Wewow A-LITE Instruction sheet

3 AXIS GIMBAL
Video Filming and selFie
Product instructions

Model
Material
Size
Weight
Battery type
Battery specification
Duration
Charging time
Operating temperature
Operating humidity
Adaptation
A-LITE
PA+GF
Length 318.5max, Width 120max, High 106max
* The size is measured in working condition. It has slight change
due to different application combinations.
440g max
* The weight has slight change due to different application
combinations
Lithium ion
3.7V 2200 mAh
4~5 hours continuous use at room temperature
About 2 hours at room temperature (5V1A)
-10℃ ~ 40 ℃
<90%
Smart phones not larger than 6 inches
(weight no more than 230g)
1.Parameters

2.Product description
1.Tilt axis motor
4.Mode indicator LED1
7.Focusing shift lever
10.Handle
13.Telescopic
16.Inner arm adjusting knob
2.Smartphone holder
5.Rocker direction button
8.Battery power digital display
11.1/4 expanded thread hole
14.Yaw axis motor
3.Status indicator LED2
6.Power/Camera button
9.Mode switch button
12.Micro USB charging interface
15.Roll axis motor
1
L1
2
3
4
5
6
L3
L7
L5
L6
L9
L10
L8
L4
L2

Description of indicator function
Mode indicator LED1: Blue
1. Off: Full following mode (default)
2. Flash: Yaw axis left/right following mode
3. On: Lens locked mode
Status indicator LED2 status indicator (RGB full color)
1. Blue: Flash (stabilizer receives instruction being executed)
2. Green: Normal working status
3. Yellow: System operation is normal
When the stabilizer isn’t working normally or reports error, the status indicator turns yellow.
When the stabilizer is running overload, the status indicator flashes red and yellow alternatively.
Display of power-on indicator: The indicator stays blue when the On/Off button is pressed
and held; release the button when the indicator flashes blue; the stabilizer is reset to the
initial position when it is turned on and the indictor stays green, indicating that the running
is normal.
Judgment of power-on exception:
1.Blue indicator is off, digital tube doesn’t show battery status, battery voltage is too
low; charge in time;
2.Blue indicator flashes, green indicator is off, tilt axis is stuck; manually adjust the tilt
axis to initial position; or adjust the knob to avoid stuck.
3.Instable after power-on and battery power is 5% (it is recommended to charge in time
when the battery power is less than 10%)

Rocker direction button
Adjust the shooting angle up, down, left or right according to the pushing direction.
Focusing shift lever
Adjust the focus by pushing the shift lever while taking picture or recording
video (connect Bluetooth and enter App)
Power/Camera button
·In power off state, press and hold it for three seconds to turn on;
·In power on state, press and hold it for three seconds to turn off;
·Connect App via Bluetooth in power on state, and click it to control picture
shooting and video recording
Battery power digital display
Display the battery status in percentage in power on state
1. In charging state, battery power is 0-99%, digital tube flashes; when the
battery power reaches 98%, it enters trickle changing and the charging is
basically finished;
2. In fully charged state, the battery power is 100% and the digital tube stays on;
3. In power on state, the digital tube flashes when the battery power is less
than 5%;
4. In power on state, the digital tube stays on when the battery power is greater
than 5%.

Mode switch button
Micro USB charging interface
To charge the stabilizer, please use USB power adapter and Micro USB
cable of qualified manufacturer.
Telescopic
Adjust the handheld stabilizer to desired length through free stretching or retracting.
PS: You can click to switch the stabilizer mode; the interval between clicks is
at least 500ms.In any mode, you can double click the stabilizer to reset to initial
position; the interval between double clicks should be less than 200ms.
1s positioning: Manually adjust tilt axis and yaw axis to specified position for
1 second to achieve manual adjustment.
·When you double click the MODE button, the stabilizer returns to the center
automatically and the smart phone returns to the center;
·If you double click the MODE button again in 5 seconds, motor NO.1 rotates
by 180°.
·Press and hold the MODE button to switch between video recording and
image shooting.
The default is full following mode（tilt and yaw axes following). Yaw axis (turn
left or right correspondingly with handle ) mode is enabled when click it.Lens
would be locked if click it again(The camera faces the fixed direction);

Inner arm adjusting knob
The stabilizer matches smart phone model through adjustment of inner arm
adjusting knob in order to achieve balance state.
3.Installation Instruction
1.Download and install Wewow A-lite App
2.a.Android/IOS users could scan the following QR code to download the App
directly.b.Mobile phone application market search “Gimbalpro”to download
IOS 10/Android 6.0 or later required. As per instruction of App to match and
connect the stabilizer.
Please fully charge the stabilizer before using it for the first time.
2.Firmware upgrade: Upgrade the stabilizer according to APP prompt; do not
turn off the device during upgrading, and operate according to the instruction
Android IOS

Bee䯤Xfxpx!Cmpdl-!Op/2!Qbozv!Bwf/-!Ejtusjdu-!Hvboh{ipv
Ufm 䯤131.9:31:476!!!!
Xfe䯤xxx/xfxpxhjncbm/dpn
Hvboh{ipv!Xfxpx!Fmfduspojd!Dp/-Mue
4.Disclaimer
1. Please install and use properly according to the instructions.
2. Only use USB power adapter of qualified manufacturer.
3. Please make sure that the stabilizer and smart phone have been installed
properly and adjust the balance manually before turning it on.
4. Keep the stabilizer away from fire and heat sources.
5. It is prohibited to use this product for any illegal purposes! The user shall
bear all consequences of the purchase and use of this product. Any violation
of the regulations shall be the responsibility of the user and we won’t be
liable for any legal responsibility.
6. We won’t provide after-sales service for any product acquired from
abnormal channel or unknown sources.
7. If you have any question when use this product, please contact our technical
service personnel. We are not responsible for any problem caused by
improper use or subjective judgment
8. The company reserves the right to interpretation.
