Vomex ES28 User manual

ES28
WEIMA New Energy Electric Garden Tools
OPERATOR'S MANUAL
Electric Pruning Shears
http://www.vomexpower.com

Thank you for purchasing Weima new energy Electric Pruning
Shears
This manual include operation & maintenance and the
information of three “three guarantees ”
All information in the manual is based on the latest
information available at the time of printing.
We reserves the right to change the contents of this
instruction without prior notice and do not assume any
legal responsibility.
Any part of this manual shall not be reproduced or
photocopied without written consent
This manual shall be considered as part of the electric
pruning shear and shall be handed over when resold
The products sold in each stage may be inconsistent with
the specification, please refer to the actual product when
purchasing.
This tool is only used for pruning hedges, shrubs and
branches.
Users are strictly prohibited to remold the electric fruit
tree pruner without authorization
We will not be responsible for any damage to the tools or
personal injury caused by the violation of the above terms,
and will also terminate the “three guarantees” for the
implementation of the tools.

In order to use this product better, please
be sure to read the instructions carefully before use
and keep this manual for future reference. If you
have any problems during the use, please contact us
in time, we have professionals to answer your
questions.

Contents
GENERAL MACHINE SAFETY WARNINGS........................................ 1
WORK AREA SAFETY.......................................................................................... 1
ELECTRICAL SAFETY............................................................................................1
PERSONAL SAFETY............................................................................................. 2
RESIDUAL RISKS................................................................................................ 3
MACHINE USE AND CARE....................................................................................5
PROPER USE OF CHARGER...................................................................................6
BATTERY MACHINE USE AND CARE....................................................................... 8
SERVICE.........................................................................................................10
SAFETY SIGN...................................................................................10
THE LABEL ON THE MANUAL AND TOOLS.............................................................10
LOGO ON BATTERY PACK AND CHARGER..............................................................11
PRODUCT INSTRUCTION................................................................13
INTENDED USE................................................................................................13
TECHNICAL PARAMETER...................................................................................14
PART NAME AND SCHEMATIC DIAGRAMI............................................................16
OPERATION INSTRUCTION............................................................ 16
MACHINE SWITCH ON AND OFF OPERATION...................................................... 17
INDICATOR LIGHT............................................................................................19
PROMPTS INDICATES....................................................................................... 19
CHARGING THE BATTERY.................................................................................20
MAINTENANCE.............................................................................. 21
CLEANING AND MAINTENANCE.......................................................................... 21
BLADE REPLACEMENT AND MAINTENANCE...........................................................22
STORAGE....................................................................................................... 24

WASTE TREATMENT AND ENVIRONMENTAL PROTECTION........................................25
COMMON FAULTS AND TROUBLESHOOTING.............................. 25
TROUBLESHOOTING......................................................................................... 25
ABNORMAL SITUATION AND HANDLING METHOD................................................. 27
PACKING LIST................................................................................. 28
CERTIFICATE................................................................................... 29
WARRANTY CARD..........................................................................30

1
General Machine Safety Warnings
WARNING Read all safety warnings, instructions,
illustrations and specifications provided with this machine.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "machine" in the warnings refers to your mains-operated
(corded) machine or battery-operated (cordless) machine.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
Do not operate machines in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Machines
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a machine.
Distractions can cause you to lose control.
Electrical safety
Machine plugs must match the outlet. Never modify the plug
in any way. Do not use any adapter plugs with earthed (grounded)
machines. Unmodified plugs and matching outlets will reduce
risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such
as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed or
grounded.
Do not expose machines to rain or wet conditions. Water
entering a machine will increase the risk of electric shock.

2
Do not abuse the cord. Never use the cord for carrying, pulling
or unplugging the machine. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a machine outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
If operating a machine in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when
operating a machine. Do not use a machine while you are tired
or under the influence of drugs, alcohol or medication. A
moment of inattention while operating machines may result in
serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or battery
pack, picking up or carrying the machine. Carrying machines
with your finger on the switch or energising machines that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning the machine
on. A wrench or a key left attached to a rotating part of the
machine may result in personal injury.

3
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the machine in unexpected
situations.
Dress properly. Do not wear loose clothing or jewellery. Keep
your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
Do not let familiarity gained from frequent use of machines
allow you to become complacent and ignore machine safety
principles. A careless action can cause severe injury within
a fraction of a second.
Residual risks
Even when the machine is used as prescribed it is not
possible to eliminate all residual risk factors. The following
hazards may arise in connection with the machine’s construction
and design:
Damage to lungs if an effective dust mask is not worn.
Damage to hearing if effective hearing protection is not worn.
Damages to health resulting from vibration emission if the
machine is being used over longer period of time or not
adequately managed and properly maintained.
WARNING! This machine produces an electromagnetic field
during operation. This field may under some circumstances

4
interfere with active or passive medical implants. To reduce the
risk of serious or fatal injury, we recommend persons with medical
implants to consult their physician and the medical implant
manufacturer before operating this machine.
Warning! Do not touch the blade when pruner is working to
avoid personal injury.
Wear hearing protection while operating the machine.
The declared vibration total value(s) and the declared noise
emission value(s) have been measured in accordance with a
standard test method and may be used for comparing one machine
with another.
The declared vibration total value(s) and the declared noise
emission value(s) may also be used in a preliminary assessment
of exposure.
The vibration emission and noise emissions during actual
use of the machine can differ from the declared total value
depending on the ways in which the machine is used.
There is the need to identify safety measures to protect
the operator that are based on an estimation of exposure in the
actual conditions of use (taking account of all parts of the
operating cycle such as the times when the machine is switched
off and when it is running idle in addition to the trigger time).

5
Machine use and care
Do not force the machine. Use the correct machine for your
application. The correct machine will do the job better and
safer at the rate for which it was designed.
Do not use the machine if the switch does not turn it on and
off. Any machine that cannot be controlled with the switch
is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the machine before making
any adjustments, changing accessories, or storing machines.
Such preventive safety measures reduce the risk of starting
the machine accidentally.
Store idle machines out of the reach of children and do not
allow persons unfamiliar with the machine or these
instructions to operate the machine. Machines are dangerous
in the hands of untrained users.
Maintain machines and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other
condition that may affect the machine’s operation. If
damaged, have the machine repaired before use. Many accidents
are caused by poorly maintained machines.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
Use the machine, accessories and tool bits etc. in accordance
with these instructions, taking into account the working
conditions and the work to be performed. Use of the machine
for operations different from those intended could result in
a hazardous situation.

6
Keep handles and grasping surfaces dry, clean and free from
oil and grease. Slippery handles and grasping surfaces do not
allow for safe handling and control of the machine in
unexpected situations.
Proper use of charger
Warning! Measures to reduce the risk of electric shock or
short circuit are as follows:
Please check whether the product is in good condition before
use
Do not disassemble the charger by yourself
Do not contact the output and input terminals of the charger
with metal objects；
Charge the charger with a qualified and sound outlet.
Warning! Do not use battery packs and chargers near corrosive
or flammable materials. Please do not cover the charger. In
case of smoke or fire from the charger, please turn off the
power to prevent fire hazard.
Check whether the charger power cord is in good condition or
has cracks at fixed period.
Do not pull the power cord to move the charger. At the same
time, do not pull the cord to pull out the plug.
Make sure all power cords and extension cords are kept away
from water, oil and sharp edges. Make sure the power cord
doesn't get stuck in a door, fence or the place like that.
Do not use water to clean battery packs and chargers

7
Children aged 8 years or below and persons with physical,
sensory or mental disability or lack of experience and
knowledge shall not use this product unless they are under
supervision or have known about the safe use of the product
and the potential risks in advance. Children should not play
with chargers as toys. Children should not clean and maintain
the charger without supervision.
If the power cord is damaged, it must be replaced by the
manufacturer, service outlet or someone with similar skills
to avoid the risk
Chargers are only for indoor use and storage;Charging must
be placed in a well-ventilated, dry environment
Do not use the charger when take drugs,alcohol ,which are
affecting your judgment.
Only use the provided charger to charge the battery, otherwise,
it may cause fire or explosion. Use the matching charger to
ensure the safety of the tools.
Disconnect the charger from the power supply before turning
off or opening the tool.
The battery is not fully charged at the time of delivery, so
the user must fully charge it before the first use. When the
battery is fully charged, the charger should be removed from
the power source and the tool respectively.
The charging time after the battery is fully discharged is
about 2.5-3.5 hours. Please do not charge the battery for a
long time, otherwise the battery will be damaged. Note:
repeated short charge may damage the battery. Only charge the
battery when there is only one LED power display left.
ATTACHMENT

8
Battery charger which
was approved according
to EN 60335-1; EN
60335-2-29
Model: DC18-1701000G
Input:100～240Vac,50/60Hz,0.6A;
Output:17V DC 1000mA
Battery machine use and care
Recharge only with the charger specified by the manufacturer.
A charger that is suitable for one type of battery pack may
create a risk of fire when used with another battery pack.
Use machines only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury
and fire.
When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together
may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
Do not use a battery pack or machine that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
of injury.
Do not expose a battery pack or machine to fire or excessive
temperature. Exposure to fire or temperature above 130 °C
may cause explosion.

9
Follow all charging instructions and do not charge the battery
pack or machine outside the temperature range specified in
the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and
increase the risk of fire.
Only original parts used for repair by professional
maintenance personnel. This ensures that the product is
maintained safely
It is forbidden to modify or try to repair tools and battery
packs, except for the use and maintenance method specified
in the section of use and maintenance in the manual.
Do not allow battery packs to be subjected to mechanical
impact or extrusion;
Pay attention to the (+) and (-) marks on the battery pack
and tools to make sure they are connected properly.
Keep battery packs away from children.
Keep the battery pack clean and dry;
If the battery pack’s electrode tip need clean, wipe it with
a clean and dry cloth.
The battery pack needs to be charged before use. When charging,
use the correct charger and refer to the correct instructions
in the manual.
Do not charge the battery pack for a long time when not in
use;
After long-term storage, the battery pack should be charged
and discharged several times to obtain the best performance.
Keep the product manual for future reference.
Only use battery pack in power tools of Weima new energy;
Remove the battery pack when the tool is not in use.

10
Service
Have your machine serviced by a qualified repair person using
only identical replacement parts. This will ensure that the
safety of the machine is maintained.
Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorized
service providers.
Safety sign
The label on the manual and tools
Warning! Pruning machines are
dangerous. Careless or incorrect use
can result in serious or fatal injury
to the user or others.
Do not expose to rain
Read the instructions carefully and
make sure you understand them before
using them.
Keep away from the cutting edge of the
pruner. Physical contact will cause
damage
Start the power supply and press the
button before use。

11
Be careful! In order to prevent the
machine from being started abnormally
due to accidental touch, it is
necessary to remove the battery pack
during assembly, inspection or
maintenance.
Indication mark (indicated at the
exclamation point) with a message to
prevent damage
Help flag with information to improve
tool operation
Wear gloves
Please wear appropriate work clothes,
such as non-slip leather boots and
protective pants
Use and store batteries at
temperatures ranging from -10 ℃ to +
50℃
This product is in accordance with
applicable EC directives.
Logo on battery pack and charger
Warning! Improper or careless use of
chargers or batteries can be very
dangerous and can cause serious
accidents or even personal injury. So

12
reading and understanding the
instructions is very important
The product must be handled in the
correct recycling equipment
Do not expose battery packs to high
temperatures or fire
Do not dispose of the product with
household waste. Contact your local
authority or retailer for recycling
advice.
Read the instructions carefully and
make sure you understand them before
using them.
Only use and store chargers indoors
Double insulation
1A delay action fuse

13
Product instruction
Intended use
Only charge the battery at an ambient (surrounding air)
temperature between 4ºC and 40ºC. A charged battery can be
used to power the machine under ambient temperature
conditions between -10ºC and 50ºC.When not in use, store the
battery in a dry place between 10ºC and 30ºC.
This tool can be used for pruning hedges, shrubs and branches.
If the tool is used for other unapproved purposes, it may cause
damage to the tool and bring harm to the user.
This tool can only be used by adults. Minors under the age
of 16 can use it under the supervision of adults. Please do
not use this tool on rainy day or wet hedge. If any accident
occurs during use, causing injury or property loss, the
operator or user shall be fully liable.
The manufacturer shall not be liable for any damage caused
by unconventional or incorrect use.
Please check whether the blade is sharp before use.If the
blade is blunt, be sure to sharpen it to avoid overloading the
tool. Damage caused by the use of a blunt blade is not included
in the quality assurance.
This tool is an electric fruit tree pruner driven by lithium
battery, which consists of fixed blade, moving blade, lithium
battery, charger, toolbox and other components. Mainly applied
to the diameter of 28mm and below garden branch pruning and orchard
grafting fruit branch pruning and fruit picking. Combined with
the characteristics of safety, high efficiency and easy operation,

14
it is 8 ~ 10 times of the efficiency of traditional manual pruning,
and the pruning quality is obviously higher than that of
traditional manual pruning. When used, the blade is close to the
branch and the cutting surface is even and smooth. If anything
goes wrong, just release the trigger and the blade will open in
the maximum position to avoid personal injury.

15
Technical Parameter
Electric Pruning Shears technical parameters
and performance indicators
Electric Pruning Shears basic information
Model
ES28
Rated Voltage
14.8V
Rated Capacity
2000mAh
Charger input voltage
AC100V～240V
Battery charging time
2.5～3.5 hour
Battery working time
3～4 hour
Net weight
950g
Maximum shear diameter
28mm （Soft branches）
Adjustable shear diameter
28mm/18mm
Working temperature
-10℃～50℃
Sound pressure level
No load: LpA=68.52dB(A) KpA=3dB(A)
Sound power level
No load: LWA=79.52dB(A) KWA=3dB(A)
Vibration levels
2.141m/s2K= 1.500m/s2
