Wascomat EXSM 350 HI-TEK Installation and operation manual

OPERATING & MAINTENANCE MANUAL
EXSM 350 HI-TEK
WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT
PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF
YOUR WASCOMAT MACHINE.
PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S)
DATA PLATE(S).
MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE
REFERENCE.
MACHINE TYPE OR MODEL
MACHINE SERIAL NUMBER(S)
ELECTRICAL CHARACTERISTICS:________ VOLTS, _______ PHASE, ______ HZ.
471 1562-96/01
95.09

NOTICE TO: OWNERS, OPERATORS AND DEALERS OF WASCOMAT MACHINES
II
IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL
NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY.
TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLO-
WING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS.
1. Prior to operation of the machine, check to make certain that all operating instructions and
warning signs are affixed to the machine and legible. (See the following page of this manual
for description and location of the signs.) Missing or illegible ones must be replaced imme-
diately. Be sure you have spare signs and labels available at all times. These can be obtai-
ned from your dealer or Wascomat.
2. Check the door safety interlock, as follows:
(a) OPEN THE DOOR of the machine and attempt to start in the normal manner:
For FL and EX models, insert a program card, turn the starter knob to the Start
position and place the ON-OFF switch in the ON position.
For HI-TEK microprocessor models, turn the key switch to the RUN position, choose
a program and press the START button.
For SELECTA 28 models, select a wash program and press the Start button.
THE MACHINE(S) SHOULD NOT START !
(b) CLOSE THE DOOR to start machine operation and, while it is operating, attempt to
open the door without exerting extreme force on the door handle. The door should
remain locked!
If the machine can start with the door open, or can continue to operate with the door
unlocked, the door interlock is no longer operating properly. The machine must be
placed out of order and the interlock immediately repaired or replaced.(See the door
interlock section of the manual.)
3. DO NOT UNDER ANY CIRCUMSTANCES ATTEMPT TO BYPASS OR REWIRE ANY OF
THE MACHINE SAFETY DEVICES AS THIS CAN RESULT IN SERIOUS ACCIDENTS.
4. Be sure to keep the machine(s) in proper working order: Follow all maintenance and
safety procedures. Further information regarding machine safety, service and parts can be
obtained from your dealer or from Wascomat through its Teletech Service Telephone - 516/
371-0700.
All requests for assistance must include the model, serial number and electrical characteristics as
they appear on the machine identification plate. Insert this information in the space provided on the
previous page of this manual.
5. WARNING: DO NOT OPERATE MACHINE(S) WITH SAFETY DEVICES BYPASSED, REWIRED OR
INOPERATIVE! DO NOT OPEN MACHINE DOOR UNTIL DRUM HAS STOPPED ROTATING!

SAFETY AND WARNINGS SIGNS
Replace If Missing Or Illegible
One or more of these signs must be affixed on each machine as indica-
ted, when not included as part of the front instruction panel.
LOCATED ON THE OPERATING INSTRUCTION SIGN OF THE MACHINE:
LOCATED AT THE REAR OF THE MACHINE:
INSTALLATION AND MAINTENANCE WARNINGS
1. If installed on a floor of combustible material the floor area below this machine must
be covered by a metal sheet extending to the outer edges of the machine.
2. This washing machine MUST be securely bolted to an uncovered concret floor
according to the installation instructions to reduce the risk of fire and to prevent
serious injury, or damage to the machine.
3. This washing machine MUST be serviced and operated in compliance with
manufacturer's instructions. CHECK DOOR LOCKS EVERY DAY FOR PROPER
OPERATION TO PREVENT INJURY OR DAMAGE.
4. Disconnect power prior to any servicing of machine.
5. This washing machine MUST be connected to a dedicated electrical circuit to which
no other lighting unit or general purpose receptacle is connected. Use copper
conductor only.
6. To remove the top panel for service on those models on which it is secured by screws
at the rear, first remove the screws. Be certain to reinstall them when remounting the
top panel. To remove the top panel for service on those models on which it is secured
by one or two keylocks, use the keys originally shipped in the drum package. Be
certain to relock after remounting the top panel.
MANUFACTURED BY ELECTROLUX-WASCATOR, LJUNGBY SWEDEN
DISTRIBUTED BY WASCOMAT OF AMERICA, INWOOD, NEW YOUR, USA
SOLD AND SERVICED BY INDEPENDENT WASCOMAT DEALERS
LOCATED ON THE DOOR: WARNING !
If you need to order more safety or warning
signs, call Wascomat's parts department at
516-371-2000, or call your local dealer. 471 7668 02
CAUTION
1. Do not open washer door until cycle is completed, operating
light is off, and wash cylinder has stopped rotating.
2. Do not tamper with the door safety switch or door lock.
3. Do not attempt to open door or place hands into washer to
remove or add clothes during operation. This can cause
serious injury.
MACHINE SHOULD NOT BE USED BY CHILDREN
PRECAUCION
1. No abra la puerta de la máquina lavadora sino hasta que la
máquina haya terminado su ciclo, la luz operativa esté apaga
da y el cilindro de lavado haya completamento terminado de
girar.
2. No interferia o manipule el switch o la cerradura de la puerta.
3. No trate de abrir la puerta o meta las manos dentro de la
máquina para meter o sacar ropa mientras la máquina está
en operación, pues puede resultar seriamento herido.
LAS MÁQUINAS NO DEBEN SER USADAS POR NIÑOS
NEVER USE FORCE ON HANDLE. FOR
SAFETY REASON THE DOOR IS LOCKED
A WHILE AFTER THE DRUM HAS
STOPPED ROTATING.
471 7646-01

13
Contents
Introduction ......................................................................1
Technical data.................................................................. 2
Installation........................................................................4
Safety rules .................................................................... 12
Mechanical and electrical design ................................... 13
Procedure.......................................................................27
Programming..................................................................34
Service information ........................................................ 56
Maintenance...................................................................57
Trouble-shooting ............................................................ 58
The manufacturer reservs the right to make changes to design and
material specifications.
Safetyinstructions
• The machine is designed for water washing only.
• The machine must not be used by children.
• All installation operations are to be carried out by qualified
personnel. Licensed personnel are necessary for all electric
power wiring.
• The interlock of the door must be checked daily for proper
operation and must not be bypased.
• All seepage in the system, due to faulty gaskets etc., must be
repaired immediately.
• All service personnel must be fully familiar with the operating
manual before attempting any repair or maintenance of the
machine.
• The machine must not be sprayed with water, otherwise short
circuiting may occur.
• Fabrics softener with volatile or inflammable fluids are not to
be used in the machine.
EXSM 350 HI-TEK

1
Introduction
The HI-TEK solid mounted washer/extractor has been developed to cover the heavy duty
requirements of hotels, motels, nursing homes, hospitals, professional laundries,
restaurants, airlines, ships, schools, colleges and all on-premises laundries where
flexibility and quick formula variation, coupled with high quality automatic washing, are
required.
The microcomputor controlled HI-TEK model allows for complete programming of water
temperatures, water levels, wash and extraction periods and supply injections. The
machine is designed for connection to hot and cold water supplies an may be used with
free-standing powder or liquid supply injectors which can be activated by signals from the
machine.
All parts of the machine which come into contact with the items being washed are made
of heavy gauge surgical stainless steel, ensuring long life and lasting beauty, as well as
full protection for no-iron fabrics. All electrical components are made accessible for
servicing by simply removing the top panel.
This manual contains a technical description of the machine and instructions for its
installation, operation and maintenance. Together with the wiring diagram which
accompanies each individual machine it should be kept in a safe place for easy reference.
When ordering spare parts or contacting the manufacturer for any purpose always give
the machine serial number, model, voltage and other electrical characteristics appearing
on the nameplate at the rear of the machine.
Introduction
Fig.
1
1
2387

2Technical data
EXSM 350 HI-TEK
Dry load capacity up to 35 kg 80 lbs
Overall dimensions Width 1115 mm 43 7/8''
Depth (at the top) 1098 mm 43 1/4''
Height 1520 mm 59 7/8''
Net weight 420 kg 925 lbs
Max. floor load at extraction ±14 kN ±3147 lbs.force
Frequency (dynamic force) 10,8 Hz
Crated Dimensions Volume 2.4 m385 cu.ft
Inner drum Diameter 920 mm 36 7/32''
Depth 520 mm 20 1/2''
Volume 350 litre 12.6 cu.ft.
Speed of rotation Wash 40 r.p.m.
Distribution 60 r.p.m.
Extraction, low 325 r.p.m.
Extraction, high 650 r.p.m.
G-factor During wash 0.8
During extrac., low 55
During extrac., high 220
Motor speed During wash 360 r.p.m.
During distrib. 580 r.p.m.
During extrac., low 1660 r.p.m.
During extrac., high 3380 r.p.m.
Voltage requirements 208-240 V 3-Phase 60 Hz
Rated power Motor, wash 0.9 kW
1.1 HP
Motor, distrib. 0.75 kW
1.0 HP
Motor, extrac., low/high 4.5/4.8 kW
6.0/6.5 HP
Overcurrent protection, motor Three-phase 19 A
Water connections
Recommended water pressure 2-6 kp/cm225-85 psi
Hose connection, water DN 25 mm 1''
Hose connection, drain 75 mm 3''
Hose connection, steam 1/2"

3
Technical data
Outline and dimensions
2479
A
B
D
E
C
FG
HIK
L
T
2
1
U4 5 6 SRP
O
M
N
3
1 Electrical cable connection
2 Steam connection
3 Drain connection
4 Hot water connection
5 Hot water connection
6 Cold water connection
EXSM 350
mm inches
A 1114 43 7/8''
B 1520 59 7/8
C 1206 47 15/32''
D 597 23 1/2''
E 935 36 13/16''
F 66 2 5/8''
G 100 3 15/16''
H 490 19 19/64''
I 590 23 1/4''
K 930 36 5/8''
L 527 20 3/4''
M 120 4 3/4''
N 206 8 1/8''
O 1380 54 11/32''
P 89 3 1/2''
R 184 7 3/16''
S 354 13 15/16''
T 1270 50
U 125 4 15/16''

4
Installation
Machine foundation
For making the foundation, check with a
professional engineer in order to calculate
the foundation regarding dynamic and static
forces.
The machines are designed to be bolted in
position to a concrete floor or specially prepared
concrete foundation. A template showing the size
of the foundation and positioning of the foundation
bolts is delivered with each machine.
For installation on an existing concrete floor, the
floor must be at least 8'' thick and of good quality.
If the floor does not meet these requirements, then
a 6-8'' high concrete foundation should be made.
Follow the instructions below when making a
concrete foundation:
1 Decide where to place the machine and
consider maintenance requirements, i.e.
determine a suitable distance from the rear of
the foundation to the wall, and the distance
from the foundation to the nearest side wall.
The distance should be at least 16 and 2
inches, respectively.
2. Break up the floor to a depth of at least
3 inches, making sure that the sides of the hole
slope inwards - the bottom of the hole should
be 5 inches longer than the upper length.
3. Wet the hole well. Brush the bottom and sides
with cement grout.
4. Prepare a casing and fill with concrete to form
foundation. Make sure the foundation is level.
5. Use the template to position the foundation
bolts correctly - bolts are to extend 1 1/2'' above
concrete.
Reinforcing ironrods A shall be used around the
base. The ironrods shall be placed between the
bolts and the edge of the foundation.
2
2396
Installation
Fig.
2
Fig.
3
Fig.
4
3
0272
4
2397
2398

5
Installation
Measurements for foundation in inches and (mm).
A 42 29/32'' (1090)
B 43 15/64''
C 3'' (75)
D 3 15/16'' (100)
E 15 23/64'' (390)
F 3 15/16'' (100)
G 13 25/64'' (340)
Fig.
5H 3'' (77)
K 36 13/16'' (935)
L 37 1/64'' (940)
M 41 9/16'' (1056)
N 43 17/32'' (1106)
O 51 59/64'' (1319)
P 7/8'' (22)
5
2340
O
P
N
M
L
E
C
F
K
H
A
Front of machine
B
D
G

6
6
2400
Mechanical installation
• Place wide steel shims on the concrete
foundation over the bolts.
• Lift the machine and lower it in position. Never
use the door or the door handle to lift or lower
the machine.
• Check that the machine is level front-to-rear
and side-to-side and standing firmly on the ten
supporting points. Spacing washers must be
mounted if one or more of these points is not
resting against the floor/foundation.
• Place flat washers over the foundation bolts
and secure the machine in position by
tightening the self-locking nuts.
Torque for the nuts (M16) should be 145 ft lbs.
• Tighten the nuts in sequence as shown.
• Check and tighten the nuts every week for the
first month.
Installation
Fig.
6
Fig.
8
Fig.
9
Fig.
7
8
2402
9
2399
7
2401

7
Installation
0277
1795
Electrical installation
Although the machines are fitted with a thermal
overload in the motor windings and a separate
fuse for the control circuit, a separate three-phase
common-trip circuit breaker must be installed for
all three-phase machines.
For proper overcurrent protection, check the data
plate at the rear of the machine. Also consult local
electrical code for special requirements.
The machine is equipped with a control circuit
transformer, mounted on the control unit and
connected for 220 volt operation.
If your incomming voltage is below 210 volts move
the wire connection to the 208 volt tab on the
transformer. If it is above 230 volts move the wire
to the 240 volt tab on the transformer.
Check the incoming power for a high voltage leg. If
present, connect that line to L2 on the terminal
block, a high voltage leg can be found by
measuring the voltage between each leg and
ground.
Connect L1, L2, L3 and ground wires according to
the markings of the terminal block. The cable is to
hang in a large loose loop, supported by the clip of
the terminal block.
The smaller terminal block at the right is for
connection of wires from external supply injection.
To ensure proper operation the drum must rotate
counter-clockwise (seen from the front) during
extraction. If the drum rotates in the wrong
direction the text ''PHASE-OR DOOR LOCK-
ERROR'' will be seen in the display window. If this
happens, interchange line L1 and L3 at the power
connection terminal.
Fig.
10
Fig.
11
11
Fig.
13
Fig.
12
10
13
2366
12
2365

8Installation
14
15
2367
2368
Water connection
NOTE
All plumbing must conform to national and
local plumbing codes.
Incoming water lines do not require non-return or
back-suction valves, as the machine is already
fitted with a siphon breaker. However, all incoming
lines must be fitted with shut-off valves.
• Water inlets are labelled for hot and cold water
connection.
• Flush the water system thoroughly and check
that the filter at the machine inlet is fitted
correctly.
• Connect the machine to the water mains with
3/4'' reinforced rubber hosing not to exceed 6 ft
in length. Hang the hosing in a large loop. Do
not use rigid piping.
Drain connection
Connect a 3'' (75 mm) flexible hose to the drain
outlet of the machine.
The drain hose must not have any sharp bends
and must slope from the machine to assure proper
drainage. The outlet must open freely to the main
drains.
Do not reduce the size of the drain connection
from the machine to the waste line.
Fig.
16
Fig.
14
Fig.
15
Fig.
17
17
1761
16
0283

9
Installation
Steam connection (optional steam heating)
The steam inlet pipe must be fitted with a manual
cut-off valve in order to facilitate installation and
service operations.
Attach the filter supplied with the machine to the
manual cut-off valve.
Conncection hoses should be of the quality
required according to regulations in the country
of use.
Connections size at filter: DN 15 (1/2'').
Steam pressure required:
• minimum: 50 kPa (0.5 kp/cm2) (7 psi)
• maximum: 800 kPa (8 kp/cm2) (113 psi)
Check there are no sharp angles or bends in the
connection hose.
Connection of top-mount manifold for
connection of external liquid supplies
Remove the cover and cover support from over
the soap box.
Bend all the way back the metal plate in
compartment 3.
Pull the manifold knobs up and forward.
1. Loosen both knobs so that one side of the
metal fingers underneath can slide under the
top lid of the machine, within the supply box.
2. Fit the supply manifold into the supply box so
that both sides are held securely in places by
the metal fingers.
Note:
If the supply manifold does not fit, turn it
around. You have it in backwards.
2369
21
1333
18
Fig.
18
Fig.
20
Fig.
19
Fig.
21
1336
19
20
1334

10
1. Drop the knop into the larger opening in the
supply injector lid.
2. Tighten securely. Do not overtighten! Do not
use pliers or other tools to tighten the knobs!
1. Stretch the multi-rubber ring B and select the
correct size ring which will fit snugly on the
chemical tube you are using. Ring A is used
for tubes with Ø1/3'' (8 mm).
2. Use scissors or a razor to carefully cut out the
proper size rubber ring. Wrap the rubber ring
around each tube after threading each tube
through the plastic nipple. Run the tube
through the compression nut to the bottom of
the compartment. Cut the end of the tube at an
angle. Hand tighten the plastic nipple on to the
compression nut.
Installation
22
23
1332
1331
23
1331
Supply injector
Cut to fit
on tube
Multi-rubber ring
Plastic
nipple
Rubber A
rings B
Compression
nut
Fig.
23
Fig.
22

11
24
25
2399
1763
Start-up and safety checklist
Before initial start-up of a Wascomat washer-
extractor, the following safety checks must be
performed:
• Make sure the machine is properly bolted to the
floor.
• Make sure that all electrical and plumbing
connections have been made in accordance
with applicable local codes.
• Use only flexible water fill and drain hoses of
the proper length to avoid sags and kinks.
• Make sure the machine is properly grounded
electrically.
Before the machine is operated, the door safety
interlock must be checked for proper operation as
follows:
• When washer loading door is open, the
machine must not start. Verify this by
attempting to start washer with door open.
• When washer is in operation, the loading door
is locked and cannot be opened. Verify this by
attempting to open the loading door when the
machine is operating. If necessary, consult this
manual for proper operation of the door lock
and door safety interlock or call a qualified
serviceman.
IMPORTANT:
Door safety interlock must be checked daily
in accordance with above procedure.
WARNING:
Before servicing Wascomat equipment,
disconnect electrical power.
Start -up and safety checklist
Fig.
24
Fig.
25
Fig.
26
Fig.
27
27
1797
26
1796

12 Safety rules
Safety rules
• The machine is designed for water washing only.
• Machines must not be used by children.
• All installation operations are to be carried out by qualified personnel.
Licensed personnel are necessary for all electric power wiring.
• The interlock of the door must be checked daily for proper operation
and must not be bypassed.
• All seepage in the system, due to faulty gaskets etc., must be repaired
immediately.
• All service personnel must be fully familiar with the operating manual
before attempting any repair or maintenance of the machine.
• The machine must not be sprayed with water, otherwise short
circuiting may occur.
• Fabrics softener with voltaile or inflammable fluids are not to be used
in the machine.

13
Mechanical and electrical design
General
The door and the electronic timer with display and keyboard are fitted at the front of the
machine.
All control and indicating components, i.e. relays, delay unit, etc are assembled under the
top cover, easily accessible from the top of the machine for simplified servicing.
Main units
1 Electronic timer with display and keyboard for operating the machine.
2 Door - with automatic locking device which remains locked throughout the different wash
processes.
3 Detergent supply box - three compartments for automatic injection of powered
detergents and fabric softener.
4 Inner cylinder - of stainless steel supported at the rear by two ballraces.
5 Outer drum - of stainless steel (18/8) securely attached to the frame.
6 Wash motor - for reversing wash action and distribution. Extraction motor - for high
speed spin action.
7 Hot and cold water valves - program and level controlled solenoid valves for filling with
water, and for flushdown of automatic detergent dispenser.
8 Drain valve - timer controlled valve for draining the machine of water.
9 Siphon breaker - to prevent water in the machine from re-entering the water supply
system.
10Control circuit - of plug in type, for time and temperature control of the different wash
cycles.
Fig.
28
28
2381

14 Mechanical and electrical design
29
Machine construction
Panels
The machines are equipped with a top panel made of stainless steel. The front panel
is available in different colours or in stainless steel. The coloured panels are made of
phosphatized steel plate. For servicing purposes, the panels can easily be removed.
Outer shell
The outer shell is made of heavy gauge surgical steel and is attached to a heavy duty,
rigid head casting (back gable).
The whole assembly is mounted on a heavy gauge fabricated steel base, hot-dip
galvanized for long life and corrosion resistance.
Inner cylinder
The inner cylinder is made of perforated surgical stainless steel. It is equipped with
three lifting ribs and has highly-polished side sheets and back with maximum
embossed perforated area to assure high flow of water and supplies through fabrics.
Scientifically correct ratio of cylinder diameter and depth assures maximum washing
action.
The shaft is electrically welded to the reinforced back of the cylinder. A specially
designed chromeplated sleeve bushing protects the seals from wear.
Fig.
29
2381

15
Mechanical and electrical design
30
Back gable and bearing
The back gable and the bearing trunnion housing
are constructed of a webbed heavy casting for
extra rigidity. The bearings are protected against
filtration of water by three seals. An intermediate
safety outlet provides an escapement for any
possible condensation.
The seals are mounted on a chrome-plated,
noncorrosive, specially hardened sleeve bushing
that is mounted on the drive shaft to prevent wear
of the seals and shaft. The main bearing is fitted
machinetight into the bearing trunnion housing. A
nut is tightened on the shaft to prevent the cylinder
from moving in and out.
The extension of the bearing trunnion housing
supports the rear bearing holding the shaft. A
grease seals is mounted to prevent escape of
grease. The bearings are permanently lubricated
and need no maintenance.
Clamping sleeve
Pulley
Rear bearing
Bearing housing
Shaft
Sealing rings
Bushing
Front bearing
Drum
Back gable
Rotation guard
Fig.
30
2371

16 Mechanical and electrical design
Control unit
The control panel (1), mounted at the front,
includes all components necessary for operating
the machine, such as display window, control
switches and a key-operated switch.
The printed circuit board (2) with the
microprocessor-controlled electronic timer is
mounted just behind the control panel.
Relays (3) and delay unit (4) are located at the top
of the machine, easily accessible for service.
Electrical connections to the machine are made by
quick-disconnect plugs.
31
1800
Fig.
31
