TRACKPixx3 (VPX-TRK-3410C)
Installation Guide
Version 1.4

1
TRACKPixx3 Installation Guide
IMPORTANT
VPixx Technologies Inc. reserves the right to modify or otherwise update this document without notice as required by a constantly
evolving marketplace, client requests or to adapt to new progress or constraints in engineering or manufacturing technology. The
information contained in this document may change without prior notice.
No part of the written material accompanying this product may be copied or reproduced in any form, in an electronic retrieval system
or otherwise, without prior written consent of VPixx Technologies Inc.
Product/company names mentioned in this document are the trademarks of their respective owners.
VideoBahn, TRACKPixx, TRACKPixx3, TRACKPixx /mini, VIEWPixx, DATAPixx, PROPixx, are registered trademarks of VPixx Technologies
Inc.
For more information about our company and products, visit our website at www.vpixx.com
For information, comments or suggestions, please contact us by e-mail at [email protected]
Our offices are located at: 630 Clairevue West suite 301, Saint-Bruno, Qc, Canada, J3V 6B4
Version History of this document
Table 1 – Document history
Version
Date
Author
Changes
1.0
2018/07/23
P.Kakos
v1.0 release
1.1
2018/09/14
P.Kakos
Added cabling/connection information and procedures.
1.2
2018/11/14
P.Kakos and
JF.Hamelin
Multiple small changes: updated pictures, added cable part numbers, updated
technical content.
1.3
2019/04/04
P.Kakos
Removed first startup procedure and placed it in VPixx Products Application
Guide, removed part numbers, updated DATAPixx3 rear connector pictures,
small modifications throughout
1.4
2019/11/20
P. Kakos
Added InfraRed Short-Range 940nm illuminator product
Document Icons
The use of icons emphasizes helpful, caution or warning notes. Below is a list of the available icons.
Table 2 – Document icons
Icon
Type
Description
Helpful Hint Information to help out during assembly, installation or usage
Caution Notice Important Information to prevent misuse and/or damage to equipment
Warning Critical information to prevent damage to equipment and/or personnel

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
2
TRACKPixx3 Installation Guide
Table of Contents
Table of Contents ..................................................................................................................................................................2
List of Tables .........................................................................................................................................................................3
Table of Figures.....................................................................................................................................................................3
Overview.................................................................................................................................................................................4
Compliance information.........................................................................................................................................................5
For the United States of America .......................................................................................................................................5
For Canada..........................................................................................................................................................................5
For European Countries......................................................................................................................................................6
Declaration of RoHS Compliance........................................................................................................................................7
WARNINGS, SAFETY INFORMATION & USAGE NOTES ...........................................................................................................8
WARNINGS..........................................................................................................................................................................8
SAFETY INFORMATION .......................................................................................................................................................9
USAGE NOTES .....................................................................................................................................................................9
Typical setup.........................................................................................................................................................................10
Setup – TRACKPixx3 Short-Range System ............................................................................................................................11
Setup – TRACKPixx3 Long-Range System .............................................................................................................................11
Installation Steps ..............................................................................................................................................................12
DATAPixx3 connections ....................................................................................................................................................12
Camera and InfraRed Illuminator installation and connections.......................................................................................13
Lens installation................................................................................................................................................................15
Console Monitor and Stimulus Display power connections.............................................................................................17
Chinrest installation..........................................................................................................................................................17
TRACKPixx3 camera rear LED............................................................................................................................................17
Software installation instructions.........................................................................................................................................17
Maintenance.........................................................................................................................................................................18
Cleaning the TRACKPixx3..................................................................................................................................................18
Warranty...............................................................................................................................................................................18
Specifications........................................................................................................................................................................19

3
TRACKPixx3 Installation Guide
List of Tables
TABLE 1 – DOCUMENT HISTORY................................................................................................................................................................1
TABLE 2 – DOCUMENT ICONS ...................................................................................................................................................................1
TABLE 3 – TRACKPIXX3 SETUP CONNECTION DESCRIPTIONS..................................................................................................................10
TABLE 4 - SPECIFICATIONS.......................................................................................................................................................................19
Table of Figures
FIGURE 1 - TYPICAL TRACKPIXX3 SYSTEM SETUP ....................................................................................................................................10
FIGURE 2 - TYPICAL TRACKPIXX3 SHORT-RANGE SYSTEM SETUP............................................................................................................11
FIGURE 3 - TYPICAL TRACKPIXX3 LONG-RANGE SYSTEM SETUP .............................................................................................................11
FIGURE 4 - TRACKPIXX3 CAMERA REAR CONNECTORS ...........................................................................................................................13
FIGURE 5 - CABLE CONNECTOR RED DOT................................................................................................................................................14
FIGURE 6 - INFRARED INTERFACE CONNECTOR ......................................................................................................................................14
FIGURE 7 - MOUNTING SCREW ...............................................................................................................................................................15
FIGURE 8 - MOUNTING APPARATUS CAM LEVERS..................................................................................................................................15
FIGURE 9 - TRACKPIXX3 CAMERA (WITH LENS).......................................................................................................................................16
FIGURE 10 - LENS C-MOUNT ADAPTOR...................................................................................................................................................16
FIGURE 11 - TRACKPIXX3 CAMERA REAR LED..........................................................................................................................................17

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
4
TRACKPixx3 Installation Guide
Overview
This installation guide provides conformity, safety, hardware, installation and maintenance information for VPixx
Technologies Inc.’s TRACKPixx3 Short-Range and Long-Range systems.
The TRACKPixx3 is a versatile 2 kHz eye/gaze-tracking solution supporting both monocular and binocular tracking with a
single mechanical configuration. Interchangeable lenses support tracker distances from 24’’ to over 63’’ (60 cm to over
160 cm) depending on your application needs.
The TRACKPixx3 does not require a dedicated PC to process eye images and generate gaze information; all image
processing is performed within the TRACKPixx3 hardware.
For technical questions or product support information, do not hesitate to contact the VPixx support team by phone or
by sending an E-mail to [e-mail]
By creating your MyVPixx account on the VPixx Technologies website, you will have access to additional
product documentation, demos, source code examples and the latest firmware and software drivers.
The TRACKPixx3 device is suitable only for research and is not designed for medical applications or for
diagnostic purposes.

5
TRACKPixx3 Installation Guide
Compliance information
The VideoBahn interface on the TRACKPixx3 uses a fiber optic module whose manufacturer provides a certificate of
conformance for standard IEC 60825-1 Ed. 3 (2014)
CLASS 1 LED DEVICE
IEC 60825-1 Ed. 3 (2014)
For the United States of America
This device complies with part 15 subpart B of FCC rules. Its operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 subpart B of the FCC rules.
For Canada
This Class A digital apparatus complies with Canadian ICES-003.
CISPR warning
This is a Class A product. In domestic environments this product may cause radio interference in which case the user may
be required to take adequate measures.

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
6
TRACKPixx3 Installation Guide
For European Countries
DECLARATION OF CONFORMITY
Manufacturer’s Name: VPixx Technologies Inc.
Manufacturer’s Address: 630 Clairevue West suite 301
Saint-Bruno, Qc
Canada, J3V 6B4
Product Name: TRACKPixx3
Part Numbers: VPX-DPX-3410C
Product Options : All
Application of Council Directive:
2014/30/EU -Electromagnetic Compatibility directive
2001/95/EU -General Product Safety directive
2015/863/EU -Restriction of Hazardous Substances directive
2012/19/EU -Waste Electrical and Electronic Equipment directive
The following harmonised standards have been used:
EN 61326-1:2013 –Electrical equipment for measurement, control and laboratory use.
•IEC CISPR 11 -Radio frequency disturbance characteristics (Class A)
•IEC 61000-3-2 -Limits for harmonic current emissions (Class D)
•IEC 61000-3-3 -Limitation of voltage changes, voltage flicker (≤16A per phase)
•IEC 61000-4-2 –Electrostatic discharge immunity test (Level 2 contact, air) (Perf Criteria B)
•IEC 61000-4-3 –Radiated, radio-frequency, electromagnetic field immunity test (Level 2, Perf Criteria A)
•IEC 61000-4-4 –Electrical fast transient/burst immunity test (Level 2, Perf Criteria B)
•IEC 61000-4-5 –Surge immunity test (Level 2, Perf Criteria B)
•IEC 61000-4-6 –Immunity to conducted disturbances, induced by radio-frequency fields (Level 2, Perf Criteria A)
•IEC 61000-4-8 –Power frequency magnetic field immunity test (Level 2, Perf Criteria A)
•IEC 61000-4-11 –Voltage dips, short interruptions and voltage variations immunity tests (Perf Criteria B and C)
IEC 60825-1 Ed. 3 (2014)-CLASS 1 LASER PRODUCT
Supplementary Information:
To remain CE compliant, only CE compliant parts should be used with this product. Maintaining CE compliance also
requires proper cable and cabling techniques. VPixx Technologies will not retest systems or components that have been
modified by customers.
Signature: __________________________
Printed name: Jean-François Hamelin, Eng Title: Vice President

7
TRACKPixx3 Installation Guide
The following information is only for EU member states:
The mark shown to the left is in compliance with the Waste Electrical and Electronic Equipment directive
2012/19/EU (WEEE).
The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste. For
more information call VPixx Technologies Inc. or email us at [e-mail]
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2011/65/EU of the
European Parliament and the Council on restriction of the use of certain hazardous substances in electrical
and electronic equipment (RoHS Directive).

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
8
TRACKPixx3 Installation Guide
WARNINGS, SAFETY INFORMATION & USAGE NOTES
WARNINGS
The TRACKPixx3 can be used and mated with the InfraRed Short-Range Illuminator (VPX-TRK-9000), InfraRed Short-
Range 940nm Illuminator (VPX-TRK-9002) or the InfraRed Long-Range Illuminator (VPX-TRK-9010). Please refer to their
specific manuals for additional installation and safety information.
The 850 nm infrared light from the InfraRed Short-Range Illuminator device (VPX-TRK-9000)
and the 940 nm light from the InfraRed Short-Range 940nm Illuminator device (VPX-TRK-9002)
is invisible under most viewing conditions.
Subjects should not have their eyes within 16’’ (40 cm) of the Illuminator.
UNDER NO CIRCUMSTANCE SHOULD A SUBJECT HAVE HIS OR HER EYES CLOSER THAN 4’’ (10
CM) FROM THE ILLUMINATOR.
The 850 nm infrared light from the InfraRed Long-Range Illuminator device (VPX-TRK-9010) is
invisible under most viewing conditions.
Subjects should not have their eyes within 40’’ (100 cm) of the Illuminator.
UNDER NO CIRCUMSTANCE SHOULD A SUBJECT HAVE HIS OR HER EYES CLOSER THAN 4’’ (10
CM) FROM THE ILLUMINATOR.
Any modification and/or unauthorized (not previously approved in writing by VPIXX
TECHNOLOGIES Inc.) or improper use of the equipment contained in this product package may
void the warranty and may result in injury to users or damage to equipment. This includes the
opening of electronic equipment and connectors. There are no user-serviceable parts inside.
CISPR WARNING: this is a Class A product. In domestic environments, this product may cause
radio interference in which case the user may be required to take adequate measures.
Use of controls or procedures other
than those specified herein may result in hazardous
radiation exposure.

9
TRACKPixx3 Installation Guide
SAFETY INFORMATION
As Class 1 LED devices, the InfraRed Short-Range Illuminator (VPX-TRK-9000), InfraRed Short-Range 940nm Illuminator
(VPX-TRK-9002) and the InfraRed Long-Range Illuminator (VPX-TRK-9010) are compliant with the IEC-62471 LED safety
standard, which regulates LED and laser eye and skin safety. Class 1 LED devices are safe under most operational and
testing conditions. As the Illuminator may be used in test and laboratory conditions where a subject may be exposed to
its infrared emissions for protracted periods, precautions must be taken, mainly to ensure maximum subject comfort.
Please refer to the specific InfraRed Illuminator manual for installation and safety information.
USAGE NOTES
•Use only the provided power cable.
•Do not expose any component of the TRACKPixx3 to adverse weather conditions such as rain, water, heat, cold
or abnormally high levels of humidity.
•Unplug the system before cleaning, and refer to the appropriate cleaning procedure in the maintenance section
of this document to clean any component.
•Handle the power cable carefully. Never use a damaged power cable.
•Ensure that air circulation surrounds all system components.
In the event of failure, the TRACKPixx3 and InfraRed Illuminator devices should be replaced. There are no user
serviceable/adjustable parts inside. Contact VPixx Technologies Inc. for repair or replacement as required.
The TRACKPixx3 requires 15 minutes of warm-up time after power up before use. This warm-up period
will ensure the best image and tracking quality.

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
10
TRACKPixx3 Installation Guide
Typical setup
The DATAPixx3 and the TRACKPixx3 constitute the core data acquisition components of your eye-tracking solution. The
following illustration details a typical setup applicable to both the Short-Range and Long-Range systems.
DATAPixx3
TRACKPixx3
camera
Lab computer
No connection
between lab
computer and
Console monitor
X
Console monitor
D
B
C
InfraRed
Illuminator
AE
F
Stimulus
display
G
Figure 1 - Typical TRACKPixx3System Setup
Table 3 – TRACKPixx3 Setup Connection Descriptions
Connection
Description
A Fiber Optic cable from DATAPixx3 VideoBahn#1 connector to VideoBahn connector of
TRACKPixx3 camera
B USB cable from lab computer to DATAPixx3
C DisplayPort cable between computer and DATAPixx3 DisplayPort IN1 connector
D DisplayPort cable from DATAPixx3 DisplayPort OUT2 to console monitor DisplayPort input
E Power cable from DATAPixx3 power OUTPUT connector to TRACKPixx3 camera LEMO
power connector
F Cable from InfraRed Illuminator to TRACKPixx3 camera infrared interface connector
G DisplayPort cable from DATAPixx3 OUT1 to stimulus display

11
TRACKPixx3 Installation Guide
Setup – TRACKPixx3 Short-Range System
The following illustration details a typical setup and subject placement for a TRACKPixx3 Short-Range System (using either
VPixx Technologies’ InfraRed Short-Range Illuminator or InfraRed Short-Range 940nm Illuminator). Notice the suggested
distance between the subject and the camera.
Figure 2 - Typical TRACKPixx3Short-Range System Setup
Setup – TRACKPixx3 Long-Range System
The following illustration details a typical setup and subject placement for a TRACKPixx3 Long-Range System (using VPixx
Technologies’ InfraRed Long-Range Illuminator). Notice the suggested distance between the subject and the camera.
Figure 3 - Typical TRACKPixx3Long-Range System Setup

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
12
TRACKPixx3 Installation Guide
Installation Steps
Refer to the following steps for additional information concerning the installation of your TRACKPixx3. All connection
references refer to Figure 1 and Table 3.
Refer to the DATAPixx3 Installation Guide for associated cabling information.
DATAPixx3 connections
1. Connect the fiber optic cable from:
a. The DATAPixx3 VideoBahn#1 interface to the TRACKPixx3 VideoBahn fiber optic interface (Figure 4).
(connection A). A loud CLICK will be heard when this cable is properly connected both to the TRACKPixx3
and the DATAPixx3.
Remember when manipulating or connecting fiber optic cables not to kink or otherwise bend them below a
bending radius of 2‘’ (5 cm). Doing so may damage the cable.
2. Connect the USB cable from one of the Control Room computer’s USB ports to the DATAPixx3’s USB port
(connection B).
3. Connect a DisplayPort cable from:
a. The Control Room computer to the DATAPixx3 DisplayPort IN1 (connection C)
b. The DATAPixx3 DisplayPort OUT2 to the console monitor DisplayPort input (connection D)
c. The DATAPixx3 OUT1 to the stimulus display (connection G)
A
B

13
TRACKPixx3 Installation Guide
4. Connect a power cable from:
a. The DATAPixx3 +12 V OUTPUT (8 pins) to the TRACKPixx3 camera (connection E)
b. The TRACKPixx3 camera’s infrared interface connector to the InfraRed Illuminator (connection F)
c. Finally, connect the DATAPixx3’s supplied power cable to its power supply and the power supply to your
facility’s power outlet.
Camera and InfraRed Illuminator installation and connections
Figure 4 - TRACKPixx3 camera rear connectors
LEMO power
connector
Infrared interface
connector
Female connector
notch
VideoBahn fiber
optic interface
Female connector
notch
C
E
G
D

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
14
TRACKPixx3 Installation Guide
1. Ensure that when inserting either the Infrared interface cable or the power cable into the TRACKPixx3, the cable
connector orientation is such that its red dot is in line with the TRACKPixx3 camera connector’s female connector
notch (refer to Figure 4 and Figure 5).
Figure 5 - cable connector red dot
When disconnecting either an Infrared Interface connector or a LEMO power connector, remember that you
must first gently pull on the surrounding metal sleeve and then pull the connector out, or else the connector
will not come out. Using force to pull a connector out may damage the connector/cable.
2. The InfraRed Illuminator’s connector possesses an alignment notch at the top, to ensure that the connector is
properly aligned when inserted.
Figure 6 - InfraRed interface connector
3. Included in your TRACKPixx3 package is a mounting apparatus allowing you to assemble the TRACKPixx3 and the
InfraRed Illuminator device and arrange them in the exact position required by your application. The procedure
to mount either the TRACKPixx3 or InfraRed Illuminator device to the mounting apparatus is the same.
InfraRed interface
connector
Metal sleeve
Red dot

15
TRACKPixx3 Installation Guide
4. Slide the device along the mounting apparatus’ support arm.
5. Once in its desired location along the mounting arm, tighten the mounting screw at the back of the device to
secure it in place.
Figure 7 - Mounting screw
6. Once the devices are securely fitted to the mounting apparatus, use the three cam levers to aim the TRACKPixx3
and the InfraRed Illuminator device towards your subject.
Figure 8 - Mounting apparatus cam levers
Lens installation
Your TRACKPixx3 package includes one 50 mm or 75 mm lens which must be attached to the TRACKPixx3 camera before
using the system.
Cam levers

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
16
TRACKPixx3 Installation Guide
Figure 9 - TRACKPixx3 camera (with lens)
1. Your TRACKPixx3 package includes one 50 mm or 75 mm lens which must be attached to the TRACKPixx3 camera
before using the system. The lens type is identified on the lens itself. Ensure that you use the proper lens for
your experiment.
The 50 mm lens is typically used for an installation using a chinrest where the subject’s head is fixed and relatively
close to the TRACKPixx3 camera, while the 75 mm lens is used for setups using the Long-Range Illuminator. If
your experiment requires a remote installation, the TRACKPixx3 and the slave tracker should use a 25 mm lens.
To add the lens to the TRACKPixx3, simply place it on the lens receptacle area of your TRACKPixx3 and gently
screw it clockwise using its C-mount adaptor until the adaptor cannot turn anymore.
Figure 10 - Lens C-mount adaptor
2. Once the camera lens has been firmly installed and the system is operational, use the focus adjustment ring and
light aperture adjustment ring on the lens (refer to Figure 10) to adjust the image focus and brightness recorded
by the camera.
C-mount adaptor
Light aperture
adjustment
Focus adjustment

17
TRACKPixx3 Installation Guide
Console Monitor and Stimulus Display power connections
Use the appropriate power cables to connect the console monitor and the Stimulus display.
Chinrest installation
If your TRACKPixx3 package includes the optional chinrest, install it at a proper distance from the TRACKPixx3 camera
according to the setup diagram appropriate to your experiment (Figure 2 or Figure 3).
TRACKPixx3 camera rear LED
To the rear of your TRACKPixx3 camera is a status LED which, under normal operation will be ORANGE. After power up, a
short delay during which the LED will be RED signifies that the camera is in initialization mode.
Figure 11 - TRACKPixx3 camera rear LED
Software installation instructions
For information on how to install your software, please refer to the
Application Guide for VPixx Products
Rear status LED

Copyright © 2020 VPixx Technologies Inc. All Rights Reserved
18
TRACKPixx3 Installation Guide
Maintenance
The TRACKPixx3 system does not require periodic maintenance.
Cleaning the TRACKPixx3
Clean your TRACKPixx3 system as required and depending on usage.
For the lens, only use an appropriate microfiber cleaning cloth.
Do not use cleaners that contain any petroleum-based materials such as benzene,
thinner, or any volatile substance
Warranty
The TRACKPixx3 is warranted against manufacturing defects in materials and workmanship for a period of two years from
the date of purchase.
