Wanner Engineering STAN-COR MK Series User manual

“MK” Series Magnetically-Driven,
Kynar, Sealless Centrifugal Pumps
W0469
Installation and
Operation Manual
SCM-991-2400A
WANNER ENGINEERING, INC.
1204 Chestnut Avenue, Minneapolis, MN 55403
TEL: [phone] FA X: [phone]
TOLL-FREE FAX [US only]: [phone]
www.stancorpump.com
email: [e-mail]

Wanner Engineering, Inc.
2United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Contents
General Instructions ............................................2
Explanation of Symbols....................................... 2
List of Tools ..........................................................2
Dimensions ........................................................... 3
Parts ...................................................................... 4
Pump and Motor Installation ............................... 6
Startup...................................................................7
Shutdown ..............................................................7
Maintenance and Repair ...................................... 7
Removal from System.......................................... 7
Disassembly .........................................................8
Assembly ............................................................ 10
Troubleshooting ................................................. 14
Warranty .............................................................. 15
General Instructions
This Manual covers Group 1 Wanner MK Series pumps.
Upon receipt of your WANNER MK pump verify:
1. The equipment has not been damaged in transit.
2. The pump model number and serial number are stamped on
the nameplate.
Model:
Serial No:
Explanation of Symbols
Work Safety Symbol
This symbol indicates remarks applicable to
operational safety, where injury to personnel may
be posed. All cautions should be passed on to other
users.
Attention Symbol
Special attention must be paid in order to avoid
damage to the pump and/or other plant equipment.
List of Tools
• Bearing removal/installation kit
• 9/16” wrench
• 3/4” wrench (two required)
• 15/16” wrench (two required)
• 5/16” Allen wrench
• Flat screw driver(s)
!
ATTENTION
Contents

3
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
2" Discharge Flange
5/8-11 Threaded Inserts
on 4-3/4 BC (4) Places
ANSI Class 150 FF
3 Sunction Flange
5/8-11 Inset Bolts
on 6 BC (4) Places
ANSI Class 150 FF
3/8 NPT Far Side
Plugged
Mtg Bolt 3/8-16 Case Lock
C
L
Motor Mtg Face
Rotation
2.0
(50.8)
2.0
(50.8)
8.91
(226.3)
4.00
(101.6)
0.22
(5.6)
1.52
(38.6)
6.50
(165.1)
5.25
(133.4)
0.50
(12.7)
11.75
(298.5)
0.63
(16) 3.00
(76.2) 4.72
(119.9)
6.22
(158)
6.22
(158)
W0471
1" Discharge Flange
1/2-13 Threaded Inserts
on 3-1/8 BC (4) Places
ANSI Class 150 FF
1-1/2 Sunction Flange
1/2-13 Inset Bolts
on 3-7/8 BC (4) Places
ANSI Class 150 FF
3/8 NPT Far Side
Plugged
Mtg Bolt
Rotation
3/8-16 Case Lock
Motor Mtg Face
C
L
2.0
(50.8)
2.0
(50.8)
0.50
(12.7)
8.91
(226.3)
4.00
(101.6)
0.22
(5.6)
6.50
(165.1)
5.25
(133.4)
11.75
(298.5)
0.63
(16) 3.00
(76.2) 4.72
(119.9)
6.22
(158)
1.43
(36.3)
6.22
(158)
W0470
Models MK04, MK08
Pump Dimensions in (mm)
Model MK12
Flange Dimensions – ANSI B73.1
ANSI Suction Discharge
Model Size 150 lb FF Flange 150 lb FF Flange
MK04 1.5 x 1 x 6 1-1/2” 1”
MK08 1.5 x 1 x 8 1-1/2” 1”
MK12 3 x 2 x 6 3” 2”
Dimensions

Wanner Engineering, Inc.
4United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Mounting to
254TC-256TC NEMA Frame Motors
Mounting to
56C-215TC, 284TC, 284TSC
NEMA Frame Motors
27 33 6 17 15 37 30 44
x 6
44
x 6
44
x 2
21
x 2
14 23 38 3 1 2 43 35 21
x 4
29
45
20
7
11
36
13
5
4
22
28
34
31
25
32
26 24 39 19 8 16 10 18 9 12
32 26
27 21
x 4
21
x 4
33
W0472A
INSET A
10
6.42" (163 mm)
Outer Magnet
Mounting Distance
1 Casing
2 Discharge Flange
3 O-ring, Discharge
4 Suction Flange
5 O-ring, Suction
6 Containment Can
7 Impeller
8 Inner Magnet
9 Wear Ring, Outer Rear
10 Wear Ring, Inner Rear
11 Wear Ring, Outer Front
12 Wear Ring, Inner Front
13 Thrust Washer, Front
14 Bearing, Forward
15 Bearing, Rear
16 Spacer, Bearing
17 Shaft,
18 O-ring, Containment Shell
19 Stator
20 Case Support
21 Hex Nut
22 Support, Suction Flange
23 Support, Discharge Flange
24 Outer Magnet
25 Motor Hub
26 Adapter
27 Motor Adapter
28 Screw, Hex-Head Cap
29 Screw, Hex-Head Cap
30 Hex Nut
31 Screw, Socket-Head Set Screw
32 Screw, Socket-Head Cap
33 Screw, Socket-Head Cap
(for 56C-215TC, 284TC,
284TSC NEMA motors)
Screw, Hex-Head Cap (Inset A)
(for 254TC-256TC NEMA
motors)
34 Screw, Socket-Head Cap
35 Screw, Hex-Head Cap
36 Screw, Hex-Head Cap
37 Screw, Hex-Head Cap
38 Hex Nut
39 Pipe Plug
43 Washer
44 Washer
45 Screw, Hex-Head Cap
Parts

5
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
1 001S110 MK04: Casing, 1-1/2 x 1 x 6, Kynar........................... 1
001S111 MK08: Casing, 1-1/2 x 1 x 8, Kynar........................... 1
001S112 MK12: Casing, 3 x 2 x 6, Kynar................................... 1
2 300S001 MK04 & MK08: Discharge Flange, 1.0”, Kynar ..... 1
300S003 MK12: Discharge Flange, 2.0”, Kynar...................... 1
3 530S001-1 MK04 & MK08: O-ring, Discharge Flange, 1”,
Viton .................................................................................. 1
530S001-2 MK04 & MK08: O-ring, Discharge Flange,
1”, Blk Chemraz.............................................................. 1
530S001-3 MK04 & MK08: O-ring, Discharge Flange, 1”,
EPDM................................................................................. 1
530S001-4 MK04 & MK08: O-ring, Discharge Flange, 1”,
SIMRIZ 485 ...................................................................... 1
530S004-1 MK12: O-ring, Discharge Flange, 2”, Viton........... 1
530S004-2 MK12: O-ring, Discharge Flange, 2”, Blk Chemraz.....1
530S004-3 MK12: O-ring, Discharge Flange, 2”, EPDM.......... 1
530S004-4 MK12: O-ring, Discharge Flange, 2”, SIMRIZ 485.....1
4 300S002 MK04 & MK08: Suction Flange, 1.5”, Kynar.......... 1
300S004 MK12: Suction Flange, 3”, Kynar .............................. 1
5 530S002-1 MK04 & MK08: O-ring, Suction Flange, 1-1/2”,
Viton .................................................................................. 1
530S002-2 MK04 & MK08: O-ring, Suction Flange,
1-1/2”, Blk Chemraz ...................................................... 1
530S002-3 MK04 & MK08: O-ring, Suction Flange, 1-1/2”,
EPDM................................................................................. 1
530S002-4 MK04 & MK08: O-ring, Suction Flange, 1-1/2”,
SIMRIZ 485 ...................................................................... 1
530S005-1 MK12: O-ring, Suction Flange, 3”, Viton................ 1
530S005-2 MK12: O-ring, Suction Flange, 3”, Blk Chemraz . 1
530S005-3 MK12: O-ring, Suction Flange, 3”, EPDM .............. 1
530S005-4 MK12: O-ring, Suction Flange, 3”, SIMRIZ 485..... 1
6 050S001 Containment Can, Kynar............................................ 1
7 031S010 MK04: Impeller, 1-1/2 x 1 x 6, Kynar........................ 1
031S012 MK08: Impeller, 1-1/2 x 1 x 8, Kynar........................ 1
031S011 MK12: Impeller, 3 x 2 x 6, Kynar................................ 1
8 040S002 Inner Magnet, Kynar.................................................... 1
9 075S012 Wear Ring, Outer Rear, Kynar/SC............................. 1
10 075S004 Wear Ring, Inner Rear, SC........................................... 1
11 075S011 Wear Ring, Outer Front, Kynar/SC........................... 1
12 075S013 Wear Ring, Inner Front, Kynar/SC............................ 1
13 080S001 Thrust Washer, Front, SC............................................ 1
14 070S001 Bearing, Forward, SC................................................... 1
15 070S002 Bearing, Rear, SC ........................................................... 1
16 105S001 Spacer, Bearing, Kynar ................................................ 1
17 060S003 Shaft, SC........................................................................... 1
Ref
No. Part Number Description Qty/Pump
Ref
No. Part Number Description Qty/Pump
18 530S003-1 O-ring, Containment Shell, Viton........................... 1
530S003-2 O-ring, Containment Shell, Blk Chemraz............. 1
530S003-3 O-ring, Containment Shell, EPDM.......................... 1
530S003-4 O-ring, Containment Shell, SIMRIZ 485 ............... 1
19 105S002 Stator, Kynar ................................................................... 1
20 800S001 Case Support, Vinyl Ester .......................................... 1
21 D10-028-2012 Hex Nut, 3/8-16, 18-8 SST.........................................10
22 850S002 MK04 & MK08: Support, Suction Flange, 1-1/2”,
GF Nylon .......................................................................... 1
850S004 MK12: Support, Suction Flange, 3”,
GF nylon........................................................................... 1
23 850S001 MK04 & MK08: Support, Discharge Flange,
1”, GF nylon..................................................................... 1
850S003 MK12: Support, Discharge Flange,
2”, GF nylon..................................................................... 1
24 090S100 Outer Magnet, Steel .................................................... 1
25 090S004 Motor Hub, for 256TC NEMA, Steel (1.625” bore)...1
090S008 Motor Hub, for 56C NEMA, Steel (0.625” bore).. 1
090S009 Motor Hub, for 145TC NEMA, Steel (0.875” bore).. 1
090S010 Motor Hub, for 182TC NEMA, Steel (1.125” bore)... 1
090S011 Motor Hub, for 215TC NEMA, Steel (1.375” bore)... 1
090S012 Motor Hub, for 284TC NEMA, Steel (1.875” bore).. 1
26 508S001 Adapter, Close Coupled, Ductile Iron ................... 1
27 560S001 Motor Adapter for 56C to 215TC, 254TC-256TC**
NEMA, GF Nylon..............................................................................1
560S002 Motor Adapter for 254TC-256TC**
NEMA, GF Nylon............................................................ 1
560S003 Motor Adapter for 284TC NEMA, Steel................. 1
560S004 Motor Adapter for 284TSC NEMA, Steel .............. 1
28 902S007 Screw, Hex-Head Cap 1/2-13 x 6-1/2, 18-8 SST... 6
29 902S006 Screw, Hex-Head Cap 1/2-13 x 7, 18-8 SST........... 2
30 901S002 Hex Nut 1/2-13, 18-8 SST .......................................... 14
31 904S001 Screw, Soc-Head Set Screw, 3/8-16 x 1/2, Steel.. 2
32 903S003 Screw, Soc-Head Cap, for 56C to 215TC
NEMA, 1/2-13 x 1, 18-8 SST ........................................ 4
33 903S002 Screw, Soc-Head Cap, for 56C to 215TC, 284TC,
284TSC NEMA, 3/8-16 x 1-1/4, 18-8 SST ................ 4
903S010 Screw, Soc-Head Cap, for 254TC-256TC
NEMA, 3/8-16 x 2-1/4, 18-8 SST ................................ 4
34 903S001 Screw, Soc-Head Cap, 10-32 x 3/4, 18-8 SST ....... 8
35 902S001 Screw, Hex-Head Cap, 3/8-16 x 1-3/4, 18-8 SST . 4
36 902S002 MK04 & MK08: Screw, Hex-Head Cap,
1/2-13 x 3, 18-8 SST....................................................... 4
902S005 MK12: Screw, Hex-Head Cap, 5/8-11 x 3-1/4,
18-8 SST............................................................................ 4
Parts

Wanner Engineering, Inc.
6United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Pump and Motor Assembly
Installation
All items included in this section.
The following should be observed for proper installation of the
pump.
1. Pump should be accessible for servicing and inspection.
2. The foundation area should be rigid .
3. The inlet should be as close to the liquid source as practical
and preferably below it.
4. Piping should be supported. Do not use the pump as a pipe
hanger.
5. Install valves to isolate pump during maintenance.
6. Suction and discharge piping should be the same size or
larger than the pump inlet and outlet ports. Install a pressure/
vacuum gage in the suction piping a pressure gage in the
discharge piping.
7. Clean piping as necessary to remove dirt, grit, weld slag,
etc.
8. Provide clearance behind motor to remove motor and outer
magnet (24) approximately 2 feet.
9. For further instructions on mounting or installing your pump,
refer to the Hydraulic Institute Handbook.
Ref
No. Part Number Description Qty/Pump
37 902S003 Screw, Hex-Head Cap, 3/8-16 x 1-1/4, 18-8 SST.. 2
38 901S002 MK04 & MK08: Hex Jam Nut, 1/2-13, 18-8 SST.... 4
901S004 MK12: Hex Jam Nut, 5/8-11, 18-8 SST..................... 4
39 906S001 Pipe Plug, 3/8, Steel ..................................................... 1
40* 23017 Name Plate, SST............................................................. 1
41* 12530 Drive Screws, Steel/Zinc Plate ................................. 4
42* 902S004 Screw, Hex-Head Cap 3/8-16 x 1, 18-8 SST .......... 2
43 100-657 Washer, 3/8 at, 18-8 SST........................................... 4
44 905S001 Washer, 1/2 at, 18-8 SST.........................................14
45 902S008 MK04& MK08: Screw, Hex-Head Cap,
1/2-13 x1-3/4.............................................................................................4
902S009 MK12: Screw, Hex-Head Cap,
5/8-11 x 2-1/4 .................................................................. 4
* Not Shown
** Items 560S001 and 560S002 are required for 254TC-256TC NEMA
motors.
Parts/Installation

7
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Removal from System
When the pump is handling flammable, toxic or hazardous fluid,
flush the pump prior to removal from the piping system. Prior
to flushing and disassembly consult the Material Safety Data
Sheet (MSDS) for the pumped fluid to ensure procedures and
precautions as specified are adhered to. Exercise extreme care
to avoid contact with the fluid.
Insure the pump’s motor switch is in “off” position and locked
out.
Maintenance
Flush the pump and drain. Use drain connection “if option has
been installed”.
!
Maintenance and Repair
The pump has internal bearings that will require replacement
over time.
The selection of a sealless pump may have been due to a
concern for leakage of hazardous liquids. When performing
maintenance on this pump, cautionary steps should be taken
to ensure proper drainage or cleansing of the liquid inside the
pump prior to disassembly.
Work Safety
Magnetic drive pumps contain strong magnets, which pose risk
to people and property. Based on this, the following must be
observed.
1. Individuals with cardiac pacemakers should avoid repairs on
these units.
2. Individuals with internal wound clips, metallic wiring, or other
metallic prosthetic devices should avoid repairs on these
units.
3. Strong magnetic field can cause tools and parts to slam
together; injuring hands and fingers.
4. Keep magnets away from credit cards, computers, computer
discs and watches.
Start-up
Preliminary
BE CERTAIN MOTOR IS LOCKED OUT.
1. Open suction and discharge valves.
2. Check system for leaks.
3. Rotate unit by hand. On close coupled units, rotate motor
fan.
4. Be certain guards are in place.
5. Remove motor lockout.
6. Jog pump to check rotation.
Running
1. Observe suction and discharge gages.
2. Monitor the unit for 15 minutes to make certain it is operating
satisfactorily.
a. Check suction and discharge valves.
b. Check for unusual sound or vibration.
Shutdown
Short Term
1. Stop unit.
2. Lock out motor.
3. Leave suction and discharge valves open.
Long Term
1. Stop unit.
2. Lock out motor.
3. Close and lock out suction and discharge valves.
Start-up

Wanner Engineering, Inc.
8United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0473
2. Remove hex bolts (35), and then detach flange support
(23) with discharge flange (2) by lifting straight up as
shown in Figure 2. Remove discharge flange (2) from
flange support (23) and inspect O-ring (3). Replace if
damaged.
1. Remove socket head cap screws (33) using a 5/16” Allen
wrench to detach pump assembly from motor.
Figure 1
W0474
Figure 2
Figure 3
3. Position the pump so the suction is facing up as shown in
Figure 3 while being careful not to loose the 3/8” hex nuts
inserted in the bottom rear half of case support (20).
4. Remove hex bolts (28 & 29), and then remove the front
half of case support (20).
5. Insert two flat screw drivers 180° from each other between
case (1) and discharge flange support (22). Using the
screw drivers, gently pry the flange support off the case (1).
Remove suction flange (4) from support. Inspect O-ring (5)
on flange (4), and replace if damaged.
5.1. Remove case (1) from containment can (6). It may be
necessary to remove the case (1) and containment can
(6) from the adapter (26). If the two are removed together,
position them so the containment can (6) is up. Hold
containment can while tapping the case edge around the
case diameter using a small rubber hammer. Do not let case
fall as the two pieces are separated.
W0475
Disassembly

9
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0479
W0477
W0476
W0478
11. Remove shaft (17) from the containment can by lifting/pulling
straight out. Do not twist.
12. Rotate outer rear wear ring (9) clockwise and lift out.
13. Inspect O-ring (18) and replace if damaged.
8. Rotate inner front wear ring (12) counter clockwise and lift.
9. Push bearings (14,15) and spacer (16) from impeller (7) using
bearing removal tool and a small press. Note: the bearings
can be removed with the inner magnet attached.
10. Remove inner rear wear ring (10) from impeller (7).
Figure 4
Figure 5
Figure 6
6. Remove inner magnet and impeller assembly from pump.
7. If the inner magnet (8) needs to be removed from the impeller,
insert a flat screw driver into the slot and depress the lock
by pushing in and at the same time rotate inner magnet (8)
counter clockwise. A vise can be used to clamp the inner
magnet.
14. Rotate stator (19) clockwise to remove. A stator removal tool
is available if the stator is stuck or damaged. (Note: the stator
has left hand threads.)
15. Remove containment can (6) from adapter if it has not been
removed. Inspect inside and outside of can and replace if
damaged.
Figure 7
Disassembly

Wanner Engineering, Inc.
10 United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0482
W0484
Alignment
Notch (14)
W0481
W0480
W0483
9. Align notch in forward bearing (14) with spot on end face of
impeller (7). Press into impeller to seated position with bearing
installation tool.
10. Install spacer (16) and press to seat into notch of forward
bearing (14).
11. Install rear bearing (15) and press to seat into lug on spacer
(16) with bearing installation tool.
6. Install stator (19) into containment can (6), with counter
clockwise rotation (left hand thread).
7. Install outer rear wear ring (9) into lock pockets and rotate
counter clockwise. Heat stake in three places.
8. Install shaft (17).
3. Insert two hex head cap screws (37) into back half of case
support (20), and into adapter (26). Secure with hex nuts (21).
Position pump vertically as shown in Figure 10.
4. Install containment can (6).
5. Install O-ring (18).
1. Assemble motor adapter (27) to motor and secure with socket
head cap screws (32).
2. Assemble outer magnet assembly (24, 25) to motor shaft and
lock with two set screws (31). Locate at 6.4 inches as shown
on page 4.
Figure 8
Figure 9
Figure 10
Figure 11
Assembly

11
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0487
W0486
W0485
12. Place inner rear wear ring (10) on impeller (7). Notches no
the ring are to engage drive lugs on back face of impeller.
Figure 12
W0488
16. Install inner front wear ring (12) by first aligning tabs of ring
with grooves on the impeller. Once aligned, press ring onto
the impeller and rotate clockwise to lock. If the fit is not tight,
heat stake the ring to the impeller in three places. Remove
any raised plastic from heat staking process.
13. Assemble inner magnet (8) by FIRST aligning key on impeller
(7) with keyway notch inside the inner magnet bore. Once
the key and the keyway are aligned, press the inner magnet
onto the impeller.
14. Once the inner magnet is tight against the impeller, rotate
the inner magnet clockwise until the anti-rotation lock/tab is
visible in the notch in the inner magnet.
Figure 13
Figure 14
Figure 15
W0498
Assembly

Wanner Engineering, Inc.
12 United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0493
W0490
W0492
Figure 20
W0491
W0489
18. Install front thrust washer (13) into cover and engage anti
rotation dogs.
19. Install outer front wear ring (11) into case lug pockets and
rotate clockwise to secure and lock thrust washer tight into
the case. Heat stake in three places.
Figure 16
Figure 17
17. Install assembled inner magnet and impeller assembly onto
shaft and lower gently into containment can.
21. Carefully install case (1) over shaft carefully and onto
containment can. Press firmly in place. The case will not seat
tight over the containment can at this time during assembly
because the containment can O-ring will not be compressed.
See Figures 18-19.
Figure 19
22.The suction flange support (22) has four pockets with raised
ribs to hold the hex head bolts (36) in place after installed.
Insert hex head bolts into the suction flange support (22) as
shown in Figure 20.
Figure 18
Assembly

13
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
W0494
W0497
W0496
28. There are four nut pockets with ribs in the discharge flange
support (23). Install hex nuts (38) into discharge flange
support (23) using a hammer as needed to fully seat the
nuts.
29.Install hex nuts (21) into the slots in the front half of casing
support (20).
30.Lubricate the O-ring (3) that is inside the discharge flange (2)
and press the flange into the discharge flange support (23).
32.Install two remaining hex nuts (21) into rear half of case
support.
33.Install washers (43) and hex head cap screw (35) fastening
the discharge flange support ash shown in Figure 25. Hand
tighten only.
35.Position pump vertically as shown in Figure 22 and fully
tighten bolts (28) and (29) to 12-13 ft. lbs.
36.AFTER all case bolts are tight, then fully tighten discharge
flange support bolts (35).
37. Lubricate O-ring (5) inside of the suction flange (4) and install
suction flange support.
38.Guide assembled pump module over drive magnet.
Caution: Magnets will pull strongly. Keep fingers clear.
39.Secure pump module to motor adapter (27) with socket head
cap screws (33).
Prior to start up, be certain that motor turns freely. Rotate
motor fan by hand.
26.Install front half of case support (20), and secure with six
bolts (28) with washers (44) and hex nuts (30). Insert two hex
nuts (21) into the pockets. Install two longer bolts (29) and
washers (44) in the two bolt holes near the discharge port.
Snug all bolts – do not fully tighten.
27. Install two hex head cap screws (42) until they make contact
with the case.
24.Install O-ring (3) onto discharge flange (2).
25.Install O-ring (5) onto suction flange (4).
Figure 22
Figure 23
Figure 24
W0495
23.Install suction flange support (22) over the case suction port
shown in Figure 21. Bolts to straddle centerlines.
Figure 21
W0475
Assembly

Wanner Engineering, Inc.
14 United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Problem Possible Cause Remedy
Pump Does Not Prime Fluid not reaching pump Verify suction pipe is submerged
Open suction valve
Wrong direction of rotation Reverse motor leads
No Discharge Valves closed Verify valves are open
Bypass valve open Adjust by pass valve
Air leak in suction Tighten connections
Apply sealant to all threads
Verify suction pipe is submerged
Clogged strainer Clean strainer
Pump is worn Rebuild pump
Magnetic coupling broken free Stop pump. Wait until there is no rotation and
restart pump
NPSH problems
Inlet pressure too low Verify suction pipe is not too long
Insufficient Discharge Insufficient flow Fully open suction valves
Clogged strainer Clean strainer
Speed too low Increase driver speed if possible
Pump not sized to application A larger pump may be required
Bypass valve open Adjust bypass valve
Pump worn Rebuild pump
Loss of Suction After Change in fluid properties Verify fluid properties
Satisfactory Operation Air leak in suction Tighten connections
Verify suction pipe is submerged
Excessive Power Head lower than rated Reduce flow
Consumption Liquid to heavy Check specific gravity and viscosity
Worn or damaged parts Service unit
Rapid Pump Wear Abrasives in fluid
Erosion Materials of construction not
suitable for fluid being pumped
Troubleshooting

15
Wanner Engineering, Inc.
United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
Limited Warranty
Wanner Engineering, Inc. extends to the original purchaser
of equipment manufactured by it and bearing its name, a
limited one-year warranty from the date of purchase against
defects in material or workmanship, provided that the
equipment is installed and operated in accordance with the
recommendations and instructions of Wanner Engineering,
Inc. Wanner Engineering, Inc. will repair or replace, at its
option, defective parts without charge if such parts are
returned with transportation charges prepaid to Wanner
Engineering, Inc., 1204 Chestnut Avenue, Minneapolis,
Minnesota 55403.
This warranty does not cover:
1. The electric motors (if any), which are covered by
the separate warranties of the manufacturers of these
components.
2. Normal wear and/or damage caused by or related to
abrasion, corrosion, abuse, negligence, accident, faulty
installation or tampering in a manner which impairs normal
operation.
3. Transportation costs.
This limited warranty is exclusive, and is in lieu of any
other warranties (express or implied) including warranty
of merchantability or warranty of fitness for a particular
purpose and of any noncontractual liabilities including
product liabilities based on negligence or strict liability.
Every form of liability for direct, special, incidental or
consequential damages or loss is expressly excluded
and denied.
Warranty

Wanner Engineering, Inc.
16 United States Instant Information: www.stancorpump.com
[phone] Fax [phone] SCM-991-2400A
WANNER ENGINEERING, INC.
1204 Chestnut Avenue, Minneapolis, MN 55403
TEL: [phone] FA X: [phone]
TOLL-FREE FAX [US only]: [phone]
www.stancorpump.com
email: [e-mail] © 2005 Wanner Engineering, Inc. Printed in USA
SCM-991-2400A 8/2005, Revised 9/2007
