Volvo V60 Twin Engine User manual

OWNER'S MANUAL

VÄLKOMMEN!
We hope you will enjoy many years of driving pleasure in your Volvo. The
car has been designed for the safety and comfort of you and your pas-
sengers. Volvo is one of the world's safest passenger vehicles. Your
Volvo is also designed to meet applicable safety and environmental
requirements.
In order to increase your enjoyment of your Volvo, we recommend that
you read the instructions and maintenance information in this owner's
manual. The owner's manual is also available as a mobile app (Volvo
Manual) and on the Volvo Cars support site (support.volvocars.com).

2
INTRODUCTION
This is how you find owner's information 12
Digital owner's manual in the car 13
Volvo Cars support site 15
Reading the owner's manual 16
Recording data 19
Accessories and extra equipment 20
Volvo ID 21
Environmental philosophy 22
The owner's manual and the environment 25
Laminated glass 25
Twin Engine - overview 26
Twin Engine - introduction 28
SAFETY
General information on seatbelts 30
Seatbelt - putting on 31
Seatbelt - loosening 32
Seatbelt - pregnancy 32
Seatbelt reminder 33
Seatbelt tensioner 33
Safety - warning symbol 34
Airbag system 34
Driver airbag 35
Passenger airbag 36
Passenger airbag - activating/deac-
tivating*37
Side airbag (SIPS) 39
Inflatable Curtain (IC) 40
General information on WHIPS
(whiplash protection) 41
WHIPS - seating position 42
Roll Over Protection System (ROPS) 43
When the systems deploy 43
General information on safety mode 44
Safety mode - attempting to start the car 45
Safety mode - moving the car 45
General information on child safety 46
Child seats 47
Child seats - location 52
Child seat - two-stage booster seat*53
Two-stage booster seat*- raising 54
Two-stage booster seat*- lowering 55
Child seat - ISOFIX 56
ISOFIX - size classes 57
ISOFIX - types of child seat 58
Child seats - upper mounting points 60
TABLE OF CONTENTS

3
INSTRUMENTS AND CONTROLS
Instruments and controls, left-hand
drive car - overview 62
Instruments and controls, right-hand
drive car - overview 65
Combined instrument panel 68
Digital combined instrument panel -
overview 69
Eco guide & Hybrid guide 73
Combined instrument panel - mean-
ing of indicator symbols 74
Combined instrument cluster -
meaning of warning symbols 75
Outside temperature gauge 77
Trip meter 77
Clock 78
Combined instrument panel - license
agreement 78
Symbols in the display 79
Volvo Sensus 81
Key positions 82
Key positions - functions at different
levels 83
Seats, front 84
Seats, front - electrically operated*85
Seats, rear 87
Steering wheel 89
Heating*of the steering wheel 90
Light switches 91
Position lamps 93
Daytime running lights 93
Tunnel detection*94
Main/dipped beam 94
Active main beam*95
Active Xenon headlamps*97
Headlamps - adjusting headlamp pattern 98
Rear fog lamp 98
Brake lights 99
Hazard warning flashers 99
direction indicators 100
Interior lighting 101
Home safe light duration 102
Approach lighting 102
Wipers and washers 103
Power windows 105
Door mirrors 107
Windows and rearview and door mir-
rors - heating 108
Rearview mirror - interior 108
Compass*109
Sunroof*110
Menu navigation - combined instru-
ment panel 112
Menu overview - combined instru-
ment panel 113
Messages 113
Messages - handling 114
MY CAR 115
Trip computer 116
Trip computer - digital combined
instrument panel 118
Trip computer - trip statistics*121

4
CLIMATE CONTROL
General information on climate control 124
Actual temperature 125
Sensors - climate control 125
Air quality 125
Air quality - passenger compartment filter 126
Air quality - Clean Zone Interior
Package (CZIP)*126
Air quality - IAQS*126
Air quality - material 127
Menu settings - climate control 127
Air distribution in the passenger
compartment 127
Electronic climate control - ECC 130
Heated front seats*131
Heated rear seat*132
Fan 132
Auto-regulation 133
Temperature control in the passen-
ger compartment 133
Air conditioning 134
Demisting and defrosting the windscreen 134
Air distribution - recirculation 135
Air distribution - table 136
General information about precondi-
tioning 138
Preconditioning - parking inside 139
Preconditioning - parking outside 139
Preconditioning - direct start 140
Preconditioning - immediate stop 141
Preconditioning - timer 142
Timer - setting 142
Timer - starting 143
Timer - switching off 143
Preconditioning - messages 144
General information about heaters 146
Electrically-driven heater 146
Fuel-driven heater 146
Fuel-driven heater - auto mode/
deactivation 147
LOADING AND STORAGE
Storage spaces 150
Tunnel console 152
Tunnel console - cigarette lighter
and ashtray*152
Glovebox 152
Inlaid mats*153
Vanity mirror 153
Tunnel console - 12 V-sockets 153
Loading 154
Loading - long load 155
Roof load 156
Load retaining eyelets 156
12 V electrical socket - cargo area*156
Safety net*157
Safety grille 159
Cargo cover 159

5
LOCKS AND ALARM
Remote control key 162
Remote control key - losing 162
Remote control key - personalisation*163
Locking/unlocking - indicator 164
Lock indicator 164
Immobiliser 165
Remote-controlled immobiliser with
tracking system*165
Remote control key - functions 166
Remote control key - range 167
Remote control key with PCC*-
unique functions 167
Remote control key with PCC*- range 168
Detachable key blade 169
Detachable key blade - detaching/
attaching 169
Detachable key blade - unlocking doors 170
Privacy locking*171
Remote control key - replacing the
battery 172
Keyless drive*173
Keyless Drive*- remote control key
range 174
Keyless drive*- secure handling of
the remote control key 174
Keyless Drive*- interference to
remote control key function 175
Keyless Drive*- locking 175
Keyless drive*- unlocking 176
Keyless Drive*- unlocking with the
key blade 176
Keyless Drive*- lock settings 177
Keyless Drive*- antenna location 177
Locking/unlocking - from the outside 178
Manual locking of the door 178
Locking/unlocking - from the inside 179
Global opening 180
Locking/unlocking - glovebox 181
Locking/unlocking - tailgate 181
Deadlocks*183
Child safety locks - manual activation 184
Child safety locks - electrical activation*184
Alarm 185
Alarm indicator 186
Alarm - automatic re-arming 186
Alarm - remote control key not working 187
Alarm signals 187
Reduced alarm level 187
Type approval - remote control key
system 188
DRIVER SUPPORT
Adjustable steering force*190
Electronic stability control (ESC) -
general 190
Electronic stability control (ESC) -
operation 191
Electronic stability control (ESC) -
symbols and messages 193
Speed limiter*195
Speed limiter*- getting started 195
Speed limiter*- changing speed 196
Speed limiter*- temporary deactiva-
tion and standby mode 196
Speed limiter*- alarm for speed
exceeded 197
Speed limiter*- deactivation 197
Cruise control*198
Cruise control*- managing speed 199
Cruise control*temporary deactiva-
tion and standby mode 199
Cruise control*- resume set speed 200
Cruise control*- deactivate 200
Distance Warning*201
Distance Warning*- limitations 202
Distance Warning*- symbols and
messages 203
Adaptive cruise control - ACC*204

6
Adaptive cruise control*- function 205
Adaptive cruise control*- overview 206
Adaptive cruise control*- managing
speed 207
Adaptive cruise control*- set time
interval 209
Adaptive cruise control*- temporary
deactivation, and standby mode 209
Adaptive cruise control*- overtaking
another vehicle 210
Adaptive cruise control*- deactivate 211
Adaptive Cruise Control*- queue
assistance 211
Adaptive cruise control*- fault trac-
ing and action 214
Adaptive cruise control*- symbols
and messages 215
Radar sensor 217
Radar sensor - limitations 217
Type approval - radar system 219
City Safety™222
City Safety™- function 223
City Safety™- operation 223
City Safety™- limitations 224
City Safety™- laser sensor 226
City Safety™- symbols and messages 228
Collision warning system*229
Collision warning system*- function 230
Collision warning system*- detection
of cyclists 231
Collision warning system*- detection
of pedestrians 232
Collision warning system*- operation 233
Collision warning system*- limitations 235
Collision warning system*- camera
sensor limitations 236
Collision warning system*- symbols
and messages 238
BLIS*240
BLIS*- operation 241
CTA*242
BLIS - symbols and messages 244
Road Sign Information (RSI)*244
Road sign information (RSI)*- operation 245
Road sign information (RSI)*- limitations 248
Driver Alert System*248
Driver Alert Control (DAC)*248
Driver Alert Control (DAC)*- operation 249
Driver Alert Control (DAC)*- symbols
and messages 250
Lane Departure Warning (LDW)*251
Lane Departure Warning (LDW) -
function 251
Lane Departure Warning (LDW) -
operation 252
Lane Departure Warning (LDW) -
limitations 253
Lane Departure Warning (LDW) -
symbols and messages 254
Park Assist*255
Park assist syst*- function 255
Park assist syst*- backward 256
Park assist syst*- forward 257
Park assist syst*- fault indication 258
Park assist syst*- cleaning the sensors 258
Park assist camera*259
Park assist camera - settings 261
Park assist camera - limitations 262

7
STARTING AND DRIVING
Starting the engine 264
Switching off the engine 265
Steering lock 265
Jump starting with another battery 266
Drive systems 267
Drive system - drive modes 268
Energy flow 271
Drive system - symbols and messages 272
Gearboxes 274
Gear shift indicator*274
Automatic gearbox - Geartronic 275
Gear selector inhibitor 277
Hill start assist (HSA)*278
All-wheel drive - (AWD) 278
Foot brake 279
Foot brake - anti-lock braking system 282
Foot brake - emergency brake lights
and automatic hazard warning flashers 282
Foot brake - emergency brake assistance 282
Parking brake 283
Driving economically 287
Driving in water 288
Overheating 289
Driving with open tailgate/boot lid 289
Overload - starter battery 290
Before a long journey 290
Winter driving 290
Range for electric operation 291
Fuel filler flap - Opening/closing 292
Fuel filler flap - manual opening 292
Filling up with fuel 293
Fuel - handling 293
Fuel - diesel 294
Diesel particle filter (DPF) 296
Catalytic converters 297
Charging the hybrid battery 297
Charging current 298
Charging the hybrid battery - prepa-
rations 300
Charging cable with control unit 301
Charging cable with control unit -
status messages 303
Charging cable with control unit -
temperature monitoring 305
Charging cable with control unit -
ground fault breaker 305
Charging the hybrid battery - starting 306
Charging the hybrid battery - ending 308
Long-term storage of vehicles with
hybrid batteries 309
Driving with a trailer*310
Driving with a trailer*- automatic gearbox 311
Towing bracket/Towbar*311
Detachable towbar*- storage 312
Detachable towbar*- specifications 312
Detachable towbar*- attachment/
removal 313
Trailer Stability Assist - TSA 316
Towing 317
Towing eye 317
Recovery 318

8
WHEELS AND TYRES
Tyres - maintenance 320
Tyres - direction of rotation 321
Tyres - tread wear indicators 322
Tyres - air pressure 322
Wheel and wheel rim dimensions 323
Tyres - dimensions 323
Tyres - load index 324
Tyres - speed ratings 324
Wheel bolts 325
Winter tyres 325
Changing wheels - removing wheels 326
Changing wheels - fitting 328
Warning triangle 330
Tools 330
Jack*331
First aid kit*332
Tyre pressure monitoring*332
Tyre pressure monitoring system
(TPMS)*- general information 333
Tyre pressure monitoring (TPMS)*-
adjust (recalibration) 334
Tyre pressure monitoring system
(TPMS)*- tyre status 334
Tyre pressure monitoring system
(TPMS)*- activate/deactivate 335
Tyre pressure monitoring (TPMS)*-
recommendations 335
Tyre pressure monitoring system
(TPMS)*- rectifying low tyre pressure 336
Tyre pressure monitoring system
(TPMS)*- driveable punctured tyres*337
Type approval - tyre pressure moni-
toring system (TPMS)*338
Emergency puncture repair 344
Emergency puncture repair kit - location 344
Emergency puncture repair kit - overview 345
Emergency puncture repair - operation 346
Emergency puncture repair - rechecking 348
Emergency puncture repair kit -
inflating the tyres 350
MAINTENANCE AND SERVICE
Volvo service programme 352
Book service and repair*352
Raising the car 355
Bonnet - opening and closing 357
Engine compartment - overview 357
Engine compartment - checking 358
Engine oil - general 359
Engine oil - checking and filling 360
Coolant - level 361
Brake and clutch fluid - level 362
Power steering fluid - level 363
Climate control system - fault tracing
and repair 364
Lamp replacement - general 364
Lamp replacement - headlamps 366
Lamp replacement - cover for main/
dipped beam bulbs 367
Lamp replacement - dipped beam 367
Lamp replacement - main beam 368
Lamp replacement - extra main beam 369
Lamp replacement - direction indica-
tors front 369
Lamp replacement - rear lamp 370
Lamp replacement - location of rear
lamps 371

9
Lamp replacement - number plate
lighting 371
Lamp replacement - lighting in cargo
area 371
Lamp replacement - vanity mirror lighting 372
Lamps - specifications 372
Wiper blades 373
Washer fluid - filling 375
Starter battery - general 376
Battery - symbols 378
Starter battery - replacement 378
Hybrid battery 380
Electrical system 380
Fuses - general 381
Fuses - in engine compartment 382
Fuses - under glovebox 385
Fuses - in the control module under
the glovebox 387
Fuses - in cargo area 389
Fuses - in the engine compartment's
cold zone 393
Car wash 395
Polishing and waxing 396
Water and dirt-repellent coating 397
Rustproofing 398
Cleaning the interior 398
Paint damage 399
SPECIFICATIONS
Type designations 404
Dimensions 407
Weights 408
Towing capacity and towball load 409
Engine specifications 410
Motor specifications - Electric drive
motor 411
Engine oil - adverse driving conditions 411
Engine oil - grade and volume 413
Coolant - grade and volume 414
Transmission fluid - grade and volume 415
Brake fluid - grade and volume 416
Power steering fluid - grade 416
Fuel tank - volume 417
Specifications for air conditioning 418
Fuel consumption and CO2 emissions 420
Tyres - approved tyre pressures 423
Hybrid Battery - specification 424

10
ALPHABETICAL INDEX
Alphabetical Index 425

INTRODUCTION

INTRODUCTION
12
This is how you find owner's
information
Owner's information is available in several differ-
ent product formats, both digital and printed.
The owner's manual is available in the car's
screen, as a mobile app and on the Volvo Cars
support site. There is a Quick Guide and a sup-
plement to the owner's manual available in the
glovebox, with specifications and fuse informa-
tion, amongst other things. A printed owner's
manual can be ordered.
The car's screen1
A digital version of the owner's
manual is available in the car's
screen. Press the MY CAR but-
ton in the centre console, press
OK/MENU and select
Owner's manual. The infor-
mation is searchable and can
also be subdivided into categories.
Read more in the Digital owner's manual in the
car.
Mobile app
In App Store or Google Play,
search for "Volvo Manual",
download the app to your
smartphone or tablet and select
the car.
The app contains video tutorials
as well as options for visual navigation with exte-
rior and interior images of the car. It is easy to
navigate between the different sections in the
owner's manual and the content is searchable.
Read more about Owner's Manual in mobile devi-
ces.
Volvo Cars support site
Go to support.volvocars.com
and select your country. Here
you can find owner's manuals,
both online and in PDF format.
On the Volvo Cars support site
there are also video tutorials
and further information and
help regarding your Volvo and your car owner-
ship. The page is available for most markets.
Read more on the Volvo Cars support site.
Printed information
There is a supplement to the
owner's manual2in the glove-
box that contains information
on fuses and specifications, as
well as a summary of important
and practical information.
There is also a Quick Guide available in printed
format that helps you to get started with the most
commonly used functions in the car.
Depending on equipment level selected, market,
etc. additional owner's information may also be
available in printed format in the car.
A printed owner's manual and associated supple-
ment can be ordered. Contact a Volvo dealer to
order. See how the owner's manual is structured
in Reading the owner's manual.
1A complete printed manual is included with the car for markets without owner's manual in the screen.
2A complete printed manual is included with the car for markets without owner's manual in the screen.

INTRODUCTION
}}
13
Changing the language in the car's
screen
Changing the language in the car's display may
mean that some information does not correspond
to national or local laws and regulations. Don't
change to a language that's difficult to under-
stand, it may then be difficult to find your way
back in the structure on the screen.
IMPORTANT
The driver is always responsible that the vehi-
cle is driven safely in traffic and that applica-
ble laws and regulations are followed. It is
also important that the car is maintained and
handled in accordance with Volvo's recom-
mendations in the owner's information.
If there should be a difference between the
information in the screen and the printed
information then it is always the printed infor-
mation that applies.
Related information
•Digital owner's manual in the car (p. 13)
•Volvo Cars support site (p. 15)
•Reading the owner's manual (p. 16)
Digital owner's manual in the car
The owner's manual can be read on the screen
in the car3. The content is searchable and it is
easy to navigate between different sections.
Open the digital owner's manual - press the MY
CAR button in the centre console, press OK/
MENU and select Owner's manual.
For basic navigation, see Operating the system.
See below for a more detailed description.
Owner's manual, start page.
There are four options for finding information in
the digital owner's manual:
•Search - Search function for finding an arti-
cle.
•Categories - All articles sorted into catego-
ries.
•Favourites - Quick access to favourite-
bookmarked articles.
•Quick Guide - A selection of articles for
common functions.
Select the information symbol in the lower right-
hand corner in order to obtain information about
the digital owner's manual.
NOTE
The digital owner's manual is not available
while driving.
Search
Searching using the character wheel.
Character list.
Changing the input mode (see following
table).
3Applies to certain car models.

||
INTRODUCTION
14
Use the character wheel to enter a search term,
e.g. "seatbelt".
1. Turn TUNE to the desired letter, press OK/
MENU to confirm. The number and letter
buttons on the control panel in the centre
console can also be used.
2. Continue with the next letter and so on.
3. To change the input mode to numbers or
special characters, or to perform a search,
turn TUNE to one of the options (see explan-
ation in the following table) in the list for
changing the input mode (2), press OK/
MENU.
123/AB
C
Change between letters and num-
bers with OK/MENU.
MORE Change to special characters with
OK/MENU.
OK Perform the search. Turn TUNE to
select a search result article, press
OK/MENU to go to the article.
a|A Changes between lowercase and
uppercase letters with OK/MENU.
|| }Changes from the character wheel
to the search field. Move the cur-
sor with TUNE. Delete any mis-
spelling with EXIT. To return to the
character wheel, press OK/MENU.
Note that the digit and letter but-
tons on the control panel can be
used for editing in the search field.
Enter with the numerical keyboard
Numerical keyboard.
Another way of entering characters is to use the
centre console's buttons 0-9, *and #.
When e.g. 9is pressed, a bar appears with all
characters4under the button, e.g. W, x, y, zand
9. Quick presses on the button move the cursor
through these characters.
•Stop with the cursor on the desired character
in order to select it - the character is shown
on the enter line.
•Delete/undo using EXIT.
To enter a number, hold in the corresponding
number key.
Categories
The articles in the owner's manual are structured
into main categories and subcategories. The
same article can be in several appropriate cate-
gories in order to be found more easily.
Turn TUNE to navigate in the category tree and
press OK/MENU to open a category - selected
- or article - selected . Press EXIT to go
back to the previous view.
Favourites
Located here are the articles that are saved as
favourites. To select an article as a favourite, see
the heading "Navigating in an article" below.
Turn TUNE to navigate in the favourite list and
press OK/MENU to open an article. Press EXIT
to go back to the previous view.
4The character for each button may vary depending on market/country/language.

INTRODUCTION
}}
* Option/accessory, for more information, see Introduction. 15
Quick Guide
Located here is a selection of articles for getting
to know the car's most common functions. The
articles can also be accessed via categories, but
are collected here for quick access.
Turn TUNE to navigate in the Quick Guide and
press OK/MENU to open an article. Press EXIT
to go back to the previous view.
Navigating in an article
Home - leads to the start page for the
owner's manual.
Favourite - adds/removes an article as a
favourite. You can also press the FAV button
in the centre console to add/remove an arti-
cle as a favourite.
Highlighted link - leads to linked article.
Special texts - if the article contains warn-
ings, important or note texts then an associ-
ated symbol is shown here as well as the
number of such texts in the article.
Turn TUNE to navigate between the links or
scroll in an article. When the screen has scrolled
to the start/end of an article the home and
favourite options are accessed by scrolling a fur-
ther step up/down. Press OK/MENU to activate
the selection/highlighted link. Press EXIT to go
back to the previous view.
Volvo Cars support site
There is additional information regarding your
car on the Volvo Cars website and support
page. From the website, it is also possible to
navigate through to My Volvo, a personal web
page for you and your car.
Support on the Internet
Go to support.volvocars.com or use the QR code
below to visit the page. The support page is avail-
able for most markets.
QR code that leads to the support page.
The information on the support page is searcha-
ble and can also be subdivided into different cat-
egories. Available here is support for options rela-
ted to e.g. Internet connected services and func-
tions, Volvo On Call (VOC)*, the navigation sys-
tem*and apps. Video and step-by-step instruc-
tions explain different procedures, e.g. how the
car is connected to the Internet via a mobile
phone.

||
INTRODUCTION
* Option/accessory, for more information, see Introduction.
16
Downloadable information from the
support page
Maps
For cars equipped with Sensus Navigation*, there
is the facility to download maps from the support
page.
Mobile apps
For selected Volvo models from model year 2014
and 2015, the owner's manual is available in the
form of an app. The VOC*app can also be
accessed from here.
Owner's manuals from previous model years
Owner's manuals from previous model years are
available here in PDF format. The Quick Guide
and supplement can also be accessed from the
support page. Select car model and model year in
order to download the publication required.
Contact
On the support page there is contact information
for customer support and the nearest Volvo
dealer.
My Volvo on the Internet5
From www.volvocars.com it is possible to navigate
through to My Volvo Web which is a personal
Web page for you and your car.
Create a personal Volvo ID, log in to My Volvo
Web and get an overview of service, agreements
and warranties, amongst other things. At My
Volvo Web there is also information about acces-
sories and software adapted for your car model.
Related information
•Volvo ID (p. 21)
Reading the owner's manual
A good way of getting to know your new car is
to read the owner's manual, ideally before your
first journey.
Reading the owner's manual is a good way to
become familiar with new functions, get advice
on how best to handle the car in different situa-
tions and learn how to make the best use of all
the car's features. Please pay attention to the
safety instructions contained in the owner's man-
ual.
Development work is constantly in progress to
improve our product. Modifications may mean
that information, descriptions and illustrations in
the owner's manual differ from the equipment in
the car. We reserve the right to make modifica-
tions without prior notice.
©Volvo Car Corporation
IMPORTANT
Do not remove this manual from the car -
should a problem arise then the information
required about where and how to seek pro-
fessional help would be missing.
5Applies to certain markets.

INTRODUCTION
}}
* Option/accessory, for more information, see Introduction. 17
Owner's Manual in mobile devices
NOTE
The Owner's manual is available for download
as a mobile application (applies for certain car
models and mobile devices), see
www.volvocars.com.
The mobile application also includes video
and searchable content and easy navigation
between different sections.
Options/accessories
All types of option/accessory are marked with an
asterisk*.
In addition to standard equipment, the owner's
manual also describes options (factory fitted
equipment) and certain accessories (retrofitted
extra equipment).
The equipment described in the owner's manual
is not available in all cars - they have different
equipment depending on adaptations for the
needs of different markets and national or local
laws and regulations.
In the event of uncertainty over what is standard
or an option/accessory, contact a Volvo dealer.
Special texts
WARNING
Warning texts appear if there is a risk of
injury.
IMPORTANT
"Important" texts appear if there is a risk of
damage.
NOTE
NOTE texts give advice or tips that facilitate
the use of e.g. features and functions.
Footnote
There is footnote information in the owner's man-
ual that is located at the bottom of the page. This
information is an addition to the text that it refers
to via a number. If the footnote refers to text in a
table then letters are used instead of numbers
for referral.
Message texts
In the car there are displays that show menu
texts and message texts. In the owner's manual
the appearance of these texts differs from the
normal text. Examples of menu texts and mes-
sage texts: Media, Sending location.
Decals
The car contains different types of decal which
are designed to convey important information in a
simple and clear manner. The decals in the car
have the following descending degree of impor-
tance for the warning/information.
Warning for personal injury
G031590
Black ISO symbols on yellow warning field, white
text/image on black message field. Used to indi-
cate the presence of danger which, if the warning

||
INTRODUCTION
18
is ignored, may result in serious personal injury or
fatality.
Risk of property damage
G031592
White ISO symbols and white text/image on
black or blue warning field and message field.
Used to indicate the presence of danger which, if
the warning is ignored, may result in damage to
property.
Information
G031593
White ISO symbols and white text/image on
black message field.
NOTE
It is not intended that the decals illustrated in
the owner's manual should be exact replicas
of those in the car. They are included to show
their approximate appearance and location in
the car. The information that applies to your
particular car can be found on the decal on
the car.
Procedure lists
Procedures where action must be taken in a cer-
tain sequence are numbered in the owner's man-
ual.
When there is a series of illustrations for
step-by-step instructions each step is num-
bered in the same way as the corresponding
illustration.
Lists of letters appear adjacent to the series
of illustrations where the order of the instruc-
tions is not significant.
Arrows appear numbered and unnumbered
and are used to illustrate a movement.
Arrows with letters are used to clarify a
movement when the reciprocal order is of no
relevance.
If there is no series of illustrations for step-by-
step instructions then the different steps are
numbered with normal numbers.
Position lists
Red circles containing a number are used in
overview images where different components
are pointed out. The number recurs in the
position list featured in connection with the
illustration that describes the item.
Bulleted lists
A bulleted list is used when there is a list of
points in the owner's manual.
Example:
