WayFinder V2000 User manual

QUICK REFERENCE GUIDE
Getting started:
1. Install battery, observing dia-
grammed polarity (page 1).
2. Plug 12-volt adapter into “POWER”
jack and your vehicle lighter socket
(page 1).
3. Adhere peel-and-stick temperature
sensor to interior or exterior loca-
tion, and plug into “TEMP” jack
(page 2)
4. Mount compass to windshield with
suction cups in a position that does
not block driver’s view, is more than
5” away from a speaker, and puts
the controls within reach (page 3).
5. Adjust compass so it is level and facing
rear of vehicle (not toward driver).
Never loosen pivot screw! To adjust,
simply pull to right against spring-
loaded pivot (page 3).
Before rst use:
Calibrate compass to your vehicle:
Hold button and follow on-screen
directions. You simply turn your vehi-
cle in one complete circle, taking 20 to
60 seconds to complete (page 5).
Using your compass:
• Press button to switch on;
unit shuts off automatically about
10 minutes after your vehicle stops
moving.
• Read your compass heading three
ways: by any of 16 cardinal points,
numerically in 5° increments, and
graphically by an arrow on the com-
pass rose.
• Hold button to store a bearing
and follow a desired course (page 6).
• Press button for a tempera-
ture reading (page 6).
• Press button to switch screen
backlight on or off (page 6).
Note: Be sure to read the manual
for detailed instructions.

1
CONGRATULATIONS!
Now you have a new navigational part-
ner when you drive — one of the most
modern and accurate compasses avail-
able for use in all types of vehicles. To
get the most from your compass, please
read this manual thoroughly, and keep
it in a safe place for future reference.
Features
• Three compass displays.
• Memory stores your compass head-
ing to help you stay on course.
• Interior or exterior thermometer
for accurate comfort monitoring.
• ICE alert warns of hazardous road
conditions.
• Alert for magnetic interference.
• Auto power off conserves battery.
• Bright backlight with auto on/off
for night use.
• Two power modes: 12-volt and/or
internal battery for cord-free use.
EASY INSTALLATION
Note: Remove the protective overlay
lm from the LCD screen.
Step 1: Install the battery.
Slide open the battery cover on the
rear of the unit and insert the battery
straight down (not at an angle), observ-
ing the correct polarity. Replace the
cover. The screen should come on
with a quick quality test. If the dis-
play becomes stuck, remove the bat-
tery, wait about a minute, then reinsert
the battery.
Step 2: Plug in the 12-volt adapter.
Insert the small end into the jack
marked “Power” on the back of the
unit, and plug the large end into your
vehicle lighter receptacle.
Power notes
• Use of the 12-volt adapter or hard-
wire kit (see Optional Accessories
on page 8) is highly recommended
to avoid draining the unit’s battery

2
and losing memory settings.
• Keep the unit plugged into your
vehicle while changing the battery
to avoid losing memory settings.
• Since not all vehicles supply con-
stant power to the lighter socket,
a battery must be in the unit at all
times to retain memory settings.
• Unit shuts off automatically about
10 minutes after the last detected
change in magnetic eld. During
night use, a built-in light sensor
automatically switches on the screen
backlight (disabled when the unit is
operating on its battery alone).
Step 3: Install the temperature
sensor.
Mount the sensor inside for monitor-
ing interior temperatures or outside
for exterior temperatures (required for
ICE alert feature). If used inside, place
the sensor in a natural airow, out of
direct sunlight, and not in the direct
outow of a vent. For exterior use,
select a ventilated location outside the
passenger compartment, such as the
grill area or doorjamb (away from
sunlight and engine heat).
Making sure the surface is free of dirt,
use the peel-and-stick pad to adhere
the sensor. Mount to a less heat-con-
ductive plastic or rubber component
instead of to a steel body part. (As all
vehicles are different, you may need
to experiment to nd the best site.)
Use the included retainer clips to
secure the sensor cable to the wind-
shield or dashboard. Plug the sensor
connector into the jack marked
“TEMP” on the back of the compass.
Note: A longer 30-foot temperature
sensor is available (see Optional
Accessories on page 8).
Note: Do not leave the Waynder
V2000 in a parked vehicle that is
likely to be exposed to extremely hot
or cold temperatures.

3
Step 4: Mount on windshield.
Slide the compass into the mounting
bracket until it clicks securely into
place (it only ts one way). Slide the
suction cups into their mounting holes
(if not pre-installed).
Select a location on the windshield
that will not obstruct the driver’s view,
is at least 5 inches away from an audio
speaker (to prevent interference), and
permits easy reach of the compass
buttons. Clean the window glass.
Press the suction cups rmly against
the windshield.
For accurate readings the compass
can be tilted up or down no more than
20º from horizontal (road level).
20° max
20° max
Dashboard
Windshield
To adjust the angle, grasp the spring-
loaded pivot and pull to the right,
freeing the locking teeth (see diagram
below). Set the bracket to the correct
angle and release the pivot. The lock-
ing teeth will re-engage in this new
position.
Note: never loosen the pivot screw as
small internal parts could become lost.
Important: The screen should point
toward the rear of the vehicle (not
at the driver) so that the compass is
aligned with the direction of travel.

4
CONTROLS AT A GLANCE The screen shows your heading in
one of 16 cardinal points (N, NNE,
NE, etc.), and an arrow on the com-
pass rose points toward that direction.
Plus, your precise heading is shown
numerically in increments of 5°.
Buttons and icons
Light button: Press to switch the
backlight on or off, or hold for two sec-
onds to adjust the auto shut-off interval.
Cal button: Press or hold to
begin calibration.
Temp button: Press to display
the temperature, or hold to select
Fahrenheit or Celsius.
Point button: Press to display a
stored bearing point, or hold to store a
new bearing.
Power button: Press to switch
the Waynder V2000 on or off.
“Distortion” icon: Indicates that mag-
netic interference is compromising com-
pass accuracy, or that the battery has been
changed and calibration is required.
Battery Photo Diode
Compartment
Temperature 12-Volt Power
Sensor Jack AdapterJack
Compass Back
“DISTORTION” Cardinal Point Numeric Heading
Icon Readout Readout
Compass Rose Temperature and Buttons
Bearing Point Readout
Compass Front

5
OPERATION OF YOUR COMPASS
Calibrating the compass
For accurate readings, your compass
must be calibrated before the rst
use, and any time it is moved to a
new location in a vehicle or whenever
the memory settings are lost from a
power interruption. Recalibration is
also required after a change to your
vehicle (such as installation of a stereo),
or whenever “DISTORTION” is dis-
played continuously on the screen.
Always calibrate with the compass in
place on your windshield and electri-
cal devices such as headlights, stereo,
etc. switched on. Select a level sec-
tion of pavement, such as an empty
parking lot or a non-busy street. For
boats, calibration is best performed in
a calm harbor or marina.
Calibration steps:
1. Hold
The message “PRESS AGAIN TO
START OR PRESS LIGHT TO
CANCEL” cycles in the lower
right corner.
2. Press
Now “TURN ONCE” will ash in
the lower left corner, and “TURN
ONCE THEN PRESS CAL TO
END” appears in the lower right
corner for approximately 2 minutes.
3. Turn vehicle in one complete circle
in either direction. Take at least 20
seconds, but not more than 60 sec-
onds to complete (circle size does
not matter).
4. Press
“DONE” displays briey in lower
right corner. The V2000 is now
calibrated.

6
Let the compass guide you
You can enter a course direction (bear-
ing point) and a guiding arrow will
appear on the compass rose. (Until a
bearing is stored, 00° displays in the
lower right corner.)
To enter a bearing point:
1. Align your vehicle so that the
desired numeric heading appears.
2. Hold
The message “PRESS AGAIN TO
STORE” cycles in the lower right
corner.
3. Press
The stored bearing point appears
in the lower right corner, and a
ashing arrow points toward that
direction on the compass rose. This
bearing point remains in memory
until you enter a new bearing point
or the battery is replaced.
4. Press
Turns display of stored bearing
point on or off.
Using the thermometer
Press to turn the temperature
display on or off. (If the temperature
sensor has not been properly installed,
“PLUG IN THE SENSOR” will
appear on the screen.) The Waynder
V2000 displays temperatures between
1°F and 158°F (-17°C to 70°C), or
will indicate that the measured tem-
perature is above or below this range.
To select °C or °F:
1. Hold
The message “PRESS AGAIN TO
STEP HOLD TO SELECT” cycles
in the lower right corner.
2. Press
Either °C or °F ashes in the lower
right corner.
3. Press
To toggle between °C and °F
4. Hold
Until “DONE” displays, saving
your selection in memory.

7
ICE alert
When the exterior sensor is properly
installed, the Waynder V2000 can
alert you to dangerous road con-
ditions. Any time the temperature
drops to 35ºF (2ºC), it automatically
switches to temperature mode and
“ICE” will ash in the bottom right
corner along with the temperature.
This is shown until any button is
pressed. (ICE alert feature will not
work if the temperature sensor is not
installed or is installed incorrectly.)
Adjusting the screen backlight
Press to switch on the backlight.
When operating on the internal battery,
the backlight has been set to shut off
automatically after 10 seconds, con-
serving power. To change this setting:
1. Hold
“PRESS AGAIN TO STEP,”
“HOLD LIGHT TO SELECT”
cycles in the lower right corner.
2. Press
The values 00, 10, 30, 60, and 180
seconds appear in sequence.
3. Hold
To select the desired interval until
“DONE” displays. Note: selecting
00 disables the auto shut-off fea-
ture.
4. Press
The backlight remains on for the
selected time, then shuts off.
When using the 12-volt adapter or
optional hardwire kit, the built-in light
sensor overrides the auto-shutoff func-
tion. Now the backlight operates when-
ever the compass is on in low-light
conditions such as night. It will switch
off whenever no magnetic eld change
has been detected for about 10 minutes,
or when you press the button.

8
OPTIONAL ACCESSORIES
• 15-foot hardwire kit connects the
unit directly into your 12-volt
power system (recommended for
installation only by a qualied
automotive accessory installer).
• 30-foot temperature sensor for
vehicles requiring a longer sensor
cable.
Each is available for an additional
charge by calling our customer ser-
vice department at [phone]
from anywhere in the U.S.A., (707)
566-2260, or by e-mail at
[email protected].
FREQUENTLY ASKED
QUESTIONS
How does the Waynder V2000
work?
Developed by PNI Corporation for
the U.S. military, the patented mag-
netic sensor technology, called mag-
neto-inductive, is the greatest advance
in compass technology in 60 years.
It senses the difference between the
magnetic elds of the earth and your
vehicle, then electronically subtracts
the latter to display accurate compass
readings. This superior performance is
achieved with reduced power consump-
tion and at a lower cost. The technol-
ogy is so advanced, it has been adopted
for compasses in GM, Ford, and Chrys-
ler automobiles, Polaris jet skis, Bay-
liner boats, and Timex watches.
Where can the Waynder 2000 be
used?
You’ll nd it a valuable help to navi-
gation in any type of vehicle, includ-
ing cars, trucks, vans, SUVs, off-road
vehicles, boats, and RVs.
What is calibration, and why is it
necessary?
Calibration permits the Waynder
V2000 to distinguish between the
earth’s magnetic eld and stray mag-
netic elds such as those generated

9
by a vehicle’s steel body or electron-
ics. Without calibration, the built-in
microprocessor interprets the detected
magnetic elds as coming entirely
from the earth, which can produce
inaccurate compass readings.
What does the “DISTORTION”
alert mean?
This indicates magnetic distortion
from stray magnetic elds caused by
electronics or metal. The message
may appear briey when driving over
a bridge, under an overpass, over rail-
road tracks, within close proximity to
a strong magnetic eld, or when the
battery is installed. The message will
go away when you move beyond the
source of distortion. If it appears con-
tinuously or right after calibration, the
unit needs to be calibrated again in a
location where there is less magnetic
interference.
How can I improve the calibration
process?
Remember to match conditions to
your actual use before calibrating. For
example, calibrate with both the tem-
perature sensor and 12-volt adapter
attached (if you intend to use the
12-volt adapter). If you typically drive
with your headlights and stereo on
(or any other electronic device), turn
these on prior to calibration.
How can the bearing point feature
help me?
In nice weather most drivers can sense
the direction they are headed by the
position of the sun and features of the
landscape. But at night and in the fog
you can rapidly lose your way. Setting
a bearing point to a desired heading
or to a landmark lets you monitor and
maintain your heading and remain on
course. A bearing point also lets you
vary your course and get back to your
original bearing path.

10
SERVICE AND REPLACEMENT
Customer Service
For customer service questions, our
customer service department can
be contacted by e-mail at
[email protected], or
call us between 8:00 a.m. and 5:00
p.m. (PST), Monday through Friday.
Replacement Service
For the fastest service, it is best to
contact or return your unit to the place
of purchase within 30 days of the pur-
chase. If you wish to return the unit
for replacement or repair to PNI Cor-
poration, please follow these steps:
1. Obtain a return merchandise autho-
rization (RMA) number by con-
tacting PNI:
• By phone at [phone]
(toll-free within the U.S.A.
only) or at [phone]
between 8:00 a.m. and 5:00
p.m. (PST).
• By fax at [phone].
• You may also contact us by
e-mail at the following address
[e-mail].
2. Provide a proof of purchase, such
as a mechanical reproduction or
carbon copy of your sales receipt.
If you send your original receipt,
it cannot be returned. Proof-of-
purchase must show printed date
of purchase, model number, and
place of purchase. There will be
a charge for repair/replacement if
no proof of purchase is provided,
or if the 12-month warranty period
is past.
Once you have acquired a RMA
number, pack the unit securely to
prevent damage in transit. If possi-
ble, use the original packing mate-
rial and box. Be sure to send the
entire product.
3. Ship prepaid and insured by way
of a traceable carrier such as

11
United Parcel Service (UPS),
FedEx Parcel Service, or First
Class Mail to avoid loss in transit.
4. Write the issued RMA number on
the outside of your package and
send your proof-of-purchase and
description of the problem to:
PNI Corporation
Attn: RMA#___________________
5464 Skylane Boulevard, Suite A
Santa Rosa, CA 95403-1084
Be sure to type or clearly print your
name and the address where your
wish the replacement to be sent. After
receipt of your documents and unit, a
replacement unit will be sent to you.
Please allow 2 to 3 weeks after receipt
of your returned product for delivery
of your replacement.
SPECIFICATIONS
Power
1 x Lithium CR123 battery
12V DC adapter
Battery Life
3,600 hours without backlight, 140
hours with constant backlight usage
Display resolution / accuracy
5° / ±5°
Temperature resolution/accuracy
1°F / ±3°F within operating range
Storage temperature
-40° to 185°F (-40° to 85°C)
Operating temperature
14° to 140°F (-10° to 60°C)
Dimensions (without bracket)
4 x 2 x 1 inches
(101.6 x 63.5 x 31.7 mm)
Weight (with bracket, with battery)
4.4 oz (124.7g)

12
LIMITED WARRANTY; LIMITATION OF LIABILITY
PNI Corporation (“PNI”) manufactures its products,
which include accessories, from parts and compo-
nents that are new or equivalent to new in perfor-
mance and expressly warrants to the original retail
purchaser who is also the original user that this
product will be free of defects in workmanship and
materials for one (1) year from the date of purchase.
Implied warranties are limited to such person for the
same period.
If the product is found by PNI to be defective, PNI’s
entire liability and your exclusive remedy for breach
of warranty, express or implied, shall be that PNI will
repair or replace the product and return the product
or its replacement to you at no charge, provided that
you ship the product to PNI at your expense with
a description of the defect and subject to the other
conditions of this warranty. Should the product prove
to be irreparable, PNI may substitute an equivalent
product of the same or similar style and of a value
not in excess of the original purchase price of your
product. PNI warrants the repaired or replacement
product to be free from defects in material and
workmanship for the balance of the original war-
ranty period, extended by the time period from your
shipment to PNI for repair or replacement until the
repaired or replaced product was received by you.
This warranty will be void if the serial number or
other identication marks on the product or its acces-
sories have been defaced, damaged or removed.
This warranty does not cover wear and tear due to
normal use, or damage to the product as the result of
improper usage, neglect of care, alteration, accident
or unauthorized repair, nor does this warranty apply
to the battery necessary to operate the product.
This warranty is extended only to the original retail
purchaser who is also the original user and may not
be transferred or assigned to subsequent owners.
In order to validate your warranty, you must provide
proof of purchase acceptable to PNI, together with
the product shipped for warranty repair/replacement.
Products returned to PNI must be pre-authorized
by PNI with an RMA (return material authorization)
number marked on the outside of the package.
Please refer to the Service and Replacement sec-
tion for PNI Corporation contact information.
THE FOREGOING WARRANTY IS GIVEN IN LIEU
OF AND PNI DISCLAIMS ALL OTHER EXPRESS
WARRANTIES OR REPRESENTATIONS IN FACT
OR IN LAW WITH RESPECT TO THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, ANY WAR-
RANTY OR REPRESENTATION THAT USE OF
THE PRODUCT WILL BE UNINTERRUPTED OR
ERROR FREE.
Except for the breach of warranty remedies set forth
herein, or for personal injury, PNI shall have no lia-
bility for any indirect or speculative damages (includ-
ing, but not limited to, consequential, incidental,
punitive and special damages) relating to the use of
or inability to use this product, whether arising out
of contract, negligence, tort, or under any warranty
theory, or for infringement of any other party’s intel-
lectual property rights, irrespective of whether PNI
had advance notice of the possibility of any such
damages, including, but not limited to, loss of use,
revenue or prot. In no event shall PNl’s total liability
for all claims regarding the product exceed the price
paid for the product. PNI neither assumes nor autho-
rizes anyone to assume for it any other liabilities.
Some states and provinces do not allow limitations
on how long an implied warranty lasts or the exclu-
sion or limitation of incidental or consequential dam-
ages, so the above limitations or exclusions may not
apply to you. This warranty gives you specic legal
rights and you may have other rights that vary by
state or province.

Your Opinion Matters!
Please take a few minutes to register and let
us know about yourself. It will help us serve
you better in the future, and all information
will remain condential.
To register, log on to:
www.pniservice.com
