Wanner Engineering Vector 2000 Series User manual

W0454
Peristaltic Pumps
W0453
Installation and
Operation Manual
VEC-991-2400E
Vector 2000 Series
Models: 2002, 2003, 2004, 2005, 2006, 2007
Models: 2002, 2003, 2004
Models: 2005, 2006, 2007
1204 Chestnut Avenue, Minneapolis, MN 55403
Tel: [phone] Fax: [phone]
Toll-free fax [US only]: [phone]
www.vectorpump.com
email: [email protected]

Wanner Engineering, Inc.
2United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Contents
Important Precautions ........................................... 2
How to Use this Maintenance Manual ................... 2
Principles of Operation ........................................... 2
Installation Planning ............................................... 2
Pump Test and Installation ..................................... 3
Before Initial Start-Up ............................................. 3
Maintenance .......................................................... 4
Troubleshooting ...................................................... 4
Service
Models 2002, 2003, 2004, 2005........................ 5
Models 2006, 2007............................................ 7
Parts ....................................................................... 9
Warranty ............................................................... 15
Installation Planning
Inlet Piping
• Size the inlet line one or two sizes larger than pump suction
opening.
• Suction lines should be as short and direct as possible.
• Size the suction line so that the velocity will not exceed
1 – 3 ft/sec.
Velocity = 0.408 x GPM
Pipe ID2
• Install a 3 ft. to 4 ft. exible hose between pump and hard
piping to absorb vibrations, expansions, or contractions.
• Install an inlet pressure/vacuum gauge on the inlet side of the
pump.
• To reduce turbulence and resistance, do not use 90° elbows.
If turns are necessary in the suction line use 45° elbows or
long sweeping elbows when required.
• Install piping supports where necessary to relieve strain on
the inlet line and to minimize vibration.
• In extreme cases, a pulsation dampener may be required if
hard piped.
Discharge Piping
• Size the discharge line to at least one size larger than the
pump inlet connection.
• Between the pump and hard piping, install exible a hose long
enough to reduce pulsations (typically 3 ft. to 4 ft.).
• Install a pressure gauge in the discharge piping.
• In extreme cases, a pulsation dampener may be required to
absorb excessive pulsation (caused by high pump speed and
long discharge lines).
Vector 2000 Series Installation
! CAUTION
Important Precautions
• To avoid personal injury or pump damage, follow all
instructions and safety precautions carefully.
• Don’t exceed the manufacturer’s recommended RPM
or pressure limits.
• Follow all codes and hydraulic recommendations on
installation and operation of the pumping system.
• To prevent vibration, mount the pump and motor securely
toarigid, level base.
• For safety and easier servicing, provide adequate work
space around the pump. Allow space to remove the front
cover, hose clamps, hose, and drive unit.
W0387
How to Use this Maintenance Manual
This technical manual covers the Vector 2000 Series pumps.
The manual provides instructions on how to install, start, and
maintain the pumps. All persons, installers, and users must
read the manual in its entirety prior to installation and use.
Your local Wanner distributor is also available for additional
information.
For a reply, please include the following information:
• Type of pump
• Pump
Also visit our website www.vectorpump.com for further infor-
mation.
Principle of Operation
Two rollers, mounted on a rotor, alternately compress a thick-
walled hose in a patented concentric guide. As they rotate, they
push the liquid in the hose from the suction to the discharge side.
The subsequent opening of the hose, after a roller passes, creates
a vacuum on the suction side — resulting in continuous pumping.

3
Wanner Engineering, Inc.
Material Operating Temperatures
Material Operating Temperatures
EPDM 32 to 185˚ F
Hypalon 32 to 180˚ F
Neoprene 50 to 130˚ F
Silicone 14 to 185˚ F
Varprene 14 to 185˚ F
Natural Rubber 14 to 185˚ F
Nitrile Rubber 23 to 160˚ F
Pharmed®32 to 180˚ F
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Vector 2000 Series Installation
Pump Test and Installation
Before you install the pump in the system, set the direction of
pump rotation and the position of the pressure rollers:
1. Remove front cover from pump.
2. See Figure 1. For easier adjustment, check that pressure
rollers are in position shown (one roller compressing middle
of hose, and one roller free).
Note: Model 2006 and 2007 pumps use a di󰀨erent rotor
assembly than the one shown.
Before Initial Start-Up
Before you pump uid through the system, be sure that:
1. All shuto󰀨 valves are open.
2. All connections are tightly secured.
3. See Hose Identication Table. Hose material is compatible
with uid being pumped, and hose design matches duty cycle
and discharge pressures.
Hose Identication
Extruded Code Description
Hypalon HE Black color, shinny smooth surface
Neoprene PE Flat black color, rough surface, rubber
smell
Varprene VE Cream color, smooth surface
Silicone SE Rust color, smooth surface
Pharmed®FE Cream color, Pharmed® name on hose
Fiber Braided
Hypalon HF Black color, yellow or blue stripe, double
braided
EPDM EF Black color, white stripe, double braided
Natural Rubber NF Black color, green stripe, double braided
(standard duty)
Natural Rubber MF Black color, no stripes, thick double
braids (heavy duty)
Nitrile Rubber BF Black color, white inner hose
Nitrile Rubber - Oil Rated OF Black color, HBRF-HY-K stamped on
hose
W0455
W0456
Pressure
Rollers
Figure 1
W0456
DISCHARGE
INLET
Figure 2
3. Connect incoming power supply to motor (refer to motor
manufacturer’s instructions).
4. See Figure 2. Run pump and check direction of rotation,
“A” or “B” as shown. All pumps must rotate in direction “A“
(counterclockwise). To reverse rotation, exchange two of three
wires that connect incoming power to motor.
5. Set pressure rollers (see “Service: Setting the Roller
Pressure”). Roller pressure is not set at factory, because it
must be adjusted to compensate for size of inlet and discharge
lines and specic gravity of uid being pumped.
6. Verify all fasteners are properly tightened.
7. Reattach front cover.
8. Install pump in system.
4. See Material Operating Temperatures Table. Temperature of
uid pumped is within operating temperature range of hose
material installed in pump. Hose material can be identied by
5th and 6th digit of pump model number. E.g. 2007-NF-BB-D2,
where ‘NF’ designates natural rubber.
CAUTION: Contact factory when pumping a uid that is
within 15˚ F of the maximum hose temperature. Take safety
precautions to insure hot pumpage does not harm operators
if a hose leaks.

Wanner Engineering, Inc.
4United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Vector 2000 Series Installation
Troubleshooting
If the hose fails prematurely, check for:
• Chemical attack. If the hose becomes soft, spongy, or harder
than when originally supplied, chemical attack may be the
problem.
• Improper hose selection for the uid being pumped.
• Improper roller setting. If ow uctuates back and forth or up
and down in the discharge line, the rollers may not be adjusted
with equal pressure on the hose.
• See Figure 3. If the hose fails in area A, this may occur from
operating the pump at a discharge pressure higher than the
hose is rated for, or with a closed discharge line. If the hose
fails in area B, this may occur from operating the pump under
a higher vacuum or higher inlet pressure than the hose is rated
for, or with a closed suction line.
• Line system problems — debris, closed valves, or a clogged
or packed line.
• Fluid temperature too high.
• Abrasive material being pumped, or solid size too large.
• Hose connector becomes loose:
- Wrong size connector.
- Suction pressure too high
W0456
DISCHARGE
INLET
A
B
Figure 3
Routine Maintenance
Periodically inspect hose for signs of failure caused by chemical
attack, material fatigue, etc.
Check non-petroleum silicone lubricant on hose, and reapply if
worn o󰀨.
Inspect roller bearings for damage, and replace if necessary
(See Parts List, item 11).
Check that all fasteners are properly tightened.

5
Wanner Engineering, Inc.
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Replacing Worn Hose
Remove Old Hose
1. Turn o󰀨 and lock out all power to pump motor.
2. Remove front cover from pump (four screws).
3. See Figure 4. Position pressure rollers as shown.
4. Loosen screw(s) that secure mounting bracket of pressure
roller which is compressing hose. To maintain correct hose
compression adjustment, DO NOT loosen opposite roller’s
mounting bracket.
5. See Figure 5. Loosen hose clamp bolts. Remove hose
supports and clamps that secure both ends of hose.
6. Remove hose from pump casing.
7. Pull (cut hose if needed) hose connectors from worn hose.
Clean if reusable.
8. Carefully clean pump casing and front cover.
Service (Models 2002, 2003, 2004, 2005)
W0458
Loosen screw(s) that
secure this bracket.
Do not loosen screw(s)
for this bracket.
Figure 4
Hose Support
Hose Clamp
W0459
Figure 5
9. Spin each roller to determine integrity of the bearings. Replace
roller and bearing assembly if either roller does not spin or
either roller runs rough.
Install New Hose
1. Check for correct length of hose:
Model 2002: 13 in. (330 mm)
Model 2003: 15 3/8 in. (390 mm)
Model 2004: 23 1/4 in. (590 mm)
Model 2005: 33 7/8 in. (860 mm)
2. Install connectors in new hose.
3. Make sure that pressure rollers are in same position as before.
See Remove Old Hose, Step 3.
4. Position bent hose inside pump casing.
5. Push upper connector against end of pump casing. Install top
hose clamp and secure its bolt.
6. Repeat Step 5 on lower connection.
Important: On models 2002 through 2005, make sure the
hose lays completely against the inside of the pump casing.
7. Smear non-petroleum silicone grease on inner surface of
hose (where rollers contact hose).
8. Set roller pressure according to procedure following
(steps 2 thru 6).

Wanner Engineering, Inc.
6United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Service (Models 2002, 2003, 2004, 2005)
Setting Roller Pressure
Note: This pressure setting must be checked when a new hose
is installed, because of variations in hose thickness.
1. Remove front cover from pump.
2. See Figure 6. Loosen all roller bracket screws and slide both
rollers away from the hose to reduce compression on the
hose. Retighten all roller bracket screws.
4. Test pump in full operation, and readjust as necessary.
5. Reattach front cover.
a. If there is vacuum on rst attempt, rollers are set.
b. See Figure 8. If not enough vacuum, gradually move rollers
forward in 1/32 to 1/8 in. (0.8 to 3.0 mm) increments and
repeat test until suction seems to be correct. (Make sure
compression is same for both rollers by measuring roller
bracket in relation to rectangular rotor block).
3. See Figure 7. Start pump. Place palm of hand over suction
opening and check for vacuum.
W0460
Roller adjustment
position
Figure 6
W0461
Inlet (Suction)
Opening
Figure 7
W0462
Measure
here.
Measure
here.
These two dimensions
should be the same.
Figure 8

7
Wanner Engineering, Inc.
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Service (Models 2006 and 2007)
Replacing a Worn Hose
Remove Old Hose
1. Turn o󰀨 and lock out all power to pump motor.
2. Remove front cover from pump.
3. See Figure 9. Position rotor as shown.
Install New Hose
1. Check for correct length of hose:
Model 2006: 45 1/4 in. (1150 mm)
Model 2007: 57 1/4 in. (1455 mm)
2. Install connectors in new hose.
3. Position bent hose inside pump casing.
4. Push upper connector against end of pump casing. Install top
clamp and secure clamp bolt.
5. Repeat Step 4 on the lower connection.
Important: On models 2006
and 2007, allow a 1-1.5 mm gap
between the hose and the inside
of the pump casing at Point A as
shown in the illustration at right.
6. Smear non-petroleum silicone grease on inner surface of
hose (where rollers contact hose).
7. Turn the rotor 180°. Reinstall the roller holder without shims.
8. Set roller pressure according to procedure following
(steps 3 thru 7).
5. See Figure 11. Loosen clamp bolts. Remove hose supports
and clamps that secure both ends of hose.
6. Remove hose from pump casing.
7. Pull (cut hose if needed) hose connectors from worn hose.
Clean if reusable.
8. Carefully clean pump casing and front cover.
9. Spin each roller to determine integrity of the bearings. Replace
roller and bearing assembly if either roller does not spin or
either roller runs rough.
W0465
Point
A
W0463
Roller
Holder
Rotor
Figure 9
W0464
Figure 10
Hose Support
Hose Clamp
W0459
Figure 11
4. Remove roller holder not compressing hose. Also remove any
shims under it.
5. See Figure 10. Turn rotor 180° as shown.

Wanner Engineering, Inc.
8United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
W0466
Inlet (Suction)
Opening
Figure 12
Setting Roller Pressure
Note: The pressure setting must be checked when a new hose
is installed, because of variations in hose thickness.
1. Remove front cover from pump.
2. Remove any shims under two roller holders.
3. Be sure bolts securing roller holders are tight.
4. See Figure 12. Start pump. Place palm of hand over suction
opening and check for vacuum.
a. If there is vacuum on rst attempt, rollers are set.
b. If not enough vacuum, gradually add 0.02 in. (0.5 mm).
shims under one of rollers and repeat test until suction
seems to be correct. Contact factory before installing
more than four shims under each roller.
5. Add same number of shims under other roller.
6. Test pump in full operation, and readjust as necessary.
7. Reattach front cover.
Service (Models 2006 and 2007)

9
Wanner Engineering, Inc.
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2002
W0467B
24
32
31
28
29
27
30
33
10
1 2002-001-1001 Casing with shaft assembly.............. 1
2 2002-002-1001 Cover, Front......... ............................. 1
3 2002-003-1001 Window, Cover, clear........................ 1
2002-003-1002 Window, Cover, solid........................ 1
4 2002-004-1001 Bracket............. ................................. 1
5 2002-005-1001 Roller Assembly ............................... 1
6 100-038 Clamp, Hose.... ................................. 2
7 2004-007-1001 Screw, Cover ................................. 1
8 2002-108-2312 Hose, Neoprene ............................... 1
2002-108-2314 Hose, Varprene ................................ 1
2002-108-2316 Hose, Hypalon...... ............................ 1
2002-108-2318 Hose, PharMed ................................ 1
2002-108-2323 Hose, EPDM..... ................................ 1
2002-108-2329 Hose, Natural Rubber....................... 1
10 G20-089-2010 Screw, Roller ................................. 1
16 2002-016-1001 Connector, PTFE, 1/2”...................... 2
2002-016-1102 Connector, 316 SST, 3/4” ................. 2
2002-016-1104 Connector, 316 SST, 3/8” ................. 2
2002-016-1108 Connector, Brass, 3/8” ..................... 2
2002-016-1109 Connector, Brass, 3/8” male ............ 2
2002-016-1112 Connector, 316 SST, 3/8” male ........ 2
Ref. Quantity/
No. Part Number Description Pump
17 2002-017-1001 Base ................. ................................ 1
18 2003-018-1001 Bolt, Mounting................................... 6
19 2002-019-1001 Nut..................... ................................ 6
20 2002-020-1001 Washer.............. .............................. 16
21 2003-021-1001 Bolt, Cover........ ................................ 4
23 2002-023-1001 Support, Hose................................... 2
24 2003-024-1001 Washer, Roller................................... 1
27 2002-005-1004 Bracket, Roller. ................................. 2
28 2004-005-1005 Screw, Bracket ................................. 2
29 2004-005-1006 Washer, Bracket ............................... 2
30 2002-005-1003 Roller, Shaft, & Bearing Assy........... 2
31 2002-005-1006 Screw, Roller..................................... 4
32 2002-005-1005 Washer, Roller... ............................... 4
33 2002-005-1008 Rotor................. ................................. 1
Ref. Quantity/
No. Part Number Description Pump

Wanner Engineering, Inc.
10 United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2003
W0467B
24
32
31
28
29
27
30
33
10
1 2003-001-1001 Casing with shaft assembly.............. 1
2 2003-002-1001 Cover, Front...... ................................ 1
3 2003-003-1001 Window, Cover, clear........................ 1
2003-003-1002 Window, Cover, solid........................ 1
4 2003-004-1001 Bracket ............. ................................ 1
5 2003-005-1001 Roller Assembly ............................... 1
6 2003-006-1001 Clamp, Hose..... ................................ 2
7 2004-007-1001 Screw, Cover..................................... 1
8 2003-108-2314 Hose, Varprene ................................ 1
2003-108-2316 Hose, Hypalon......... ......................... 1
2003-108-2317 Hose, Silicone................................... 1
2003-108-2318 Hose, PharMed.. .............................. 1
2003-108-2323 Hose, EPDM...................................... 1
2003-108-2329 Hose, Natural Rubber....................... 1
10 G20-089-2010 Screw, Roller..................................... 1
16 2003-016-1001 Connector, PTFE, 3/4”...................... 2
2003-016-1102 Connector, 316 SST, 3/4” ................. 2
2003-016-1104 Connector, 316 SST, 1/2” ................. 2
2003-016-1108 Connector, Brass, 1/2” ..................... 2
2003-016-1109 Connector, Brass, 1/2” male............. 2
2003-016-1112 Connector, 316 SST, 3/4” male ........ 2
Ref. Quantity/
No. Part Number Description Pump
17 2003-017-1001 Base .................................................. 1
18 2003-018-1001 Bolt, Mounting................................... 6
19 2003-019-1001 Nut ..................................................... 6
20 2002-020-1001 Washer ............................................ 16
21 2003-021-1001 Bolt, Cover ............................ ............ 4
23 2003-023-1001 Support, Hose ................................. 2
24 2003-024-1001 Washer, Roller................................... 1
27 2003-005-1006 Bracket, Roller... ............................... 2
28 2004-005-1005 Screw, Bracket ................................. 2
29 2004-005-1006 Washer, Bracket ............................... 2
30 2003-005-1005 Roller, Shaft, & Bearing Assy........... 2
31 2002-005-1006 Screw, Roller..................................... 4
32 2002-005-1005 Washer, Roller............... .................... 4
33 2003-005-1009 Rotor ........................ ......................... 1
Ref. Quantity/
No. Part Number Description Pump

11
Wanner Engineering, Inc.
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2004
W0467B
24
32
31
28
29
27
30
33
10
1 2004-001-1001 Casing with shaft assembly.............. 1
2004-001-1002 Casing only........................................ 1
2004-011-1001 Bearing.............................................. 1
2004-001-1004 Shaft only........................................... 1
2 2004-002-1001 Cover, Front....................................... 1
3 2004-003-1001 Window, Cover, clear ....................... 1
2004-003-1002 Window, Cover, solid........................ 1
4 2004-004-1001 Bracket .............................................. 1
5 2004-005-1001 Roller Assembly ............................... 1
6 2004-006-1001 Clamp, Hose...................................... 2
7 2004-007-1001 Screw, Cover..................................... 3
8 2004-108-2312 Hose, Neoprene ............................... 1
2004-108-2314 Hose, Varprene................................. 1
2004-108-2316 Hose, Hypalon................................... 1
2004-108-2317 Hose, Silicone................................... 1
2004-108-2323 Hose, EPDM.......... ........................... 1
2004-108-2329 Hose, Natural Rubber....................... 1
2004-108-2332 Hose, Nitrile....................................... 1
2004-108-2349 Hose, Natural Rubber, HD ............... 1
2004-108-2332 Hose, Nitrile....................................... 1
10 G20-089-2010 Screw, Roller..................................... 1
Ref. Quantity/
No. Part Number Description Pump
16 2004-016-1001 Connector, PTFE, 1”......................... 2
2004-016-1102 Connector, 316 SST, 1” .................... 2
2004-016-1104 Connector, 316 SST, 3/4” ................. 2
2004-016-1107 Connector, Carbon Steel, 3/4”.......... 2
2004-016-1108 Connector, Brass, 3/4”...................... 2
2004-016-1109 Connector, Brass, 3/4” male............. 2
2004-016-1112 Connector, 316 SST, 3/4” male ........ 2
17 2004-017-1001 Base ................................................... 1
18 2004-018-1001 Bolt, Mounting.................................... 6
19 2004-019-1001 Nut ..................................................... 6
20 2007-020-1001 Washer..................... ........................ 16
21 2004-021-1001 Bolt, Cover......................................... 4
23 2004-023-1001 Support, Hose.................. ................. 2
24 2004-024-1001 Washer, Roller....................................1
27 2004-005-1004 Bracket, Roller ................................. 2
28 2005-005-1005 Screw, Bracket ................................. 2
29 2005-005-1006 Washer, Bracket............................... 2
30 2004-005-1003 Roller, Shaft, & Bearing Assy .......... 2
31 2004-005-1005 Screw, Roller..................................... 4
32 2004-005-1006 Washer, Roller.................................. 4
33 2004-005-1008 Rotor ................................................. 1
Ref. Quantity/
No. Part Number Description Pump

Wanner Engineering, Inc.
12 United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2005
W0468
X
X
10
24
W0468D
24
32
31
28
29
27
30
33
10
1 2005-001-1001 Casing with shaft assembly ............. 1
2 2005-002-1001 Cover, Front...................................... 1
3 2005-003-1001 Window, Cover, clear ....................... 1
2005-003-1002 Window, Cover, solid........................ 1
5 2005-005-1001 Roller Assembly ............................... 1
6 2005-006-1001 Clamp, Hose .................................... 2
7 2004-007-1001 Screw, Cover.................................... 3
8 2005-108-2312 Hose, Neoprene............................... 1
2005-108-2314 Hose, Varprene................................ 1
2005-108-2323 Hose, EPDM .................................... 1
2005-108-2326 Hose, Hypalon ................................. 1
2005-108-2329 Hose, Natural Rubber ...................... 1
2005-108-2349 Hose, Natural Rubber, HD ............... 1
2005-108-2332 Hose, Nitrile ..................................... 1
10 2005-010-1001 Screw, Roller.................................... 1
16 2005-016-1102 Connector, 316 SST, 1-1/2”.............. 2
2005-016-1104 Connector, 316 SST, 1” ................... 2
2005-016-1105 Connector, 316 SST, ANSI 1” .......... 2
Ref. Quantity/
No. Part Number Description Pump
Ref. Quantity/
No. Part Number Description Pump
2005-016-1107 Connector, Carbon Steel, male 1” ... 2
2005-016-1010 Connector, PTFE, 1” ........................ 2
2005-016-1011 Connector, PTFE, 1-1/4” .................. 2
17 2005 -017-1001 Base ................................................. 1
18 2005-018-1001 Bolt, Mounting .................................. 4
20 2007-020-1001 Washer............................................. 4
21 2005-021-1001 Bolt, Cover ....................................... 4
23 2005-023-1001 Support, Hose.................................. 2
24 2005-024-1001 Washer, Roller.................................. 1
25 2005-025-1001 Bolt, Drive ........................................ 4
26 2005-026-1001 Washer, Drive................................... 4
27 2005-005-1004 Bracket, Roller.................................. 2
28 2005-005-1007 Screw, Bracket ................................. 2
29 2005-005-1009 Washer, Bracket............................... 2
30 2005-005-1003 Roller, Shaft, & Bearing Assy........... 2
31 2005-005-1005 Screw, Roller.................................... 4
32 2005-005-1006 Washer, Roller.................................. 4
33 2005-005-1008 Rotor................................................. 1

13
Wanner Engineering, Inc.
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2006
W0584A
19
17
9
18
23
4
1
4
3
11
7
2
10
24
16
6
8
5
33
30
29
28
1 2006-001-1001 Casing (old)........................................ 1
2006-001-2001 Casing (new 2018)........................ ..... 1
2 2006-002-1001 Cover, front (old)............................... 1
2006-002-2001 Bracket, front (new 2018) ................. 1
3 2006-003-1001 Window, cover (old).......................... 1
2006-003-2001 Window, cover (new 2018) ............... 1
4 STD HDW SHC Screw, M8x20, SST ............... 16
5 2006-005-1001 Roller Assembly ............................... 1
6 2006-006-1001 Clamp, Hose (old)............................. 4
2006-006-2001 Clamp, Hose (new 2018) .................. 4
7 STD HDW SHC Screw, M6x20, SST ................ 3
8 2006-108-2312 Hose, Neoprene ............................... 1
2006-108-2314 Hose, Varprene ................................ 1
2006-108-2317 Hose, Silicone.................................... 1
2006-108-2323 Hose, EPDM...................................... 1
2006-108-2326 Hose, Hypalon................................... 1
2006-108-2329 Hose, Natural Rubber....................... 1
2006-108-2332 Hose, Nitrile........................................ 1
2006-108-2349 Hose, Natural Rubber, HD................ 1
9 2006-017-1004 Frame, Left (new 2018)..................... 1
10 2006-010-1001 Screw, Roller...................................... 1
11 STD HDW Washer, M6, SST ............................ 3
Ref. Quantity/
No. Part Number Description Pump
16 2006-016-2102 Connector, 316 SST, tri, 1-1/2” ......... 2
2006-016-2104 Connector, 316 SST, barb, 1-1/4” ....... 2
2006-016-2105 Connector, 316 SST, ANSI, 1-1/4” ......... 2
2006-016-2103 Connector, 316 SST, 1-1/2” male .......2
2006-016-2106 Connector, Carb stl, ANSI, 1-1/4” ........ 2
2006-016-2007 Connector, Carb stl, male, 1-1/2”........ 2
2006-016-2110 Connector, PTFE, 1-1/4” ................... 2
2006-016-2111 Connector, PTFE, 1-1/4” ................... 2
17 2006-017-1005 Frame, Right (new 2018)................... 1
18 STD HDW Stud, M12x40, SST ........................... 4
19 STD HDW SHC Screw, M12x25 ........................ . 4
23 2006-017-2003 Bracket, Rear (new 2018) ................. 1
24 2006-024-1001 Washer, Roller .................................. 1
28 2006-005-1005 Screw, Bracket.................................. 4
29 2006-005-1006 Washer, Bracket................................ 4
30 2006-005-1003 Roller, Shaft, & Bearing Assy ........... 2
33 2006-005-1004 Rotor ................................................. 1
- 2006-099-1001 Shim, 0.5 mm.................................... 8
Ref. Quantity/
No. Part Number Description Pump

Wanner Engineering, Inc.
14 United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Parts - Model 2007
W0584A
19
17
9
18
23
4
1
4
3
11
7
2
10
24
16
6
8
5
33
30
29
28
1 2007-001-1001 Casing (old)........................................ 1
2007-001-2001 Casing (new 2017)............................. 1
2 2007-002-1001 Cover, front (old)............................... 1
2007-001-2002 Bracket, front (new 2017) ................. 1
3 2007-003-1001 Window, cover (old).......................... 1
2007-003-1002 Window, cover (new 2017) ............... 1
4 STD HDW SHC Screw, M8x25, SST ................16
5 2007-005-1001 Roller Assembly ............................... 1
6 2007-006-1001 Clamp, Hose (old)............................. 4
2007-006-2001 Clamp, Hose (new 2017) .................. 4
7 STD HDW SHC Screw, M6x20, SST ................. 3
8 2007-108-2314 Hose, Varprene ................................ 1
2007-108-2323 Hose, EPDM...................................... 1
2007-108-2326 Hose, Hypalon................................... 1
2007-108-2329 Hose, Natural Rubber....................... 1
2007-108-2332 Hose, Nitrile....................................... 1
2007-108-2349 Hose, Natural Rubber, HD................ 1
9 2007-017-1004 Frame, Left (new 2017)..................... 1
10 2007-010-1001 Screw, Roller..................................... 1
11 STD HDW Washer, M6, SST ............................. 3
Ref. Quantity/
No. Part Number Description Pump
16 2007-016-2102 Connector, 316 SST, tri, 2” ............... 2
2007-016-2104 Connector, 316 SST, barb, 2-1/2” ........ 2
2007-016-2105 Connector, 316 SST, ANSI, 2”........... 2
2007-016-2106 Connector, Carb stl, ANSI, 2” ........... 2
2007-016-2107 Connector, Carb stl, male, 2” ............ 2
2007-016-2010 Connector, PTFE, 2”......................... 2
2007-016-2011 Connector, PTFE, 2”......................... 2
17 2007-017-1005 Frame, Right (new 2017)................... 1
18 STD HDW Stud, M12x40, SST ........................... 4
19 STD HDW SHC Screw, M12x25 ........................ . 4
23 2007-001-2003 Bracket, Rear (new 2017) ................. 1
24 2007-024-1001 Washer, Roller .................................. 1
28 G35-081-2010 Screw, Bracket.................................. 4
29 G35-084-2010 Washer, Bracket................................ 4
30 2007-005-1002 Roller, Shaft, & Bearing Assy ........... 2
33 2007-005-1009 Rotor ................................................. 1
- 3007-017-1005 Shim, 0.5 mm.................................... 8
Ref. Quantity/
No. Part Number Description Pump

15
Wanner Engineering, Inc.
Warranty
United States Instant Information: www.vectorpump.com
[phone] Fax [phone] VEC-991-2400E
Limited Warranty
Wanner Engineering, Inc. (“Wanner”) extends to the original
purchaser of equipment supplied or manufactured by Wanner
and bearing its name, a limited one-year warranty from the
date of purchase against defects in material or workmanship,
under normal use and service, and provided the equipment is
installed, operated and maintained in accordance with instruc-
tions supplied by Wanner. Wanner will repair or replace, at its
option, defective parts without charge if: (a) you provide written
notice of any defect within thirty (30) days from the discovery of
the defect; (b) the claim is received by Wanner before the ex-
piration of the warranty period; and (c) such parts are returned
with transportation charges prepaid to Wanner Engineering,
Inc., 1204 Chestnut Avenue, Minneapolis, Minnesota 55403. A
return goods authorization must be received prior to the return
of the defective part. No allowance will be made for repairs
undertaken without Wanner written consent or approval.
Notwithstanding anything to the contrary, this warranty does not
cover:
1. Electric motors (if applicable) not manufactured by Wanner.
The warranties, if any, on such equipment are assigned to you
by Wanner (without recourse) at the time of purchase.
2. Normal wear and/or damage caused by or related to abra-
sion, corrosion, abuse, negligence, accident, faulty installation
or tampering which impairs normal operation.
3. Transportation costs.
This limited warranty is exclusive, and is in lieu of any other
warranties (oral, express, implied or statutory) including, but not
limited to, implied warranties of merchantability and tness for
a particular purpose; warranties of non-infringement; warranties
arising from course of dealing or usage of trade or any other
matter. Any descriptions of the equipment, drawings, specica-
tions, and any samples, models, bulletins, or similar material
used in connection with the sale of equipment are for the sole
purpose of identifying the equipment and are not to be con-
strued as an express warranty that the equipment will conform
to such description. Any eld advisory or installation support is
advisory only. Every form of liability for direct, special, incidental
or consequential damages or loss is expressly excluded and
denied. All liability of Wanner shall terminate one (1) year from
the date of purchase of the equipment.
Use Of The Pump
The pump was dened for specic application. Any other use
which does not comply with this use invalidates the warranty.
Wanner cannot be held responsible for damage or possible
injury incurred during the use of the pump. The pump was de-
signed in accordance with applicable norms and directives. Use
the pump only for applications represented above. If you want
to change your application, rst contact your Wanner distributor.
Responsibility
Wanner will be under no circumstances responsible for damage
or wounds caused by non respect of security directives and
maintenance instructions contained in this manual, or by negli-
gence during the installation, use, service or repair of Wanner
hose pumps. Moreover, additional directives of security can be
necessary according to working conditions or according pro-
cess. Contact your Wanner distributor if you notice a potential
danger during the use of the pump.
User Training And Instruction
Every person who installs, uses, or performs any operations
or maintenance on the pump must be qualied. The person
must also read and be familiar with this technical manual. Any
temporary personnel must be supervised by skilled users.
The order of operational steps dened in this manual must be
followed. Store this manual next to the pump so that it can be
consulted at any time.

© 2004 Wanner Engineering, Inc. Printed in USA
VEC-991-2400E 10/2004, Revised 5/2018
1204 Chestnut Avenue, Minneapolis, MN 55403
Tel: [phone] Fax: [phone]
Toll-free fax [US only]: [phone]
www.vectorpump.com
email: [email protected]
