NPB-232 Option
INSTALLATION SHEET
NPB-232 Option Installation Sheet
Part Number 10762 Draft:January 19, 2007 1
Information and specifications published here are current as of the date of publication of this document. Tridium, Inc. reserves the right to change or modify
specifications without prior notice. The latest product specifications can be found by contacting our corporate headquarters, Richmond, Virginia. Products or
features contained herein may be covered by one or more U.S. or foreign patents. © 2006 Tridium, Inc.
Thisdocumentcoversthemountingandwiringofthe
NPB‐232optioncardinaVykon®JACE‐2orJACE‐6
series(JACE‐2/6)controller.
ForrelatedJACE®mountingandwiringdetails,see
theappropriatedocument,forexampletheJACE‐2
MountingandWiringInstructionsdocument.
Included in this Package
Includedinthispackageyoushouldfindthe
followingitems:
•anNPB‐232optioncard,alongwithconnector
endplate.
•ThisNPB‐232OptionInstallationSheet,Part
Number10762,Draft:January19,2007.
Material and Tools Required
Thefollowingtoolsandsuppliesmayberequiredfor
installation:
•#2phillipsscrewdriver:usedtoinstallthe
NPB‐232optioncard.
Figure 1 NPB-232 option.
Mounting
Warning PowertotheJACEmustbeOFFwhen
installingorremovingoptioncards,or
damagewilloccur!Also,youmustbevery
carefultopluganyoptioncardintoits
connectorproperly(pinsaligned).
MounttheNPB‐232optioncardineitheroftheoption
cardslotsoftheJACE‐2/6,asavailable.Seethenotes
inTable 1onsoftwareCOMportassignmentsif
installingtwoNPB‐232optioncards.
Procedure 1 Mounting NPB-232 option card on a JACE.
1. Remove powerfromtheJACE—seethe
previousWarning.
2. RemovetheJACEcover.
Todothis,pressinthefourtabsonbothendsof
theunit,andliftthecoveroff.
Note Ifaccessorymodulesarepluggedintothe
JACE,youmayneedtoslidethemawayfrom
theunittogettothecovertabs.
3. Removethebatteryandbracketassemblyby
takingoutthefourscrewsholdingitinplace,
settingthescrewsasideforlater.Unplugthe
batteryfromtheconnectorontheJACE.See
Figure 2foranexplodedview.
Table 1 NPB-232 option description.
Description Notes
Single port RS-232
adapter, with DB-9M
connector. Uses its
ownon-boardUART.
Supports baud rates
up to 115200.
Note: The JACE
requires NiagaraAX
build level 3.1.24 or
higher to use the
NPB-232 option.
Up to 2 RS-232 option cards may be
installed. COM ports are assigned as
follows:
•If a single RS-232 option in Option
Slot 1, port is COM3.
•If two RS-232 options, ports are
COM3 for Option Slot 1, and COM4
for Option Slot 2.
•If a single RS-232 option in Option
Slot 2, with another option type in
Slot 1, the COM assignment varies:
See Figure 2 on page 2 for location of
JACE Option Slots.
Slot 1 Slot 2 NPB-232
NPB-MDM COM 3
NPB-LON COM 3
NPB-2X-485 COM 5
See Notes in
Table 1 about
COM port
assignment.

NPB-232 Option Installation Sheet
Draft: January 19, 2007 Part Number 10762
Port Pinouts
Material and Tools Required
2
Figure 2 Remove screws and battery assembly.
4. Removetheblankingendplatefortheslotyou
areinstallingtheoptioncardinto.
(Retaintheblankingendplateincasetheoption
cardmustberemovedatalaterdate.)
5. CarefullyinsertthepinsoftheNPB‐232intothe
socketoftheappropriateoptioncardslot.The
mountingholesontheoptionboardshouldline
upwiththestandoffsonthebaseboard.Ifthey
donot,theconnectorisnotproperlyaligned.
Pressuntiltheoptioncardiscompletelyseated.
6. Placethecustomendplatethatcamewiththe
NPB‐232overitsconnector(seeFigure 3).
Figure 3 NPB-232 inserted, end plate on top.
7. Plugthebatterycableintothebatteryconnector
ontheJACE(seeFigure 3forlocation).
8. Setthebatteryandbracketassemblybackover
theoptioncardslots,withthemountingholes
alignedwiththestandoffs.
9. Placethefourscrewsthroughthebatterybracket,
endplates,andintothestandoffsontheJACE
baseboard.Handtightenthesescrews.
Figure 4 Re-fasten screws through battery bracket.
10. ReplacetheJACEcover.
Ifaccessorymoduleswereunplugged,plugthem
backintotheJACEasbefore,andsecure.
Port Pinouts
TheNPB‐232optionhasstandardDB‐9Mpinouts,
identicaltotheRS‐232portontheJACE‐2/6base.
Table 2providesavisualreference.
StandardDB‐9serialcablesmaybeused,for
example,a“nullmodem”cabletocommunicateto
anotherDTEdevice.
LEDs
TwoLEDsarevisibleonthetopoftheNPB‐232
optioncard(covermustberemovedfromJACE).
Theyarealsonotedonthelabel—seeFigure 1.The
twoLEDsaredescribedasfollows:
•TX(yellow)—Transmit,indicatesthattheJACE
issendingdatatoadevice.
•RX(green)—Receive,indicatesthattheJACEis
receivingdatafromadevice.
Screws (4)
Option Slot 2
Area
JACE-2/6
Blanking
End
Plate
Battery
Assembly
(includes
cable and
bracket)
Unplug battery here
Option Slot 1
Area
JACE
Battery
Connector
Place NPB-232 custom
end plate over end.
Insert NPB-232 into
option card slot carefully,
with pins aligned.
Fully seat card.
Table 2 NPB-232 port pinouts.
Pinout Reference Signal DB-9 Plug Pin
DCD 1
RXD 2
TXD 3
DTR 4
GND 5
DSR 6
RTS 7
CTS 8
not used 9
Hand tighten the
4 screws through
battery bracket,
end plates, into
standoffs.
DB-9 Plug (male)
1
5
6
9
