Westcott FJ-X2m User manual

QUICK START GUIDE
Visit fjwestcott.com/4705 to download the latest firmware

Included Components & Overview
FJ-X2m, USB Cable
Group Selection
Buttons
Menu Selection
Buttons
(1, 2, 3)
Test Button
Shoe Lock
Power | Menu
Button
Wireless Signal
Indicator
Selection
Wheel

LCD Display
Canon
Camera CH SYNC
TTL
TTL
M
CH 15
9.0
A
B
C
3.7
2.3
-
Camera Brand
Selection
Group Icons
TTL / M Group
Designations
Selectable
Menu Icons
Battery Icon
Indicator
Channel Icon
Sync Function
Icon
Audible Beep
Icon
Modeling Lamp
Icon
Bluetooth Icon
Settings Menu
Settings
Screen MID
15
01
Auto-Off
RT ID#
Screen
Brightness
(Min, Mid, Max)
Auto-O
(05, 15, 30 Min)
RT ID #
(00-99)
Bluetooth
(On/O)
SYNC-X
(On/O)
Reset OK
SYNC-X OFF
OFF

Introduction
Preparing Your Camera
This guide covers setup, controls, and basic operation.
Visit fjwestcott.com/4705 and scroll to the Support section
to download the complete FJ-X2m User Manual.
Warning
• Keep away from fire, water, and moisture. Do not submerge in water.
• Avoid drastic temperature changes before, during, and/or after use.
• Do not overtighten shoe lock wheel when mounting to camera.
• Ensure the FJ-X2m is securely mounted before use.
• Surrounding RF interference may aect the communication performance of the FJ-X2m.
• Do not attempt to modify any Westcott products. Contact Westcott for assistance.
• The maximum operating temperature is 32-104°F (0-40°C).
An FJ-X2m Wireless Trigger is compatible with various brands of cameras to operate
the FJ400 strobe. Each camera manufacturer chooses a dierent approach to how
their cameras interact with o-camera lights. A few adjustments to your camera
settings are required for the FJ-X2m and FJ400 to properly perform with your
camera. Below are a few settings to check out first. We recommend referring your
camera’s user manual for details specific to your camera brand and model.
• Set Silent Shutter to OFF.
• Set E-Front Curtain to OFF.
• Set Wireless Mode to ON or OFF (camera brand/model dependent).
• Set Red-Eye Reduction to ON or OFF (camera brand/model dependent).
• Set Exposure Compensation to 0 (zero) in camera.
• Set White Balance to Daylight, 5500K, or Custom at 5500K (not Auto).
• Various camera models require you to set the Sync type (Front Curtain, Rear Curtain,
HSS) manually in the camera’s Flash Menu before the FJ-X2m Sync can be adjusted.
• Various camera models automatically adjust the Sync setting to HSS when HSS is
enabled in the camera settings and the native sync speed is exceeded.
• Ensure the camera’s battery level is above 25%.
• Ensure the camera contacts are clean and the FJ-X2m is seated properly and aligned.

Getting Started
Charging the FJ-X2m
1. Access the USB-C port behind the rubber protection gasket.
2. Plug the USB-C cable into the FJ-X2m.
3. Plug the opposing end of the cable in any 5V power source.
4. Estimated charging time is 2 hours.
Powering On
Long press and hold the Power | Menu button for 3 seconds until you see the Westcott
logo. The wireless signal indicator will continually flash green.
Powering O
Long press and hold the Power | Menu button for 3 seconds until the screen turns o.
Test Fire
Press the Test button once to remotely test-fire the FJ400 strobe. When the Test button
is pressed the wireless signal indicator LED will illuminate red.
Trigger Settings Lock
Press Menu Selection buttons 1 and 2 simultaneously to lock the current trigger settings.
Press Menu Selection buttons 1 and 2 simultaneously again to unlock the trigger to adjust
the settings.
Settings Menu
• Long press Menu Selection buttons 2 and 3 to access the Settings Menu.
• Use the side Group Selection buttons to select the corresponding displayed screen
option or use the Selection Wheel to scroll through the screen options. Additional
menu options are available by scrolling down on the Selection Wheel.
• Press the Selection Wheel to select the green highlighted option. Turn the Selection
Wheel to adjust the setting.
• Press the Selection Wheel, or a side Group Selection button, to confirm the setting.
• Press OK to exit the Settings Menu.
