TABLE OF CONTENTS GB
DESCRIPTION OF THE APPLIANCE Page 8
BEFORE USING THE REFRIGERATOR Page 8
PRECAUTIONS AND GENERAL SUGGESTIONS Page 9
HOW TO OPERATE YOUR REFRIGERATOR Page 9
HOW TO DEFROST AND CLEAN THE REFRIGERATOR Page 10
TROUBLE SHOOTING GUIDE Page 11
AFTER-SALES SERVICE Page 11
INSTALLATION Page 12
DOOR REVERSIBILITY Page 12
To get full satisfaction of your refrigerator, please read carefully your instruction manual.
7
7

NC
MY
DESCRIPTION OF THE APPLIANCE
1. Thermostat control knob
2. Ice cube tray (if provided)
3. Ice compartment
4. Defrost tray
5. Shelf
6. Feet
7. Rating plate - Service plate
8. Bottle rack
9. Inner door
10. Small bottle rack
BEFORE USING THE REFRIGERATOR
xAfter unpacking, please ensure that the
appliance is undamaged and that the door
closes tightly.
Any damage must be reported to your
dealer within 24 hours of receipt of the
appliance.
xThe package is recyclable and is marked
with the recycling symbol
Ù
.
xThe appliance is built with re-usable material.
When scrapping, follow the local
environmental protecting regulations.
xRender the refrigerator inoperative. Cut the
power-cable off.
Take the refrigerator to the local disposal
centres so that refrigerating agent properly
treated will not pollute air.
xPlease ensure that the installation and the
electrical connection has been carried out
following the manufacturer’s instructions and
in compliance with local safety regulations.
8
8

NC
MY
PRECAUTIONS AND GENERAL SUGGESTIONS
xOnly use the refrigerator for the storage of
foods.
xAfter installation, please make sure that the
refrigerator does not stand on the supply
cable.
xDo not store glass containers with carbonated
drinks in the ice compartment as they may
explode.
xDo not eat ice cubes or ice lollies immediately
after their removal from the ice compartment,
as they may cause “cold” burns.
xBefore any cleaning or maintenance operation,
disconnect the refrigerator by switching off
the electricity at the mains or by pulling the
plug.
Conformity declaration
xThis appliance incorporates parts intended to
come into contact with foodstuffs in
compliance with EEC directive 89/109.
xThis appliance conforms to EEC directive
87/308 on radio-interference.
Information
This appliance is free of HCFC’s (refrigerant circuit
contains R 34 a) or free of HFC’s (refrigerant
circuit contains R 600 a - Isobutane). For more
details, please refer to the rating plate on the
appliance.
For appliance with Isobutane
(R 600 a)
The refrigerant Isobutane is a natural gas of high
environmental compatibility but which is
inflammable. Therefore, it is essential to ensure
that the ducts of the refrigerant circuit do not get
damaged.
HOW TO OPERATE YOUR REFRIGERATOR
1. Turn the thermostat control knob clockwise to
the desired position (higher numbers to get
colder temperature).
How to store food
1. First wrap food in aluminium foils or cling film,
in order to maintain all their characteristics
(vitamins, freshness .......).
2. Load the refrigerator as shown in opposite
figure:
A. Meat, sausages, fish, cooked food
B. Fruit and vegetables
C. Cheese, dairy products, beverages
D. Small bottles, cans.
Note: Never store food in an open can.
Production of ice cubes
Fill 3/4 the ice cube tray with water and place it
on the ice compartment.
d
a
bc
9
9

NC
MY
HOW TO DEFROST AND CLEAN THE REFRIGERATOR
X
4
We suggest you defrost your refrigerator once
ice build up reaches about 3 mm in thickness.
1. Check that the defrost tray is still under the
ice compartment.
2. Turn the thermostat control knob to position
defrost.
3. When the ice has melted completely, empty
the water from the defrost tray.
4. Turn back the thermostat control knob to the
desired setting.
Quick defrosting
This function is used to defrost your refrigerator
more quickly.
1. Empty the refrigerator from food.
2. Disconnect the appliance from the
mains.
3. Place a bowl of warm water (max. 50oC)
under the ice compartment and leave the
refrigerator door open (this will speed up the
defrost process).
X
4.When the ice has melted completely, empty
the water from the defrost tray.
5. Clean the inside with a sponge dampened in
a solution of warm water and neutral
detergent. Rinse and dry with a soft cloth.
Do not use abrasives.
6. Connect the appliance to the mains and put
back all items into the refrigerator.
xWipe the outside with a soft cloth dampened
in water.
xPeriodically clean the condenser (radiator)
situated at the rear of the refrigerator with a
vacuum cleaner or a brush.
For prolonged absences
1. Empty all items from the appliance.
2. Disconnect it from the mains.
3. Defrost and clean the inside.
4. Leave the door open to prevent any bad
odour.
10
10

NC
MY
TROUBLE SHOOTING GUIDE
1. The temperature in the compartment is
not cold enough
xIs the door properly closed ?
xIs the refrigerator too close to a heat source ?
xIs the condenser clean ?
xIs the air flow over and around the appliance
restricted ?
xIs the layer of frost in the ice compartment
too thick ?
2. The temperature in the refrigerator is
too cold.
xAre the thermostat and the defrost tray in the
correct position ?
3. The refrigerator is excessively noisy.
xIs the refrigerator in contact with other
furniture or appliances ?
xAre the parts in the back in contact with each
other ?
Attention: Under normal conditions, the cooling
system of the refrigerator may cause some noise.
4. The appliance does not work at all
xIs there a power failure ?
xIs the refrigerator well plugged ?
xIsthefuseblown?
xIs the supply cord broken ?
For Great Britain only
Check that the plug fuse is well fitted. A 13 A
fuse must be used.
Check removable plugs for loose connections
and tighten them if necessary. Loose connections
can overheat the plug.
5. Water inside the refrigerator
xIs the thermostat control knob properly set ?
xIs the defrost tray empty ?
AFTER-SALES SERVICE
Before calling for Service:
1. Check the Trouble-Shooting Guide carefully to
see if you can correct the fault yourself.
2. Re-operate the appliance to check if the fault
has cleared itself.
If both attempts fail, please call for Service.
Describe the fault and give the model Noand
Service Noof your appliance, your address and
phone No.
11
11

NC
MY
INSTALLATION
xDo not install the refrigerator close to any
heat source.
xPlace it in a dry and well ventilated space.
xMake sure that the appliance is well levelled.
xNever cover the plinth. You must leave at
least a 50 mm gap, if the appliance is installed
under a kitchen furniture.
xLet the appliance to stand for 1 hour prior to
connecting it to the electricity supply.
Electrical connection
xCheck that the voltage on the rating plate
corresponds to the voltage in your home.
xThe earthing of the refrigerator is
compulsory by law.
The Manufacturer will accept no liability
for damage to persons or to objects
arising from the non-observance of this
requirement.
xIf the plug and the wall socket do not comply,
have the socket replaced by a qualified
technician.
xDo not use adapters, multipole sockets or
extension cords.
Door reversibility
X
1. Tilt the appliance backwards and remove the
lower right hinge.
X
2. Remove the door from the pin of the top
hinge.
X
3. Remove the screw cover, the screws and the
top right hinge.
4. Remove the 3 clips covering the holes of the
left screws.
5. Fix the hinge to the top left hand side, using
thesamescrewstotightenit.
6. Reposition the clips and the screws cover in
the new relevant holes.
7. Fit the door in the pin of the top hinge.
8. Mount the lower hinge on the left hand side
and the foot on the right hand side using the
same screws in the holes already provided
on the appliance.
X
1
X
2
X
3
12
12

NC
MY
FOR GREAT BRITAIN ONLY - ELECTRICAL INFORMATION
“Warning - this appliance must
be earthed”
Fuse replacement.
If the mains lead of this appliance is fitted with a BS
1363A 13 amp fused plug, to change a fuse in this
type of plug use an A.S.T.A. approved fuse to BS
1362 type and proceed as follows:
1. Remove the fuse cover (A) and fuse (B).
2. Fit replacement 13A fuse into fuse cover.
3. Refit both into plug.
Important: The fuse cover must be refitted when
changing a fuse and if the fuse cover is lost the
plug must not be used until a correct replacement
is fitted.
Correct replacement are identified by the colour
insert or the colour embossed in words on the base
of the plug.
Replacement fuse covers are available from your
local electrical store.
Connection to a rewireable plug
If the fitted plug is not suitable for your socket
outlet, then it should be cut off and disposed of in
order to avoid a possible shock hazard should it be
inserted into a 13A socket elsewhere.
A suitable altenative plug should then be fitted to
the cable.
The wires in this mains lead are coloured in
accordance with the following code;
BLUE - “NEUTRAL” (“N”)
BROWN - “LIVE” (“L”)
GREEN AND YELLOW - “EARTH” (“E”)
1. The GREEN AND YELLOW wire must be
connected to the terminal in the plug which is
marked with the letter “E” or by the Earth symbol
4
or coloured green or green and yellow.
2. TheBLUEwiremustbeconnectedtothe
terminal which is marked with the letter “N” or
coloured black.
3. The BROWN wire must be connected to the
terminal which is marked with the letter “L” or
coloured red.
For the Republic of Ireland only
The information given in respect of Great Britain will
frequently apply, but a third type of plug and socket
is also used, the 2-pin, side earth type. In this case,
the wire which is coloured GREEN AND YELLOW
must be connected to the EARTH contact, and the
other two wires to the two pins, irrespective of
colour. The supply to the socket must be fitted with
a16ampfuse.
GREEN AND
YELLOW (“E”) BROWN (“L”)
CABLE CLAMP.
BLUE (“N”)
Connection to a
typical 13 amp plug
DEUTSCH 1
ENGLISH 7
FRANC¸AIS 13
NEDERLANDS 20
SVENSKA 26
NORSK 32
DANSK 38
SUOMI 45
ESPANO×L 51
PORTUGUE×S 57
ITALIANO 63
Gebrauchsanweisung Seite
Instructions for use Page
Notice d’emploi Page
Gebruiksaanwijzing Bladzijde
Bruksanvisning Sida
Bruksanvisning Side
Brugsanvisning Side
Käyttöohje Sivu
Instrucciones para el uso Pa´gina
Manual de uso Pa´g.
Istruzioni per l’uso Pagina

SERVICE Whirlpool EMEA
Customer Services
8534 091 01020, 02/09/11
page 2 of 5
Spare Part List
Pos 12NC Description
011 2 4819 462 78423 Foot
040 1 4819 417 19603 Hinge upper
040 2 4819 417 19602 Hinge lower
104 0 4812 416 18188 Door refriger.
111 7 4812 459 18283 Nameplate
154 0 4819 418 78185 Holder bottles
154 9 4819 460 88458 Console
191 4 4819 468 18033 Magnetic seal
241 7 4819 458 19003 Grid
245 0 4819 458 19022 Grid
252 0 4819 418 78835 Thermostathous.
252 1 4819 459 19507 Thermostat dial
335 0 4819 411 28479 Knob thermostat
335 6 4819 492 68528 Spring
402 0 4812 817 18825 Compressor 1/10HP EMT22HLP S.P.
491 0 4812 290 88103 Cover conn.bloc
554 0 4812 271 28576 Thermostat A01-0379-16
554 2 4812 466 88906 Plate
561 7 4812 290 68325 Connectionblock
614 0 4812 280 38147 Monoblock TX1C1
740 0 4812 511 48307 Condenser
745 0 4812 511 38219 Evaporator
745 1 4819 418 48089 Tray
764 2 4819 480 28144 Dryer
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8534 091 01020, 02/09/11
page 3 of 5
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8534 091 01020, 02/09/11
page 4 of 5
Circuit Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8534 091 01020, 02/09/11
page 5 of 5
Technical Data
Factory Code
.................................................................................................................RE090X
Product dimensions
Height ................................................................................................. 55.0 cm
Width ..................................................................................................55.0cm
Depth ..................................................................................................60.3 cm
Capacity
Total
Gross ...................................................................................................90 l
net ......................................................................................................88 l
Electrical base data
Voltage ...........................................................................................220 V -240 V
Frequency ............................................................................................... 50 Hz
Power Consumption
in 24 hours ...........................................................................................0.40 kWh
Compressor
Type ..............................................................................................EMT22HLP
Capacity(CECOMAF) .....................................................................................53 W
Refrigerant
Type ...................................................................................................R 134a
Quantity ...................................................................................................32g
Thermostat switching value
Switch on temperature
MIN .................................................................................................- 1.5°C
MAX ...............................................................................................-10.5 °C
Switch off temperature
MIN .................................................................................................- 7.5°C
MAX ...............................................................................................-16.5 °C
© Whirlpool EMEA www.scc-service.com
