Walkera iLook User manual

iLook Camera User manual
1.0 Key Features
1) Lightweight and smart design (2) 5.8G FPV wireless transmission
3) Low latency and long range FPV (4) Support output Micro SD card
7) Support wireless Video link to 5.8G radio / OSD device/iPhone/iPad
8) Support Walkera 5.8G DEVO F7 to send the live video directly to the
transmitter's display
(
(
(5) Support G-2D brushless gimble (6) Support Video and Camera
(
(
2.0 Specifications
(1) Video
a. Video Resolution: HD 1280 x720P
c. Micro High Speed SD card: Max 32G
e. AV output QVGA 320x240 PAL/1Vp-p
b. FPS: 30
d. Video Format: AVI
f. Photo: 1,000,000 Pixels
(2) 5.8G wireless
a. 5.8G wireless image transmission b. FCC Bind B section: 4 channels
c. CE Bind B section: 8 channels d. FCC Output Power <200mW
e. CE Output Power <25mW
3.0 Pictures illustration
Button Rear view of iLook
Antenna Video/Phote Switch
Ww Walkera © E)
© = (E)
look Power port(DC 7V-15V)
Channel code switch
Indicator(Blue light) Micro SD card slot
4.0 Transmitting channel selection
Note: When iLook camera transmission channel corresponds to
transmitter video receiving channel , the transmitter can receive the
video display, other channels appear blue screen.
WW walkera
4.1 DEVO F7 Video Select
Press ENT to the Main Menu. Press UP or DN to move the cursor — to
point to System Menu, press ENT to System Menu; Press UP or DN to
move the cursor — to point to Video Select, press ENT to Video Select
setting interface. Press R or L to select Active. Press DN to move the cursor
— to point to Channel item, press R or L to make the Number change
between 1 and 8. With the iLook camera transmitting channel,
1-8 channels could be
chosen to receive the
image signal. Press ENT | ~Status eave Status Asie
to confirm and then press
EXT to exit.
Video Select 7.4V Video Select 7.4V
Ch | Channel
anne > 1/8
4.2 iLook(FCC/CE) camera transmitting channel selection
There are 8 different channels can be selected. You can choose the best
frequency channel according to the image quality as bellow:
ON ON ON
| l 00
0 0 0 I |
1 2 3 1 2 3 1 2 3
Channel 1 Channel 2 Channel 3 Channel 4
code position code position code position code position
ON ON ON ON
[l [l U 0 0 0 0 0
1 O | [l
1 2 3 1 2 3 12 3 1 2 3
Channel 5 Channel 6 Channel 7 Channel 8
code position code position code position code position
Note: Only transmitting channel 2, 4, 6, 8 are available for the iLook(FCC).
5.0 Video and Photo user guide
Note: MICOR SD card must be inserted to the iLook camera before
connecting the power, and took off after disconnecting the power.
(Recommend to use high speed SD card)
5.1 Video instruction

iLook Camera User manual
(1) Manual Operation
Please first turn the Video/Photo Swich to pil, press and release the button,
iLook camera starts to Video(the blue indicator keep flash); Press again
and release, iLook camera stops video(The blue indicator keeps solid).
(2) Radio Operation
Please first turn the Video/Photo Swich to pl, turn the GEAR switch to "1"
position within 1-2 seconds, then return to "0" position, iLook camera will
start to video(the blue indicator keep flash); toggle the GEAR switch again,
iLook camera stop video(The blue indicator keeps solid)
5.2 Photo instruction
Please put the video/photo switch to I, Press and release the button,
iLook camera starts single phase (The blue indicator keeps solid), press
again and release the button, and then take another picture.
6.0 Connect Illustration
Note: The GEAR switch of the transmitter output port channel should
be consistent with the receiver output port.
Normal
Connect
Illustration
Power port
(DC 7V-15V)
loom
@ iLook Camera transfer wire
@ Transfer wire
®© Aircraft power wire
Camera control wire
® Camera
controller
Receiver
QR X350PRO
Connect
Illustration
a | Power port
WY walkera
(DC 7V-15V)
@ iLook Camera transfer wire
© Transfer wire
®© Aircraft power wire
@ Camera control wire
Camera
controller
When user-defined
video, connect AUX1
(DIY is necessary).
QR X350
Connect
Illustration
Power port
(DC 7V-15V)
@ iLook Camera transfer wire
@ Transfer wire
© Aircraft power wire
@ Camera control wire
W
Camera
controller
— iy
