Welch Allyn SCANTEAM 2380 User manual

Keyboard Wedge/
Decoded Out Wand
Technical Manual

STATEMENT OF AGENCY COMPLIANCE
Thisdevicecomplieswithpart15oftheFCCRules. Operationissubjecttothe
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB
digitaldevicepursuanttopart15oftheFCCRules. Theselimitsaredesignedto
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
FCC Class B Compliance Statement
Caution: Any changes or modifications made to this device that are not
expressly approved by Welch Allyn, Inc. may void the user’s authority to
operate the equipment.
Note: To maintain compliance with FCC Rules and Regulations, cables
connected to this device must be
shielded cables, in which the cable shield
wire(s) have been grounded (tied) to the connector shell.
Thisequipmentdoesnot exceed theClassBlimitsfor radio noise emissionsas
describedintheRadioInterferenceRegulationsoftheCanadianDepartmentof
Communications.
Canadian Notice
Lepresentappareilnumeriquen’emetpasdebruitsradioelectriquesdepassant
leslimitesapplicables auxappareilsnumeriquesde laclasseB prescritesdans
le Reglement sur le brouillage radioelectrique edicte par le ministere des
Communications du Canada.
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•Consultthedealeroranexperiencedradioortelevisiontechnicianforhelp.
FCC ID: EIF58QST2380

or
Welch Allyn Ltd.
The Lodge, Tanners Lane
Warrington, Cheshire WA2 7NA
England
European Contact: European Regulatory Manager
Welch Allyn Ltd.
28 Sandyford Office Park
Foxrock, Dublin 18
Ireland
The CE mark on the product indicates that the system has been tested to and
conforms with the provisions noted within the 89/336/EEC Electromagnetic
Compatibility Directive and the 73/23/EEC Low Voltage Directive.
Welch Allyn shall not be liable for use of our product with equipment
(i.e., power supplies, personal computers, etc.) that is not CE marked and
does not comply with the Low Voltage Directive.
Disclaimer
Welch Allynreserves the right to make changes in specifications and
otherinformationcontainedinthisdocumentwithoutpriornotice,andthe
readershould inall casesconsult WelchAllynto determinewhether any
suchchangeshavebeenmade. Theinformationinthispublicationdoes
not represent a commitment on the part of Welch Allyn.
Welch Allyn shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of this
material.
This document contains proprietary information which is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated into another language without
the prior written consent of Welch Allyn, Incorporated.
1999 Welch Allyn, Inc. All rights reserved.
Data Collection Web Addresss: http://dcd.welchallyn.com

Limited Warranty
Limited Warranty
Welch Allyn, Inc., hereby warrants its standard Decoded Output Scanner to
be functional and free from manufacturing defects at the time of delivery.
Welch Allyn, Inc. further warrants that it will replace or repair, at its
option, any unit that fails to perform according to Welch Allyn’s published
specifications during a period of five (5) years from the time of shipment
by Welch Allyn, Inc. to the user or the time it is purchased from any of
Welch Allyn Inc.’s Authorized Distributors. Any attempt on the part of the
user to disassemble or service the wand, except for tip replacement, shall
void the warranty.
This warranty does not apply to products which have been damaged by
improper handling, shipping or misuse. The warranty does not apply if, in
the sole opinion of Welch Allyn, Inc., the unit has been damaged by
accident, misuse, neglect, improper shipping or handling. Since the unit is
sensitive to static discharges and electricity, the responsibility to protect it
from static damage is solely that of the user. The warranty is valid only if
the wand has not been tampered with, or serviced by any party
unauthorized by Welch Allyn, Inc. as a repair facility.
THE WARRANTIES SET FORTH HEREIN ARE IN LIEU OF ANY AND ALL
OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THE BUYER ACKNOWLEDGES THAT NO
OTHER REPRESENTATIONS WERE MADE OR RELIED UPON WITH
RESPECT TO THE QUALITY AND FUNCTION OF THE SCANNER HEREIN
SOLD.
In no event shall Welch Allyn, Inc. or its resellers be liable for any loss,
inconvenience or damage whether direct, incidental, consequential or
otherwise, and whether caused by negligence or other fault resulting from
the breach of any express warranty except as set forth herein. Some states
do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state or country to country.

Limited Warranty

i
Table of Contents
TABLE OF CONTENTS
Statement of Agency Compliance
Limited Warranty
Chapter 1 Introduction to the SCANTEAM 2380 Scanner
Section Page
1.1 Introduction 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Hardware Description 1–1. . . . . . . . . . . . . . . . . . . . . . .
1.3 Software Description 1–3. . . . . . . . . . . . . . . . . . . . . . . .
1.4 Wand Models 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2 Operational Description
Section Page
2.1 Chapter Objectives 2–1. . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Main Elements of the 2380 System 2–1. . . . . . . . . . .
2.3 Scanner Identification Label 2–2. . . . . . . . . . . . . . . . .
2.4 Operating Theory 2–2. . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Factors Affecting Scanner Performance 2–2. . . . . . .
2.5.1 Scanner Illumination Source 2–2. . . . . . . .
2.5.2 Scanning Aperture 2–3. . . . . . . . . . . . . . . . .
2.5.3 Depth of Field 2–4. . . . . . . . . . . . . . . . . . . . .
2.5.4 Scanning Velocity 2–4. . . . . . . . . . . . . . . . . .
2.5.5 High/Low Density Bar Codes 2–4. . . . . . . .
2.5.6 Print Contrast 2–5. . . . . . . . . . . . . . . . . . . . .
Chapter 3 Setup and Installation
Section Page
3.1 Chapter Description 3–1. . . . . . . . . . . . . . . . . . . . . . . .
3.2 Preparation 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Setup and Installation 3–1. . . . . . . . . . . . . . . . . . . . . . .
3.4 Scanner Checks 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . .

ii Table of Contents
Chapter 4 Programming the Scanner
Section Page
4.1 Introduction 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 The Programming Menu 4–1. . . . . . . . . . . . . . . . . . . .
4.2.1 Programming Menu Pages 4–1. . . . . . . . . .
4.2.2 Facing Page 4–4. . . . . . . . . . . . . . . . . . . . . .
4.2.3 Bar Code Chart 4–4. . . . . . . . . . . . . . . . . . .
4.3 Direct Connect Terminal Selection Menu Page 4–6.
4.4 Terminal Selection Menu Page 4–6. . . . . . . . . . . . . . .
4.5 Output Parameters & Format Menu Page 4–6. . . . .
4.6 COMM 1 Menu Page 4–12. . . . . . . . . . . . . . . . . . . . . . .
4.7 Scancode Selection Menu Page 4–13. . . . . . . . . . . . . .
4.8 Symbology Selection Menu Page 4–14. . . . . . . . . . . . .
4.9 Message Format 4–15. . . . . . . . . . . . . . . . . . . . . . . . . . .
4.10 Configuration Example 4–16. . . . . . . . . . . . . . . . . . . . . .
4.11 Keyboard Layouts and Delimiters 4–18. . . . . . . . . . . . .
Chapter 5 Maintenance and Troubleshooting
Section Page
5.1 Scanner Maintenance and Service 5–1. . . . . . . . . . .
5.2 Cleaning 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Inspection 5–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Troubleshooting 5–2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 Obtaining Factory Service in the U.S. 5–4. . . . . . . . .
Obtaining Factory Service in Europe 5–4. . . . . . . . . .
Obtaining Factory Service in Asia 5–4. . . . . . . . . . . .
Technical Support 5–5. . . . . . . . . . . . . . . . . . . . . . . . . .

iii
Table of Contents
Appendices
A Technical Specifications
Section Page
A.1 Scanner Performance A–1. . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2 Optical Specifications A–1. . . . . . . . . . . . . . . . . . . . . . . . . . .
A.3 Electrical Specifications A–2. . . . . . . . . . . . . . . . . . . . . . . . .
A.4 Environmental Specifications A–4. . . . . . . . . . . . . . . . . . . . .
A.5 Mechanical Specifications A–4. . . . . . . . . . . . . . . . . . . . . . .
A.6 Bar Code Symbol Specifications A–5. . . . . . . . . . . . . . . . . .
B Keyboard Function Relationships
B.1 Keyboard Function Relationships B–1. . . . . . . .
Index
List of Illustrations
Figure Page
1.1 Keyboard Wedge Connection 1–2. . . . . . . . . . . . . . . . . . .
3.1 “Y” Interface Cable Connections 3–2. . . . . . . . . . . . . . . .
4.1 Example of Programming Menu Page 4–2. . . . . . . . . . .
4.2 Bar Code Chart 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 NCR 7052/32 & 56 Key Terminal 4–18. . . . . . . . . . . . . . . .

iv Table of Contents
Preface
SCANTEAM 2380 Bar Code Wand Scanners are used in both retail and
commercial environments. The retail environment includes point–of–sale
uses, while the commercial environments include industrial type
applications (e.g., time and attendance information gathering).
This technical manual is an extension of the SCANTEAM 2380
Programming Menu. The Programming Menu contains information and
bar codes that you will use to set up your system to meet your needs. This
manual provides you with additional, in–depth information about the
options in the Programming Menu.
Chapter 1 provides a description of the 2380 scanner software and
hardware.
Chapter 2 is an in–depth description of the operating system, explaining
how the scanner works, and how it reads/decodes a bar code symbol.
Scanner identification and scanning techniques are discussed.
Chapter 3 explains how to set up and install your scanner. Instructions to
confirm scanner operation and to check bar code labels is provided.
Chapter 4 explains how to program your scanner to meet your specific
needs. Refer to Chapter 4 for detailed information when you are using the
2380 Programming Menu.
Chapter 5 explains how to maintain (clean and inspect), troubleshoot and
obtain service and technical assistance for your 2380 scanner.
Appendix A provides information about scanner performance, optical,
electrical, environmental, mechanical, and bar code label specifications.

1–1
Introduction to the SCANTEAM 2380
1
INTRODUCTION TO THE
SCANTEAM 2380 SCANNER
1.1 Introduction
The SCANTEAM 2380 Decoder Output Scanner Keyboard Wedge is a
convenient and cost effective way of adding bar code data entry capability
to the IBM (and IBM compatible) PC/XT/AT personal computers and IBM
PS/2 Models 30, 50, 60 and 80.
Additional interfaces are continually being developed; check with Welch
Allyn or an authorized representative for availability.
As described on page 1–4, the SCANTEAM 2380 is available in the
following models: 2380/J and 2380/K with visible red illumination. All
models of the 2380 are available with stainless steel scanner housings. The
contents of this manual applies to these devices except where
differentiated.
The SCANTEAM 2380 is designed to read and decode any of nine (9)
popular bar code symbologies and output the bar code data to the keyboard
port in the same format the keyboard does.
1.2 Hardware Description
The SCANTEAM 2380 system consists of the wand body and a 6’ (1.8m)
coil (extended) interface cord. When connected as shown in Figure 1.1, the
2380 keyboard “wedge” device provides a transparent interface between
the keyboard and the keyboard input port of the host device.
Operation of the SCANTEAM 2380 with a particular computer is
accomplished by installing the proper “Y” interface cable and
programming the proper keyboard interface routine using the TERMINAL
SELECTION sheet of the programming menu.

1–2 Introduction to the SCANTEAM 2380
Once installed, the 2380 simply passes keyboard activity onto the host.
Symbols decoded by the SCANTEAM 2380 are translated to
corresponding keyboard keycodes and then sent to the keyboard input port
of the terminal. Thus, the data appears as if it has been “keyed in” at the
keyboard.
Figure 1.1 SCANTEAM 2380 Keyboard Wedge Connection
Decoding capability is achieved through the use of an internal
microprocessor.
All SCANTEAM 2380 units are referred to as contact scanners since the
tip of the wand must be in or near contact with the bar code label in order
to read.

1–3
Introduction to the SCANTEAM 2380
1.3 Software Description
The standard SCANTEAM 2380 is configured for specific user
applications by scanning bar code symbols from the printed programming
menu which is supplied with the unit.
System software will support the keyboard model normally supplied with
the host device, and is capable of emulating keyboard “function keys.”
The SCANTEAM 2380 may be programmed to autodiscriminate among
the following bar code symbologies and their variations: CODABAR,
Code 3 of 9, UPC, EAN/JAN, Code 2 of 5, Interleaved 2 of 5, Code 93,
MSI, Code 128 and Code 11§.
In addition to the bar code symbology selections, certain input/output
parameters, message format and communications protocol are
programmable using the wand with the programming menu.
All programmable parameters are stored in non–volatile memory resident
in the wand where they are permanently retained in the event of power
interruption to the 2380 or the host device.
§ This feature is not supported in all wand models/software revisions.

1–4 Introduction to the SCANTEAM 2380
1.4 Wand Models
The SCANTEAM 2380 decoded output scanner keyboard wedge is
available in the following Welch Allyn industrial grade digital wand
scanner models:
SCANTEAM 2380/J and SCANTEAM 2380/K
The 2380/J and 2380/K are “SRD” scanners, meaning they have a visible
red LED illumination source. These units feature a durable body and a
replaceable tip. The 2380 has a Welch Allyn logo on the scanner housing.
Either of the models may be ordered with high, medium or low resolution
scanning optics so as to meet special requirements imposed by the label
substrate and printing method or environmental factors which affect bar
code label quality.
For additional assistance in selecting the SCANTEAM 2380 decoded
output scanner keyboard wedge best suited to your bar code application,
contact Welch Allyn or an authorized representative.

2–1
Operational Description
2
OPERATIONAL DESCRIPTION
2.1 Chapter Objectives
This chapter describes:
•Scanner identification key.
•Overview of how the SCANTEAM 2380 works, including scanning
aperture, depth of field and scanning velocity.
•Reading and decoding a bar code symbol. Description of print
contrast, high and low density bar code symbols.
•Discussion of RS–232 interface and external power options.
2.2 Main Elements of the 2380 Bar Code System
The major operational elements of the SCANTEAM 2380 decoded output
scanner keyboard wedge include the scanner optics, the digitizing
electronics and the decoding circuitry.
The key components of the scanner optical system are the illumination
source (LED) and the illumination sensor (photodiode). Both the LED and
photodiode are positioned directly behind a specially designed lens in the
scanner body.
Cable connections are made directly to the board and exit the scanner body
through a flexible strain relief at the end of the wand handle. The integral
cable shield affords EMI and associated drain protection to output signals.

2–2 Operational Description
2.3 Scanner Identification Label
The scanner identification label is located on the scanner’s cable. The
identification corresponds to the configuration work sheet description.
(Welch Allyn p/n 16206714)
2.4 Operating Theory
The reading ability of the wand scanner is based on the detection of
reflected illumination from the bars and spaces which form a bar code
symbol.
During a typical scanning operation, the tip of the scanner is moved across
the bar code symbol. Illumination from the LED is focused on the bar
code symbol. This is absorbed by the dark colored bars and reflected by
the lighter background.
The reflected portion re–enters the scanner through the lens where it is
detected by the read sensor photodiode. The photodiode converts this into
a series of analog pulses which are proportional in width to the bars and
spaces in the symbol. These pulses are then digitized and sent to the
microprocessor where they are decoded into the characters represented by
the bar code symbol.
2.5 Factors Affecting Scanning Performance
The following factors influence reading performance and should be
considered when selecting a contact scanner for a particular bar code
application.
2.5.1 Scanner Illumination Source
Wand type scanners are equipped with a visible red (660nm) source.

2–3
Operational Description
Red illumination is compatible with most printing inks including most
thermal papers. Because it provides a visual indication to the operator that
the scanner is functioning, red illumination is considered to be more user
friendly. Visual feedback to the operator is an important consideration
when making a scanner selection.
2.5.2 Scanning Aperture
Scanning performance is affected by the size of the scanning aperture and
it is a significant factor to be considered when selecting a scanner. The
scanning aperture defines the effective size of the area of the bar code
symbol viewed by the scanner optics. It affects the relative ability of the
scanning device to “see” or resolve bars and ignore printing defects.
Large aperture systems typically cannot resolve high density bar code or
the small printing features (voids within bars or dark specs within the light
areas) that small aperture systems would. Thus, they are more compatible
with low density bar code and more tolerant of printing defects
characteristic of poorly printed labels.
Small aperture systems (high resolution) are better able to resolve which
makes them compatible with high density good quality symbol reading
requirements.
The SCANTEAM 2380 is available with circular apertures ranging from 6
to 8 mil.
Most scanning applications can be satisfied with a 6 mil (high resolution)
or a 8 mil (low resolution) aperture. When selecting an aperture, it is
recommended that the aperture dimension be no less than 0.7 times the “X”
(width of the narrowest bar code coding element) dimension to be read.
An aperture size that is slightly smaller than the narrowest bar code
element, 0.9 times “X,” provides optimum resolution of the bars and results
in the generation of a digital signal which accurately represents the bar
code. An 8 mil (0.2mm) aperture is often a good compromise when labels
produced by different printing and label generation methods must be read
with one scanner. In no case should the viewing aperture exceed 1.2 the
“X” dimension.

2–4 Operational Description
2.5.3 Depth of Field
Depth of field is the maximum perpendicular distance from the scanner tip
to the bar code symbol surface at which the scanner is capable of operating
effectively. In general, most of the SCANTEAM 2380 scanners have a
depth of field of 0.065 inches (1.65mm) with a symbol appropriate for the
scanner.
A chart showing the relationships between depth of field, scanning aperture
and bar code density appears on page A–1.
In normal use, the wand is seldom held perpendicular to the surface of the
bar code symbol. Rather, an operator tends to tilt the scanner. Useable
scan angle is a function of tip geometry and depth of field. If the depth of
field is too small, the scanner may fail to operate at extreme tilt angles
(>35°).
2.5.4 Scanning Velocity
The wand will operate at scan velocities from 2 to 50 inches/second (5 to
127cm per second) when the minimum bar/space size exceeds 7 mils
(0.18mm).
2.5.5 High Density vs Low Density Bar Code Symbols
Bar code density is a measure of the number of characters in a linear
measure of bar code. The standard of measure is normally given in terms
of the “X” dimension, the width of the narrowest bar code element. As bar
code density increases, the width of the narrowest bar code element
decreases. The scanning aperture should always be smaller than the
narrowest element to assure optimum resolution and the generation of a
digital signal which accurately represents the bar code.

2–5
Operational Description
2.5.6 Print Contrast
Print contrast is a measure of the relative difference in brightness between
the bars and spaces of a symbol and is specified as the Minimum
Reflectivity Difference (MRD). The MRD is the difference between the
lowest minimum space reflectance value and the highest maximum bar
reflectance value as measured across the entire symbol.
MRD = Max (Rbmax) – Min (Rsmin)
where: Rsmin = Minimum Space Reflectance
Rbmax = Maximum Bar Reflectance
The scanner will operate with a MRD as low as 37.5% with the proper
aperture and appropriate symbol.
A complete description of bar code specifications for factors which affect
overall bar code quality are provided on page A–5.

2–6 Operational Description
