Wascomat EX-12 HI-TEK Installation and operation manual

WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT
PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF
YOUR WASCOMAT MACHINE.
PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S)
DATA PLATE(S).
MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE
REFERENCE.
MACHINE TYPE OR MODEL
MACHINE SERIAL NUMBER(S)
ELECTRICAL CHARACTERISTICS:________ VOLTS, _______ PHASE, ______ HZ.
OPERATING & MAINTENANCE MANUAL
EX-12 HI-TEK
EX-22 HI-TEK
From machine No. 91/6411- EX 12, 91/5875- EX 22
471 1562-62/01
95.38

NOTICE TO: OWNERS, OPERATORS AND DEALERS OF WASCOMAT MACHINES
II
IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL
NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY.
TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLO-
WING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS.
1. Prior to operation of the machine, check to make certain that all operating instructions and
warning signs are affixed to the machine and legible. (See the following page of this manual
for description and location of the signs.) Missing or illegible ones must be replaced imme-
diately. Be sure you have spare signs and labels available at all times. These can be obtai-
ned from your dealer or Wascomat.
2. Check the door safety interlock, as follows:
(a) OPEN THE DOOR of the machine and attempt to start in the normal manner:
For coin-operated models, insert the proper coins to start the machine.
For manually operated models, place the ON-OFF switch in the ON position and
press the Start switch.
For FL and EX models, insert a program card, turn the starter knob to the Start
position and place the ON-OFF switch in the ON position.
For HI-TEK microprocessor models, turn the key switch to the RUN position, choose
a program and press the START button.
For SELECTA 28 models, select a wash program and press the Start button.
THE MACHINE(S) SHOULD NOT START !
(b) CLOSE THE DOOR to start machine operation and, while it is operating, attempt to
open the door without exerting extreme force on the door handle. The door should
remain locked!
If the machine can start with the door open, or can continue to operate with the door
unlocked, the door interlock is no longer operating properly. The machine must be
placed out of order and the interlock immediately repaired or replaced.(See the door
interlock section of the manual.)
3. DO NOT UNDER ANY CIRCUMSTANCES ATTEMPT TO BYPASS OR REWIRE ANY OF
THE MACHINE SAFETY DEVICES AS THIS CAN RESULT IN SERIOUS ACCIDENTS.
4. Be sure to keep the machine(s) in proper working order: Follow all maintenance and
safety procedures. Further information regarding machine safety, service and parts can be
obtained from your dealer or from Wascomat through its Teletech Service Telephone - 516/
371-0700.
All requests for assistance must include the model, serial number and electrical characteristics as
they appear on the machine identification plate. Insert this information in the space provided on the
previous page of this manual.
5. WARNING: DO NOT OPERATE MACHINE(S) WITH SAFETY DEVICES BYPASSED, REWIRED OR
INOPERATIVE! DO NOT OPEN MACHINE DOOR UNTIL DRUM HAS STOPPED ROTATING!

DO NOT ATTEMPT TO OPEN DOOR
UNTIL PROGRAM HAS FINISHED AND
DRUM HAS STOPPED ROTATING.
WARNING !
If you need to order more safety or warning
signs, call Wascomat's parts department at
516-371-2000, or call your local dealer. 471 7651-17
CAUTION
1. Do not open washer door until cycle is completed, operating
light is off, and wash cylinder has stopped rotating.
2. Do not tamper with the door safety switch or door lock.
3. Do not attempt to open door or place hands into washer to
remove or add clothes during operation. This can cause
serious injury.
MACHINE SHOULD NOT BE USED BY CHILDREN
PRECAUCION
1. No abra la puerta de la máquina lavadora sino hasta que la
máquina haya terminado su ciclo, la luz operativa esté apaga
da y el cilindro de lavado haya completamento terminado de
girar.
2. No interferia o manipule el switch o la cerradura de la puerta.
3. No trate de abrir la puerta o meta las manos dentro de la
máquina para meter o sacar ropa mientras la máquina está
en operación, pues puede resultar seriamento herido.
LAS MÁQUINAS NO DEBEN SER USADAS POR NIÑOS
SAFETY AND WARNINGS SIGNS
Replace If Missing Or Illegible
One or more of these signs must be affixed on each machine as indica-
ted, when not included as part of the front instruction panel.
LOCATED ON THE OPERATING INSTRUCTION SIGN OF THE MACHINE:
LOCATED AT THE REAR OF THE MACHINE:
INSTALLATION AND MAINTENANCE WARNINGS
1. This machine MUST be securely bolted to an uncovered concrete floor,
according installation instructions, to reduce the risk of fire and to prevent
serious injury, or damage to the machine.
2. When installed on a floor of combustible material, the floor area below this
machine must be covered by a metal sheet extending to the outer edges of the
machine.
3. This machine MUST be connected to a dedicated electrical circuit to which no
other lighting unit or general purpose receptacle is connected.
4. This machine MUST be serviced and operated in compliance with
manufacturer's instructions. CHECK DOOR LOCKS EVERY DAY FOR PROPER
OPERATION TO PREVENT INJURY OR DAMAGE. IF THE DOOR LOCK FAILS
TO OPERATE PROPERLY, PLACE THE MACHINE OUT OF ORDER UNTIL THE
PROBLEM IS CORRECTED.
5. Disconnect power prior to servicing of machine.
6. To remove top panel for service first remove screws at rear. Be certain to
reinstall screws when remounting the top panel.
MANUFACTURED BY WASCATOR
DISTRIBUTED BY WASCOMAT INWOOD, NEW YORK, USA
LOCATED ON THE DOOR:
471 76 62 02

33
Extract-O-Matic EX 12, EX 22 HI-TEK
Contents
Introduction ........................................................................................... 1
Technical data ...................................................................................... 2
Installation............................................................................................. 5
Electro-Lube Dispenser ........................................................................12
Safety rules...........................................................................................15
Mechanical and electrical design..........................................................16
Programming ........................................................................................32
Procedure .............................................................................................54
Maintenance .........................................................................................61
Service information ..............................................................................62
Trouble-shooting...................................................................................63
The manufacturer reserves the right to make changes to design and material
specifications.
Safety instructions
• The machine is designed for water washing only.
• The machine must not be used by children.
• All installation operations are to be carried out by qualified
personnel. Licensed personnel are necessary for all electric
power wiring.
• The interlock of the door must be checked daily for proper
operation and must not be bypassed.
• All seepage in the system, due to faulty gaskets etc., must be
repaired immediately.
• All service personnel must be fully familiar with the operating
manual before attempting any repair or maintenance of the
machine.
• The machine must not be sprayed with water, otherwise short
circuiting may occur.
• Fabric softeners with volatile or inflammable fluids are not to be
used in the machine.

1
0148
Introduction
The EX-HI-TEK model washer/extractor has been developed to cover the
heavy duty requirements of hotels, motels, nursing homes, hospitals,
professional laundries, restaurants, airlines, steamships, schools, colleges and
all on-premises laundries where flexibility and quick formula variation, coupled
with high quality automatic washing, are required.
The microcomputer controlled EX-HI-TEK model allows for complete
programming of water temperatures, water levels, wash and extraction periods
and supply injections.
The machines are free-swinging, i.e., the drum is moveable and spring
suspended in relation to the frame. This minimises vibrations transferred to the
frame thus simplifying installation, as no concrete base is required.
The high speed spin gives a G factor of approximately 300, providing very
efficient water removal during the spin.
All parts of the machine which come into contact with the items being washed
are made of heavy gauge surgical stainless steel, ensuring long life and lasting
beauty, as well as full protection for no-iron fabrics. All electrical components
are made accessible for servicing by simply removing the top panel.
This manual contains a technical description of the machine and instructions for
its installation, operation and maintenance. Together with the wiring diagram
which accompanies each individual machine it should be kept in a safe place
for easy reference.
When ordering spare parts or contacting Wascomat for any purpose always
give the machine serial number, model, voltage and other electrical
characteristics appearing on the nameplate at the rear of the machine.
Introduction
Fig.
1
1

2
EX-12 HI-TEK
Dry load capacity up to 13,5 kg 30 lbs
Overall dimensions Width 870 mm 34 1/4'’
Depth 900 mm 35 15/16'’
Height 1302 mm 51 1/4'’
Net weight 290 kg 639 lbs
Dyn.weight 120 lbs./sqft
Crated dimensions Volume 1.25 m344 cu.ft
Weight 315 kg 695 lbs
Inner drum Diameter 620 mm 24 7/16'’
Depth 412 mm 16 5/16'’
Volume 120 litre 4.4 cu.ft
Speed of rotation Wash 48 r.p.m.
Distribution 75 r.p.m
Low extract 475 r.p.m.
High extract 950 r.p.m.
G-factor During wash 0.8
During high extract 310
Motor speed During wash 360 r.p.m.
During high extract 3200 r.p.m.
Voltage requirements Choice:
208-240 V 3-Phase 60 Hz
440 V 3-Phase 60 Hz
Rated power Motor, wash 250 W
0.35 HP
Motor, extraction 1800 W
2.5 HP
Overcurrent protection Three.-phase 15 A
Water connections
Water pressure, max 10 kp/cm2142 psi
Recommended water pressure 2-6 kp/cm225-85 psi
Hose connection, water 20 mm 3/4'’
Hose connection, drain 75 mm 3'’
Technical data

3
EX 22 HI-TEK
Dry load capacity up to 22.5 kg 50 lbs
Overall dimensions Width 1000 mm 39 3/8'’
Depth 1102 mm 43 3/8'’
Height 1412 mm 55 9/16'’
Net weight 553 kg 1218 lbs
Dyn.weight 157 lbs./sqft
Crated Dimensions Volume 2.05 m372.3 cu.ft
Weight 588 kg 1295 lbs
Inner drum Diameter 750 mm 29 1/2'’
Depth 500 mm 19 11/16'’
Volume 220 litre 7.8 cu.ft
Speed of rotation Wash 45 r.p.m.
Distribution 67 r.p.m.
Low Extract 425 r.p.m.
High Extract 850 r.p.m.
G-factor During wash 0.8
During High Extract 300
Motor speed During wash 540 r.p.m.
During High Extract 3200 r.p.m.
Voltage requirements Choice:
208-240 V 3-Phase 60 Hz
440 V 3-Phase 60 Hz
Rated power Motor, wash 410 W
0.55 HP
Motor, extraction 2600 W
3.5 HP
Overcurrent protection Three-phase 20 A
Water connections
Water pressure, max 10 kp/cm2142 psi
Recommended water pressure 2-6 kp/cm225-85 psi
Hose connection, water 20 mm 3/4'’
Hose connection, drain 75 mm 3'’
Technical data

4
Outline and dimensions
A 870 34 1/4 1000 39 3/8
B 1302 51 1/4 1412 55 9/16
C 913 36 1102 43 3/8
D 792 31 3/16 906 35 3/32
E 121 4 3/4 196 7 3/4
F 625 24 5/8 630 24 13/16
G 570 22 1/2 560 22
H 480 18 15/16 610 24
J 1100 43 5/16 1210 47 5/8
K – – 320 12 5/8
L 240 9 1/2 240 9 1/2
M 120 4 3/4 120 4 3/4
N 1200 47 1/4 1310 51 9/16
O 1110 43 11/16 1220 48
P 85 3 11/32 85 3 11/32
Q 203 8 203 8
R 433 17 498 19 5/8
712543
ED
C
A
G
F
B
H
K
L
M
J
N
Q
R6
O
P
2664
1 Opening for electrical cable connection
2 Steam connection (optional)
3 Cold water
4 Hot water
5 Hot water (only EX22)
6 Drain outlet
7 Soap box
mm inches mm inches
EX 22
EX12
Technical data

5
2
3
4
1247
1248
1249
Installation
The machine is delivered with expansion bolts
and other items packed inside the drum.
Shipping securities
The machine is shipped with four large metal
bracket bolted to the suspension legs, as well as
a support between the pulley and the back plate.
Prior to installation, follow these steps:
• Unpack the machine.
• Remove the lower front panel and the two rear
panels.
• Remove the support from the pulley at the
back of the machine.
• Remove both front brackets.
• Remove both rear brackets.
Placement
The machine should be installed close to a floor
drain or open drain to make installation, use and
service easier.
The following clearances are recommended for
ease of installation and service:
• At least 20 inches between the machine and
the wall behind it.
• At least 2 inches on each side.
The floor must be able to support a static load of
790 lbs for the EX-12 and 1440 lbs for the EX-22.
The maximum impact load at extraction is 260
lbs force for the EX-12 and 480 lbs for the EX-22.
Installation
Fig.
2
Fig.
3
Fig.
4

6
5
6
7
1250
0620
0621
Mechanical installation
• Mark and drill two holes 3/8'' in (8 mm) in
diameter and approximately 3 1/2'' in. (90 mm)
deep according to the dimensions in figure 5.
• Place the machine in position. Never lift the
machine by the door or handle.
• Check that the machine is level and steady.
Use stainless or galvanized washers between
the machine and the floor.
• Insert the expansion bolts supplied with the
machine. Fit the washers and nuts.
It is of utmost importance that the machine
is level, from side-to-side as well as front-
to-rear. If the machine is not properly
levelled, it may result in out-of-balance
cutout without a real out-of-balance in the
drum.
EX12
782 mm
30 25/32 in.
866 mm
34 3/32 in.
716 mm
28 3/16 in.
EX22
780 mm
30 23/32 in.
33 mm
1 5/16 in.
43 mm
1 11/16 in.
996 mm
39 7/32 in.
830 mm
32 11/16 in.
33 mm
1 5/16 in.
43 mm
1 11/16 in.
910 mm
35 13/16 in.
896 mm
35 9/32 in.
Installation
Fig.
7
Fig.
6
Fig.
5

7
Electrical installation
Although the machines are fitted with thermal
overloads in the motor windings and separate
fuses for the control circuit, a separate three-
phase circuit breaker must be installed for all
three-phase machines.
For proper overcurrent protection, check the data
plate at the rear of the machine. Also consult
local electrical code for special requirements.
The machine is equipped with a control circuit
transformer, mounted on the control unit and
connected for 220 volt operation. If your
incoming voltage is below 210 volts move the
wire connection to the 208 volt tab on the
transformer. If it is above 230 volts move the
wire to the 240 volt tab on the transformer.
Check the incoming power for a high voltage leg.
If present, connect that line to L2 on the terminal
block. Make certain it is not connected to the
transformer.
Connect L1, L2, L3 and ground wires according
to the markings of the terminal block. The cable
is to hang in a large loose loop, supported by the
clip of the terminal block.
To ensure proper operation the drum must
rotate counter-clockwise (seen from the front)
during extraction. If the drum rotates in the wrong
direction interchange line L1 and L3 at the power
connection terminal.
8
9
1612
0623
Installation
Fig.
8
Fig.
9
Fig.
8

8
11
12
13
1628
10
1252
0626
1641
Installation
Water connection
NOTE
All plumbing must conform to national and
local plumbing codes.
Incoming water lines do not require non-return
valves, as the machine is already fitted with a
siphon breaker. However, all incoming lines must
be fitted with shut-off valves and strainers.
• Water inlets are labelled for hot and cold
water connection.
• Flush the water system thoroughly and check
that the strainer at the machine inlet is fitted
correctly.
• Connect the machine to the water mains with
3/4'’ reinforced rubber hosing not to exceed 6
ft in length. Hang the hosing in a large loop.
Do not use rigid piping.
Drain connection
Connect a 3'’ (75 mm) flexible hose to the drain
outlet of the machine.
The drain house must not have any sharp bends
and must slope from the machine to assure
proper drainage. The outlet must open freely to
the main drains.
Do not reduce the size of the drain connection
from the machine to the waste line.
Fig.
11
Fig.
12
Fig.
13
Fig.
10

9
Connection of external liquid
supply
Remove cover and cover support over the soap
box.
Bend all the way back the metal plate in
compartment 3.
Pull the knobs up and forward.
1. Loosen both knobs so that one side of the
metal fingers underneath can slide under the
top lid of the machine, within the supply box.
2. Fit the supply injector into the supply box so
that both sides are held securely in places by
the metal fingers.
Note:
If the supply injector does not fit turn it
around. You have it in backwards.
1336
14
1333
16
1334
15
Installation
Fig.
16
Fig.
15
Fig.
14

10
1. Drop the knob into the larger opening in the
supply injector lid.
2. Tighten securely. Do not overtighten! Do not
use pliers or other tools to tighten the knobs!
1. Stretch the multi-rubber ring B and select the
correct size ring which will fit snuggly on the
chemical tube you are using. Ring A is used
for tubes with Ø 1/3" (8 mm).
2. Use scissors or a razor to carefully cut out the
proper size rubber ring. Wrap the rubber ring
around each tube after threading each tube
trough the plastic nipple. Run the tube trough
the compression nut to the bottom of the
compartment. Cut the end of the tube at an
angle. Hand tighten the plastic nipple on to the
compression nut.
17
Fig.
17
Fig.
18
1332
18
1331
1331
18
Installation

11
Electrical connection
At the rear side of the control unit are two quick
connectors. When the machine is delivered
connector A is connected. When using powder
supply, change to connector B.
Pump connection
To the right of the incoming power terminal
connection block is the connection for pumps.
Depending on the number of pumps to be
connected, they shall be connected from 1-5 and
C (common) on resp. connection. The pumps
obtain signals from the electronic timer.
1932
19
Installation
Fig.
20
Fig.
19
1612
20

12 Electro-Lube Dispenser
2733
1M
2M
3M
6M
12M
B
ON
LIGHT
O
F
F
2208
2207
24 IMPORTANT
NOTICE
This machine is equipped with an automatic oiler,
located at the right rear of the machine, which keeps
it lubricated for long bearing and seal life.
The amount of oil in the container is sufficient for
approximately one year's lubrication. It is of utmost
importance that the oiler does not become empty.
Therefore we recommend that the rear panel to be
removed and a visual inspection to be made on a
bimonthly basis. When the oil reaches a low level,
the cannister must be replaced with a new one
available from Wascomat as Part No. 827601.
Date Last Replaced Date Last Replaced
23
22
21
Fig.
24
Fig.
21
Instruction for setting timing on
electro-lube oil dispensing
Pry off the switch panel cap with a screwdriver.
• Under the cap are the switches for time
setting.
• Set the "Light" and "12M" dip switches to the
"On" position. Make certain all other switches
are in "Off" position.
• The light will start flashing after a few minutes
and will continue to flash every 15th to 20th
seconds as long as the dispencer is in
operation.
• The decal shown below should be affixed at
the front of the machine and updated as
required.
Fig.
23
Fig.
22

13
25
26
27
1637
1639
1638
Start-up and safety checklist
Before initial start-up of a Wascomat washer-
extractor, the following safety checks must be
performed:
• Make sure that all electrical and plumbing
connections have been made in accordance
with applicable local codes.
• Use only flexible water fill and drain hoses of
the proper length to avoid sags and kinks.
• Make sure the machine is properly grounded
electrically.
Before the machine is operated, the door safety
interlock must be checked for proper operation
as follows:
• When washer loading door is open, the
machine must not start. Verify this by
attempting to start washer with door open.
• When washer is in operation, the loading door
is locked and cannot be opened. Verify this by
attempting to open the loading door when the
machine is operating. If necessary, consult
this manual for proper operation of the door
lock and door safety interlock or call a
qualified serviceman.
IMPORTANT:
Door safety interlock must be checked
daily in accordance with above procedure.
WARNING:
Before servicing Wascomat equipment,
disconnect electrical power.
Installation
Fig.
25
Fig.
26
Fig.
27

14
1640
28
Function control check-out list
In the machine cylinder, you will find the warranty
registration card, a copy of the warranty policy
and other pertinent material.
The warranty card should be completed and sent
to Wascomat. All other items should be placed in
a safe place for future reference.
The machine should be cleaned when the
installation is completed, and checked out as
detailed below without loading the machine with
fabrics:
1. Check the incoming power for proper voltage,
phase and cycles.
2. Open manual shut-off valves to the machine.
3. Turn on electric power.
4. Check the door safety interlock as detailed on
page 9 of this manual.
5. Run through a complete cycle, checking for
water temperature, drain operation and the
extract function. For operating instructions,
see the section marked ’’Procedure’’.
NOTE
All machines are factory tested prior to
shipment. Occasionally, some residual
water may be found when the machine is
installed.
Installation
Fig.
28

15
Safety rules
• This machine is designed for water washing only.
• Machines must not be used by children.
• All installation operations are to be carried out by qualified personnel.
Licensed personnel are necessary for all electric power wiring.
• The interlock of the door must be checked daily for proper operation
and must not be bypassed.
• All seepage in the system, due to faulty gaskets etc., must be repaired
immediately.
• All service personnel must be fully familiar with the operating manual
before attempting any repair or maintenance of the machine.
• This machine must not be sprayed with water, otherwise short circuiting
may occur.
• Fabric softeners with volatile or inflammable fluids are not to be used in
this machine.
Safety Rules

16
1617
Mechanical and electrical design
General
This machine is a free-swinging model i.e. the outer drum and motor bridge are
suspended in the machine chassis via a spring suspension with a strong spring in
each corner of the machine. Each spring has a shock absorber which dampens the
movement of the machine.
The inner drum is driven by two motors via a V-belt: one motor for washing and
distribution speed and one for extract speed. The inner drum is mounted in the
outer drum with two heavy duty bearings at the back plate and is sealed with two
V-rings.
The two motors are suspended underneath on a motor support with a belt
tensioning device. The motors are mechanically coupled to each other with V-belts.
During wash and distribution speed the spin motor transmits power to the drum,
through a clutch arrangement.
The water inlet and drain are both situated under the outer drum. This improves the
flow during filling and prevents water vapour from entering the detergent
compartment.
The robust square door is locked with a handle which is interlocked by a safety
device when the machine is running.
The manual push buttons and card programmed control are fitted at the front of the
machine.
All control and indicating components i.e. relays, delay unit, etc. are assembled
under the top cover, easily accessible from the top of the machine for simplified
servicing.
The machine housing consists of hot-dip galvanised, painted steel plates and
stainless steel sheets, painted on the front and sides. It has a stainless door (and
front, on request).
29
Extract motor
Wash and distribution
motor
Operating
instruction panel
Fig.
29
