Wagan Sport-Fridge/Radio User manual

Item #2407
User’s Manual
10.5 Liter Thermo
Sport-Fridge/Radio

www.wagan.com
1
10.5 Liter Thermo Sport-Fridge/Radio by Wagan Tech
©2010 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation 2
User’s Manual—Read before using this equipment
Always unplug your unit before cleaning.
Avoid all contact with enclosed or metal parts while your unit is in use.
Electrical shock or burn may result.
Keep your Sport Fridge in a clean environment with good airflow. Pet hair,
dust and dirt may impair your unit’s operation and void its warranty.
Features:
Cooling power = 10 pound block of ice
Superior foam insulation
Energy efficient
Low maintenance
Environmentally safe
No dangerous gases
ON/OFF switch with green LED indicator light
AM/FM Radio with built-in speakers and audio input jack
iPod/MP3 holder
Shoulder strap
•
•
•
•
•
•
•
•
•
•
•
•
•
Thank you for purchasing the 10.5 Liter Sport Fridge with AM/FM Radio by
Wagan Tech. With normal care and proper treatment it will provide years of
reliable use. Please read all operating instructions carefully before use.
Introduction:
The 10.5 Liter Sport Fridge with AM/FM Radio is the next step in temperature
control. Drinks are kept refreshingly cool in the hot summer without any more
needless ice purchases. Unit operates without the harmful CFC’s that is often
used in other refrigerants, and which can damage the ozone. As a result, the
Sport Fridge is an ecologically friendly solution that never needs recharging or
is in danger of toxic leaks and spills.
How This Unit Works:
The Sport Fridge uses 12 Volt Direct Current power source. This system
allows for easy power access from almost any Automotive or Marine
vehicle.
The Sport Fridge is also equipped with an adapter that operates via the
vehicle’s cigarette lighter.
Simply plug the male adapter into the 12 Volt socket, and the female end
of the cord into the two-prong socket on the Fridge.
Safety and Maintenance:
To maintain optimum working efficiency, periodically clean the unit with a
damp, cotton cloth. Avoid harsh cleaning agents as they can damage the
unit’s electrical wiring.
Please keep the unit out of temperature extremes, as excessive heat or cold
can cause the exterior shell to become hard and brittle and will increase the
likelihood of fractures.
Due to the electrical nature of the unit please be careful while handling
liquids around the exterior of the unit.
Do not operate unit for long extended periods of time as it may drain the
battery source.
Do not use ice in your Sport Fridge. Never fill your unit with liquid which is
not in a container. Liquid can corrode the fan and motor parts, impairing
performance.
Air intake and fan areas should never be blocked. Never operate your unit
in a car trunk or enclosed area.
•
•
•
•
•
•
•
•
•
High insulated cover
Adjustable should strap
Clear plastic cover
Durable rubber seal ring
High insulation body material
On/Off Switch
AD/DC Power input
iPod/MP3 holder
Exhalation vents
Long-life brushless motor

Radio bands display
On/Off Switch
and Volume control
Audio input jack
Headphone jack
Tuning control
Stereo speaker
AM/FM Switch
Radio power input (Radio
can be powered with 9V
battery or AC/DC adapter)
www.wagan.com
3
10.5 Liter Thermo Sport-Fridge/Radio by Wagan Tech
©2010 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation 4
User’s Manual—Read before using this equipment
Operation:
The Sport Fridge uses low battery power and operates up to three hours on a
normal car battery. For any extended time beyond that, it is suggested that the
unit be used with a running engine, or else the battery levels may become too
low to start the engine.
Check to make sure the cooler power switch is in the OFF position.
Plug the cigarette lighter plug into the cigarette lighter socket in your vehicle
or other 12 volt DC power supply (minimum 5 Amps).
Move the switch into the on position.
The green LED indicator light will illuminate to show the unit is working.
Place items inside the storage compartment and close the lid.
1.
2.
3.
4.
5.
Using The AM-FM Radio:
Select either AM or FM band.
Turn on the Radio by turning the ON/OFF Volume knob clockwise.
Rotate the Tuning Dial to the desired frequency.
Adjust the Volume control to desired loudness.
After use, Turn OFF the Radio by rotating the ON/OFF Volume knob
counterclockwise until the knob “clicks”.
Troubleshooting:
If the unit seems to be not working properly:
First check to see if the adapter is firmly secured within the lighter socket
before proceeding.
Make sure the two-prong socket is firmly attached to the cooling unit. If both
adapters are securely plugged in, make sure that the battery source has
enough power to charge the unit.
Try plugging the unit into another power source, and checking to see if the
unit can work with this new power source.
Some parts of the 12V adaptor may come loose after prolonged use, and
may dislodge them. If this is the case, simply retighten the adapter top by
screwing in crisscrossed top until tight.
Specifications:
Capacity: 10.5 Liters (Approx. 16 12oz Cans)
Cools to 40ºF-45ºF below room temperature
Power consumption: 54W
Brushless motor: 30,000 hrs
Input power: 5 Amps 12V DC
Temperature control: Thermostatic
Insulation material: Polyurethane foam
Audio Input Jack: 3.5mm diameter (1/8 in)
Power cord: Approx. 9ft
1.
2.
3.
4.
5.
•
•
•
•
•
•
•
•
•
•
•
•
•
AM-FM Radio:
The Radio can receive frequencies in the standard AM and FM broadcast
bands: AM-520 to 1710 kHz; FM 88 to 108 MHz.
All Radio controls are conveniently located in one area. The controls are:
ON/OFF Volume, AM-FM Selection Switch, a Tuning Dial and an Audio
Input Jack for external audio devices such as MP3s or CD players (Required
3.5mm mini audio cable-not included).
The Radio can be powered with a 9V battery or AC/DC adapter.
NOTE: All AM band radios are subject to receiving noise interference from electronic
devices, static lightning strikes, and some motorized equipment. If you are operating the
Sport Fridge and noise is being received on the AM band, either turn OFF the fridge or
change the radio to receive the FM band.
•
•
•

All WAGAN Corporation products are warranted to the original purchaser of this
product.
Warranty Duration: This product is warranted to the original purchaser for a
period of one (1) Year from the original purchase date, to be free of defects in
material and workmanship. WAGAN Corporation disclaims any liability for
consequential damages. In no event will WAGAN Corporation be responsible for
any amount of damages beyond the amount paid for the product at retail. In the
event of a defective item, please contact WAGAN Corporation at [phone]
to obtain a Returned Merchandise Authorization number (RMA#), and return
instructions. Each item returned will require a separate RMA#. After you have
received the RMA# and the return instructions from WAGAN Corporation, please
follow the instructions and send the item with PREPAID SHIPPING, along with all of
the required documentation, a complete explanation of the problem, your name,
address and daytime phone number. WAGAN Corporation will, at its option,
replace or repair the defective part.
A Returned Merchandise Authorization number (RMA#) is REQUIRED when
sending in any defective item. WAGAN Corporation is not responsible for any
item(s) returned without an official Returned Merchandise Authorization number.
The item(s) must be returned with prepaid shipping. WAGAN Corporation is not
responsible for any shipping charges incurred in returning the item(s) back to the
company for repair or replacement. This warranty is void if the product has been
damaged by accident, in shipment, unreasonable use, misuse, neglect, improper
service, commercial use, repairs by unauthorized personnel or other causes not
arising out of defects in materials or workmanship. This warranty is effective only
if the product is purchased and operated in the USA and does not extend to any
units which have been used in violation of written instructions furnished.
Warranty Disclaimers: This warranty is in lieu of all warranties expressed or
implied and no representative or person is authorized to assume any other liability
in connection with the sale of our products. There shall be no claims for defects
or failure of performance or product failure under any theory of tort, contract or
commercial law including, but not limited to negligence, gross negligence, strict
liability, breach of warranty and breach of contract.
Warranty Performance: During the above one (1) Year warranty period, a product
with a defect will be replaced with a comparable model when the product is
returned to WAGAN Corporation with an original store receipt. The replacement
product will be in warranty for the balance of the one (1) Year warranty period.
Updated August 2008
