Westinghouse LVM-37W1 Assembly instructions

Westinghouse Digital Electronics
POWER INDICATOR
KEYPAD
CONGRATULATIONS on
purchasing a HD-ready LCD
Video Monitor! This Quick
Connect Guide will help you
get started in 3 easy steps.
On the back you will find
information to maximize your
LCD Video Monitor experience.
For complete installation,
usage instructions, and safety
precautions please refer to the
User’s Manual.
37”
QUICK
CONNECT
GUIDE
CONNECT THE
POWER
Use the enclosed A/C
power cable to connect
the A/C power to the
power input on the HD
Video Monitor.
CONNECT THE HD
VIDEO SOURCE
Connect a HD digital cable,
HD satellite receiver, ATSC
tuner or DVD player to the
corresponding video input
on the connector panel.
CONNECT A
COMPUTER
Connect a computer to
the VGA or DVI inputs
and the corresponding
audio inputs.
Press the power button
on the keypad to turn on
the Video Monitor.
1
1
2
2
3
3
GO!
GO!
LVM-37w1
LCD Video Monitor
www.westinghousedigital.com
DVI/AV/S-Video Inputs VGA/DVI/YPbPr Inputs

MAXIMIZE
YOUR HD
VIDEO MONITOR
EXPERIENCE
You can attach your HD Video
Monitor to a variety of electronic
devices including a digital cable
or satellite set top box, a game
console, a VCR, or a computer. The
chart shows our recommendations
for the best quality picture for
these commonly used devices.
If you have trouble connecting
these or other devices, please
refer to the User’s Manual.
VGA Audio Input
YPbPr 2 Input
YPbPr 2
Audio Input
TYPICAL SETUP
• Progressive scan DVD players with YPbPr
• Game console system with AV
• VCR viewing and editing with S-Video
PC INPUTS
VGA
(RGB)
Monitor Good Best
DID YOU KNOW THAT YOUR
HD VIDEO MONITOR ALSO HAS:
• Integrated 20 W Stereo Speakers
• Progressive Scan
• Inverse 3:2 Pull Down
CHECK OUT
www.westinghousedigital.com for our:
• Versatile Décor Wall Mounting options
• Décor Frames for LCD TVs with
Acoustical Mattes
© 2005 Westinghouse Digital Electronics, LLC. All rights
reserved. Specifications subject to change without notice.
¼, Westinghouse and You can be sure... if it's Westinghouse are
trademarks of Westinghouse Electric Corporation and are
used under license.
MA-PS-0601-0501 Customer Service: 866.287.5555 • www.westinghousedigital.com
Use the input button on the remote control or keypad to navigate between the
TV, S-Video, AV, YPbPr, DVI-HDCP or VGA inputs.
Digital Cable/
Satellite Receiver Good Better Best
DVD Player Good Good Better Best
Game Console Good Better Best
VCR Good Better Best
YPbPr
AV S-VideoTV Tuner
VIDEO INPUTS
Note: The audio input is shared between AV and S-Video.
DVI-HDCP
DVI-HDCP
• Remember to adjust the resolution of your
computer or HD MediaPC to 1920 x 1080 for
best performace.
VGA
DVI 1 Audio Input
YPbPr 1 Input
YPbPr 1
Audio Input
DVI 2
(up to 1080i)
AV
DVI 2 Audio Input
S-Video
AV & S-Video
Audio Input
Audio Output
DVI 1
(up to 1080p)
VGA Audio Input
VGA
DVI 1 Audio Input
DVI 1
