IDR V1000
User’s Guide
Installing and Operating the
Intelligent Data Receiver V1000
MS-4900, Rev. A
January 1998

This equipment complies with the requirements in Part 15 of the FCC rules for a Class
Computing Device. Operation of this equipment in a residential area may cause
unacceptable interference to radio and TV reception, requiring the operator to take
whatever steps are necessary to correct the interference.
The IDR V1000 passes the European Community’s CE mark in the basic unit (single
port) and 4-port daughtercard (five ports) models. Other models will be tested and
approved as necessary.
WavePhore Networks™ is a trademark of WavePhore, Inc.
Copyright © 1998 WavePhore Networks Inc.
All rights reserved.

MS-4900, Rev. A iii
Table of Contents
Section 1. Using This Guide
About This Guide.........................................................................................................1-1
Audience...............................................................................................................................1-2
Organization..........................................................................................................................1-2
Procedures....................................................................................................................1-2
Overview......................................................................................................................1-2
Supplementary Information...........................................................................................1-2
Terminology..........................................................................................................................1-3
Style Conventions..................................................................................................................1-3
Customer Support.......................................................................................................1-3
Safety Issues................................................................................................................1-4
Section 2. Installing the IDR V1000
Before You Begin.........................................................................................................2-1
Step 1: Connect the Cables .......................................................................................2-1
Step 2: Verify Initial Lock on Carrier..........................................................................2-2
Step 3: Check Eb/N0and AGC Readings....................................................................2-3
Step 4: Call the Network Operator..............................................................................2-4
Step 5: Maintain the Equipment..................................................................................2-4
Section 3. Using the Front Panel
Viewing the Main Topics..............................................................................................3-1
Using the Front Panel Buttons ...................................................................................3-1
Understanding the Identification Screen.................................................................................3-2
Choose Operation: Messages...............................................................................................3-2
Viewing and Deleting Messages....................................................................................3-2
Choose Operation: Show Status..........................................................................................3-3
Choose Operation: View Setup.............................................................................................3-3
Choose Operation: Specify Setup........................................................................................3-4
To Enable or Disable a Screen Login............................................................................3-4
To Specify a Password..................................................................................................3-5
To Enable or Disable the Screen Lock...........................................................................3-5
Choose Operation: Set Features...........................................................................................3-6
Set Local Time..............................................................................................................3-6
Choose Operation: Device Restart........................................................................................3-6
Choose Operation: Logoff.....................................................................................................3-7

Table of Contents
iv MS-4900, Rev. A
Section 4. Interpreting Screen Displays
Identifying Problem Indications.................................................................................. 4-1
Check Signal Quality............................................................................................................. 4-2
Superscreen Fields........................................................................................................4-2
Demodulator Screen Fields ........................................................................................... 4-3
TDD Screen Fields ........................................................................................................4-4
Active Sessions Screen Fields.......................................................................................4-5
Check Output Ports............................................................................................................... 4-6
Show Status/Logical Receivers......................................................................................4-6
View Setup of Logical Receivers....................................................................................4-7
TDD Channels...............................................................................................................4-8
Diagnostic Screens........................................................................................................4-9
Verifying Ethernet Screens....................................................................................... 4-10
View Setup.......................................................................................................................... 4-10
Local IP Address..........................................................................................................4-10
Subnet Mask................................................................................................................4-10
Gateway IPO Address .................................................................................................4-10
SNMP Trap IP Address................................................................................................4-11
Host IP Address...........................................................................................................4-11
Specify Setup: IP Addresses.............................................................................................. 4-11
Changing an Address...................................................................................................4-11
Examining System Messages ................................................................................... 4-12
Error and Warning Messages.............................................................................................. 4-12
Section 5. Functional Overview
Network Overview........................................................................................................ 5-1
Network Components............................................................................................................ 5-1
The NCC: Input and Output................................................................................................... 5-2
The Receiver: Input and Output ............................................................................................ 5-4
Modes of Moving Data................................................................................................. 5-4
Transparent Sync and Async Data ........................................................................................ 5-4
Stat Mux Data....................................................................................................................... 5-5
Logical Receivers..........................................................................................................5-5
TVCs and PVCs.................................................................................................................... 5-6
PAD and Node Modes........................................................................................................... 5-6
PAD Mode and PVC Sessions.......................................................................................5-7
PAD Mode and TVC Sessions .......................................................................................5-7
Node Mode....................................................................................................................5-7
IDR V1000: Functional Overview ................................................................................ 5-8
Signal Input: LNB and Tuner................................................................................................. 5-9
Demodulating and Error-Correcting....................................................................................... 5-9
Time-Division Demultiplexer (TDD)..................................................................................... 5-10
Processor............................................................................................................................ 5-10
Statistical Demultiplexer (Stat Demux)................................................................................ 5-10
Buffering and Flow Control.................................................................................................. 5-11
Serial Output Ports.............................................................................................................. 5-11

Table of Contents
MS-4900, Rev. A v
Supplementary Information
Appendix A. Technical Specifications............................................................................A-1
Appendix B. Pin-outs..........................................................................................................B-1
Asynchronous Serial Port...........................................................................................B-1
Synchronous Serial Port.............................................................................................B-1
4-Port Daughtercard....................................................................................................B-2
Ethernet Daughtercard................................................................................................B-2
Appendix C. Screen Display Diagram ..............................................................................C-1
Messages, Show Status, View Setup, Device Restart and Logoff............................C-1
Specify Setup, Set Features, Diagnostics..................................................................C-2
Additional Screens, Ethernet Model Only ..................................................................C-3
Glossary .................................................................................................................................G-1
Index......................................................................................................................................... I-1

MS-4900, Rev. A 1-1
Section 1. Using This Guide
This guide describes how to install and use a WavePhore Intelligent Data Receiver™
V1000 (IDR V1000). The IDR V1000s comprise a family of satellite receivers that
receive, demodulate, and process data streams over high-speed carriers. These data
streams supply real-time news, market information, and other subscription services to
businesses.
The IDR V1000 family includes four models. The models are virtually identical in
appearance and basic operation, but they each provide a unique set of data handling or
connectivity options:
•The basic model (1235) provides the basic receiver capabilities with one
asynchronous, serial output port.
•The 4-port model (1236) includes the optional 4-port serial daughtercard for
multiple serial output connections.
•The Reed-Solomon model (1216) includes the integrated Reed-Solomon Forward
Error Correction capability along with the additional 4-port serial output ports.
•The Ethernet model (1233) includes the optional Ethernet daughtercard for
connection to Local Area Network (LAN) devices.
Figure 1-1. The IDR V1000
About This
Guide
This guide provides the high level information needed to understand the IDR V1000
in its context as a network receiver. Site- or customer-specific information is not
provided here. Typically, a WavePhore customer service representative or a network
operator provides the detailed settings, procedures, and contact numbers for specific
sites.

Using This Guide
MS-4900, Rev. A1–2
Audience Two types of audiences are assumed to be users of this guide:
The primary audience is the technical user who is assumed to have a working
knowledge of satellite and telecommunications equipment. These users include
installation technicians, network operators, and on-site technical staff who work
directly with the equipment to install it, verify its functionality, or perform network
maintenance or troubleshooting procedures.
The second type of audience may not deal directly with the equipment, but needs a
general understanding of the context in which the IDR V1000 operates and an
overview of the receiver’s operational capabilities.
Organization Sections 2 and 3 are intended for the technical user who needs procedures for
installing the IDR V1000 and verifying or troubleshooting its operation. Terminology
and concepts are not described within the procedures; users unfamiliar with this
information are referred to Section 4.
Section 4 is a functional overview that describes data transfer, general network
functions, and data handling within the IDR V1000. Terms and concepts encountered
within the IDR V1000 screens are defined and described here
The Appendixes include supplementary technical information such as equipment
specifications, cabling pinouts, and screen display structure.
The Glossary includes the italicized terms used in this guide.
Procedures If you are: Refer to:
•installing the IDR V1000
•learning how to use the front panel and screen displays
•verifying signal quality
•verifying basic functionality of the receiver
Section 2
•troubleshooting operational problems
•monitoring a network download
•interpreting screens for stat mux operations
•interpreting screens for transparent asynchronous operation
Section 3
Overview If you need to understand: Refer to:
•an overview of the network
•the internal functions of the IDR V1000
•statistical demultiplexing operation
•transparent asynchronous operation
•flow control
•data transmission
Section 4
Supplementary
Information If you need a quick reference to: Refer to:
•technical specifications of the IDR V1000 Appendix A
•electrical connections for the output connectors Appendix B
•complete set of screen displays Appendix C

Using This Guide
MS-4900, Rev. A 1–3
•terms
•abbreviations and acronyms Glossary
Terminology The terms “IDR,” “IDR V1000,” or “the receiver,” used in this manual, refer to all of
the IDR V1000 models. A specific model is noted where the information applies only to
that model.
Terms that are unique to the IDR V1000 or WavePhore products are defined in
context, as well as included in the Glossary. Industry-standard terms, acronyms, and
abbreviations are listed and defined in the Glossary.
Style
Conventions A note (NOTE: ) within this guide provides supplemental information that may be
useful in procedures or may indicate an exception or anomaly.
A caution (CAUTION: ) indicates a condition or a risk factor that could disrupt
normal operations or create difficulty with data reception or output.
Italicized terms are defined in the Glossary.
Customer
Support
Most sites establish their own specific support procedures. Check with your customer
service representative for specific contact instructions for your site.

Using This Guide
MS-4900, Rev. A1–4
Safety
Issues
Following some basic, common-sense procedures will protect you and will help keep
the IDR V1000 operating without disruption.
Do:
•Unplug power before changing external cables.
This reduces the chance of electrical shorts that could damage the receiver.
•Protect the IDR V1000 from liquids and excessive heat, humidity, or dust.
These elements can damage or wear electrical components.
•Connect the IDR V1000 to grounded power outlets.
Do Not:
•Open the casework.
Nothing inside the IDR V1000 is field-repairable.
NOTE: Opening the casework for any reason is prohibited and will void the
warranty.
•Stack the receivers.
Vents in the receiver’s casework are designed to provide the necessary ventilation
to the components. While the foot pads on the receiver may help provide
sufficient space for ventilation, stacking is not recommended.

MS-4900, Rev. A 2–1
Section 2. Installing the IDR V1000
The installation process covers the following steps:
1. Ensuring all cables are properly connected.
2. Tuning the IDR V1000 to its maximum achievable levels for that site
3. Notifying the network operator that installation is complete and to download the
appropriate services as necessary.
For more descriptive detail on the screen displays, refer to Sections 3 and 4.
Before You
Begin:
First, verify the current conditions:
1. A suitable satellite dish (with lightning protection) is already installed
2. Coaxial cable is already run from the dish to the receiver location. (RG-6 cable
is recommended, length not to exceed 500 feet.)
3. RF coaxial cable shield is connected to earth ground with a #10 gauge (or
heavier) solid copper wire at the point of entry to the building.
4. Output data cables are shielded, with shield wire attached to connector shell at
both ends of the cable.
5. Power module is not yet connected to the IDR V1000.
CAUTION: To prevent accidental shorts from causing circuit damage, the power
module should always be disconnected during installation or
whenever cables are being changed.
In addition:
•You should know the expected Eb/N0reading and AGC levels for the site.
Contact the network operator now if you do not have this information.
•Read through the safety issues in Section 1.
CAUTION: Rain, snow, high winds, or extreme cloudiness can attenuate the
signal. Do not attempt to install the receiver during inclement
weather.

Installing the IDR V1000
2–2 MS-4900, Rev. A
Step 1:
Connect
The Cables
1. Connect the coaxial cable to the RF Input connector
2. Connect data cables between the serial or Ethernet outputs on the IDR V1000
and the external devices. See Figures 2-1 and 2-2.
3. Connect the power module to the IDR V1000 power input and to the power
source.
Figure 2-1. Rear Panel Connectors, 4-Port Daughtercard
Figure 2-2. Rear Panel Connectors, Ethernet Output

Installing the IDR V1000
MS-4900, Rev. A 2-3
Step 2:
Verify
Initial Lock
On Carrier
As soon as power is supplied to the IDR V1000, an automatic self-test runs. The IDR
V1000 then locates and “locks” onto the preset frequency. When this completes
successfully, the following identification screen appears (Figure 2-3).
Figure 2-3. WavePhore Identification Screen
If you do not see the identification screen within two minutes of powering on, or if you
see a character other than the “L”after a minute or two of the screen being displayed,
refer to Section 4 to troubleshoot the cause.
Step 3:
Check
Eb/N0and
AGC
Readings
After the receiver has achieved initial lock on the carrier, you should try to “peak,”
or maximize both the Eb/N0 and AGC numbers. You can see both readings in the
Show Status screen (Figure 2-4).
NOTE: Refer to Section 3 for instructions on using the front panel buttons to
display screens.
Figure 2-4. Show Status Screen: AGC and Eb/N0 Readings
1. The AGC level indicates that cabling is complete and the LNB is powered.
Ideally, the reading should be near 200. If the number is under 100, check the
coaxial cable connections and the LNB on the satellite dish.
2. The Eb/N0reading indicates signal quality; it is possible to fine tune that
reading by slightly adjusting the positioning of the satellite dish. The Eb/N0
should be at least 5.0, usually higher. (The site will have specific
requirements.)
©1997 WavePhore 1236
00:00 S/N:xxxxxxxx L
IDR V1000
Model #
L = locked on
signal
LOCKED table:xxxxxx
AGC:XXX Eb/No: X.X dB

Installing the IDR V1000
2–4 MS-4900, Rev. A
Step 4:
Call the
Network
Operator
Once the Eb/N0 and AGC readings are at the expected levels and the Eb/N0 has been
maximized by adjusting the dish alignment, notify the network operator that the
receiver has been installed and is ready to be downloaded.
The operator may provide you additional instructions following the download.
NOTE: If the IDR V1000 was pre-configured at the factory, the necessary
settings may already be established and do not need to be downloaded.
Verify this with your site coordinator.
Step 5:
Maintain
the
Equipment
Satellite transmission can be adversely affected by bad weather. High winds can
knock a satellite dish out of alignment, and heavy snows, rain, or cloud cover can
severely diminish signal quality. You, or another designated individual at the site,
should attend to the following:
•Check satellite dish alignment (by monitoring the Eb/N0 reading) following
heavy or gusty winds.
•Remove snow from satellite dish using a stiff whisk broom.
•Make sure snow doesn’t accumulate on the dish and that the LNB window is
clear.

MS-4900, Rev. A 3–1
Section 3. Using the Front Panel
This section describes how to use the front panel of the IDR V1000 to view or modify
receiver settings. This information includes the following:
•Displaying and deleting messages
•Viewing and modifying configuration parameters
•Changing screen locks, password access, and local time
Configuration parameters typically are preset at the factory or are downloaded by the
network operator. The 2-line, 24-character LCD display on the front panel of the IDR
V1000 provides useful access to view these parameters, along with current activity
and status messages. You may be asked to monitor some of these displays routinely,
or you may be asked by telephone support personnel to describe the current settings.
Appendix C is an illustration of the entire screen display structure. Refer to Section 4
to interpret the displays.
Viewing
the Main
Topics
The eight screens shown in Figure 3-1 are the main topics of the screen display
hierarchy. (The identification screen is not one of the main topic screens, but it is the
top tier of the hierarchy and displays automatically after the self-test completes.)
Figure 3-1. Main Topics of the Screen Displays
Using the
Front
Panel
Buttons
Use the front panel buttons to move through the screens and to enter changes:
•Pressing the SELECT button displays one level deeper into a main topic or
activates a new setting.
•Pressing the <and >buttons move backward and forward within the same
hierarchical level.
•Pressing the CANCEL button returns to the previous display level.
Pressing CANCEL several times moves you from any main topic level back to the
identification screen.
From the identification screen, press SELECT once to access the first main topic,
Choose Operation: Messages.

Using the Front Panel
3–2 MS-4900, Rev. A
Figure 3-2. IDR V1000 Front Panel
Understanding
the
Identification
Screen
The first screen that appears after the self-test is the identification screen. It displays
the IDR V1000 model number, locally set time of day, main serial number, and
current lock status.
Figure 3-3. Identification Screen
Choose
Operation:
Messages
Two types of messages can appear under this display: user messages and system
messages. User messages notify you that the network operator has sent a message to
the receiver. You can choose to view the message or erase it. System messages record
events such as errors or carrier signal loss, along with the time of the occurrence
(logged according to the time set in the receiver). The IDR V1000 stores up to three
messages of each type.
If the network operator has sent a user message, a * appears in the bottom line of the
identification screen.
Viewing and
Deleting
Messages
From the Messages main topic screen, press SELECT to view the first message.
•To access subsequent messages use the < > keys.
•To delete a message, press SELECT.
•To read another message or return to the previous level, press CANCEL.
00:00 S/N:xxxxxxxx L
Main serial
number
Locked on carrier
Model number
Time

Using the Front Panel
MS-4900, Rev. A 3–3
Choose
Operation:
Show Status
Press SELECT from the Show Status main topic to access the following displays:
•Logical receiver activity
•“Summary” screen of active stat mux sessions and memory utilization
•“Superscreen” data (stat mux status, data errors, packets received, lock on carrier)
•AGC and Eb/N0reading (demodulator status)
•Network control channel activity, carrier ID, cluster (group) number
NOTE: For information on interpreting these screens, refer to Section 4.
Choose
Operation:
View Setup
Press SELECT from the View Setup main topic to access the following displays:
•Current communications parameters for each asynchronous serial port (baud
rate, flow control, etc.)
•Pools, groups, PVC assignments for stat mux channels
•Time of the latest network download to each logical receiver
•IP address (for the Ethernet model only)
•IDR V1000 software version; modulation type
•Password login and screen lock requirements
•TDM channels assigned to the IDR V1000 output paths.
NOTE: You cannot modify parameter settings within the View Setup screens. For
information on interpreting these screens, refer to Section 4.

Using the Front Panel
3–4 MS-4900, Rev. A
Choose
Operation:
Specify Setup
Press SELECT from the Specify Setup main topic. Then use the < > buttons to
access screens for the following purposes:
•Change output port configuration settings
•Enable or disable a screen login
•Enter a password to restrict access to certain screens
•Enable or disable a screen lock
•Enter or change IP addresses (Ethernet model only)
CAUTION: Changes you enter on these screens are not visible to the network
operator and could be reset with a network download, possibly
interrupting site operation. It is a good idea to record (and report to
the network operator) important changes you make to parameters
onsite, in case you need to re-install those settings.
To Enable or
Disable a Screen
Login:
Enabling the login requires a user to enter a password to access any IDR V1000
screens where parameters can be modified. (The Set Features screen can still be
changed and all settings can still be viewed without entering a password.)
Use the >button to access this screen:
Press SELECT to display this screen:
1. Use the < > buttons to change from “no” to “yes”.
2. Press SELECT to set the entry.
3. Enter your password.
4. Press CANCEL twice to return to the main topics
NOTE: You must enable the screen login if you want to use the Logoff function to
turn off asynchronous data output (from the main topic Logoff).
Login Enabled:
3N Y
Specify:
Enable Login

Using the Front Panel
MS-4900, Rev. A 3–5
To Specify a
Password: This set of screens enables you to enter the password that restricts access to many
screens.
CAUTION: Before you enter and activate the password protection, be sure the site
requires that level of security. The password/login function restricts
access to many screens and could pose an unnecessary inconvenience
to you or to future technicians. If you can’t remember your password,
you need to contact network operations and request that they
download clear the password.
Use the > button to access this screen:
Press SELECT to access this screen:
1. Use the < > buttons to move to the underline “cursor” beneath a letter.
2. Press SELECT to enter the letter. (The selected letters appear in the first line.)
3. When the password is complete, use the < key to move the cursor to END.
4. Press SELECT establish the password. Press CANCEL twice to return to the
main topics.
NOTE: Only one password can be in effect at any time.
To Enable or
Disable the
Screen Lock
Enabling the screen lock allows only the identification screen to be displayed without
entering a password. This safeguard helps prevent unauthorized access to the
receiver.
Use the > button to access this screen:
Press SELECT to display this screen:
1. Use the <> buttons to move between “No” and “Yes.”
2. Press SELECT to enter your choice.
3. Enter the password.
4. Press CANCEL return to the main topics.
New Password:
END ABCDEFGHIJKLMNOP
Specify:
New Password
Specify:
Screen Lock
Screen Lock:
3N Y

Using the Front Panel
3–6 MS-4900, Rev. A
Choose
Operation:
Set Features
Set Local Time The first screen within the Set Features topic allows you to set the time that this
receiver will use to log messages and events.
Press SELECT once to display this screen:
Press SELECT again to display this screen:
1. Use the <> buttons to increment or decrement the hours (hh)
2. Press SELECT to set your entry. The cursor jumps to the minutes field (mm).
3. Set the minutes fields in the same way.
4. After entering the minutes, press SELECT to activate the time.
5. Press CANCEL twice to return to the main topics.
NOTE: Local time is lost if power to the IDR V1000 is interrupted. The clock
automatically resets to 00:00 and counts from that time, unless you re-
establish local time through these screens.
Choose
Operation:
Device Restart
Press SELECT from the Device Restart main topic to reset the logical receiver
assigned an asynchronous output port. The second screen, accessed with the >
button, clears any data stored in the received-data buffer.
These commands are useful if the port or device connected to the port suddenly stops
passing data. You can reset an individual port without resetting the entire IDR
V1000.
Set Time
hh:mm
Specify:
Local Time

Using the Front Panel
MS-4900, Rev. A 3–7
Choose
Operation:
Logoff
Press SELECT from the Logoff main topic to disable stat mux or transparent
asynchronous mode output. (The “Enable Login” option in the Specify Setup screens
must first be enabled.)
The password entry screen appears. Enter the password to re-enable data output and
to gain access to the other screens.
