Warm4Less Xenon User manual

Xenon –RF Receiver Operating Instructions
Specification:
•Power source: 100-240VAC 50/60HZ
•Wireless Signal Frequency: 868MHZ (FSK)
•Wireless signal Range: 100m
•Accuracy + 1°C
•Ambient Temperature Operation: 0°C –50°C
•Dimensions: 86mm x 86mm x 24.4mm
Safety Information:
•Always turn off power at the main power source by unscrewing fuse or switching off
the circuit breaker before installing, removing, cleaning or servicing this thermostat.
•Read all of the information in this manual before installing this unit.
•Only a professional contractor should install this unit.
•All wiring must conform to local and national building and electrical codes.
•Only use the thermostat as described in this manual.
Mounting the receiver:
1. Remove the back board of the receiver by unscrewing the screw at the bottom.
Some units may vary and may not have screws on the bottom, if not gently pull the
back off, please be careful when doing this as it may cause damage to the unit.
2. Connect the wires beneath the terminal screws to a power supply module using an
appropriate wiring schematic.
3. Push the back of the unit into a 86mm x 86mm surface box.
4. Using the mounting screws provided, mount the back of the unit onto the wall in the
surface box. Place a level against the base of the unit to ensure the unit is straight.

Please note that levelling is purely for appearance and will not affect the operation
of the unit.
5. Once the unit is straight, tighten the screws to make the unit secure.
6. Once in place return the front of the unit to the base by either clicking it back in or
using the screws.
Wiring Diagram:
Button indicators:
Checking the receivers operation:
•Standby: When in standby mode and there is no power input, none of the lights will
be lit.

•Power Status: Short press the power button and the red indicator light should turn
on as long as there is power to the unit. If the light does not turn on, there is no
input to the unit.
•Shutdown status: When turned on the red light should be on. Short press the power
button. The red indicator should turn off to show that it is in shutdown mode. The
thermostat will shut down all output.
•Working state: When in use and the heating is on, the green indicator will turn on.
Forced Output Function:
In the shutdown state, long press the power button for 8 seconds until the green indicator
lights up. Open all output, don’t accept emission control signal or launch control damage
cases effective. The mandatory output state, accor4ding to the lift off buttons short back to
the state.
Communication signals:
When the yellow indicator is flashing, this shows it is ready to receive communication
signals.
Enter Code Match Mode:
When the controller is in code match mode (see controller manual), switch off the receiver
and long press the power button for 3 seconds and the yellow LED should light up. If the
controller and a receiver code match successfully, the yellow LED will flash 6 times, it will
then save the current settings and exit automatically. If it does not do this it means it has
not been done correctly. The receiver will exit the menu after 20 seconds and you will need
to repeat the steps again.
Checking the receivers operation:
The unit will be controlled via an air sensor in the controller and the controller will
determine weather to activate/deactivate the heating by comparing the set temperature
with the current temperature.
When adjusting the temperature on the controller it will emit signals to the receiver asking
to adjust the heating device. The yellow LED on the receiver will flash when it is receiving
signals. The green LED will be on when the heating is on. When the green LED turns off it
means that the heating device is deactivated.
