Void Stasys 118 User manual

Stasys 118
User Guide V1.0

©2018 Void Acoustics Research Ltd.
Version 1.0
This user guide is subject to change without notice.
For the latest online version, visit: www.voidacoustics.com
Void Acoustics and the Void logo are registered trademarks of Void
Acoustics Research Ltd. in the United Kingdom, USA and other
countries; all other Void trademarks are the property of Void Acoustics
Research Ltd.

Stasys 118 User Guide V1.0 Page 3
Contents
1 Safety and regulations 4
1.1 Important safety instructions 4
1.2 Limitations 4
1.3 EC declaration of conformity 4
1.4 WEEE directive 4
2 Limited warranty 5
3 Unpacking and Checking 6
4About 7
4.1 Welcome 7
4.2 Stasys 118 overview 7
4.3 Key features 7
4.4 Stasys 118 specifications 8
4.5 Stasys 118 dimensions 8
5 Cabling and wiring 9
5.1 Electrical safety 9
5.2 Cable consideration for fixed installations 9
5.3 Impedance graph 9
5.4 Stasys 118 wiring diagram 10
5.5 Bias V3/V9 speakONTM wiring 10
5.6 Bias Q5 speakONTM wiring 11
5.6 Amplifier loading guidelines 12
6 Operating modes 13
6.1 Manual handling guidelines 13
6.2 Typical modes 13
6.3 Cardioid modes 14
7 Adjustments 15
7.1 Wheel removal 15
7.2 Grille removal 16
8 Service 17
8.1 Return authorisation 17
8.2 Shipping and packing considerations 17
9 Appendix 18

Stasys 118 User Guide V1.0 Page 4
1.1 Important safety instructions
The lightning flash with and arrowhead symbol
within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sucient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user of the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Safety instructions - read this first
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat source such as radiators, heat
registers, stoves, or other such apparatus that produce heat.
9. Do not defeat the safety purpose of the grounding-type
plug. A grounding type plug has two blades and a third
grounding prong. The third prong is provided for your safety.
If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect power cords from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit the apparatus.
11. Onlyuseattachmentsandaccessoriesspecifiedby Void
Acoustics.
12. Only use with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplugtheapparatusduringlightningstormsorwhenunused
forlongperiodsoftime.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in
any way, such as when the power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Since the mains power supply cord attachment plug is used
to disconnect the device, the plug should always be easily
accessible.
16. Void loudspeakers can produce sound levels capable
of causing permanent hearing damage from prolonged
exposure. The higher the sound level, the less exposure
needed to cause such damage. Avoid prolonged exposure to
the high sound levels from the loudspeaker.
1.2 Limitations
This guide is provided to help familiarise the user with the
loudspeaker system and its accessories. It is not intended to provide
comprehensive electrical, fire, mechanical and noise training and is
not a substitute for industry-approved training. Nor does this guide
absolve the user of their obligation to comply with all relevant
safety legislation and codes of practice.
While every care has been taken in creating this guide, safety is
user-dependent and Void Acoustics Research Ltd cannot guarantee
complete safety whenever the system is rigged and operated.
1.3 EC declaration of conformity
Manufacturer:
Void Acoustics Research Ltd,
Unit 15 Dawkins Road Ind Est,
Poole, Dorset,
BH15 4JY,
United Kingdom.
We declare the under our sole responsibility the following product
models: Stasys 2, 3, 4, 5, 8, X, Xv2, Xair, 218, 118, Prime
are intended to be used as loudspeakers and are in conformity with
the following EC Directives, including all amendments, and with
national legislation implementing these directives:
• BS EN 60065:2002
• BS EN 55103-1/-2
March 2016
Alex Skan
Technical Director
1.4 WEEE directive
If the time arises to throw away your product, please recycle all the
components possible.
This symbol indicates that when the end-user
wishes to discard this product, it must be sent
to separate collection facilities for recovery
and recycling. By separating this product from
other household-type waste, the volume of
waste sent to incinerators or land-fills will be
reduced and natural resources will thus be
conserved.
The Waste Electrical and Electronic Equipment Directive (WEEE
Directive) aims to minimise the impact of electrical and electronic
goods on the environment. Void Acoustics Research Ltd complies
with the Directive 2002/96/EC and 2003/108/EC of the European
Parliament on waste electrical finance the cost of treatment and
recovery of electronic equipment (WEEE) in order to reduce the
amount of WEEE that is being disposed of in land-fill sites. All of
our products are marked with the WEEE symbol; this indicates that
this product must NOT be disposed of with other waste. Instead
it is the user’s responsibility to dispose of their waste electrical
and electronic equipment by handing it over to an approved
reprocessor, or by returning it to Void Acoustics Research Ltd for
reprocessing. For more information about where you can send
your waste equipment for recycling, please contact Void Acoustics
Research Ltd or one of your local distributors.
1 Safety and regulations

Stasys 118 User Guide V1.0 Page 5
Limited warranty
The warranty
For a period of three (3) years from the date of
delivery to the original purchaser (as shown on the
original invoice or sales receipt; a copy of this may be
required as proof of warranty dates), Void Acoustics
Research Ltd (hereinafter ‘Void’) warrants to the
Original Owner (person or company who originally
purchased the product brand new from either Void
or a Void Authorised Dealer/Distributor) of each new
Stasys Series product (provided it was purchased at
an Authorised Void Dealer) that it is free of defects
in materials and workmanship and that each
product will meet or exceed all factory published
specifications for each respective model. Void agrees
to repair or replace (at its discretion) all defective
parts at no charge for labour or materials; subject to
following provisions:
Warranty violations
Void shall take no responsibility for repair or
replacement as specified under this warranty, if
the damaged product has been subject to misuse,
accident, neglect or failure to comply with normal
maintenance procedures; or if the serial number
has been defaced, altered or removed. Nor will Void
accept responsibility for, or resulting from, improper
alterations or unauthorised parts or repairs. This
warranty does not cover any damage to speakers
or any other consequential damage resulting from
breach of any written or implied warranty.
Void warranty provisions
Void will remedy any defect, regardless of the
reason for failure (except as excluded) by repair, or
replacement. Void will remedy the defect and ship
the product within a reasonable time after receipt of
the defective product at a Void Authorised Service Centre.
To obtain warranty service
If a Void product requires service, the Owner must
contact Void or an Authorised Void Service Centre to
receive an R.A.N. (Return Authorisation Number) and
instructions on how to return the product to the Void
Authorised Service Centre, or to Void.
Void (or its Authorised Service Centre) will initiate
corrective repairs upon receipt of the returned
product. Please save the original carton and all the
packing materials in case shipping is required. All
products being returned to the factory or service
centre for repairs must be shipped prepaid.
If the repairs made by Void or the Void Authorised
Service Centre are not satisfactory, the Owner
is instructed to give written notice to Void. If the
defect or malfunction remains after a reasonable
number of attempts by Void to remedy the defect
or malfunction, the Original Owner shall then have
the option to elect either a refund or replacement of
said Void product free of charge. The refund shall be
an amount equal to but not greater than the actual
purchase price, not including any taxes, interest,
insurance, closing costs and other finance charges
(minus reasonable depreciation on the product).
If a refund is necessary, the Original Owner must
make the defective or malfunctioning product
available to Void free and clear of all liens or other
restrictions.
Equipment modifications
Technical and design specifications are subject to
change without notice.
Void reserves the right to modify or change
equipment (in whole or part) at any time prior to
delivery thereof, in order to include therein electrical
or mechanical improvements deemed appropriate
by Void, but without incurring any liability to modify
or change any equipment previously delivered, or
to supply new equipment in accordance with any
earlier specifications.
Disclaimer of consequential and incidental
damages
You, the Original Owner, are not entitled to recover
from Void any incidental damages resulting from any
defect in the Void product.
This includes any damage to another product or
products resulting from such a defect.
Warranty alterations
No person has the authority to enlarge, amend, or
modify this Warranty. This Warranty is not extended
by the length of time which the Original Owner
is deprived of the use of product. Repairs and
replacement parts provided pursuant to the Warranty
shall carry only the non-expired portion of the
Warranty.
This Statement of Warranty supersedes all
others contained in this user guide.
2 Limited warranty

Stasys 118 User Guide V1.0 Page 6
All Void Acoustics products are carefully manufactured and thoroughly tested before being
despatched. Your dealer will ensure that your Void products are in pristine condition before
being forwarded to you but mistakes and accidents can happen.
Before signing for your delivery:
• Inspect your shipment for any signs of contamination, abuse or transit damage as soon as
you receive it
• Check your Void Acoustics delivery fully against your order
• If your shipment is incomplete or any of its contents are found to be damaged; inform the
shipping company and inform your dealer.
When you are removing your Stasys 118 loudspeaker from its original packaging:
• Stasys 118 loudspeakers come packaged in a lid and base carton that has a protective sleeve
around it; avoid using sharp implements to remove the cardboard to protect the finish
• If you need to place the loudspeaker on a flat surface make sure it is free from debris
• When you have removed the Stasys 118 loudspeaker from the packaging inspect it to
ensure there is no damage and keep all original packaging in case it needs to be returned
for any reason.
See section 2 for warranty conditions and see section 8 if your product needs servicing.
3 Unpacking and checking

Stasys 118 User Guide V1.0 Page 7
4.1 Welcome
Many thanks for purchasing this Void Acoustics Stasys 118. We truly appreciate your support.
At Void, we design, manufacture and distribute advanced professional audio systems
for the installed and live sound market sectors. Like all Void products, our highly skilled
and experienced engineers have successfully combined pioneering technologies with
groundbreaking design aesthetics, to bring you superior sound quality and visual innovation. In
buying this product, you are now part of the Void family and we hope using it brings you years
of satisfaction. This guide will help you both use this product safely and ensure it performs to
its full capability.
4.2 Stasys 118 overview
The Stasys 118 is a single 18” reflex loaded low frequency enclosure built around traditional
principles but designed with Stasys philosophy and attention to detail. Resonance mapping
has influenced the optimal brace positioning and minimal destructive nodal conditions,
creating a superior structure with minimum mass, the least possible cabinet colouration,
and vastly increased output. Marrying a technologically advanced enclosure with powerful
transducer results in a phenomenal package with state-of-the-art performance.
4.3 Key features:
• High power reflex loaded 18” low frequency enclosure
• 1.2 kW AES power handling
• Optimally damped, minimal mass cabinet
• 1 x 18” neodymium low frequency transducer with 4” coil
• 18 mm birch plywood construction
4 About

Stasys 118 User Guide V1.0 Page 8
4.4 Stasys 118 specifications
Frequency response 40 Hz - 200 Hz ±3 dB
Eciency198 dB 1W/1m
Crossover points 70 Hz - 160 Hz, 24 dB/oct
Nominal impedance 8 Ω
Power handling21200 W AES
Maximum output3129 dB cont, 132 dB peak
Driver configuration 1 x 18” LF
Dispersion Array dependent
Connectors 2 x 4-pole speakON™ NL4
Height 638 mm (25.1”)
Width 560 mm (22”)
Depth 600 mm (23.6”)
Weight 47 kg (103.6 lbs)
Enclosure 18 mm birch plywood
Finish Textured ‘TourCoat’ polyurea
Grille Perforated steel with foam filter
1Measured in half space 2AES2 - 1984 compliant 3Calculated
4.5 Stasys 118 dimensions
4 About
560 (22”)
638 (25.1”)
600 (23.6”)
607 (23.9”)
560 (22”)
646 (25.4”)
560 (22”)
600 (23.6”)
280 (11”)
290 (11.4”)
607 (23.9”)
560 (22”)
Figure 4.1: Dimensions

Stasys 118 User Guide V1.0 Page 9
5.1 Electrical safety
To avoid electrical hazards please note the following:
• Do not access the inside of any electrical equipment. Refer servicing to
Void-approved service agents.
5.2 Cable considerations for fixed installations
We recommend specifying installation-grade Low Smoke Zero Halogen (LSZH) cables for
permanent installations. The cables should use Oxygen Free Copper (OFC) of grade C11000
or above. Cables for permanent installations should be compliant with the following standards:
• IEC 60332.1 Fire retardancy of a single cable
• IEC 60332.3C Fire retardancy of bunched cables
• IEC 60754.1 Amount of Halogen Gas Emissions
• IEC 60754.2 Degree of acidity of released gases
• IEC 61034.2 Measurement of smoke density.
We suggest using the following maximum copper cable lengths to keep level losses below 0.6 dB.
Metric mm2Imperial AWG 8 Ωload 4 Ωload 2 Ωload
2.50 mm213 AWG 36 m 18 m 9 m
4.00 mm211 AWG 60 m 30 m 15 m
5.3 Impedance graph
5 Cabling and wiring
Figure 5.1: Impedance graph
10 10020 50 200 500 1k 2k 5k 10k 20k
20
40
60
80
100
Frequency (Hz)
Impedance (Ω)

Stasys 118 User Guide V1.0 Page 10
+
-
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
In
Out/Link
18” LF
5.4 Stasys 118 wiring diagram
speakONTM pins 1+/1- speakONTM pins 2+/2-
In LF (18”) n/c
Out LF link n/c
Figure 5.2: Wiring diagram
5.5 Bias V3/V9 speakONTM wiring
1+
1-
1+
1-
Figure 5.3: Bias V3
1+
1-
1+
1-
Figure 5.4: Bias V9
Bias V3/V9 Output 1 or 2
Output LF (18”)
Max parallel units 4 (2 Ωload to amplifier)
5 Cabling and wiring

Stasys 118 User Guide V1.0 Page 11
5 Cabling and wiring
5.6 Bias Q5 speakONTM wiring
1+
1-
1+
1-
Figure 5.5: Bias Q5
Bias Q5 Output 1
Output LF (18”)
Max parallel units 4 (2 Ωload to amplifier)

Stasys 118 User Guide V1.0 Page 12
5 Cabling and wiring
Figure 5.6: 2 x Stasys 118: 8 Ωper channel / 1 amplifier
Figure 5.7: 4 x Stasys 118: 4 Ωper channel / 1 amplifier
Figure 5.8: 6 x Stasys 118: 4 Ωper channel / 2 amplifier
Ensure all amplifier channels are loaded equally. Limiters engage correctly. Cabinets acoustic
principles are the same.
Figure 5.9: 8 x Stasys 118: 4 Ωper channel / 2 amplifier
5.6 Amplifier loading guidelines

Stasys 118 User Guide V1.0 Page 13
6 Operating modes
6.1 Manual handling guidelines
To avoid manual handling hazards please note the following:
• Be sure to secure any loudspeaker systems following correct local
procedures/guideline
• Low frequency enclosures are heavy and require a minimum of two people to
move; for more information on safe handling consult INDG143.
6.2 Typical modes
Although the modes of arrangement shown here are typical operating modes for low
frequency enclosures, the Stasys 118 system’s symmetrical design lends itself to wide range of
configurations. Simple planer arrays and stacks to directional and steerable arrays are possible
given suitable electronics and presets. Contact your local Void distributor/dealer for more
information.
Single Horizontal
Vertical Block
Figure 6.1: Typical modes

Stasys 118 User Guide V1.0 Page 14
6.3 Cardioid modes
As low frequency enclosures are omnidirectional, rear projection can cause a range of
diculties. If there is a wall behind the array, the sound wave can reflect o the surface and
may cause cancellation in front if it arrives out of phase with the wave from the source.
Another problem may occur during performances where an array is deployed in front of
the stage, possibly creating a maximum sound pressure level that makes it dicult for some
performers. Adopting a cardioid configuration can overcome this problem as it creates a heart
shaped horizontal dissipation reducing the rear projection. A variety of cardioid configurations
are available, as shown below. For other layouts or more information, please contact your
local Void distributor/dealer.
6 Operating modes
Figure 6.2: Cardioid mode layouts

Stasys 118 User Guide V1.0 Page 15
Step 3:
Replace the M8 bolts by hand until finger tight
before using hand tools.
Note: Replacing bolts is of particular
importance as without them there
can be air leakage and detuning.
7 Adjustments
To avoid damage when making adjustments please note the following:
• Removing the grille can cause debris to collect within the enclosure, take care
to remove anything that may have collected internally
• Do not use impact tools.
7.1 Wheel removal
B
Figure 7.1: Bolt removal
Step 1:
Remove all four M6 bolts with a 13 mm
spanner/wrench.
Step 2:
Remove/add the wheels and keep in a safe
place. Repeat the process for the other three
wheels.
Figure 7.2: Wheel removal
Figure 7.3: Bolt tightening

Stasys 118 User Guide V1.0 Page 16
Figure 7.4: Bolt removal
Step 1:
Undo all twelve M6 tab bolts using a 4 mm
Allen key, take care NOT to remove the tab
bolts as they may become lost within the
enclosure.
Figure 7.5: Grille removal
Step 2:
Remove grille.
Step 3:
Replace the M6 bolts by hand until finger tight
before using hand tools.
Figure 7.6: Bolt replacement
7 Adjustments
7.2 Grille removal

Stasys 118 User Guide V1.0 Page 17
Void Stasys 118 loudspeakers should only be serviced by a fully-trained technician.
No user serviceable parts inside. Refer servicing to your dealer.
8.1 Return authorisation
Before returning your faulty product for repair, please remember to get an R.A.N. (Return
Authorisation Number) from the Void dealer who supplied the system to you. Your dealer will
handle the necessary paperwork and repair. Failure to go through this return authorisation
procedure could delay the repair of your product.
Note that your dealer will need to see a copy of your sales receipt as proof of purchase so
please have this to hand when applying for return authorisation.
8.2 Shipping and packing considerations
• When sending a Void Stasys 118 loudspeaker to an authorised service centre, please write a
detailed description of the fault and list any other equipment used in conjunction with the
faulty product.
• Accessories will not be required. Do not send the instruction manual, cables or any other
hardware unless your dealer asks you to.
• Pack your unit in the original factory packaging if possible. Include a note of the fault
description with the product. Do not send it separately.
• Ensure safe transportation of your unit to the authorised service centre.
8 Service

Stasys 118 User Guide V1.0 Page 18
The loudspeaker system shall be of the sub bass type consisting of one high power 18”
(457.2 mm) direct radiating, reflex loaded, low frequency (LF) transducer in a birch plywood
enclosure.
The low frequency transducer shall be constructed on a cast aluminium frame, with a treated
paper cone, long excursion 101.6 mm (4”) voice coil, wound with copper wires on a high
quality voice coil former and a neodymium magnet for high power handling and long-term
reliability.
Performance specifications for a typical production unit shall be as follows: the usable
bandwidth shall be 40 Hz to 200 Hz (±3 dB) and have a maximum on axis SPL of 129 dB
continuous (132 dB peak) measured at 1 m using IEC268-5 pink noise. Power handling shall
be 1200 W AES at a rated impedance of 8 Ωwith pressure sensitivity of 98 dB measured at
1W/1m. The system shall be powered by its own dedicated power amplification module with
DSP management. The wiring connection shall be via two Neutrik speakON™ NL4 (one for
input and one for loop-out to another speaker), to allow for pre-wiring of the connector
before installation.
The enclosure shall be constructed from 18 mm multi-laminate birch plywood, finished in a
textured polyurethane and shall contain fixture points for a pressed weather-resistant, powder
coated steel grille with foam filter to protect the low frequency transducer. The cabinet shall
have four handles (two per side) for ecient manual handling. External dimensions of (H) 638
mm x (W) 560 mm x (D) 600 mm (25.1” x 22” x 23.6”). Weight shall be 47 kg (103.6 lbs).
The loudspeaker system shall be a Void Acoustics Stasys 118.
Architectural Specifications
9 Appendix

www.voidacoustics.com
Head Oce
Void Acoustics Research Ltd
Unit 15 Dawkins Road Industrial Estate
Poole
Dorset
BH15 4JY
England
[phone]
[e-mail]
Registered in England & Wales No. 07533536
North America
Void Acoustics North America
503-854-7134
[email protected]
