Water Creation EMPIRE30 User manual

MODEL: EMPIRE30 / EMBASSY30
WASH STAND INSTALLATION GUIDE

MODEL: EMPIRE30 / EMBASSY30
BEFORE YOU BEGIN ** IMPORTANT **
1) Professional installation by two-person crew is required for this fixture
2) Assemble this fixture on a soft blanket is highly recommended
3) We do recommend installing wood blocking inside your wall to add
support to your stand. You will need to use heavy duty anchors (such as steel or toggles)
if you choose not to install wood blocking
4) Gently slide the joint onto support bar to avoid scratch
PARTS
(A) Escutcheon x 6 pcs (E) 3-Way Joint x 2 pcs (I) Floor Screw x 2 pcs
(B) Side Bar x 2 pcs (F)4-Way Joint x 2 pcs (J) Screw & Anchor x 6 pcs
(C) Support Bar x 2 pcs (G)Front Bar x 1 pc
(D) Support Bar x 2 pcs (H) Foot Flange x 2 pcs
B
G
E
F
D
C
H
A
Recommended Tools:
- Drill - Level - Hammer
- Pencil - Silicone
- Phillips head screwdriver
- Safety Glasses

MODEL: EMPIRE30 / EMBASSY30
INSTALLATION STEP
1) Assemble the back support as shown. Tighten set screw on the escutcheon
and 3-way joint.
2) Assemble support legs as shown. Use a level to ensure the top
escutcheons are straight. Tighten set screws on the 3-way joints, 4-way joints
and all escutcheons.
3) After assembling both sides support legs, attach front bar to join both sides
and tighten set screw.
4) With one person on either side of assembled stand, carefully position the
wash stand in desired location. Use a pencil mark position of wall
escutcheon screw holes on wall as well as the perimeter of the location of
foot flanges on floor.
5) Thread the floor screws with foot flange and screw it into floor.
6) Drill holes on wall for wall escutcheons and push anchors flush with wall
7) Insert the support legs into foot flanges and fasten wash stand to wall with
mounting screws.
8) Apply a thin coat of silicone on the top flanges to secure the counter top to
stand.
(If counter top need slight leveling adjustment, place attached sponge pads
on escutcheons as necessary to stabilize.)
D
A
E

MODEL: EMPIRE30 / EMBASSY30
MARBLE TOP INSTALLATION
Storage:
1. Keep marble top in it’s box until installation
2: Store box vertically in a place safe from being hit or knocked over
3. Do not stack anything on top of the box
Opening Box:
1. Before unpacking please make sure you have installation requirement present:
> A professional two man crew
> Tools and materials required:
a. Flat, non-abrasive work surface, such as a soft blanket
b. Carpenter’s level
c. Sealant
2. Carefully, without allowing any free fall, rotate the box from vertical to at.
(This is the only time the box placed horizontally.)

MODEL: EMPIRE30 / EMBASSY30
MARBLE TOP INSTALLATION
Installation:
1. Always use a two man crew, a single person crew is much more likley to cause damage
2: Apply sealant to secure marble top on washstand
