WESTERSTRAND 190100 Series User manual

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
1
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Manual
Westerstrand T/T- display

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
2
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
General
Westerstrand time- and temperature displays, alternates time and temperature in 1-25 seconds
intervals.
Consists of 7-segments LED digits in dimensions 150, 190, 250, 300 and 450 mm.
The time and temperature display could be single or double sided with or without second.
One side contains four or six symbols with symbols between who shows blank, colon (:) or dot (.).
Example for time display:
4 digits:
6 digits:
Example for date display:
4 digits:
6 digits:
Example for temperature display:
4 digits:
6 digits:
4 digits:
6 digits:
2
3
:59:
48
2
3
:59
17.06.
08
17.06
20
ºC
20
ºC
-
12
º
C
-
12
º

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
3
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
The Temperature sensor is not included. It is an option.
The programming of the time and temperature display is made by buttons at the computer board or via
remote control.
The digital clock can operate stand-alone with a built in quartz crystal as time reference, as a slave
clock to a master clock transmitting 24 V polarised 1/1 minute impulses or synchronised by TC, DCF
or GPS.
If the DLS-function is set , the clock is changing summer and winter time, the last Sunday in March
and the last Sunday in October automatically.
The clock has adjustable light intensity.
If power failure occurs the display is turned off. The internal clock continues to keep the correct time
for 48 hours. After the power failure the display is turned on and correct time is shown.
Installation
•Mount the clock by means of the mounting brackets. Both wall and roof mounting is possible by
rotating the brackets.
•To open the clock, slide the front glass by loosening the aluminium profile on the short side of the
clock. Unscrew 2 screws and open the service plate.
•Connect the synchronisation source if present (radio, impulse etc). See the connection diagrams,
page 5.
See also the configuration instructions for setting of synchronisation (page. 6 and 8.)
•Connect the mains, 230VAC 50Hz . Installation fuse max 10A.
The socket outlet shall be installed near the clock and shall be easily accessible.
When the clock is installed permanently, a readily accessible disconnect device (2-polar, 3 mm
contact gap) shall be incorporated in the fixed wiring.
•Set correct time and date according to the programming instructions on page 10.

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
4
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Connection
Connection synchronisation
TC and MIN-imp is connected at +IMP and –IMP.
V+
-IMP+IMP
DCF -
DCF 2-wire is connected V+ and – (GND)
DCF, GPS 3-wire is connected DCF , V+ and – (GND)

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
5
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Strapping TC / MIN-impulse computer board (default)
Strapping DCF- radio(2 –wire) computer board

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
6
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Strapping DCF,GPS-radio (3 –wire) computer board
The DIP-switch on the computer board should be set as follows:
Dip 1: OFF Display format is HH:MM.
ON Display format is HH:MM:SS.
Dip 2: OFF always OFF
Dip 3: OFF TC/Min impulse synchronisation. (default)
ON DCF/GPS synchronisation.
Dip 4: OFF TC/Min impulse or 3-wire DCF/GPS synchronisation. (default)
ON 2-wire DCF synchronisation.
Dip 5: OFF
DCF/GPS synchronisation.
ON
TC/Min impulse synchronisation.(default)
Dip 6: OFF ½ Min impulse synchronisation.
ON
TC/Min impulse synchronisation or
DCF/GPS synchronisation. (default)
Dip 7: OFF always OFF
Dip 8: OFF always OFF

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
7
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Synchronisation
Stand alone
If no synchronisation is used, the T/T works as stand-alone.
Minute impulse
Set the straps according to the strapping schema page 6.
Connect the wires, see page 5.
The T/T could be set for synchronisation or slave mode.
Synchronisation mode:
Set the T/T in synchronisation mode InSy, see programming page 10.
Set time and wait for next minute impulse. It is now synchronised.
Slave mode:
Set the T/T in slave mode InSL, see programming page 10.
Set time and wait for next minute impulse. It is now working in slave mode.
TC
Set the straps according to the strapping schema page 6.
Connect the TC wires, see page 5.
Set the T/T in synchronisation mode sync. Functions DCF see programming page 10.
After one correct accepted time message the time is displayed and the colon starts flashing on and off.
DCF or GPS
DCF 3 wire and GPS has the same setting
Set the straps according to the strapping schema page 6 and 7.
Connect the DCF/GPS wires, see page 5.
Set the T/T in synchronisation mode sync. Functions DCF see programming page 10.
After one correct accepted time message the time is displayed and the colon starts flashing on and off.
If GPS antenna synchronisation the GPS antenna has to be set for correct time zone.

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
8
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Connection temperature sensor (option).
Temperature sensor connection
1 brown.
2 black
3 Screen
1 2 3
TEMP.SENSOR

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
9
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Programming
Programming is made via a remote control or push buttons at the computer board.
Remote control:
R (Return) Enter the base mode (display time)
F (Function) Next function / Accept displayed value
P (Program) Enter the displayed function / Increase displayed value.
Manual programming time
Push [F] until display shows:
Push [P] display shows: year
Push [P] until desired year (00-99)
Accept with [F].
Display shows: month
Push [P] until desired month (1-12).
Accept with [F].
Display shows: day
Push [P] until desired date (1-31).
Accept with [F].
ti ne
yy 95
nn 1
d d 1

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
10
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Display shows: hour
Push [P] until desired hour (0-23).
Accept with [F].
Display shows: minute
Push [P] until desired minute (00-59).
Push [F] for synchronisation.
Display shows:
Push [R]. Programming of time is finished.
Display shows:
Setting light intensity
The light intensity for the digits has one minimum and one maximum level. The setting levels (1-50)
are set in function disp. An automatic dimmer function regulates the light intensity between minimum
and maximum levels that are set.
Push [F] until display shows:
Push [P]
Display shows: light intensity 1 (weakest), 50 (strongest) (one of the levels).
Push [P] for desired light intensity. Accept with [F].
Display shows: light intensity 1 (weakest), 50 (strongest) (the
Other level).
Push [P] for desired light intensity. Accept with [F].
Display shows:
hh 12
nn 07
ti ne
12 : 07
di sp
dL 1
Sy nc
dh 50

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
11
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Push [R] for entering base mode or push [F] for next function.
Setting synchronisation
Synchronisation for this model is minute impulse, TC, DCF,GPS (or stand alone).
Push [F] until display shows:
Push [P] for desired synchronisation.
No synchronisation, stand-alone
TC,DCF or GPS
Impulse synchronisation
Impulse slave-mode
Push [R] for entering base mode or push [F] for next function.
Sy nc
no sy
dcf
InSL
InSy

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
12
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Setting alternating time, Loop time
Push [F] until display shows:
Push [P].
Display shows: Alternating time for display time is 4 seconds.
Push [P] for desired alternating time (0-25). Accept with [F].
Display shows: Alternating time for display temperature is 0
Push [P] for desired alternating temperature (0-25). Accept with [F].
Display shows: Alternating time for display date is 4 seconds.
Push [P] for desired alternating time (0-25). Accept with [F].
Push [R] for entering base mode or push [F] for next function.
Setting Correction value, for the temperature sensors.
With this function the temperature sensors can be adjusted ±9 ˚C.
Push [F] until display shows:
Push [P].
Display shows:
Push [P] for desired correction value (±9 ˚C). Accept with [F].
Push [R] for entering base mode or push [F] for next function.
LooP
L1 4
L2 0
L3 4
Corr
C1 0

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
13
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Setting DLS-function.
With this function the DLS can be activated.
Push [F] until display shows:
Push [P].
Display shows:
Or:
Push [P] for DLS or not
Push [R] for entering base mode or push [F] for next function
Setting12/24 h format.
With this function the format 12/24 hours display can be set.
Push [F] until display shows:
Push [P].
Display shows: 12 hour format
Or:
24 hour format
Push [P] for desired format.
Push [R] for entering base mode or push [F] for next function.
dLS
YES
no
Fo rn
12
24

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
14
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
Technical specification
Common
Mains 100-240 VAC, 50/60Hz
Temperature range -20˚C – + 55˚C
Synchronisation Polarised 24V impulse 1/1, TC, DCF,GPS
Accuracy ±0.1 seconds/24 hour
Running reserve 48 hour
Changing Summer/
Winter Last Sunday in march, last Sunday in October.
Measure range temperature
sensor -30˚C – +60˚C
Accuracy temperature sensor
±1 ˚ C
Temperature measurement Once per minute
:Specific for:
190100-xx
Type Single sided without second
Connection current max 2A
Size of digits HH:MM 150mm:150mm
Dimension (WxHxD) 685x245x92mm
190101-xx
Type Double sided without second
Connection current max 2A
Size of digits HH:MM:SS 150mm:150mm
Dimension (WxHxD) 685x245x130mm
190110-xx
Type Single sided with second
Connection current max 2A
Size of digits HH:MM:SS 150mm:150mm:120mm
Dimension (WxHxD) 965x245x92mm
190111-xx
Type Double sided with second
Connection current max 2A
Size of digits HH:MM:SS 150mm:150mm:120mm
Dimension (WxHxD) 965x245x130mm

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
15
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
190120-xx
Type Single sided without second
Connection current max 2A
Size of digits HH:MM 190mm:190mm
Dimension (WxHxD) 740x270x92mm
190121-xx
Type Double sided without second
Connection current max 2A
Size of digits HH:MM 190mm:190mm
Dimension (WxHxD) 740x270x130mm
190130-xx
Type Single sided with second
Connection current max 2A
Size of digits HH:MM:SS 190mm:190mm:150mm
Dimension (WxHxD) 1070x270x92mm
190131-xx
Type Double sided with second
Connection current max 2A
Size of digits HH:MM:SS 190mm:190mm:150mm
Dimension (WxHxD) 1070x270x130mm
190140-xx
Type Single sided without second
Connection current max 2A
Size of digits HH:MM 250mm:250mm
Dimension (WxHxD) 900x330x92mm
190141-xx
Type Double sided without second
Connection current max 2.5A
Size of digits HH:MM 250mm:250mm
Dimension (WxHxD) 900x330x130mm
190150-xx
Type Single sided with second
Connection current max 2.5A
Size of digits HH:MM:SS 250mm:250mm:190mm
Dimension (WxHxD) 1320x330x92mm
190151-xx
Type Double sided with second
Connection current max 2.5A
Size of digits HH:MM:SS 250mm:250mm:190mm
Dimension (WxHxD) 1320x330x130mm

Document:
1867en10
.doc
Auth.:
TAn
Date:
2016
-
11
-
07
Page:
16
of 16
WESTERSTRAND URFABRIK AB
Box 133 Tel. 0506 48 000 Internet:: www.westerstrand.se
190160-xx
Type Single sided without second
Connection current max 2.5A
Size of digits HH:MM 300mm:300mm
Dimension (WxHxD) 1000x380x92mm
190161-xx
Type Double sided without second
Connection current max 2.5A
Size of digits HH:MM 300mm:300mm
Dimension (WxHxD) 1000x380x130mm
190170-xx
Type Single sided with second
Connection current max 2.5A
Size of digits HH:MM:SS 300mm:300mm:250mm
Dimension (WxHxD) 1450x380x92mm
190171-xx
Type Double sided with second
Connection current max 2.5A
Size of digits HH:MM:SS 300mm:300mm:250mm
Dimension (WxHxD) 1450x380x130mm
190191-xx
Type Double sided with second
Connection current max 5A
Size of digits HH:MM:SS 450mm:450mm:300mm
Dimension (WxHxD)
This manual suits for next models
16
Table of contents
Other WESTERSTRAND Monitor manuals
