: 909-593-8893
FAX: 909-593-8890
VocoPro Company Email Directory
Customer Service & General Information
Tech Support
Remember Our Website
Be sure to visit the VocoPro website www.vocopro.com for the latest information on
new products, packages and promos. And while you're there don't forget to check out
our Club VocoPro for Karaoke news and events, chat rooms, club directories and even
a KJ Service directory!
We look forward to hearing you sound like a PRO, with VocoPro, the singer’s ultimate
choice.
FOR YOUR RECORDS
Please record the model number and serial number below, for easy reference, in case of loss or theft. These
numbers are located on the rear panel of the unit. Space is also provided for other relevant information
Model Number
Serial Number
Date of Purchase
Place of Purchase
Welcome
VocoPro
1728 Curtiss Court
La Verne, CA 91750
Toll Free: 800-678-5348
TEL: 909-593-8893
FAX: 909-593-8890
VocoPro Company E-mail Directory
Customer Service & General Information
Tech Support
Remember Our Website
Be sure to visit the VocoPro Website www.vocopro.com for the latest
information on new products, packages and promos. And while you’re
there don’t forget to check out our Club VocoPro for Karaoke news and
events, chat rooms, club directories and even a Service directory!
We look forward to hearing you sound like a PRO, with VocoPro, the
singer’s ultimate choice.
Thank you for purchasing the JAMCUBE from VocoPro, your ultimate
choice in vocal entertainment! With years of experience in the music
entertainment business, VocoPro is a leading manufacturer of vocal
equipment, and has been providing patrons of bars, churches, schools,
clubs and individual consumers the opportunity to sound like a star with
full-scale club models, in-home systems and mobile units. All our
products offer solid performance and sound reliability, and to further
strengthen our commitment to customer satisfaction, we have
customer service and technical support professionals ready to assist
you with your needs. We have provided some contact information for
you below.
FOR YOUR RECORDS
Please record the model number and serial number below, for easy
reference, in case of loss or theft. These numbers are located on
the rear panel of the unit. Space is also provided for other relevant
information.
Model Number
Serial Number
Date of Purchase
Place of Purchase

7
JAMCUBE (4-Channel Portable P.A. System with Multi-Format Player)
Your Portable P.A. On The Go!
Need a “to go” P.A. system that’s easy to transport and set up? Vocopro’s all new
JamCube has got you covered!
The JamCube is lightweight, full-featured, and with its adjustable shoulder strap,
super easy to transport. The system is built around a four-channel mixer that
can accommodate both microphones & instruments. its built-in media player will
player just play about every kind of disc out there, including CD, MP3, DVD, CDG,
and Photo-CD. If you prefer to tote your media on a portable storage device, the
onboard USB port and SD card slot can access your files. You can even add a
two-channel wireless microphone module and a digital SD recorder. (Both included
on JamCube 2 package.)
It’s the dream machine for program directors, traveling pastors & aerobic
instructors. So take along the JamCube on your next trip and fill the room with
some kicking sounds.
Features:
• 100W (MAX) of Power for a Loud & Clear Sound with Heavy Bass
• Full Featured Media Player Takes Disc, USB & SD cards and plays CD, MP3,
DVD, CDG, Photo CD
• Remote Control Operates Disc Player and Media Player
• Module Slots Ready for Wireless System and Digital Recorder
• 4 Channel Inputs with Mic/Line Switch
• Echo, Repeat, and Delay Controls
• Independent Music and Mic Master Volume Controls Each with Treble and Bass
Control
• 1/4” Headphone Jack
• 1/8” Audio Input Optimized for iPod®, iPad® and Computers*
• RCA Stereo Input Jacks
• RCA A/V Output Jacks
• 120/240V Switch for Worldwide Use
• S-VIDEO and Component Video Outputs
• Durable Plastic Shock Absorbers Help to Prevent Damage to the Unit
• Carrying Strap Built-in
*iPod® and iPad® are registered trademarks of Apple Inc.
Features and Specifications

8
Thank you for purchasing the JAMCUBE system. The JAMCUBE will provide years of reliability and high quality
entertainment for you if used properly. Please read this manual carefully before using your JAMCUBE to ensure best
performance.
Unpacking the JAMCUBE:
Carefully remove the JAMCUBE from its carton. It is recommended that you store the original packaging materials in
case you need to ship this equipment for any reason.
Before setting up, please make sure you have the following parts and components included with your JAMCUBE:
ITEMS:
1 JAMCUBE
1 AC Power Cable
1 Remote Control
Before Getting Started
JAMCUBE
Optional
(included
only on
JamCube 2)

9
Getting Started
Connecting the Power Cable
Plug the supplied AC power cable into the AC inlet after all other connections are complete and then plug the AC power
cable to an AC wall outlet.
CAUTION: Use the supplied AC cable. Do not use other AC power cables as doing so may result in fire hazard or electrical
shock.
AC IN
120V
240V
For EU 220~240V
AC IN
120V
240V
For US 110~120V
WARNING: Plugging in the power cable with the voltage selector switch set
incorrectly may damage this device.
Make sure the selector switch is set to the voltage of your region:
115V - United States
230V - Europe

10
Getting Connected
JAMCUBE
Microphones
Guitar Bass
Laptop or Mp3 player
Powered Speakers
External Player
HD TV
TV
OR
PLAY/PAUSE STOP PREV NEXT
REPEAT OPEN/CLOSE
DIGITAL KEY
CONTROL
DIGITAL
ECHO
DVX-880 PRO MULTIFORMAT KARAOKE PLAYER
JAMCUBE TOP PANEL
JAMCUBE REAR PANEL
Connect your microphones, instruments, and portable media devices as shown.
Connect video and audio devices as shown.
Choose the video connection that best suits your needs.
Quickstart Diagram

11
Connecting to an MP3 player (or other device)
to the JAMCUBE
You can use the JAMCUBE as an amplifier for your MP3 player,
laptop or other audio device with an 1/8” output.
What you will need:
• 1/8” cable
• MP3 player (or other device, laptop etc. with a 1/8” output)
To connect an MP3 player to the JAMCUBE:
1. Connect one end of the 1/8” cable to the output
on the MP3 player or audio device.
2. Connect the other end of the 1/8” cable to the
1/8” AUX input on the top panel of the
JAMCUBE.
3. Set the INPUT (DVD/AUX) BUTTON on the top
panel of the JAMCUBE to AUX (out position).
Connecting an External Player to the JAMCUBE
You can use an external CD/DVD player or other audio device with
RCA outputs to play back through the JAMCUBE.
What you will need:
• Stereo RCA cable
• External player or other audio device with RCA outputs
To connect an external audio player to the JAMCUBE:
1. Connect one end of the RCA cable to the L/R output
on the external player or audio devic e.
2. Connect the other end of the RCA cable to the L/R
IN jacks on the rear panel of the JAMCUBE.
3. Set the INPUT (DVD/AUX) BUTTON on the top
panel of the JAMCUME to AUX (out position).
Connecting to an External Powered Speakers
The JAMCUBE has built-in speakers, and does not need to be
connected to external speakers. However, if you want to connect
powered speakers to add an extra boost to your performance, you
can do so using the MIXED OUTPUT.
What you will need:
• Stereo RCA cable
• Powered speakers with RCA inputs
To connect to powered speakers:
1. Connect the ends of the RCA cable to the L/R
AUDIO OUT jacks on the rear panel of the JAMCUBE.
2. Connect the other ends of the RCA cable to the Left
and Right inputs of your powered speakers.
Getting Connected
JAMCUBE
Audio Output
1/8” - 1/8”
Stereo Cable
Player Output
L Y Pb/Cb Pr/Cr
R
Mixed Out
Mic + Music
Out
COAXIAL HDMI VIDEO S-VIDEO OPTICAL
L Y Pb/Cb
FL CENTER SL
5.1 CH Audio Output
FR SW SR
FL CENTER
100~240V 50-60Hz
DOUBLE INSULATION. WHEN SERVICING
USE ONLY IDENTICAL REPLACEMENT PARTS.
SL
Pr/Cr
R
Mixed Out
Mic + Music
Out
5.1 CH Audio Output
COAXIAL HDMI VIDEO S-VIDEO OPTICAL
SCART OUTPUT
FR SW SR
Model Number: DVX-890K
AC Power: 100~240V 50/60Hz
Power Consumption: 12W
Manufactured under License from Dolby
Laboratories. DOLBY, PRO Logic and the
double-D symbol are trademarks of
Dolby Laboratories. Confidential unpubl-
ished works. © 1992-1997 Dolby
Laboratories Inc. All Rights Reserved.
WARNING: SHOCK HAZARD. DO NOT OPEN!
RISK OF ELECTRIC SHOCK.
DO NOT OPEN!
CAUTION!
WARNING:
To Reduce The Risk of Fire or Electric Shock, Do
Not Expose This Apparatus to Rain or Moisture.
RCA - RCA
Stereo Audio Cable
Powered Speakers
RCA - RCA/ 1/4”
Stereo Audio Cable
(VARIES)

12
Getting Connected
Connecting a Microphone or Instrument to the
JAMCUBE
You can connect a standard high-impedance microphone,
line output from a wireless microphone system, or a musical
instrument to the 1/4” inputs on CH1-4 on the top panel.
What you will need:
• Microphone or instrument cable with a 1⁄4” plug
• Microphone device or musical instrument
To connect a microphone:
1. If connecting a handheld microphone, connect the
1⁄4” end of the microphone cable to an available
1⁄4” input on the top panel of the JAMCUBE.
2. If connecting a wireless microphone system, plug the
1⁄4” end of the line output to an available 1⁄4” input
on the top panel of the JAMCUBE.
3. Set the MIC-INST/LINE button to MIC/INST.
To connect an instrument:
1. Connect one end of the 1⁄4” instrument cable to the
instrument’s output.
2. Connect the other end of the instrument cable to an
available 1⁄4” input on the top panel of the
JAMCUBE.
3. Set the MIC-INST/LINE button to MIC/INST.
Connecting a Digital Receiver to the JAMCUBE
You can route a digital audio signal to a receiver or mixer using
the digital coaxial output.
What you will need:
• RCA cable
• Receiver or mixer with digital coaxial audio input
To connect to a receiver:
1. Connect one end of the RCA cable to the COAXIAL
output on the rear panel of the JAMCUBE.
2. Connect the other end of the RCA cable to a coaxial
digital audio input on your receiver or mixer.
NOTE: Microphone output is not present in this
digital signal. Microphone output is only available from
the analog RCA outputs. Digital Receiver
IMPEDANCE
SELECT
AC ~115V/60Hz
AC ~ 230V/50Hz
MAX 1000W
AC INLET
SEE MANUAL TO SWITCH VOLTAGE
IN
VIDEO IN
IN IN
COMPONENT VIDEO IN
DVD
1 2 3
1 2 2
3
1 2 3
1 2 3
1
1 1 2
RCA - RCA
Cable
Microphones
Guitar Bass
1/4” - 1/4”
Instrument Cable
or
1/4” - XLR-F

13
Connecting a TV or Monitor to the JAMCUBE
The JAMCUBE has three ways to output video. Choose the method
that best suits your needs.
Using RCA video output
What you will need:
• RCA video cable
• TV or Monitor with RCA inputs
To connect to a TV or Monitor using RCA video output:
1. Connect one end of the RCA cable to the VIDEO
output on the rear panel of the JAMCUBE.
2. Connect the other end of the RCA cable to the VIDEO
INPUT jack on your TV or Monitor.
NOTE: While some TVs automatically switch when
a video signal is detected, you may need to manually
switch your TV to the correct video input. On most
TVs, the INPUT jack is labeled A/V, AUX or VIDEO IN.
Using S-Video output
What you will need:
• S-Video cable
• TV or Monitor with an S-Video input
To connect to a TV or Monitor using S-VIDEO output:
1. Connect one end of the S-Video cable to the S-VIDEO
output on the rear panel of the JAMCUBE.
2. Connect the other end of the S-Video cable to the
S-VIDEO INPUT jack on your TV or Monitor.
NOTE: While some TVs automatically switch when
a video signal is detected, you may need to manually
switch your TV to the correct video input. On most
TVs, the INPUT jack is labeled A/V, AUX or VIDEO
IN.
Using Component (YPBPR) video output
What you will need:
• Component (YPBPR) video cable
• TV or monitor with component (YPBPR) video inputs
To connect to a TV or Monitor using Component (YPBPR)
video output:
1. Connect one end of the component (YPBPR) cable to
the Y, PB, PR outputs on the rear panel of the
JAMCUBE.
2. Connect the other end of the Component (YPBPR)
cable to the Component (YPBPR) jack on your TV or
Monitor.
NOTE: While some TVs automatically switch when
a video signal is detected, you may need to manually
switch your TV to the correct video input. On most
TVs, the INPUT jack is labeled A/V, AUX or VIDEO
IN.
Getting Connected
RCA - RCA
Cable
TV
HD TV
S-VIDEO Cable
HD TV
RCA Component
Video Cable

14
Descriptions and Functions
Front/Top Panel
1. SD CARD SLOT – Insert an SD card into this slot for playback of media files.
2. USB PORT – Insert a USB flash drive for playback of media files.
3. SDR-3 EXPANSION PORT – If you have an SDR-3 installed, or need to install the SDR-3, refer to
pages 21-22 for details.
4. DISC TRAY – Insert your discs for playback. Open the disc tray lid by lifting the tab on the right
side of tray lid. Carefully set your disc onto the tray and close.
5. VFD DISPLAY - Displays track, playback and setting information.
6. USB/DVD BUTTON – When an SD or USB device is connected, use this button to toggle
between DVD, USB, and SD playback.
NOTE: The INPUT (DVD/AUX) BUTTON must be set to DVD.
A video connection is required to see the options when using this button.
This button is only functional when an SD or USB device is connected.
7. PLAY/PAUSE BUTTON - Plays a disc that is stopped or paused and pauses a disc that is playing.
8. STOP BUTTON – Stops a disc that is playing.
9. PREV BUTTON – Press this button to jump to the previous track or chapter.
10. NEXT BUTTON – Press this button to jump to the next track or chapter.
11. REMOTE CONTROL SENSOR - Receives signals from the remote control. For best results, aim
the remote control directly at this sensor.
12. HEADPHONE JACK – Connect headphones with a 1⁄4” plug to this output for private listening.
NOTE: The JAMCUBE’s main speaker output is disabled when headphones are connected.
13. INPUT (DVD/AUX) BUTTON - Use this button to select which audio source you want to use:
DVD: DISC/SD/USB
AUX: 1/8” AUX/REAR RCA INPUT
14. POWER SWITCH - Use this switch to power the JAMCUBE ON or OFF.
15. AUX INPUT (1/8”) – Connect audio from an audio source (PC/MP3 player, etc) with an 1/8”
audio cable.
NOTE: The INPUT (DVD/AUX) BUTTON must be set to AUX for playback.
JAMCUBE
1 3 2
4
5 7 6 8 9 10 15
12 13 14
11

15
Descriptions and Functions
16. ECHO CONTROL – This controls the level of echo effect applied on all four mic inputs. Rotate clockwise
to increase the amount of echo effect applied to the signal, and counter-clockwise to decrease.
17. REPEAT CONTROL – This controls the number of echo repetitions heard before the echo effect fades
out. Rotate clockwise to increase the amount of repeat applied to the signal, and counter-clockwise to
decrease.
18. DELAY CONTROL – This controls the length of the gap between each echo repetition heard before
the echo effect fades out. Rotate clockwise to increase the amount of delay applied to the signal, and
counter-clockwise to decrease.
19. ¼” MIC/LINE INPUTS (CH 1-4) – Use these inputs to connect wired microphones or music
instruments with a ¼” plug.
20. MIC-INST/LINE BUTTON (CH 1-4) – Use this button to set the input for a MIC/INSTRUMENT
signal, or for a LINE LEVEL signal from a wireless receiver.
MIC/INSTRUMENT – Set button to the IN position
LINE – Set button to the OUT position
21. VOLUME CONTROL (CH 1-4) – Use this control to raise and lower the volume of microphone
output. Rotate clockwise to increase the volume, and counter-clockwise to decrease.
22. MIC/LINE HI CONTROL – Use this control to raise and lower the high frequency portion of the
MIC/LINE output. This control can be used to brighten up the sound of vocals or instruments. Rotate
clockwise to increase high frequencies, and counter-clockwise to decrease.
NOTE: This control adjusts the high frequencies for CH 1-4.
23. MIC/LINE LO CONTROL – Use this control to raise and lower the low frequency portion of the
MIC/LINE output. This control can be used to thicken up the sound of vocals or instruments.
Rotate clockwise to increase low frequencies, and counter-clockwise to decrease.
NOTE: This control adjusts the low frequencies for CH 1-4.
JAMCUBE
181716 22 23
1920 21
Top Panel

16
Descriptions and Functions
24. MIC/LINE MASTER VOL CONTROL – Use this control to adjust the volume for all MIC/LINE CH.1-4.
This is a master-level control, allowing for a one-touch volume adjustment for all the MIC/LINE channels
at once. Rotate clockwise to increase the MIC/LINE master volume, and counter-clockwise to
decrease.
25. DVD/AUX HI CONTROL – Use this control to raise and lower the high frequency portion of the music
signal from the DVD player and devices connected to the DVD/AUX inputs. This control can be used
to brighten up the sound of the music. Rotate clockwise to increase high frequencies, and counter-
clockwise to decrease.
26. DVD/AUX LO CONTROL – Use this control to raise and lower the low frequency portion of the music
signal from the DVD player and devices connected to the DVD/AUX inputs. This control can be used to
thicken up the sound of the music. Rotate clockwise to increase low frequencies, and counter-clockwise
to decrease.
27. DVD/AUX MASTER VOL CONTROL – Use this control to adjust the music volume level from the DVD
player and devices connected to the DVD/AUX inputs. Rotate clockwise to increase the MIC/LINE
master volume, and counter-clockwise to decrease.
JAMCUBE
2524 27 26
Top Panel

17
Descriptions and Functions
Rear Panel
1. WIRELESS MODULE PORT – If you have an VM-1 installed, or need to install the VM-1, refer to
pages 23-24 for details.
2. COMPONENT VIDEO OUTPUT (YPBPR) – Use this output to connect to a TV or monitor with
Component inputs (Y/Pb/Pr).
3. COAXIAL DIGITAL AUDIO OUTPUT – Use this audio output to connect to a digital receiver.
NOTE: Microphone audio will not be present in this output.
4. S-VIDEO OUT – Use this video output to connect to a TV or monitor with an S-Video input.
5. RCA A/V OUTPUT - Use this output to connect to additional TVs, monitors, recorders, or other
devices.
6. RCA AUDIO INPUT - Use this input to connect an external audio player.
7. AC VOLTAGE SELECTOR SWITCH - Use this switch to select the proper voltage for your area.
U.S. – 115V
EUROPE – 230V
8. FUSE COVER – Remove to access the fuse.
NOTE: Replace only with type of fuse listed on back panel.
9. AC POWER INPUT – Connect the power cable here.
10. SPEAKER MOUNT - Use this to mount the JAMCUBE on a speaker stand with a 1 3/8” diameter
shaft.
1
3
2 4
5
7
6
8
9
BOTTOM OF JAMCUBE
10
See getting
connected
section for more
information
on connecting
devices.

18
Descriptions and Functions
Remote Control
1. SUBTITLE – Use this button to select subtitles when viewing a DVD movie.
NOTE: This button only works with DVD discs. Not all DVDs contain subtitles.
2. MUTE – Press this button to MUTE audio output.
3. OSD – Use this button to toggle through the on-screen display options.
Track elapsed>Track remaining>Disc elapsed>Disc remaining>Off
4. PBC - This button activates menu navigation on VCD Discs.
NOTE: This button is only functional when playing a VCD disc.
5. LANGUAGE – Use this button to toggle through available audio tracks on a DVD disc. Some DVD
movies contain dialog in different languages, and some karaoke DVDs have audio tracks with and
without vocals.
NOTE: This button only works when playing DVD discs. Not all DVDs contain multiple audio tracks.
6. ZOOM – This button zooms in the video when playing a DVD, VCD or AVI media file.
7. NUMBER PAD – Use these buttons to select track numbers. Press the 10 button to access
track 10. For tracks larger than 10, press the 10+ button and another number. For example, for
track 22, press the 10+ button two times, and then press 2.
8. STEP – Press this button to view playback one frame at a time. Each time STEP is pressed, the
playback will advance one frame. To exit step mode, press the PLAY button.
9. RETURN – Press this button to return to the main menu when playing a DVD.
10. REPEAT – Use this button to enter a REPEAT play mode. Repeat modes depend on the type of
disc you are playing:
CD/CDG/VCD – Repeat One>Repeat All>Off
DVD – Repeat Chapter>Repeat Title>Repeat All>Off
11. 3D – Use this button to enter the audio properties menu. In the audio properties menu,
you can apply surround sound, EQ, and key control settings. Refer to the Operations section for
instructions on how to adjust audio settings.
NOTE: This button does not work when playing a DVD disc.
12. USB/SD/DVD - Use this button to switch between USB/SD/DVD for playback.
NOTE: The INPUT (DVD/AUX) BUTTON must be set to DVD.
A video connection is required to see the options on screen when using this button.
This button is only functional when an SD or USB device is connected.
1
3
4
5
7
6
8
9 10
2
11
12

19
Descriptions and Functions
13. INTRO – Press this button to hear the first 15 seconds of each track. To exit INTRO play mode,
press a second time.
NOTE: This feature does not work with DVD discs.
14. GOTO - Use this button to jump to a specific track or time. Use this button in combination with
the left and right arrow keys and the number pad to enter tracks and times, then confirm with
the enter button.
15. ANGLE - Use this button to change the viewing angle of the DVD.
NOTE: Not all DVDs have multiple angles available.
16. SLOW – Use this button to enter SLOW playback mode. Continue to press the SLOW button to
further slow down the playback. To exit SLOW mode, press PLAY.
17. VIEW – Use this button for viewing specific sections on a VCD disc, such as the selection screen.
NOTE: The disc must be stopped in order to access the VCD View Menu.
18. SETUP – Use this button to enter the main SETUP menu for the JAMCUBE.
19. N/P – Use this button to select between PAL/NTSC video modes.
For U.S., Mexico, and Canada, select NTSC. For European countries, select PAL.
20. DIRECTION PAD – Use the UP, DOWN, LEFT, RIGHT buttons to navigate through menu screens.
Press the ENTER button to make selections.
UP – The UP button also adjusts the KEY CONTROL UP (sharp) control when not in a menu
screen.
DOWN – The DOWN button also adjusts the KEY CONTROL DOWN (flat) when not in a menu
screen.
21. RESUME - Use this button to return to the track listing menu from any SETUP subdirectory.
13
19
14
21
15
18
20
16
17
Remote Control

20
Descriptions and Functions
22. TITLE – Use this button to go to the title screen of a DVD disc.
23. R/L – Use this button to CANCEL VOCAL on a MULTIPLEX disc. This button toggles between left
channel, right channel and stereo outputs.
Selecting MONO L will remove the R channel audio and play the L channel audio on both sides
Selecting MONO R will remove the L channel audio and play the R channel audio on both sides.
Selecting STEREO will play the audio in normal LR stereo mode.
24. PLAY/PAUSE – Press this button to start/pause playback of a disc or media file.
25. << >> - Press the << button to scan backward through a track, and press >> to scan forward
through a track.
26. |<< >>| - Press |<< to jump to the previous track, and >>| to jump to the next track.
27. STOP – Press this button to STOP a track that is playing.
28. PROGRAM – Use this button to set up a custom sequence of tracks for playback. Refer to the
Advanced Operations section for instructions on how to setup a program.
29. ENTER - Use this button to confirm onscreen selections.
23
22
24
26
29
25
28
27
Remote Control
Table of contents
Other VocoPro Speakers manuals

VocoPro
VocoPro Karaoke-Fan User manual

VocoPro
VocoPro Hero-Rec User manual

VocoPro
VocoPro PV-400 User manual

VocoPro
VocoPro PV-1800 User manual

VocoPro
VocoPro Portable Wireless PA System WARRIOR User manual

VocoPro
VocoPro DVD-SOUNDMAN User manual

VocoPro
VocoPro PV-802 User manual

VocoPro
VocoPro wireless performer User manual

VocoPro
VocoPro PA-MAN User manual

VocoPro
VocoPro Mobileman User manual
