WebDT MS400 Assembly instructions

ENGLISH
BASIC OPERATION GUIDE
MS400
MulScreen Appliances
MS400
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com I hp://signage.dtri.com
Copyright © 2011, DT Research, Inc. All Rights Reserved. DT Research, WebDT are registered trademark of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the MS400, part of the WebDT MulScreen
Appliance line by DT Research. The MS400 facilitates the creaon of a unique and powerful
communicaons medium that offers unparalleled opportunies to capture an audience’s aenon
at key decision-making locaons. The WebDT MulScreen Appliances enable efficient deployments
for digital signage, with reliable hardware features and innovave server-based soware. The
Microso® Windows® Embedded Standard 7 based MS400 offers remote management of the
devices and the displayed content with the WebDT Content Manager. The MS400 together with the
WebDT soware suite offers an effecve soluon for delivering and managing messages that target
audiences in the right place, at the right me.
Package Contents
One WebDT MS400 MulScreen Appliance1.
One security USB dongle2.
One power cord3.
Four mini DP-to-DVI cables4.
One WebDT Content Manager CD5.
One image recovery DVD6.
WebDT Content Manager Insert including network7. connecon guide and important FAQ
WebDT MS400 Release Note 4.08.
Basic operaon guide9.
NOTE: The actual package contents may vary depending on the
configuraon acquired.
2
3
5
4
Content Manager Soware
SPECIFICATIONS
System
CPU Intel® Core™ i3, 2.93GHz;
upgrade opon: Intel® Core™ i5 or Intel® Core™ i7
Graphics Card ATI FirePro Mulview™ 2460
RAM 4GB DDR3
Storage 250GB HDD
Operang System Microso® Windows® Embedded Standard 7
Display Resoluon 3840 x 2160 for 2 x 2 digital signage array
(max. DVI resoluon 1920 x 1080 per display)
Video Resoluon Full-HD/ QFHD
Network Interface 10/ 100/ 1000Mb BaseT LAN; Wi-Fi 802.11a/b/g (oponal)
Soware Compability Compable with WebDT Content Manager (WCM 4.0 SP1 or
above recommended)
Input/Output Ports
4 mini DisplayPorts; 8 audio outputs; 12 USB 2.0 ports; 1 serial
Port; 1 RJ45 connector for Ethernet; 1 IEEE 1394 port;
oponal WLAN (via internal PCI-Express slot or external USB)
Power
Power Supply 300W ATX
Mechanical
Enclosure Aluminum + steel
Dimensions (H x W x D) 3.75 x 13 x 15.5 in/ 95.3 x 330.2 x 393.7 mm
Weight 14.51 lbs/ 6.58 kg
Environmental
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 5% - 95% non-condensing
* Specificaons subject to change without noce.
BOG012011MS400ENG
1

Audio jacks USB ports Power buon Serial Port
IEEE 1394 port RJ45 connector Mini DisplayPorts
MS400
ENGLISH 23ENGLISH
Memory and Storage
Depending on the base soware configuraon, the user may need only the internal HDD of the
MS400 for user’s installed soware and storage. The user may also supplement storage space with
USB-based peripherals such as flash disks, disk drives, etc.
I/O Ports
Connecng Peripherals
Connect the mini DP-to-DVI cables to the graphic card outputs (1) and make sure your monitors are
connected the MS400 with DVI-D cables (2). Then insert the USB key to a USB port (3). Aer the
peripherals are connected, plug the power cord into the MS400 (4) and insert the other end into a
power outlet.
NOTE: DO NOT connect the power cord before connecng the USB dongle and all cables to the MS400.
Powering ON and OFF
The Power Buon is located on the front of the MS400.
To turn the MS400 on, push and release the Power Buon on the front bezel. The power LED will
be lit (blue), and the corresponding interface will be shown on the display monitors.
To turn offthe device, use the soware shutdown interface provided, or unplug the appliance.
In the event of system lockup, unplug or re-plug the power cable. Also, the Power Buon may be
used to perform a reset on the device. To do that, push and hold the Power Buon for at least
4 seconds. The system will shut down and all unsaved work may be lost. Pushing on the Power
Buon again will restart the device.
Server Installaon
Please install the WebDT Content Manager server soware from
the WebDT Content Manager CD and follow the detailed steps
described in the User Manual file included in the WebDT Content
Manager CD.
Appliance Registraon
Aer turning on the MS400 for the first me, a screen prompt is
displayed for registering the player. If the screen prompt is not
shown, please follow the instrucons below:
Press and hold “Control + Shi+ Space”to exit the WCM Player soware.1.
Navigate to Start | All Programs | DT Research | WebDT Signage Player2.
Select Register WebDT Signage Player Again. The Player Registraon screen should appear. Fill in3.
all fields to register. The required informaon is marked.
Click OK to register and connect to the WebDT Signage Appliance Publish Server.4.
<1> <2> <3> <4>
Connect the mini
DP-to-DVI cables to
the graphic card.
Connect the MS400
with DVI-D cables.
Insert the USB key. Connect the power cord.
FE
C
BD
BA
BB GAB
A B C D
E F G
MS400 Front
MS400 Rear
