OWNER'S MANUAL

VÄLKOMMEN!
We hope you will enjoy many years of driving pleasure in your Volvo. The
car has been designed for the safety and comfort of you and your pas-
sengers. Volvo is one of the world's safest passenger vehicles. Your
Volvo is also designed to meet applicable safety and environmental
requirements.
In order to increase your enjoyment of your Volvo, we recommend that
you read the instructions and maintenance information in this owner's
manual. The owner's manual is also available as a mobile app (Volvo
Manual) and on the Volvo Cars support site (support.volvocars.com).

2
INTRODUCTION
This is how you find owner's information 12
Digital owner's manual in the car 13
Volvo Cars support site 15
Reading the owner's manual 16
Recording data 19
Accessories and extra equipment 20
Volvo ID 21
Environmental philosophy 22
The owner's manual and the environment 25
Laminated glass 25
SAFETY
General information on seatbelts 28
Seatbelt - putting on 29
Seatbelt - loosening 29
Seatbelt - pregnancy 30
Seatbelt reminder 30
Seatbelt tensioner 31
Safety - warning symbol 31
Airbag system 32
Driver airbag 33
Passenger airbag 34
Passenger airbag - activating/deac-
tivating*35
Side airbag (SIPS) 37
Inflatable Curtain (IC) 38
General information on WHIPS
(whiplash protection) 39
WHIPS - seating position 40
Roll Over Protection System (ROPS) 41
When the systems deploy 41
General information on safety mode 42
Safety mode - attempting to start the car 43
Safety mode - moving the car 44
General information on child safety 44
Child seats 45
Child seats - location 51
Child seat - two-stage booster seat*52
Two-stage booster seat*- raising 53
Two-stage booster seat*- lowering 54
Child seat - ISOFIX 55
ISOFIX - size classes 56
ISOFIX - types of child seat 57
Child seats - upper mounting points 59
TABLE OF CONTENTS

3
INSTRUMENTS AND CONTROLS
Instruments and controls, left-hand
drive car - overview 62
Instruments and controls, right-hand
drive car - overview 65
Combined instrument panel 68
Analogue combined instrument
panel - overview 68
Digital combined instrument panel -
overview 69
Eco guide & Power guide*72
Combined instrument panel - mean-
ing of indicator symbols 73
Combined instrument cluster -
meaning of warning symbols 75
Outside temperature gauge 77
Trip meter 77
Clock 78
Combined instrument panel - license
agreement 78
Symbols in the display 79
Volvo Sensus 82
Key positions 83
Key positions - functions at different
levels 83
Seats, front 85
Seats, front - electrically operated*86
Seats, rear 87
Steering wheel 90
Heating*of the steering wheel 91
Light switches 92
Position lamps 93
Daytime running lights 94
Tunnel detection*94
Main/dipped beam 95
Active main beam*96
Active Xenon headlamps*98
Headlamps - adjusting headlamp pattern 99
Rear fog lamp 99
Brake lights 100
Hazard warning flashers 100
direction indicators 101
Interior lighting 101
Home safe light duration 103
Approach lighting 103
Wipers and washers 104
Power windows 106
Door mirrors 108
Windows and rearview and door mir-
rors - heating 109
Rearview mirror - interior 110
Compass*110
Panorama roof*- general 112
Panorama roof*- operation 113
Menu navigation - combined instru-
ment panel 115
Menu overview - combined instru-
ment panel 116
Messages 116
Messages - handling 117
MY CAR 118
Trip computer 119
Trip computer - analogue combined
instrument panel 121
Trip computer - digital combined
instrument panel 124
Trip computer - trip statistics*127

4
CLIMATE CONTROL
General information on climate control 130
Actual temperature 130
Sensors - climate control 131
Air quality 131
Air quality - passenger compartment filter 131
Air quality - Clean Zone Interior
Package (CZIP)*132
Air quality - IAQS*132
Air quality - material 132
Menu settings - climate control 133
Air distribution in the passenger
compartment 133
Electronic climate control - ECC 135
Heated front seats*136
Heated rear seat*137
Fan 137
Auto-regulation 138
Temperature control in the passen-
ger compartment 138
Air conditioning 139
Demisting and defrosting the windscreen 139
Air distribution - recirculation 140
Air distribution - table 141
Engine block heater and passenger
compartment heater*143
Engine block heater and passenger
compartment heater*- direct start 144
Engine block heater and passenger
compartment heater*- immediate stop 145
Engine block heater and passenger
compartment heater*- timer 145
Engine block heater and passenger
compartment heater*- messages 147
Additional heater*149
Fuel-driven additional heater*149
Electric additional heater*150
LOADING AND STORAGE
Storage spaces 152
Tunnel console 154
Tunnel console - cigarette lighter
and ashtray*154
Glovebox 154
Inlaid mats*155
Vanity mirror 155
Tunnel console - 12 V-sockets 155
Loading 156
Loading - long load 157
Roof load 158
Load retaining eyelets 158
Loading - bag holder*158
12 V electrical socket - cargo area*159
Safety net*159
Safety grille 161
Cargo cover 162

5
LOCKS AND ALARM
Remote control key 164
Remote control key - losing 164
Remote control key - personalisation*165
Locking/unlocking - indicator 166
Immobiliser 166
Remote-controlled immobiliser with
tracking system*167
Remote control key - functions 167
Remote control key - range 169
Remote control key with PCC*-
unique functions 169
Remote control key with PCC*- range 170
Detachable key blade 171
Detachable key blade - detaching/
attaching 171
Detachable key blade - unlocking doors 172
Remote control key - replacing the
battery 172
Keyless drive*174
Keyless Drive*- remote control key
range 174
Keyless drive*- secure handling of
the remote control key 175
Keyless Drive*- interference to
remote control key function 175
Keyless Drive*- locking 175
Keyless drive*- unlocking 176
Keyless Drive*- unlocking with the
key blade 176
Keyless Drive*- lock settings 177
Keyless Drive*- antenna location 177
Locking/unlocking - from the outside 178
Locking/unlocking - from the inside 179
Global opening 179
Locking/unlocking - glovebox 180
Locking/unlocking - tailgate 180
Power operated tailgate*181
Deadlocks*183
Child safety locks - manual activation 184
Child safety locks - electrical activation*185
Alarm 185
Alarm indicator 186
Alarm - automatic re-arming 187
Alarm - remote control key not working 187
Alarm signals 187
Reduced alarm level 188
Type approval - remote control key
system 188
DRIVER SUPPORT
Active chassis - Four C*190
Adjustable steering force*190
Electronic stability control (ESC) -
general 191
Electronic stability control (ESC) -
operation 192
Electronic stability control (ESC) -
symbols and messages 193
Speed limiter*195
Speed limiter*- getting started 195
Speed limiter*- changing speed 196
Speed limiter*- temporary deactiva-
tion and standby mode 196
Speed limiter*- alarm for speed
exceeded 197
Speed limiter*- deactivation 197
Cruise control*198
Cruise control*- managing speed 199
Cruise control*temporary deactiva-
tion and standby mode 199
Cruise control*- resume set speed 200
Cruise control*- deactivate 200
Distance Warning*201
Distance Warning*- limitations 202
Distance Warning*- symbols and
messages 203

6
Adaptive cruise control - ACC*204
Adaptive cruise control*- function 205
Adaptive cruise control*- overview 206
Adaptive cruise control*- managing
speed 207
Adaptive cruise control*- set time
interval 209
Adaptive cruise control*- temporary
deactivation, and standby mode 209
Adaptive cruise control*- overtaking
another vehicle 210
Adaptive cruise control*- deactivate 211
Adaptive Cruise Control*- queue
assistance 211
Adaptive cruise control*- switch
cruise control functionality 213
Adaptive cruise control*- fault trac-
ing and action 214
Adaptive cruise control*- symbols
and messages 215
Radar sensor 217
Radar sensor - limitations 217
Type approval - radar system 219
City Safety™222
City Safety™- function 223
City Safety™- operation 223
City Safety™- limitations 224
City Safety™- laser sensor 226
City Safety™- symbols and messages 228
Collision warning system*229
Collision warning system*- function 230
Collision warning system*- detection
of cyclists 231
Collision warning system*- detection
of pedestrians 232
Collision warning system*- operation 233
Collision warning system*- limitations 235
Collision warning system*- camera
sensor limitations 236
Collision warning system*- symbols
and messages 238
BLIS*240
BLIS*- operation 241
CTA*242
BLIS - symbols and messages 244
Road Sign Information (RSI)*244
Road sign information (RSI)*- operation 245
Road sign information (RSI)*- limitations 248
Driver Alert System*248
Driver Alert Control (DAC)*248
Driver Alert Control (DAC)*- operation 249
Driver Alert Control (DAC)*- symbols
and messages 250
Lane Departure Warning (LDW)*251
Lane Departure Warning (LDW) -
function 251
Lane Departure Warning (LDW) -
operation 252
Lane Departure Warning (LDW) -
limitations 253
Lane Departure Warning (LDW) -
symbols and messages 254
Lane Keeping Aid (LKA)*255
Lane Keeping Aid (LKA) - function 256
Lane Keeping Aid (LKA) - operation 257
Lane Keeping Aid (LKA) - limitations 258
Lane Keeping Aid (LKA) - symbols
and messages 259
Park Assist*260
Park assist syst*- function 260
Park assist syst*- backward 261
Park assist syst*- forward 262
Park assist syst*- fault indication 263
Park assist syst*- cleaning the sensors 263
Park assist camera*264
Park assist camera - settings 266
Park assist camera - limitations 267
Park Assist Pilot (PAP)*267
Park Assist Pilot (PAP)*- function 268

7
Park Assist Pilot (PAP)*- operation 269
Park Assist Pilot (PAP)*- limitations 271
Park Assist Pilot (PAP)*- symbols
and messages 272
STARTING AND DRIVING
Starting the engine 274
Switching off the engine 275
Steering lock 275
Remote start (ERS)*275
Remote start (ERS) - operation 276
Remote start (ERS) - symbols and
messages 277
Jump starting with another battery 279
Gearboxes 280
Manual gearbox 280
Gear shift indicator*281
Automatic gearbox - Geartronic*281
Gear selector inhibitor 284
Hill start assist (HSA)*286
All-wheel drive - (AWD)*286
Hill Descent Control (HDC)*287
Start/Stop*288
Start/Stop*- function and operation 289
Start/Stop*- the engine does not stop 290
Start/Stop*- the engine auto-starts 291
Start/Stop*- the engine does not
auto-start 292
Start/Stop*- involuntary stop manual
gearbox 293
Start/Stop*- settings 293
Start/Stop*- symbols and messages 294
Foot brake 296
Foot brake - anti-lock braking system 297
Foot brake - emergency brake lights
and automatic hazard warning flashers 298
Foot brake - emergency brake assistance 298
Parking brake 299
Driving in water 303
Overheating 303
Driving with open tailgate/boot lid 304
Overload - starter battery 304
Before a long journey 305
Winter driving 305
Fuel filler flap - Opening/closing 306
Fuel filler flap - manual opening 306
Filling up with fuel 306
Fuel - handling 307
Fuel - petrol 308
Fuel - diesel 308
Diesel particle filter (DPF) 310
Catalytic converters 311
Economical driving 311
Driving with a trailer*312
Driving with a trailer*- manual gearbox 313

8
Driving with a trailer*- automatic gearbox 314
Towing bracket/Towbar*314
Detachable towbar*- storage 315
Detachable towbar*- specifications 315
Detachable towbar*- attachment/
removal 316
Trailer Stability Assist - TSA 319
Towing 320
Towing eye 321
Recovery 322
WHEELS AND TYRES
Tyres - maintenance 324
Tyres - direction of rotation 325
Tyres - tread wear indicators 326
Tyres - air pressure 326
Wheel and wheel rim dimensions 328
Tyres - dimensions 328
Tyres - load index 329
Tyres - speed ratings 329
Wheel bolts 330
Winter tyres 330
Changing wheels - removing wheels 331
Changing wheels - fitting 333
Warning triangle 334
Tools 335
Jack*335
First aid kit*336
Tyre pressure monitoring*336
Tyre monitoring (TM)*337
Emergency puncture repair*339
Emergency puncture repair kit*- location 339
Emergency puncture repair kit*-
overview 340
Emergency puncture repair*- operation 341
Emergency puncture repair*- rechecking 343
Emergency puncture repair kit*-
inflating the tyres 344

9
MAINTENANCE AND SERVICE
Volvo service programme 346
Book service and repair*346
Raising the car 349
Bonnet - opening and closing 351
Engine compartment - overview 351
Engine compartment - checking 353
Engine oil - general 353
Engine oil - checking and filling 354
Coolant - level 357
Brake and clutch fluid - level 358
Power steering fluid - level 358
Climate control system - fault tracing
and repair 359
Lamp replacement - general 360
Lamp replacement - headlamps 361
Lamp replacement - cover for main/
dipped beam bulbs 362
Lamp replacement - dipped beam 362
Lamp replacement - main beam 363
Lamp replacement - extra main beam 364
Lamp replacement - direction indica-
tors front 364
Lamp replacement - rear lamp 365
Lamp replacement - location of rear
lamps 366
Lamp replacement - number plate
lighting 366
Lamp replacement - lighting in cargo
area 366
Lamp replacement - vanity mirror lighting 367
Lamps - specifications 367
Wiper blades 368
Washer fluid - filling 370
Starter battery - general 371
Battery - symbols 373
Starter battery - replacement 373
Battery - Start/Stop 375
Electrical system 377
Fuses - general 377
Fuses - in engine compartment 379
Fuses - under glovebox 383
Fuses - in the control module under
the glovebox 385
Fuses - in cargo area 387
Fuses - in the engine compartment's
cold zone 389
Car wash 391
Polishing and waxing 392
Water and dirt-repellent coating 393
Rustproofing 394
Cleaning the interior 394
Paint damage 395

10
SPECIFICATIONS
Type designations 400
Dimensions 403
Weights 404
Towing capacity and towball load 405
Engine specifications 407
Engine oil - adverse driving conditions 408
Engine oil - grade and volume 409
Coolant - grade and volume 411
Transmission fluid - grade and volume 412
Brake fluid - grade and volume 414
Power steering fluid - grade 414
Fuel tank - volume 415
Specifications for air conditioning 416
Fuel consumption and CO2 emissions 418
Tyres - approved tyre pressures 421
ALPHABETICAL INDEX
Alphabetical Index 423

INTRODUCTION

INTRODUCTION
12
This is how you find owner's
information
Owner's information is available in several differ-
ent product formats, both digital and printed.
The owner's manual is available in the car's
screen, as a mobile app and on the Volvo Cars
support site. There is a Quick Guide and a sup-
plement to the owner's manual available in the
glovebox, with specifications and fuse informa-
tion, amongst other things. A printed owner's
manual can be ordered.
The car's screen1
A digital version of the owner's
manual is available in the car's
screen. Press the MY CAR but-
ton in the centre console, press
OK/MENU and select
Owner's manual. The infor-
mation is searchable and can
also be subdivided into categories.
Read more in the Digital owner's manual in the
car.
Mobile app
In App Store or Google Play,
search for "Volvo Manual",
download the app to your
smartphone or tablet and select
the car.
The app contains video tutorials
as well as options for visual navigation with exte-
rior and interior images of the car. It is easy to
navigate between the different sections in the
owner's manual and the content is searchable.
Read more about Owner's Manual in mobile devi-
ces.
Volvo Cars support site
Go to support.volvocars.com
and select your country. Here
you can find owner's manuals,
both online and in PDF format.
On the Volvo Cars support site
there are also video tutorials
and further information and
help regarding your Volvo and your car owner-
ship. The page is available for most markets.
Read more on the Volvo Cars support site.
Printed information
There is a supplement to the
owner's manual2in the glove-
box that contains information
on fuses and specifications, as
well as a summary of important
and practical information.
There is also a Quick Guide available in printed
format that helps you to get started with the most
commonly used functions in the car.
Depending on equipment level selected, market,
etc. additional owner's information may also be
available in printed format in the car.
A printed owner's manual and associated supple-
ment can be ordered. Contact a Volvo dealer to
order. See how the owner's manual is structured
in Reading the owner's manual.
1A complete printed manual is included with the car for markets without owner's manual in the screen.
2A complete printed manual is included with the car for markets without owner's manual in the screen.

INTRODUCTION
}}
13
Changing the language in the car's
screen
Changing the language in the car's display may
mean that some information does not correspond
to national or local laws and regulations. Don't
change to a language that's difficult to under-
stand, it may then be difficult to find your way
back in the structure on the screen.
IMPORTANT
The driver is always responsible that the vehi-
cle is driven safely in traffic and that applica-
ble laws and regulations are followed. It is
also important that the car is maintained and
handled in accordance with Volvo's recom-
mendations in the owner's information.
If there should be a difference between the
information in the screen and the printed
information then it is always the printed infor-
mation that applies.
Related information
•Digital owner's manual in the car (p. 13)
•Volvo Cars support site (p. 15)
•Reading the owner's manual (p. 16)
Digital owner's manual in the car
The owner's manual can be read on the screen
in the car3. The content is searchable and it is
easy to navigate between different sections.
Open the digital owner's manual - press the MY
CAR button in the centre console, press OK/
MENU and select Owner's manual.
For basic navigation, see Operating the system.
See below for a more detailed description.
Owner's manual, start page.
There are four options for finding information in
the digital owner's manual:
•Search - Search function for finding an arti-
cle.
•Categories - All articles sorted into catego-
ries.
•Favourites - Quick access to favourite-
bookmarked articles.
•Quick Guide - A selection of articles for
common functions.
Select the information symbol in the lower right-
hand corner in order to obtain information about
the digital owner's manual.
NOTE
The digital owner's manual is not available
while driving.
Search
Searching using the character wheel.
Character list.
Changing the input mode (see following
table).
3Applies to certain car models.

||
INTRODUCTION
14
Use the character wheel to enter a search term,
e.g. "seatbelt".
1. Turn TUNE to the desired letter, press OK/
MENU to confirm. The number and letter
buttons on the control panel in the centre
console can also be used.
2. Continue with the next letter and so on.
3. To change the input mode to numbers or
special characters, or to perform a search,
turn TUNE to one of the options (see explan-
ation in the following table) in the list for
changing the input mode (2), press OK/
MENU.
123/AB
C
Change between letters and num-
bers with OK/MENU.
MORE Change to special characters with
OK/MENU.
OK Perform the search. Turn TUNE to
select a search result article, press
OK/MENU to go to the article.
a|A Changes between lowercase and
uppercase letters with OK/MENU.
|| }Changes from the character wheel
to the search field. Move the cur-
sor with TUNE. Delete any mis-
spelling with EXIT. To return to the
character wheel, press OK/MENU.
Note that the digit and letter but-
tons on the control panel can be
used for editing in the search field.
Enter with the numerical keyboard
Numerical keyboard.
Another way of entering characters is to use the
centre console's buttons 0-9, *and #.
When e.g. 9is pressed, a bar appears with all
characters4under the button, e.g. W, x, y, zand
9. Quick presses on the button move the cursor
through these characters.
•Stop with the cursor on the desired character
in order to select it - the character is shown
on the enter line.
•Delete/undo using EXIT.
To enter a number, hold in the corresponding
number key.
Categories
The articles in the owner's manual are structured
into main categories and subcategories. The
same article can be in several appropriate cate-
gories in order to be found more easily.
Turn TUNE to navigate in the category tree and
press OK/MENU to open a category - selected
- or article - selected . Press EXIT to go
back to the previous view.
Favourites
Located here are the articles that are saved as
favourites. To select an article as a favourite, see
the heading "Navigating in an article" below.
Turn TUNE to navigate in the favourite list and
press OK/MENU to open an article. Press EXIT
to go back to the previous view.
4The character for each button may vary depending on market/country/language.

INTRODUCTION
}}
* Option/accessory, for more information, see Introduction. 15
Quick Guide
Located here is a selection of articles for getting
to know the car's most common functions. The
articles can also be accessed via categories, but
are collected here for quick access.
Turn TUNE to navigate in the Quick Guide and
press OK/MENU to open an article. Press EXIT
to go back to the previous view.
Navigating in an article
Home - leads to the start page for the
owner's manual.
Favourite - adds/removes an article as a
favourite. You can also press the FAV button
in the centre console to add/remove an arti-
cle as a favourite.
Highlighted link - leads to linked article.
Special texts - if the article contains warn-
ings, important or note texts then an associ-
ated symbol is shown here as well as the
number of such texts in the article.
Turn TUNE to navigate between the links or
scroll in an article. When the screen has scrolled
to the start/end of an article the home and
favourite options are accessed by scrolling a fur-
ther step up/down. Press OK/MENU to activate
the selection/highlighted link. Press EXIT to go
back to the previous view.
Volvo Cars support site
There is additional information regarding your
car on the Volvo Cars website and support
page. From the website, it is also possible to
navigate through to My Volvo, a personal web
page for you and your car.
Support on the Internet
Go to support.volvocars.com or use the QR code
below to visit the page. The support page is avail-
able for most markets.
QR code that leads to the support page.
The information on the support page is searcha-
ble and can also be subdivided into different cat-
egories. Available here is support for options rela-
ted to e.g. Internet connected services and func-
tions, Volvo On Call (VOC)*, the navigation sys-
tem*and apps. Video and step-by-step instruc-
tions explain different procedures, e.g. how the
car is connected to the Internet via a mobile
phone.

||
INTRODUCTION
* Option/accessory, for more information, see Introduction.
16
Downloadable information from the
support page
Maps
For cars equipped with Sensus Navigation*, there
is the facility to download maps from the support
page.
Mobile apps
For selected Volvo models from model year 2014
and 2015, the owner's manual is available in the
form of an app. The VOC*app can also be
accessed from here.
Owner's manuals from previous model years
Owner's manuals from previous model years are
available here in PDF format. The Quick Guide
and supplement can also be accessed from the
support page. Select car model and model year in
order to download the publication required.
Contact
On the support page there is contact information
for customer support and the nearest Volvo
dealer.
My Volvo on the Internet5
From www.volvocars.com it is possible to navigate
through to My Volvo Web which is a personal
Web page for you and your car.
Create a personal Volvo ID, log in to My Volvo
Web and get an overview of service, agreements
and warranties, amongst other things. At My
Volvo Web there is also information about acces-
sories and software adapted for your car model.
Related information
•Volvo ID (p. 21)
Reading the owner's manual
A good way of getting to know your new car is
to read the owner's manual, ideally before your
first journey.
Reading the owner's manual is a good way to
become familiar with new functions, get advice
on how best to handle the car in different situa-
tions and learn how to make the best use of all
the car's features. Please pay attention to the
safety instructions contained in the owner's man-
ual.
Development work is constantly in progress to
improve our product. Modifications may mean
that information, descriptions and illustrations in
the owner's manual differ from the equipment in
the car. We reserve the right to make modifica-
tions without prior notice.
©Volvo Car Corporation
IMPORTANT
Do not remove this manual from the car -
should a problem arise then the information
required about where and how to seek pro-
fessional help would be missing.
5Applies to certain markets.

INTRODUCTION
}}
* Option/accessory, for more information, see Introduction. 17
Owner's Manual in mobile devices
NOTE
The Owner's manual is available for download
as a mobile application (applies for certain car
models and mobile devices), see
www.volvocars.com.
The mobile application also includes video
and searchable content and easy navigation
between different sections.
Options/accessories
All types of option/accessory are marked with an
asterisk*.
In addition to standard equipment, the owner's
manual also describes options (factory fitted
equipment) and certain accessories (retrofitted
extra equipment).
The equipment described in the owner's manual
is not available in all cars - they have different
equipment depending on adaptations for the
needs of different markets and national or local
laws and regulations.
In the event of uncertainty over what is standard
or an option/accessory, contact a Volvo dealer.
Special texts
WARNING
Warning texts appear if there is a risk of
injury.
IMPORTANT
"Important" texts appear if there is a risk of
damage.
NOTE
NOTE texts give advice or tips that facilitate
the use of e.g. features and functions.
Footnote
There is footnote information in the owner's man-
ual that is located at the bottom of the page. This
information is an addition to the text that it refers
to via a number. If the footnote refers to text in a
table then letters are used instead of numbers
for referral.
Message texts
In the car there are displays that show menu
texts and message texts. In the owner's manual
the appearance of these texts differs from the
normal text. Examples of menu texts and mes-
sage texts: Media, Sending location.
Decals
The car contains different types of decal which
are designed to convey important information in a
simple and clear manner. The decals in the car
have the following descending degree of impor-
tance for the warning/information.
Warning for personal injury
G031590
Black ISO symbols on yellow warning field, white
text/image on black message field. Used to indi-
cate the presence of danger which, if the warning

||
INTRODUCTION
18
is ignored, may result in serious personal injury or
fatality.
Risk of property damage
G031592
White ISO symbols and white text/image on
black or blue warning field and message field.
Used to indicate the presence of danger which, if
the warning is ignored, may result in damage to
property.
Information
G031593
White ISO symbols and white text/image on
black message field.
NOTE
It is not intended that the decals illustrated in
the owner's manual should be exact replicas
of those in the car. They are included to show
their approximate appearance and location in
the car. The information that applies to your
particular car can be found on the decal on
the car.
Procedure lists
Procedures where action must be taken in a cer-
tain sequence are numbered in the owner's man-
ual.
When there is a series of illustrations for
step-by-step instructions each step is num-
bered in the same way as the corresponding
illustration.
Lists of letters appear adjacent to the series
of illustrations where the order of the instruc-
tions is not significant.
Arrows appear numbered and unnumbered
and are used to illustrate a movement.
Arrows with letters are used to clarify a
movement when the reciprocal order is of no
relevance.
If there is no series of illustrations for step-by-
step instructions then the different steps are
numbered with normal numbers.
Position lists
Red circles containing a number are used in
overview images where different components
are pointed out. The number recurs in the
position list featured in connection with the
illustration that describes the item.
Bulleted lists
A bulleted list is used when there is a list of
points in the owner's manual.
Example:
