Wahsega WL-SPKR-SMT-A Assembly instructions

Wall Mount
Extension Speaker
Installer’s Guide
Getting Started
This step-by-step guide will help you install your Wahsega Wall
Mount Extension Speaker.

Wall Mount -A Speaker Installation Guide Page 2 10.25.2020
What’s In the Box
Speaker assembly
Mounting bracket
Mounting hardware
(4) #6-32 Screws
(4) #6 lock washers
(8) #8-32 Screws
(8) #8 lock washers

Wall Mount -A Speaker Installation Guide Page 3 10.25.2020
What You Will Need
Wahsega primary speaker
Compatible models:
WL-SPKR-22-CAR
WL-SPKR-22-INF
WL-SPKR-22-CAR-2CH
WL-SPKR-22-INF-2CH
WL-SPKR-SMT-CAR
WL-SPKR-SMT-INF
WL-SPKR-SMT-CAR-2CH
WL-SPKR-SMT-INF-2CH
WL-IPD-SPKR-510-CAR
WL-IPD-SPKR-510-INF
WL-IPD-SPKR-510-CAR-2CH
WL-IPD-SPKR-510-INF-2CH
WL-IPD-SPKR-520-CAR
WL-IPD-SPKR-520-INF
WL-IPD-SPKR-510D-CAR
WL-IPD-SPKR-510D-INF
WL-IPD-SPKR-510D-CAR-TM
WL-IPD-SPKR-510D-INF-TM
WL-IPD-SPKR-540-CAR
WL-IPD-SPKR-540-INF
Network cable
Cat 5e or Cat 6 straight cable
Screwdrivers
Small flat head screwdriver
Phillips head screwdriver

Wall Mount -A Speaker Installation Guide Page 4 10.25.2020
Connecting Your Wahsega Extension Speaker
Primary
Speaker
(-CAR or -INF)

Wall Mount -A Speaker Installation Guide Page 5 10.25.2020
PRIMARY SPEAKER CONNECTION
The -A speaker receives its power and data from a Wahsega primary
speaker. Connect a Cat5e or Cat6 straight cable to the primary speaker
up to 20m away. Do not use a crossover cable.
Compatible models:
WL-SPKR-22-CAR
WL-SPKR-22-INF
WL-SPKR-22-CAR-2CH
WL-SPKR-22-INF-2CH
WL-SPKR-SMT-CAR
WL-SPKR-SMT-INF
WL-SPKR-SMT-CAR-2CH
WL-SPKR-SMT-INF-2CH
WL-IPD-SPKR-510-CAR
WL-IPD-SPKR-510-INF
WL-IPD-SPKR-510-CAR-2CH
WL-IPD-SPKR-510-INF-2CH
WL-IPD-SPKR-520-CAR
WL-IPD-SPKR-520-INF
WL-IPD-SPKR-510D-CAR
WL-IPD-SPKR-510D-INF
WL-IPD-SPKR-510D-CAR-TM
WL-IPD-SPKR-510D-INF-TM
WL-IPD-SPKR-540-CAR
WL-IPD-SPKR-540-INF
Once the unit is successfully powered, the amber indicator LED on
the front of the speaker will begin to blink.

Wall Mount -A Speaker Installation Guide Page 6 10.25.2020
Mounting and Installation
Mount included bracket to the front of a standard two-gang electrical
backbox (preferred), using (4) included #6-32 screws and lock washers.
If mounting bracket to a solid surface rather than to an electrical
backbox, use the appropriate bolts and anchors for that surface.

Wall Mount -A Speaker Installation Guide Page 7 10.25.2020
Attach speaker to bracket using included (8) #8-32 screws and washers.

Wall Mount -A Speaker Installation Guide Page 8 10.25.2020
Cable access is available through rear opening or side panel knockout.

Wall Mount -A Speaker Installation Guide Page 9 10.25.2020
Dimensions
Front
Side

Wall Mount -A Speaker Installation Guide Page 10 10.25.2020
Rear

Wall Mount -A Speaker Installation Guide Page 11 10.25.2020
Standards Compliant
This product is designed and manufactured in the USA.
ROHS compliant
Temperature rating -40C to +60C.

Wall Mount -A Speaker Installation Guide Page 12 10.25.2020
Wahsega Wall Mount Extension Speaker
WL-SPKR-SMT-A
Installation Guide
