Waves BSS DPR-402 User manual

WAVES
BSS®DPR-402
COMPRESSOR / PEAK LIMITER / DE-ESSER
USER GUIDE

Waves BSS DPR-402
User Guide
2
TABLE OF CONTENTS
Chapter 1 –Introduction ....................................................................................................... 3
1.1 Welcome.......................................................................................................................................... 3
1.2 About BSS DPR-402.......................................................................................................................... 3
1.3 The Original Hardware..................................................................................................................... 3
1.4 Features Added to the Plugin .......................................................................................................... 4
1.5 Components..................................................................................................................................... 5
Chapter 2 –Interface and Controls ........................................................................................ 6
2.1 Interface........................................................................................................................................... 6
2.2 Controls............................................................................................................................................ 7
Chapter 3 –Suggested Settings for Initial Setups ................................................................. 13
3.1 Compression ..................................................................................................................................13
3.2 De-Essing........................................................................................................................................14
3.2.1 De-Essing Wide with Full Dynamic Control..........................................................................15
3.2.2 De-Essing HF with Full Dynamic Control ..............................................................................16
3.2.3 De-Essing Wide with Simultaneous Compression................................................................ 17
3.3 Peak Limiting..................................................................................................................................17
3.4 Additional Jumper Settings............................................................................................................18
All references to HARMAN products and all uses of HARMAN’s trademarks are made with written
permission from HARMAN INTERNATIONAL INDUSTRIES INC.
3.5WaveSystem Toolbar......................................................................................................................19

3
Chapter 1 – Introduction
1.1 Welcome
Thank you for choosing Waves! In order to get the most out of your new Waves plugin, please
take a moment to read this user guide.
To install software and manage your licenses, you need to have a free Waves account. Sign up
at www.waves.com. With a Waves account you can keep track of your products, renew your
Waves Update Plan, participate in bonus programs, and keep up to date with important
information.
We suggest that you become familiar with the Waves Support pages: www.waves.com/support.
There are technical articles about installation, troubleshooting, specifications, and more. Plus,
you’ll find company contact information and Waves Support news.
1.2 About BSS®DPR-402
The Waves BSS DPR-402 plugin is a software model of the DPR-402 Compressor/Peak
Limiter/De-Esser hardware originally manufactured by BSS Audio. This dynamics processor
provided the punchy, explosive signature sound for drum machines in the 1980s, and was
featured heavily in dance pop, electronic and hip-hop music. But it had many other versatile
uses in the studio, and was also a massively popular favorite on stage.
Working in collaboration with BSS Audio and Harman International, Waves has now modeled
this landmark dynamics processor and created a digital tool with the unique sound, functionality
and flexibility of the original.
1.3 The Original Hardware
BSS DPR-402 was designed in response to the demand for a versatile, compact stereo unit
that provides the three most commonly used dynamic functions in a single 1-unit rack space. Its
internal architecture, including two independent insert-accessible side chains per channel,
allows great flexibility and scope.
Waves BSS DPR-402
User Guide

Waves BSS DPR-402
User Guide
4
A dedicated de-esser control with a variable filter provides wideband sibilance control along with
compression and peak limiting. There are three modes of de-essing: full-spectrum attenuation,
HF-only attenuation, and a mix of de-essing and compression.
The compressor section affords full control over all the normal parameters, and offers “auto”
time constants for general-purpose use. It can be switched to operate at high frequencies only,
resulting in a dynamically controlled tunable HF filter. The control and subtract sidechain
insertion points allow for versatile dynamic tonal modification. Gain reduction is achieved using
a voltage controlled attenuator that is capable of reducing the input signal by up to 30 dB.
A calibrated peak limiter provides absolute control without compromising the dynamics setting of
the compressor. This can yield less dynamic distortion for an equivalent amount of
compression.
1.4 Features Added to the Plugin
In addition to modeling the above features of the original hardware, Waves has added five
features to the plugin for extra flexibility, control, and ease of use:
1
INPUT GAIN CONTROL
Controls the input level going into the compressor
2
MIX CONTROL
Controls the balance between the processed and the
unprocessed signal. This enables very quick parallel
compression within the plugins.
3
NOISE CONTROL
Adds hardware-modeled noise.
4
MS MATRIX
(stereo component only)
Provides separate compression between the mid and sides of
the stereo signal: Mid is compressed on one channel and sides
on the second.
5
MONITOR
(stereo component only)
Select the source of the monitor output –Mono, Stereo, Left or
Right. (In MS mode, Left monitors the mid while Right monitors
the sides.)

Waves BSS DPR-402
User Guide
5
1.5 Components
WaveShell technology enables Waves processors to be split into smaller plugins, which we call
components. A choice of different components for a particular processor allows you to choose
the configuration best suited to your material. Waves BSS DPR-402 includes the following
components:
BSS DPR-402 Mono
BSS DPR-402 Stereo

Waves BSS DPR-402
User Guide
6
Chapter 2 – Interface and Controls
2.1 Interface

Waves BSS DPR-402
User Guide
7
2.2 Controls
IN GAIN
Increases or decreases the gain of the input signal.
Range: -20 dB to 20 dB in 0.1-dB increments
Default: 0 dB
Reset: 0 dB
DE-ESS
Determines the amount of de-essing applied to the signal when Mode is set to “Compress.”
Range: Out (0 dB) to 9 dB of gain reduction in 0.1-dB increments
Default: Out
Reset: Out
FREQ
Determines the frequency that will trigger the selected frequency-dependent dynamic
processes.
Range: 800 Hz to 15 kHz in 0.01-kHz increments
Default: 15 kHz
Reset: 15 kHz
De-Esser Meter
Indicates the operation of the de-esser.
1. Off –DeEsser not active
2. Green –Shows that gain reduction is active, even at low values such as below 1 dB.
3. Orange –approximately 15 dB of Gain Reduction
THRESHOLD
Determines the level above which dynamic processes occur.
Range: Out (0.0 dB) to -50 dB in 0.1-dB increments.
Default: Out
Reset: Out

Waves BSS DPR-402
User Guide
8
RATIO
Determines the ratio of compression, expansion or de-essing, depending on the selected Mode
and Jumper settings.
Range: Out (1:1) to inf:1 in 0.1:1 increments
Default: 4:1
Reset: Out (1:1)
MODE
Determines the function of the dynamic processing operation.
1. COMPRESS –Broadband compression
2. DE-ESS Wide –Assigns Thresh/Ratio/Attack/Release controls to broadband de-essing.
The DE-ESS control is inactive in this mode.
3. DE-ESS HF –Assigns Thresh/Ratio/Attack/Release controls to frequency-specific
de-essing. De-ess and Peak Limiter controls are inactive in this mode.
ATTACK
Determines the attack time of the compression, expansion, or de-essing, depending on the
selected Mode and Jumper settings.
Range: 50 µs to 100 ms in 11 predetermined states
Default: 1 ms
Reset: 50 µs
RELEASE
Determines the release time of the compression, expansion or de-essing, depending on the
selected Mode and Jumper settings.
Range: 5 ms to 4 sec., or Auto for program-dependent Attack and Release times.
The ATTACK control is inactive in this mode.
Default: 100 ms
Reset: 5 ms

Waves BSS DPR-402
User Guide
9
BELOW TH Meter
Indicates how far the signal is below the set threshold. When the “TH” LED is illuminated, the
threshold has been reached.
Range: -18 dB to threshold.
GAIN REDUCTION Meter
Indicates the amount of gain reduction applied to the signal.
Range -3 dB to -27 dB of gain reduction
METER IN/OUT
Toggles the meter display between input and output.
Range: Input /Output
Default: Output
Reset: Output
Out Gain
Increases or decreases the gain of the output signal.
Range: -20 dB to 20 dB in 0.1-dB increments
Default: 0 dB
Reset: 0 dB
Mon S.C.
Lets you monitor the sidechain signal that triggers the VCA dynamic process.
Range: On/Off
Default: Off
Reset: Off
Input/Output Level Meter
Indicates the signal level at the plugin’s input or output, according to the state of the Meter
In/Out button.
Range: -44 dB to 0 dB

Waves BSS DPR-402
User Guide
10
PEAK LIM
Determines the threshold of the Peak Limiter. Peak level limiting occurs after Output Gain, so
changing output gain will affect output level, not the peak level. The ratio of the Peak Limiter is
fixed at 20:1.
Range: Out (0 dB) to -16 dB in 0.1-dB increments
Default: Out
Reset: Out
Peak Limiter Meter
This meter indicates when limiting begins (Green) and when heavy limiting occurs (Red).
PEAK LIM FAST/SLOW
Sets the attack and release times of the Peak Limiter. It is generally preferable to use the Fast
response setting. However, if this results in audible artifacts, try the Slow response.
Range: Fast /Slow
Default: Fast
Reset: Fast
CH IN
This button is an internal bypass button that enables you to quickly bypass all functions of the
selected channel in the DPR-402. When the button illuminated, the channel is active. When the
button is off, the channel is bypassed.
Range: In (active) / Out (bypass)
Default: In
Reset: In
LINK LED
When illuminated green, this LED indicates that the two channels are linked together as a
stereo pair.

Waves BSS DPR-402
User Guide
11
COLLAPSE / EXPAND
Exposes or hides the bottom panel of the BSS DPR-402 interface. When the plugin loads, the
interface is “collapsed” and the button displays “Expand.”
Range: Expand / Collapse
Default: Collapsed
Reset: Collapsed
JUMPER SETTING L/R
This drop-down menu provides a choice of 11 jumper settings modeled from the original BSS
DPR-402 hardware unit.
Range: 1-11 jumper settings (see section 3.4)
Default: 1 (Normal Compression)
Reset: 1 (Normal Compression)
(?) Jumper Setting Description
Displays a short description of the currently selected jumper setting.
EXT S.C.
Assigns an external key input to the VCA. This mode must be selected in order for the VCA to
“listen” to the external side chain. By driving the control s/c with an external signal, the
amplitude of the main signal will be modulated by the envelope of the external control signal.
DE-ESS controls, Peak Limiter controls, and Jumper menu are inactive in this mode.
Range: On/Off
Default: Off
Reset: Off
MIX L/R
Controls the balance between the processed and unprocessed signals.
Range: 0% to 100% (0.1% increments)
Default: 100%
Reset: 100%

Waves BSS DPR-402
User Guide
12
NOISE
Controls the amount of modeled noise and hum added to the processed signal.
Range: Off to 100
Default: Off
Reset: Off
MONITOR (Stereo Component Only)
Selects the source of the monitor output.
Left –Left output is sent to both sides (in MS Mode this monitors the mid).
Mono –Left and Right outputs are summed to mono and trimmed down by 6 dB.
Stereo –Stereo mode.
Right –Right output is sent to both sides (in MS Mode, this monitors the sides).
Default: Stereo
Reset: Stereo
STEREO MODE (Stereo Component Only)
Selects the stereo processing mode. There are three modes:
Stereo –All controls are in Link mode. When you set a control on one side (L or R), the
other side changes by the same value. Any difference in the settings between sides
(created using the Duo or MS mode) are preserved when you move back to Stereo
mode.
Duo –Controls can be set independently for each side, L and R.
MS –Applies an MS encoding matrix to the input of the plugin, allowing you to
separately compress and level the Mid (sum) and Sides (difference) signals. In this
mode, the letters M and S will be added at the header of the channels (M at the top left,
S at the top right). In MS mode, the left side controls affect the “Mid” signal in the matrix,
while the right side controls affect the “Sides” signal in the matrix.
Default: Stereo
A note on automation: When you automate settings in Stereo mode, your settings will be
saved for the specific channel (L or R) that you have selected, but will affect both L and R.
When you automate L and R to different values in Duo mode, you will need to delete your
settings for one of the channels (L or R) before you return to Stereo mode in order to avoid
conflicting values.

Waves BSS DPR-402
User Guide
13
Chapter 3 – Suggested Settings for Initial Setups
The original BSS DPR-402 had no such thing as a “standard setup”; some settings, however,
provided a good starting point for certain uses. The original unit, as well as the plugin, has four
basic modes of operation. Here are some suggestions for getting started with each.
3.1 Compression
The DPR-402 compressor will be very comfortable for anyone familiar with dynamics
processors. The following settings provide a good starting point for basic compression.
Initial Settings:
MODE SWITCH –Compress
THRESHOLD –Out
RATIO –4:1
ATTACK –Irrelevant when RELEASE is set to Auto
RELEASE –Auto
OUTPUT GAIN –0 dB
CHN IN –In (illuminated)
DE-ESS THRSHLD –Out
FREQ –When de-esser THRESHOLD is Out, the FREQ is irrelevant.
PK LIM THRSHLD –Out
1. Rotate the THRESHOLD control counterclockwise until the BELOW THRESHOLD meter is
fully illuminated and an appropriate amount of gain is indicated on the GAIN REDUCTION
meter. This will result in a drop in output level, as indicated by the OUTPUT METER.
2. The output GAIN CONTROL should now be adjusted to reinstate the output level. The levels
of the uncompressed input signal and the compressed output signal can now be compared
on the output meter by operating the METER INPUT switch.
3. Final adjustments of the controls (RATIO, ATTACK, RELEASE and others) can be made to
suit particular requirements. The “Auto” position of the RELEASE control allows program-
related operation of the dynamics of the unit, and will be acceptable for most general-
purpose applications. In case a tighter or looser result is needed, the ATTACK and
RELEASE controls can be set individually.

Waves BSS DPR-402
User Guide
14
3.2 De-Essing
The DPR-402 has three modes of de-essing available. The choice of mode depends on the
source material and the goals of the processing.
De-Essing Wide with Full Dynamic Control
In this mode, the de-esser detects only high frequencies, using a filter on the sidechain, but it
compresses the entire wide band of the signal. Usually this produces a natural-sounding
compression, but it can also result in compressing parts of the signal that are below the set
frequency. This may cause unwanted information to be attenuated. Should you encounter
undesired effects or artifacts, it is likely that the attack and release settings need to be adjusted.
De-Essing HF with Full Dynamic Control
In this mode, the de-esser splits the signal into the sibilance part and the non-sibilance part of
the audio. The sibilance part is sent to compression while the non-sibilant part is not. After
compression, the two parts are summed to recreate the wideband signal with attenuated
sibilance. This method provides more control over sibilance compression. This also allows more
compression of the sibilant part without changing the other ranges of the signal. However,
introducing a filter may create a phase shift, which can result in artifacts when the two signals
are summed together.
De-Essing Wide with Simultaneous Compression
In this mode, the de-esser detects only high frequencies, using a filter on the sidechain, but it
compresses the entire wide band of the signal. Usually this produces a natural-sounding
compression, but it can also result in compressing parts of the signal that are below the set
frequency. In this mode, the de-esser’s ratio, attack and release are pre-determined.

Waves BSS DPR-402
User Guide
15
3.2.1 De-Essing Wide with Full Dynamic Control
Initial Settings:
MODE SWITCH –De-Ess Wide
THRESHOLD –Out
RATIO –Infinity
ATTACK –50 µs
RELEASE –100 ms
OUTPUT GAIN –0 dB
CHN IN –In (illuminated)
DE-ESS THRSHLD –Out
FREQ –4 kHz
PK LIM THRSHLD –Out
1. Rotate the THRESHOLD control counterclockwise until the BELOW THRESHOLD meter is
fully illuminated and an appropriate amount of gain reduction is indicated on the GAIN
REDUCTION meter.
2. Listen to the program and fine tune the FREQ and THRESHOLD controls to achieve the
desired effect. Gain compensation is normally not required when de-essing.
3. Although fast attack and release times are most appropriate, they should be adjusted to
achieve the best results. The Auto position should NOT be used.
4. The source program can be monitored through the internal de-ess filter by clicking the MON
SC switch. This replaces the normal signal at the output connector with the output of the
de-ess filter and aids in setting the FREQ control in relation to the audible sibilance.
If desired, the peak limiter can be used simultaneously with wideband de-essing.

Waves BSS DPR-402
User Guide
16
3.2.2 De-Essing HF with Full Dynamic Control
Initial Settings:
MODE SWITCH –De-Ess HF
THRESHOLD –Out
RATIO –Infinity
ATTACK –50 µs
RELEASE –100 ms
OUTPUT GAIN –0 dB
CHN IN –In (illuminated)
DE-ESS THRSHLD - Out
FREQ –4 kHz
PK LIM THRSHLD –Out
1. Rotate the THRESHOLD control counterclockwise until the BELOW THRESHOLD meter is
fully illuminated and an appropriate amount of gain reduction is indicated on the GAIN
REDUCTION meter.
2. Listen to the program and fine tune the FREQ and THRESHOLD controls to achieve the
desired effect. Gain compensation is normally not required when de-essing.
3. Although fast attack and release times are most appropriate, they should be adjusted to
achieve the best results. The Auto position should NOT be used.
4. The source program can be monitored through the internal de-ess filter by clicking the MON
SC switch. This replaces the normal signal at the output connector with the output of the
de-ess filter and aids in setting the FREQ control in relation to the audible sibilance.
The peak limiter should NOT be used in the HF mode.

Waves BSS DPR-402
User Guide
17
3.2.3 De-Essing Wide with Simultaneous Compression
Initial settings: Set all compressor controls as required. For optimal de-essing effect, do not
exceed 10-15 dB of compression. If compression is not required, set THRESHOLD to OUT.
Initial Settings:
DE-ESS THRSHLD –Out
FREQ –4 kHz
PK LIM THRSHLD –Out
1. Use the standard controls for compression: THRESHOLD / RATIO / ATTACK / RELEASE.
Gradually rotate the DE-ESS THRESHOLD control counterclockwise until the desired
de-essing effect is achieved.
2. Adjust the FREQ control to ensure that frequencies lower than those causing concern do not
trigger de-essing.
3. Remember: In this mode the de-essing is wideband and may cause distortion or pumping
effects if the source program contains significant low frequencies.
3.3 Peak Limiting
The peak limiter is designed to be used in conjunction with compression and/or any wide
band de-essing. It cannot be used simultaneously with HF de-essing.
Initial Settings:
PEAK LIM THRESHOLD –As required
PEAK LIM FAST / SLOW –FAST
1. If the red LED indicator remains ON other than for occasional peaks, the GAIN control
should be lowered in order to reduce the signal going to the peak limiter.
2. If this produces an unwanted decrease in overall output level, then the amount of
compression should be increased either by reducing the compressor threshold, or by
increasing the compressor ratio and then reestablishing the gain.

Waves BSS DPR-402
User Guide
18
3.4 Additional Jumper Settings
Num
Setting
Description
Inactive
Controls
1
Normal Comp
Compression occurs equally at all
frequencies.
—
2
HF Re-Emph Comp
Compression is higher at LOW frequencies.
This arrangement will make heavily
compressed signals sound brighter,
compression triggered by low frequencies
modulates the high frequencies. This setting
removes low frequencies from the side
chain, eliminating this unwanted modulation.
—
3
HF Re-Emph Comp +
Compression is much higher at LOW
frequencies. This arrangement will make
heavily compressed signals sound brighter
as it lessens the effect of heavy low
frequencies modulating the treble.
—
4
LF Re-Emph Comp
Compression is higher at HIGH frequencies.
This is useful for controlling harsh or shrill
components of a signal, allowing faster
ATTACK and DECAY to be used before LF
distortion becomes a problem.
—
5
LF Re-Emph Comp +
Compression is much higher at HIGH
frequencies. This is useful for controlling
harsh or shrill components of a signal,
allowing faster ATTACK and DECAY to be
used before LF distortion becomes a
problem.
—
6
Wide LF Cntrl Comp
This mode compress the entire audio
spectrum based on the frequencies below
the setting of the FREQ control. The
modulation of HF signals by the LF signals
is an effect which may be desired.
—
7
Narrow LF Cntrl Comp
Only frequencies below that set on the
FREQ control are compressed. Low
frequencies are compressed without
modulating the high frequencies, which pass
unattenuated. Normally, the PEAK LIMITER
and DE-ESSER should not be used in this
mode.
Peak Limiter,
De-ESS
8
Expander Wide
When input signals exceed the set
threshold, expansion occurs. Normally, the
DE-ESSER should not be used in this
mode. The PEAK LIMITER may be used for
effect.
De-ESS

Waves BSS DPR-402
User Guide
19
Num
Setting
Description
Inactive
Controls
9
Expander LF Only
When input signals exceed the set
threshold, expansion occurs, but only to
those frequencies below that set by the
FREQ control. Normally, the DE-ESSER
should not normally be used in this mode.
The PEAK LIMITER may be used for effect.
DE-ESS
10
Expander LF Cntrl
Expansion occurs over the entire audio
bandwidth. However, it is under the control
of either low or high frequencies, as set by
the links and FREQ control.
Mode Switch
fixed on
Compress
11
Expander HF Cntrl
Expansion occurs over the entire audio
bandwidth. However, it is under the control
of either low or high frequencies, as set by
the FREQ control.
Mode Switch
fixed on DE-
ESS Wide
3.5WaveSystem Toolbar
Use the bar at the top of the plugin to save and load presets, compare settings, undo
and redo steps, and resize the plugin. To learn more, click the icon at the upper-right
corner of the window and open the WaveSystem Guide.
