Waversasystems W PHONO3T User manual

W PHONO3T
Tube based Modular Input
Phono Amplifier
Owner’s Manual

Table of Contents
About Waversa Systems
Key Features of The W PHONO3T
Front & Rear Panel
Specification for the W PHONO3T
W PHONO3T Owner’s Manual 02

Key Features of The W PHONO3T
•2x MM/MC Modular input
•Full balanced output and unbalanced output supported
•5 step turn over and 5 step roll off equalizer selection via
remote controller or front buttons
•12AX7 tube with Lundahl output transformer
•Ladder type attenuator volume for matching cartridge
input level
•4x 12AX7 for amplifier(2x each channel including
transformer output stage)
•LED display brightness control(1 ~ 8)
•Unbalanced, Balanced, Floating Balanced selection switch
W PHONO3T Owner’s Manual 04

Front Panel
Rear Panel
W PHONO3T Owner’s Manual 05
①Module 1 slot
②Module 2 slot
③Balanced output : XLR male
④Unbalanced output : RCA female
⑤Output mode selector
⑥AC Input : 220v only
①Power button
②IR remote sensor
③Source button : change input source
④Menu button : start and/or move menu
⑤Select button : change value
⑥High Gain Control Knob

Front Panel Guide
①Power button
②IR remote sensor
③Source button : change input source
④Menu button : start and/or move menu
⑤Select button : change value
⑥Volume control robe
W PHONO3T Owner’s Manual 06
① ② ③④⑤
⑥

Front Panel User Guide
- MODULE
W PHONO3T Owner’s Manual 07
•MODULE
- Input module selection : Source button
- Option Module type
-MM
-MC - LL1678
-MC - LL1941

Front Panel User Guide
- DISPLAY
W PHONO3T Owner’s Manual 08
* Display
- Control LED brightness
- Range : 1 ~ 8

Front Panel User Guide
- TURNOVER
W PHONO3T Owner’s Manual 09
* TURNOVER
- Range : 200, 300, 400, 500R, 500C

Front Panel User Guide
- ROLLOFF
W PHONO3T Owner’s Manual 10
•ROLLOFF
- Range : -6, -10, -12, -13.7, -16

Rear Panel Guide
W PHONO3T Owner’s Manual 15
①Module 1 slot
②Module 2 slot
③Balanced output : XLR male
④Unbalanced output : RCA female
⑤Output Selector
⑥AC Input : 220v only
① ② ③ ④⑤ ⑥

Specification for the WPHONO3T
W PHONO3T Owner’s Manual 09
Optional Input
Analog Output
Output Impedance
Equalizer
Line Voltage
Dimension
Weight
NOTES: All specifications are accurate at the time of printing.
Waversa Systems reserves the right to adjust specifications
without notice.
1 x Balanced(XLR)
1 x Unbalanced(RCA)
Module_MM –47K Bypass
Module 1678
Module 1941
Turnover(Hz) : 200, 300, 400, 500C, 500R (Waversa Custom)
Roll off(dB): -6, -10, -12, -13.7, -16
180~240 VAC @ 50~60Hz
W 440 x L 330 x H 105 ( Foot Spike 15 ) mm
13 Kg
Unbalanced : 600 Ohms
Balanced : 150 Ohms

403, 10-9, Hwangsaeul-ro 258beon-gil,
Bundang-gu, Seongnam-si, Gyeonggi-do,
Republic of Korea
http://www.waversa.com
email: [email protected]
Copyright 2017 Waversa Systems
